Learning key Windows PowerShell Workflow concepts for Automation runbooks

Runbooks in Azure Automation are implemented as Windows PowerShell Workflows. A Windows PowerShell Workflow is similar to a Windows PowerShell script but has some significant differences that can be confusing to a new user. While this article is intended to help you write runbooks using PowerShell workflow, we recommend you write runbooks using PowerShell unless you need checkpoints. There are several syntax differences when authoring PowerShell Workflow runbooks and these differences require a bit more work to write effective workflows.

A workflow is a sequence of programmed, connected steps that perform long-running tasks or require the coordination of multiple steps across multiple devices or managed nodes. The benefits of a workflow over a normal script include the ability to simultaneously perform an action against multiple devices and the ability to automatically recover from failures. A Windows PowerShell Workflow is a Windows PowerShell script that uses Windows Workflow Foundation. While the workflow is written with Windows PowerShell syntax and launched by Windows PowerShell, it is processed by Windows Workflow Foundation.

For complete details on the topics in this article, see Getting Started with Windows PowerShell Workflow.

Basic structure of a workflow

The first step to converting a PowerShell script to a PowerShell workflow is enclosing it with the Workflow keyword. A workflow starts with the Workflow keyword followed by the body of the script enclosed in braces. The name of the workflow follows the Workflow keyword as shown in the following syntax:

Workflow Test-Workflow
{
   <Commands>
}

The name of the workflow must match the name of the Automation runbook. If the runbook is being imported, then the filename must match the workflow name and must end in .ps1.

To add parameters to the workflow, use the Param keyword just as you would to a script.

Code changes

PowerShell workflow code looks almost identical to PowerShell script code except for a few significant changes. The following sections describe changes that you need to make to a PowerShell script for it to run in a workflow.

Activities

An activity is a specific task in a workflow. Just as a script is composed of one or more commands, a workflow is composed of one or more activities that are carried out in a sequence. Windows PowerShell Workflow automatically converts many of the Windows PowerShell cmdlets to activities when it runs a workflow. When you specify one of these cmdlets in your runbook, the corresponding activity is run by Windows Workflow Foundation. For those cmdlets without a corresponding activity, Windows PowerShell Workflow automatically runs the cmdlet within an InlineScript activity. There is a set of cmdlets that are excluded and cannot be used in a workflow unless you explicitly include them in an InlineScript block. For further details on these concepts, see Using Activities in Script Workflows.

Workflow activities share a set of common parameters to configure their operation. For details about the workflow common parameters, see about_WorkflowCommonParameters.

Positional parameters

You can't use positional parameters with activities and cmdlets in a workflow. All this means is that you must use parameter names.

For example, consider the following code that gets all running services.

 Get-Service | Where-Object {$_.Status -eq "Running"}

If you try to run this same code in a workflow, you receive a message like "Parameter set cannot be resolved using the specified named parameters." To correct this, provide the parameter name as in the following.

Workflow Get-RunningServices
{
    Get-Service | Where-Object -FilterScript {$_.Status -eq "Running"}
}

Deserialized objects

Objects in workflows are deserialized. This means that their properties are still available, but not their methods. For example, consider the following PowerShell code that stops a service using the Stop method of the Service object.

$Service = Get-Service -Name MyService
$Service.Stop()

If you try to run this in a workflow, you receive an error saying "Method invocation is not supported in a Windows PowerShell Workflow."

One option is to wrap these two lines of code in an InlineScript block in which case $Service would be a service object within the block.

Workflow Stop-Service
{
    InlineScript {
        $Service = Get-Service -Name MyService
        $Service.Stop()
    }
}

Another option is to use another cmdlet that performs the same functionality as the method, if one is available. In our sample, the Stop-Service cmdlet provides the same functionality as the Stop method, and you could use the following for a workflow.

Workflow Stop-MyService
{
    $Service = Get-Service -Name MyService
    Stop-Service -Name $Service.Name
}

InlineScript

The InlineScript activity is useful when you need to run one or more commands as traditional PowerShell script instead of PowerShell workflow. While commands in a workflow are sent to Windows Workflow Foundation for processing, commands in an InlineScript block are processed by Windows PowerShell.

InlineScript uses the following syntax shown below.

InlineScript
{
  <Script Block>
} <Common Parameters>

You can return output from an InlineScript by assigning the output to a variable. The following example stops a service and then outputs the service name.

Workflow Stop-MyService
{
    $Output = InlineScript {
        $Service = Get-Service -Name MyService
        $Service.Stop()
        $Service
    }

    $Output.Name
}

You can pass values into an InlineScript block, but you must use $Using scope modifier. The following example is identical to the previous example except that the service name is provided by a variable.

Workflow Stop-MyService
{
    $ServiceName = "MyService"

    $Output = InlineScript {
        $Service = Get-Service -Name $Using:ServiceName
        $Service.Stop()
        $Service
    }

    $Output.Name
}

While InlineScript activities may be critical in certain workflows, they do not support workflow constructs and should only be used when necessary for the following reasons:

  • You cannot use checkpoints inside an InlineScript block. If a failure occurs within the block, it must be resumed from the beginning of the block.
  • You cannot use parallel execution inside an InlineScriptBlock.
  • InlineScript affects scalability of the workflow since it holds the Windows PowerShell session for the entire length of the InlineScript block.

For more information on using InlineScript, see Running Windows PowerShell Commands in a Workflow and about_InlineScript.

