Azure Cosmos DB: Create, query, and traverse a graph in the Gremlin console

Azure Cosmos DB is Microsoft’s globally distributed multi-model database service. You can quickly create and query document, key/value, and graph databases, all of which benefit from the global distribution and horizontal scale capabilities at the core of Azure Cosmos DB.

This quick start demonstrates how to create an Azure Cosmos DB account, database, and graph (container) using the Azure portal and then use the Gremlin Console from Apache TinkerPop to work with Graph API (preview) data. In this tutorial, you create and query vertices and edges, updating a vertex property, query vertices, traverse the graph, and drop a vertex.

Azure Cosmos DB from the Apache Gremlin console

The Gremlin console is Groovy/Java based and runs on Linux, Mac, and Windows. You can download it from the Apache TinkerPop site.

Prerequisites

You need to have an Azure subscription to create an Azure Cosmos DB account for this quickstart.

If you don't have an Azure subscription, create a free account before you begin.

You also need to install the Gremlin Console. Use version 3.2.5 or above.

Create a database account

  1. In a new browser window, sign in to the Azure portal.

  2. Click New > Databases > Azure Cosmos DB.

    Azure portal "Databases" pane

  3. In the New account page, enter the settings for the new Azure Cosmos DB account.

    Setting Suggested value Description
    ID Enter a unique name Enter a unique name to identify this Azure Cosmos DB account. Because documents.azure.com is appended to the ID that you provide to create your URI, use a unique but identifiable ID.

    The ID can contain only lowercase letters, numbers, and the hyphen (-) character, and it must contain 3 to 50 characters.
    API Gremlin (graph) The API determines the type of account to create. Azure Cosmos DB provides five APIs to suits the needs of your application: SQL (document database), Gremlin (graph database), MongoDB (document database), Azure Table, and Cassandra, each which currently require a separate account.

    Select Gremlin (graph) because in this quickstart you are creating a graph that is queryable using Gremlin syntax.

    Learn more about the Graph API
    Subscription Your subscription Select Azure subscription that you want to use for this Azure Cosmos DB account.
    Resource group Enter the same unique name as provided above in ID Enter a new resource-group name for your account. For simplicity, you can use the same name as your ID.
    Location Select the region closest to your users Select geographic location in which to host your Azure Cosmos DB account. Use the location that's closest to your users to give them the fastest access to the data.
    Enable geo-redundancy Leave blank This creates a replicated version of your database in a second (paired) region. Leave this blank.
    Pin to dashboard Select Select this box so that your new database account is added to your portal dashboard for easy access.

    Then click Create.

    The new account blade for Azure Cosmos DB

  4. The account creation takes a few minutes. During account creation the portal displays the Deploying Azure Cosmos DB tile on the right side, you may need to scroll right on your dashboard to see the tile. There is also a progress bar displayed near the top of the screen. You can watch either area for progress.

    The Azure portal Notifications pane

    Once the account is created, the Congratulations! Your Azure Cosmos DB account was created page is displayed.

Add a graph

You can now use the Data Explorer tool in the Azure portal to create a graph database.

  1. In the Azure portal, in the menu on the left, select Data Explorer (Preview).

  2. Under Data Explorer (Preview), select New Graph. Then fill in the page by using the following information:

    Data Explorer in the Azure portal

    Setting Suggested value Description
    Database id sample-database Enter sample-database as the name for the new database. Database names must be between 1 and 255 characters and can't contain / \ # ? or a trailing space.
    Graph id sample-graph Enter sample-graph as the name for your new collection. Graph names have the same character requirements as database IDs.
    Storage capacity 10 GB Leave the default value. This is the storage capacity of the database.
    Throughput 400 RUs Leave the default value. You can scale up the throughput later if you want to reduce latency.
    Partition key /firstName A partition key that distributes data evenly to each partition. Selecting the correct partition key is important in creating a performant graph. For more information, see Designing for partitioning.
  3. After the form is filled out, select OK.

