Build a .NET console app to manage data in Azure Cosmos DB SQL API account

Welcome to the Azure Cosmos DB SQL API get started tutorial. After you complete this tutorial, you'll have a console app that creates and queries Azure Cosmos DB resources.

This tutorial shows you how to:

  • Create an Azure Cosmos DB account and connect to it
  • Configure a Visual Studio solution
  • Create a database
  • Create a collection
  • Create JSON documents
  • Query the collection
  • Update a JSON document
  • Delete a document
  • Delete the database

Prerequisites

Visual Studio 2017 with the Azure development workflow installed:

An Azure subscription or free Cosmos DB trial account:

Get the completed solution

If you don't have time to complete the tutorial, or just want the code samples, you can download the complete solution from GitHub.

To run the downloaded complete solution:

  1. Make sure you have the Prerequisites installed.
  2. Open the downloaded GetStarted.sln solution file in Visual Studio.
  3. In Solution Explorer, right-click the GetStarted project, and select Manage NuGet Packages.
  4. On the NuGet tab, select Restore to restore the references to the Azure Cosmos DB .NET SDK.
  5. In the App.config file, update the EndpointUrl and PrimaryKey values as described in the Connect to the Azure Cosmos DB account section.
  6. Select Debug > Start Without Debugging or press Ctrl+F5 to build and run the app.

Create an Azure Cosmos DB account

Follow these instructions to create an Azure Cosmos DB account in the Azure portal. If you already have an Azure Cosmos DB account to use, skip ahead to Set up the Visual Studio solution.

  1. Sign in to the Azure portal.

  2. Select Create a resource > Databases > Azure Cosmos DB.

    The Azure portal Databases pane

  3. On the Create Azure Cosmos DB Account page, enter the basic settings for the new Azure Cosmos account.

    Setting Value Description
    Subscription Subscription name Select the Azure subscription that you want to use for this Azure Cosmos account.
    Resource Group Resource group name Select a resource group, or select Create new, then enter a unique name for the new resource group.
    Account Name Enter a unique name Enter a name to identify your Azure Cosmos account. Because documents.azure.com is appended to the ID that you provide to create your URI, use a unique ID.

    The ID can only contain lowercase letters, numbers, and the hyphen (-) character. It must be between 3-31 characters in length.
    API Core (SQL) The API determines the type of account to create. Azure Cosmos DB provides five APIs: Core (SQL) and MongoDB for document data, Gremlin for graph data, Azure Table, and Cassandra. Currently, you must create a separate account for each API.

    Select Core (SQL) to create a document database and query by using SQL syntax.

    Learn more about the SQL API.
    Location Select the region closest to your users Select a geographic location to host your Azure Cosmos DB account. Use the location that is closest to your users to give them the fastest access to the data.

    The new account page for Azure Cosmos DB

  4. Select Review + create. You can skip the Network and Tags sections.

  5. Review the account settings, and then select Create. It takes a few minutes to create the account. Wait for the portal page to display Your deployment is complete.

    The Azure portal Notifications pane

  6. Select Go to resource to go to the Azure Cosmos DB account page.

    The Azure Cosmos DB account page

Set up the Visual Studio solution

  1. In Visual Studio 2017, select File > New > Project.

  2. In the New Project dialog, select Visual C# > Console App (.NET Framework), name your project AzureCosmosDBApp, and then select OK.

    Screenshot of the New Project window

  3. In Solution Explorer, right-click the AzureCosmosDBApp project and select Manage NuGet Packages.

    Project context menu

  4. On the NuGet tab, select Browse, and enter azure documentdb in the search box.

  5. Find and select Microsoft.Azure.DocumentDB, and select Install if it's not already installed.

    The package ID for the Azure Cosmos DB SQL API Client Library is Microsoft Azure Cosmos DB Client Library.

    Note

    If you are using .NET Core, please see the .NET Core docs.

    Screenshot of the NuGet Menu for finding Azure Cosmos DB Client SDK

    If you get a message about previewing changes to the solution, select OK. If you get a message about license acceptance, select I accept.

Connect to the Azure Cosmos DB account

Now, get started writing some code. The complete Project.cs file for this tutorial is in GitHub.

  1. In Solution Explorer, select Program.cs, and in the code editor, add the following references to the beginning of the file:

    using System.Net;
    using Microsoft.Azure.Documents;
    using Microsoft.Azure.Documents.Client;
    using Newtonsoft.Json;

  2. Next, add the following two constants and the client variable to public class Program.


    public class Program
    {
       private const string EndpointUrl = "<your endpoint URL>";
       private const string PrimaryKey = "<your primary key>";
       private DocumentClient client;

  3. The endpoint URL and primary key allow your app to connect to your Azure Cosmos DB account, and the Azure Cosmos DB account to trust the connection. Copy the keys from the Azure portal, and paste them into your code.

    1. In your Azure Cosmos DB account left navigation, select Keys.

      View and copy access keys in the Azure portal

    2. Under Read-write Keys, copy the URI value using the copy button at the right, and paste it into <your endpoint URL> in Program.cs. For example:

      private const string EndpointUrl = "https://mysqlapicosmosdb.documents.azure.com:443/";

    3. Copy the PRIMARY KEY value and paste it into <your primary key> in Program.cs. For example:

      private const string PrimaryKey = "19ZDNJAiYL26tmnRvoez6hmtIfBGwjun50PWRjNYMC2ig8Ob9hYk7Fq1RYSv8FcIYnh1TdBISvCh7s6yyb0000==";

  4. After the Main method, add a new asynchronous task called GetStartedDemo, which instantiates a new DocumentClient called client.

       private async Task GetStartedDemo()
       {
         client = new DocumentClient(new Uri(EndpointUrl), PrimaryKey);
       }


