Secure Socket Layer (SSL) encryption is the most commonly used method of securing data sent across the internet. This common task discusses how to specify an HTTPS endpoint for a web role and how to upload an SSL certificate to secure your application.

Note

The procedures in this task apply to Azure Cloud Services; for App Services, see this article.

This task uses a production deployment. Information on using a staging deployment is provided at the end of this topic.

Read this article first if you have not yet created a cloud service.

Note

Get going faster--use the NEW Azure guided walkthrough! It makes associating a custom domain name AND securing communication (SSL) with Azure Cloud Services or Azure App Service Web Apps a snap.

Step 1: Get an SSL certificate

To configure SSL for an application, you first need to get an SSL certificate that has been signed by a Certificate Authority (CA), a trusted third party who issues certificates for this purpose. If you do not already have one, you need to obtain one from a company that sells SSL certificates.

The certificate must meet the following requirements for SSL certificates in Azure:

  • The certificate must contain a private key.
  • The certificate must be created for key exchange, exportable to a Personal Information Exchange (.pfx) file.
  • The certificate's subject name must match the domain used to access the cloud service. You cannot obtain an SSL certificate from a certificate authority (CA) for the cloudapp.net domain. You must acquire a custom domain name to use when access your service. When you request a certificate from a CA, the certificate's subject name must match the custom domain name used to access your application. For example, if your custom domain name is contoso.com you would request a certificate from your CA for .contoso.com* or **www.contoso.com.
  • The certificate must use a minimum of 2048-bit encryption.

For test purposes, you can create and use a self-signed certificate. A self-signed certificate is not authenticated through a CA and can use the cloudapp.net domain as the website URL. For example, the following task uses a self-signed certificate in which the common name (CN) used in the certificate is sslexample.cloudapp.net.

Next, you must include information about the certificate in your service definition and service configuration files.

Step 2: Modify the service definition and configuration files

Your application must be configured to use the certificate, and an HTTPS endpoint must be added. As a result, the service definition and service configuration files need to be updated.

  1. In your development environment, open the service definition file (CSDEF), add a Certificates section within the WebRole section, and include the following information about the certificate (and intermediate certificates):

    <WebRole name="CertificateTesting" vmsize="Small">
    ...
        <Certificates>
            <Certificate name="SampleCertificate"
                         storeLocation="LocalMachine"
                         storeName="My"
                         permissionLevel="limitedOrElevated" />
            <!-- IMPORTANT! Unless your certificate is either
            self-signed or signed directly by the CA root, you
            must include all the intermediate certificates
            here. You must list them here, even if they are
            not bound to any endpoints. Failing to list any of
            the intermediate certificates may cause hard-to-reproduce
            interoperability problems on some clients.-->
            <Certificate name="CAForSampleCertificate"
                         storeLocation="LocalMachine"
                         storeName="CA"
                         permissionLevel="limitedOrElevated" />
        </Certificates>
    ...
    </WebRole>


    The Certificates section defines the name of our certificate, its location, and the name of the store where it is located.

    Permissions (permisionLevel attribute) can be set to one of the following values:

    Permission Value Description
    limitedOrElevated (Default) All role processes can access the private key.
    elevated Only elevated processes can access the private key.
  2. In your service definition file, add an InputEndpoint element within the Endpoints section to enable HTTPS:

    <WebRole name="CertificateTesting" vmsize="Small">
    ...
        <Endpoints>
            <InputEndpoint name="HttpsIn" protocol="https" port="443"
                certificate="SampleCertificate" />
        </Endpoints>
    ...
    </WebRole>

  3. In your service definition file, add a Binding element within the Sites section. This section adds an HTTPS binding to map the endpoint to your site:

    <WebRole name="CertificateTesting" vmsize="Small">
    ...
        <Sites>
            <Site name="Web">
                <Bindings>
                    <Binding name="HttpsIn" endpointName="HttpsIn" />
                </Bindings>
            </Site>
        </Sites>
    ...
    </WebRole>


    All the required changes to the service definition file have been completed, but you still need to add the certificate information to the service configuration file.

  4. In your service configuration file (CSCFG), ServiceConfiguration.Cloud.cscfg, add a Certificates section within the Role section, replacing the sample thumbprint value shown below with that of your certificate:

    <Role name="Deployment">
    ...
        <Certificates>
            <Certificate name="SampleCertificate"
                thumbprint="9427befa18ec6865a9ebdc79d4c38de50e6316ff"
                thumbprintAlgorithm="sha1" />
            <Certificate name="CAForSampleCertificate"
                thumbprint="79d4c38de50e6316ff9427befa18ec6865a9ebdc"
                thumbprintAlgorithm="sha1" />
        </Certificates>
    ...
    </Role>


(The preceding example uses sha1 for the thumbprint algorithm. Specify the appropriate value for your certificate's thumbprint algorithm.)

Now that the service definition and service configuration files have been updated, package your deployment for uploading to Azure. If you are using cspack, don't use the /generateConfigurationFile flag, as that overwrites the certificate information you inserted.

Step 3: Upload a certificate

Your deployment package has been updated to use the certificate, and an HTTPS endpoint has been added. Now you can upload the package and certificate to Azure with the Azure classic portal.

  1. Log in to the Azure classic portal.
  2. Click Cloud Services on the left-side navigation pane.
  3. Click the desired cloud service.
  4. Click the Certificates tab.

    Click the Certificates tab

  5. Click the Upload button.

    Upload

  6. Provide the File, Password, then click Complete (the checkmark).

Step 4: Connect to the role instance by using HTTPS

Now that your deployment is up and running in Azure, you can connect to it using HTTPS.

  1. In the Azure classic portal, select your deployment, then click the link under Site URL.

    Determine site URL

  2. In your web browser, modify the link to use https instead of http, and then visit the page.

    Note

    If you are using a self-signed certificate, when you browse to an HTTPS endpoint that's associated with the self-signed certificate you may see a certificate error in the browser. Using a certificate signed by a trusted certification authority eliminates this problem; in the meantime, you can ignore the error. (Another option is to add the self-signed certificate to the user's trusted certificate authority certificate store.)

    SSL example web site

If you want to use SSL for a staging deployment instead of a production deployment, you first need to determine the URL used for the staging deployment. Deploy your cloud service to the staging environment without including a certificate or any certificate information. Once deployed, you can determine the GUID-based URL, which is listed in the Azure classic portal's Site URL field. Create a certificate with the common name (CN) equal to the GUID-based URL (for example, 32818777-6e77-4ced-a8fc-57609d404462.cloudapp.net). Use the Azure classic portal to add the certificate to your staged cloud service. Then, add the certificate information to your CSDEF and CSCFG files, repackage your application, and update your staged deployment to use the new package.