Connect to your app service

  1. Before starting the Gremlin Console, create or modify the remote-secure.yaml configuration file in the apache-tinkerpop-gremlin-console-3.2.5/conf directory.
  2. Fill in your host, port, username, password, connectionPool, and serializer configurations:

    Setting Suggested value Description
    hosts [***.graphs.azure.com] See screenshot below. This is the Gremlin URI value on the Overview page of the Azure portal, in square brackets, with the trailing :443/ removed.

    This value can also be retrieved from the Keys tab, using the URI value by removing https://, changing documents to graphs, and removing the trailing :443/.
    port 443 Set to 443.
    username Your username The resource of the form /dbs/<db>/colls/<coll> where <db> is your database name and <coll> is your collection name.
    password Your primary key See second screenshot below. This is your primary key, which you can retrieve from the Keys page of the Azure portal, in the Primary Key box. Use the copy button on the left side of the box to copy the value.
    connectionPool {enableSsl: true} Your connection pool setting for SSL.
    serializer { className: org.apache.tinkerpop.gremlin.
    driver.ser.GraphSONMessageSerializerV1d0,
    config: { serializeResultToString: true }}
    Set to this value and delete any \n line breaks when pasting in the value.

    For the hosts value, copy the Gremlin URI value from the Overview page: View and copy the Gremlin URI value on the Overview page in the Azure portal

    For the password value, copy the Primary key from the Keys page: View and copy your primary key in the Azure portal, Keys page

Your remote-secure.yaml file should look like this:

hosts: [your_database_server.graphs.azure.com]
port: 443
username: /dbs/your_database_account/colls/your_collection
password: your_primary_key
connectionPool: {
  enableSsl: true
}
serializer: { className: org.apache.tinkerpop.gremlin.driver.ser.GraphSONMessageSerializerV1d0, config: { serializeResultToString: true }}
  1. In your terminal, run bin/gremlin.bat or bin/gremlin.sh to start the Gremlin Console.
  2. In your terminal, run :remote connect tinkerpop.server conf/remote-secure.yaml to connect to your app service.

    Tip

    If you receive the error No appenders could be found for logger ensure that you updated the serializer value in the remote-secure.yaml file as described in step 2.

Great! Now that we finished the setup, let's start running some console commands.

Let's try a simple count() command. Type the following into the console at the prompt:

:> g.V().count()

Tip

Notice the :> that precedes the g.V().count() text?

This is part of the command you need to type. It is important when using the Gremlin console, with Azure Cosmos DB.

Omitting this :> prefix instructs the console to execute the command locally, often against an in-memory graph. Using this :> tells the console to execute a remote command, in this case against Cosmos DB (either the localhost emulator, or an > Azure instance).

Create vertices and edges

Let's begin by adding five person vertices for Thomas, Mary Kay, Robin, Ben, and Jack.

Input (Thomas):

:> g.addV('person').property('firstName', 'Thomas').property('lastName', 'Andersen').property('age', 44).property('userid', 1)

Output:

==>[id:796cdccc-2acd-4e58-a324-91d6f6f5ed6d,label:person,type:vertex,properties:[firstName:[[id:f02a749f-b67c-4016-850e-910242d68953,value:Thomas]],lastName:[[id:f5fa3126-8818-4fda-88b0-9bb55145ce5c,value:Andersen]],age:[[id:f6390f9c-e563-433e-acbf-25627628016e,value:44]],userid:[[id:796cdccc-2acd-4e58-a324-91d6f6f5ed6d|userid,value:1]]]]

Input (Mary Kay):

:> g.addV('person').property('firstName', 'Mary Kay').property('lastName', 'Andersen').property('age', 39).property('userid', 2)

Output:

==>[id:0ac9be25-a476-4a30-8da8-e79f0119ea5e,label:person,type:vertex,properties:[firstName:[[id:ea0604f8-14ee-4513-a48a-1734a1f28dc0,value:Mary Kay]],lastName:[[id:86d3bba5-fd60-4856-9396-c195ef7d7f4b,value:Andersen]],age:[[id:bc81b78d-30c4-4e03-8f40-50f72eb5f6da,value:39]],userid:[[id:0ac9be25-a476-4a30-8da8-e79f0119ea5e|userid,value:2]]]]