Parallel processing

One advantage of Windows PowerShell Workflows is the ability to perform a set of commands in parallel instead of sequentially as with a typical script.

You can use the Parallel keyword to create a script block with multiple commands that run concurrently. This uses the following syntax shown below. In this case, Activity1 and Activity2 starts at the same time. Activity3 starts only after both Activity1 and Activity2 have completed.

Parallel
{
  <Activity1>
  <Activity2>
}
<Activity3>

For example, consider the following PowerShell commands that copy multiple files to a network destination. These commands are run sequentially so that one file must finish copying before the next is started.

Copy-Item -Path C:\LocalPath\File1.txt -Destination \\NetworkPath\File1.txt
Copy-Item -Path C:\LocalPath\File2.txt -Destination \\NetworkPath\File2.txt
Copy-Item -Path C:\LocalPath\File3.txt -Destination \\NetworkPath\File3.txt

The following workflow runs these same commands in parallel so that they all start copying at the same time. Only after they are all copied is the completion message displayed.

Workflow Copy-Files
{
    Parallel
    {
        Copy-Item -Path "C:\LocalPath\File1.txt" -Destination "\\NetworkPath"
        Copy-Item -Path "C:\LocalPath\File2.txt" -Destination "\\NetworkPath"
        Copy-Item -Path "C:\LocalPath\File3.txt" -Destination "\\NetworkPath"
    }

    Write-Output "Files copied."
}

You can use the ForEach -Parallel construct to process commands for each item in a collection concurrently. The items in the collection are processed in parallel while the commands in the script block run sequentially. This uses the following syntax shown below. In this case, Activity1 starts at the same time for all items in the collection. For each item, Activity2 starts after Activity1 is complete. Activity3 starts only after both Activity1 and Activity2 have completed for all items.

ForEach -Parallel ($<item> in $<collection>)
{
  <Activity1>
  <Activity2>
}
<Activity3>

The following example is similar to the previous example copying files in parallel. In this case, a message is displayed for each file after it copies. Only after they are all completely copied is the final completion message displayed.

Workflow Copy-Files
{
    $files = @("C:\LocalPath\File1.txt","C:\LocalPath\File2.txt","C:\LocalPath\File3.txt")

    ForEach -Parallel ($File in $Files)
    {
        Copy-Item -Path $File -Destination \\NetworkPath
        Write-Output "$File copied."
    }

    Write-Output "All files copied."
}
Note

We do not recommend running child runbooks in parallel since this has been shown to give unreliable results. The output from the child runbook sometimes does not show up, and settings in one child runbook can affect the other parallel child runbooks

Checkpoints

A checkpoint is a snapshot of the current state of the workflow that includes the current value for variables and any output generated to that point. If a workflow ends in error or is suspended, then the next time it is run it will start from its last checkpoint instead of the start of the worfklow. You can set a checkpoint in a workflow with the Checkpoint-Workflow activity.

In the following sample code, an exception occurs after Activity2 causing the workflow to end. When the workflow is run again, it starts by running Activity2 since this was just after the last checkpoint set.

<Activity1>
Checkpoint-Workflow
<Activity2>
<Exception>
<Activity3>

You should set checkpoints in a workflow after activities that may be prone to exception and should not be repeated if the workflow is resumed. For example, your workflow may create a virtual machine. You could set a checkpoint both before and after the commands to create the virtual machine. If the creation fails, then the commands would be repeated if the workflow is started again. If the worfklow fails after the creation succeeds, then the virtual machine will not be created again when the workflow is resumed.

The following example copies multiple files to a network location and sets a checkpoint after each file. If the network location is lost, then the workflow ends in error. When it is started again, it will resume at the last checkpoint meaning that only the files that have already been copied are skipped.

Workflow Copy-Files
{
    $files = @("C:\LocalPath\File1.txt","C:\LocalPath\File2.txt","C:\LocalPath\File3.txt")

    ForEach ($File in $Files)
    {
        Copy-Item -Path $File -Destination \\NetworkPath
        Write-Output "$File copied."
        Checkpoint-Workflow
    }

    Write-Output "All files copied."
}

Because username credentials are not persisted after you call the Suspend-Workflow activity or after the last checkpoint, you need to set the credentials to null and then retrieve them again from the asset store after Suspend-Workflow or checkpoint is called. Otherwise, you may receive the following error message: The workflow job cannot be resumed, either because persistence data could not be saved completely, or saved persistence data has been corrupted. You must restart the workflow.

The following same code demonstrates how to handle this in your PowerShell Workflow runbooks.

workflow CreateTestVms
{
   $Cred = Get-AzureAutomationCredential -Name "MyCredential"
   $null = Add-AzureRmAccount -Credential $Cred

   $VmsToCreate = Get-AzureAutomationVariable -Name "VmsToCreate"

   foreach ($VmName in $VmsToCreate)
     {
      # Do work first to create the VM (code not shown)

      # Now add the VM
      New-AzureRmVm -VM $Vm -Location "WestUs" -ResourceGroupName "ResourceGroup01"

      # Checkpoint so that VM creation is not repeated if workflow suspends
      $Cred = $null
      Checkpoint-Workflow
      $Cred = Get-AzureAutomationCredential -Name "MyCredential"
      $null = Add-AzureRmAccount -Credential $Cred
     }
 }

This is not required if you are authenticating using a Run As account configured with a service principal.

For more information about checkpoints, see Adding Checkpoints to a Script Workflow.