Input (Robin):

:> g.addV('person').property('firstName', 'Robin').property('lastName', 'Wakefield').property('userid', 3)

Output:

==>[id:8dc14d6a-8683-4a54-8d74-7eef1fb43a3e,label:person,type:vertex,properties:[firstName:[[id:ec65f078-7a43-4cbe-bc06-e50f2640dc4e,value:Robin]],lastName:[[id:a3937d07-0e88-45d3-a442-26fcdfb042ce,value:Wakefield]],userid:[[id:8dc14d6a-8683-4a54-8d74-7eef1fb43a3e|userid,value:3]]]]

Input (Ben):

:> g.addV('person').property('firstName', 'Ben').property('lastName', 'Miller').property('userid', 4)

Output:

==>[id:ee86b670-4d24-4966-9a39-30529284b66f,label:person,type:vertex,properties:[firstName:[[id:a632469b-30fc-4157-840c-b80260871e9a,value:Ben]],lastName:[[id:4a08d307-0719-47c6-84ae-1b0b06630928,value:Miller]],userid:[[id:ee86b670-4d24-4966-9a39-30529284b66f|userid,value:4]]]]

Input (Jack):

:> g.addV('person').property('firstName', 'Jack').property('lastName', 'Connor').property('userid', 5)

Output:

==>[id:4c835f2a-ea5b-43bb-9b6b-215488ad8469,label:person,type:vertex,properties:[firstName:[[id:4250824e-4b72-417f-af98-8034aa15559f,value:Jack]],lastName:[[id:44c1d5e1-a831-480a-bf94-5167d133549e,value:Connor]],userid:[[id:4c835f2a-ea5b-43bb-9b6b-215488ad8469|userid,value:5]]]]

Next, let's add edges for relationships between our people.

Input (Thomas -> Mary Kay):

:> g.V().hasLabel('person').has('firstName', 'Thomas').addE('knows').to(g.V().hasLabel('person').has('firstName', 'Mary Kay'))

Output:

==>[id:c12bf9fb-96a1-4cb7-a3f8-431e196e702f,label:knows,type:edge,inVLabel:person,outVLabel:person,inV:0d1fa428-780c-49a5-bd3a-a68d96391d5c,outV:1ce821c6-aa3d-4170-a0b7-d14d2a4d18c3]

Input (Thomas -> Robin):

:> g.V().hasLabel('person').has('firstName', 'Thomas').addE('knows').to(g.V().hasLabel('person').has('firstName', 'Robin'))

Output:

==>[id:58319bdd-1d3e-4f17-a106-0ddf18719d15,label:knows,type:edge,inVLabel:person,outVLabel:person,inV:3e324073-ccfc-4ae1-8675-d450858ca116,outV:1ce821c6-aa3d-4170-a0b7-d14d2a4d18c3]

Input (Robin -> Ben):

:> g.V().hasLabel('person').has('firstName', 'Robin').addE('knows').to(g.V().hasLabel('person').has('firstName', 'Ben'))

Output:

==>[id:889c4d3c-549e-4d35-bc21-a3d1bfa11e00,label:knows,type:edge,inVLabel:person,outVLabel:person,inV:40fd641d-546e-412a-abcc-58fe53891aab,outV:3e324073-ccfc-4ae1-8675-d450858ca116]

Update a vertex

Let's update the Thomas vertex with a new age of 45.

Input:

:> g.V().hasLabel('person').has('firstName', 'Thomas').property('age', 45)

Output:

==>[id:ae36f938-210e-445a-92df-519f2b64c8ec,label:person,type:vertex,properties:[firstName:[[id:872090b6-6a77-456a-9a55-a59141d4ebc2,value:Thomas]],lastName:[[id:7ee7a39a-a414-4127-89b4-870bc4ef99f3,value:Andersen]],age:[[id:a2a75d5a-ae70-4095-806d-a35abcbfe71d,value:45]]]]

Query your graph

Now, let's run a variety of queries against your graph.

First, let's try a query with a filter to return only people who are older than 40 years old.

Input (filter query):

:> g.V().hasLabel('person').has('age', gt(40))

Output:

==>[id:ae36f938-210e-445a-92df-519f2b64c8ec,label:person,type:vertex,properties:[firstName:[[id:872090b6-6a77-456a-9a55-a59141d4ebc2,value:Thomas]],lastName:[[id:7ee7a39a-a414-4127-89b4-870bc4ef99f3,value:Andersen]],age:[[id:a2a75d5a-ae70-4095-806d-a35abcbfe71d,value:45]]]]

Next, let's project the first name for the people who are older than 40 years old.

Input (filter + projection query):

:> g.V().hasLabel('person').has('age', gt(40)).values('firstName')

Output:

==>Thomas

Traverse your graph

Let's traverse the graph to return all of Thomas's friends.

Input (friends of Thomas):

:> g.V().hasLabel('person').has('firstName', 'Thomas').outE('knows').inV().hasLabel('person')

Output:

==>[id:f04bc00b-cb56-46c4-a3bb-a5870c42f7ff,label:person,type:vertex,properties:[firstName:[[id:14feedec-b070-444e-b544-62be15c7167c,value:Mary Kay]],lastName:[[id:107ab421-7208-45d4-b969-bbc54481992a,value:Andersen]],age:[[id:4b08d6e4-58f5-45df-8e69-6b790b692e0a,value:39]]]]
==>[id:91605c63-4988-4b60-9a30-5144719ae326,label:person,type:vertex,properties:[firstName:[[id:f760e0e6-652a-481a-92b0-1767d9bf372e,value:Robin]],lastName:[[id:352a4caa-bad6-47e3-a7dc-90ff342cf870,value:Wakefield]]]]

Next, let's get the next layer of vertices. Traverse the graph to return all the friends of Thomas's friends.

Input (friends of friends of Thomas):

:> g.V().hasLabel('person').has('firstName', 'Thomas').outE('knows').inV().hasLabel('person').outE('knows').inV().hasLabel('person')

Output:

==>[id:a801a0cb-ee85-44ee-a502-271685ef212e,label:person,type:vertex,properties:[firstName:[[id:b9489902-d29a-4673-8c09-c2b3fe7f8b94,value:Ben]],lastName:[[id:e084f933-9a4b-4dbc-8273-f0171265cf1d,value:Miller]]]]

Drop a vertex

Let's now delete a vertex from the graph database.

Input (drop Jack vertex):

:> g.V().hasLabel('person').has('firstName', 'Jack').drop()

Clear your graph

Finally, let's clear the database of all vertices and edges.

Input:

:> g.E().drop()
:> g.V().drop()

Congratulations! You've completed this Azure Cosmos DB: Graph API tutorial!

Review SLAs in the Azure portal

The throughput, storage, availability, latency, and consistency of the resources in your account are monitored in the Azure portal. Let's take a quick look at these metrics.

  1. Click Metrics in the navigation menu.

    Metrics in the Azure portal

  2. Click through each of the tabs so you're aware of the metrics Azure Cosmos DB provides.

    Each chart that's associated with the Azure Cosmos DB Service Level Agreements (SLAs) provides a line that shows if any of the SLAs have been violated. Azure Cosmos DB makes monitoring your SLAs transparent with this suite of metrics.

    Azure Cosmos DB metrics suite

Clean up resources

If you're not going to continue to use this app, delete all resources created by this quickstart in the Azure portal with the following steps:

  1. From the left-hand menu in the Azure portal, click Resource groups and then click the name of the resource you created.
  2. On your resource group page, click Delete, type the name of the resource to delete in the text box, and then click Delete.

Next steps

In this quickstart, you've learned how to create an Azure Cosmos DB account, create a graph using the Data Explorer, create vertices and edges, and traverse your graph using the Gremlin console. You can now build more complex queries and implement powerful graph traversal logic using Gremlin.