    If you are using a proxy object to connect to Azure Cosmos DB, you should instead use the following code block to create the DocumentClient object. The sample in this document doesn't use a proxy object, so the example below is just for your reference:

    HttpClientHandler handler = new HttpClientHandler()
    {
      Proxy = proxyObject
      UseProxy = true,
    };

    //Pass handler to the constructor of DocumentClient.
    DocumentClient client = new DocumentClient(new Uri(EndpointUrl), PrimaryKey, handler);


  5. Add the following code to the Main method to run the GetStartedDemo task. The Main method catches exceptions and writes them to the console.

       static void Main(string[] args)
       {
         try
         {
            Program p = new Program();
            p.GetStartedDemo().Wait();
         }
         catch (DocumentClientException de)
         {
            Exception baseException = de.GetBaseException();
            Console.WriteLine($"{de.StatusCode} error occurred: {de.Message}, Message: {baseException.Message}");
         }
         catch (Exception e)
         {
            Exception baseException = e.GetBaseException();
            Console.WriteLine($"Error: {e.Message}, Message: {baseException.Message}");
         }
         finally
         {
            Console.WriteLine("End of demo, press any key to exit.");
            Console.ReadKey();
         }
       }

  6. Press F5 to run your app.

  7. When you see the message End of demo, press any key to exit in the console window, it means the connection was successful. Press any key to close the console window.

You've successfully connected to your Azure Cosmos DB account. Now, work with some Azure Cosmos DB resources.

Create a database

An Azure Cosmos DB database is the logical container of JSON document storage partitioned across collections. You create a database by using the CreateDatabaseIfNotExistsAsync method of the DocumentClient class.

  1. Before you add the code for creating a database, add a helper method for writing to the console. Copy and paste the following WriteToConsoleAndPromptToContinue method after the GetStartedDemo method in your code.

    private void WriteToConsoleAndPromptToContinue(string format, params object[] args)
    {
       Console.WriteLine(format, args);
       Console.WriteLine("Press any key to continue...");
       Console.ReadKey();
    }

  2. Copy and paste the following line to your GetStartedDemo method, after the client = new DocumentClient(new Uri(EndpointUrl), PrimaryKey); line. This code creates a database named FamilyDB.

       await client.CreateDatabaseIfNotExistsAsync(new Database { Id = "FamilyDB" });

  3. Press F5 to run your app.

You've successfully created an Azure Cosmos DB database. You can see the database in the Azure portal by selecting Data Explorer in your Azure Cosmos DB account left navigation.

Create a collection

A collection is a container of JSON documents and associated JavaScript application logic. You create a collection by using the CreateDocumentCollectionIfNotExistsAsync method of the DocumentClient class.

Important

CreateDocumentCollectionIfNotExistsAsync creates a new collection with reserved throughput, which has pricing implications. For more details, visit the pricing page.

  1. Copy and paste the following code to your GetStartedDemo method after the await client.CreateDatabaseIfNotExistsAsync(new Database { Id = "FamilyDB" }); line. This code creates a document collection named FamilyCollection.

       await client.CreateDocumentCollectionIfNotExistsAsync(UriFactory.CreateDatabaseUri("FamilyDB"), new DocumentCollection { Id = "FamilyCollection" });

  2. Press F5 to run your app.

You've successfully created an Azure Cosmos DB document collection. You can see the collection under your FamilyDB database in Data Explorer in the Azure portal.

Create JSON documents

Documents are user-defined, arbitrary JSON content. Documents must have an ID property serialized as id in JSON. You create documents by using the CreateDocumentAsync method of the DocumentClient class.

Tip

If you already have data you'd like to store in your database, you can use the Azure Cosmos DB Data Migration tool to import it.

The following code creates and inserts two documents into your database collection. First, you create a Family class, and Parent, Child, Pet, and Address subclasses to use within Family. Then, you create a CreateFamilyDocumentIfNotExists method, and then create and insert two documents.

  1. Copy and paste the following Family, Parent, Child, Pet, and Address classes after the WriteToConsoleAndPromptToContinue method in your code.

     public class Family
     {
         [JsonProperty(PropertyName = "id")]
         public string Id { get; set; }
         public string LastName { get; set; }
         public Parent[] Parents { get; set; }
         public Child[] Children { get; set; }
         public Address Address { get; set; }
         public bool IsRegistered { get; set; }
         public override string ToString()
         {
             return JsonConvert.SerializeObject(this);
         }
     }

     public class Parent
     {
         public string FamilyName { get; set; }
         public string FirstName { get; set; }
     }

     public class Child
     {
         public string FamilyName { get; set; }
         public string FirstName { get; set; }
         public string Gender { get; set; }
         public int Grade { get; set; }
         public Pet[] Pets { get; set; }
     }

     public class Pet
     {
         public string GivenName { get; set; }
     }

     public class Address
     {
         public string State { get; set; }
         public string County { get; set; }
         public string City { get; set; }
     }

  2. Copy and paste the following CreateFamilyDocumentIfNotExists method after the Address class you just added.

     private async Task CreateFamilyDocumentIfNotExists(string databaseName, string collectionName, Family family)
     {
         try
         {
             await client.ReadDocumentAsync(UriFactory.CreateDocumentUri(databaseName, collectionName, family.Id));
             WriteToConsoleAndPromptToContinue($"Found {family.Id}");
         }
         catch (DocumentClientException de)
         {
             if (de.StatusCode == HttpStatusCode.NotFound)
             {
                 await client.CreateDocumentAsync(UriFactory.CreateDocumentCollectionUri(databaseName, collectionName), family);
                 WriteToConsoleAndPromptToContinue($"Created Family {family.Id}");
             }
             else
             {
                 throw;
             }
         }
     }

  3. Copy and paste the following code at the end of your GetStartedDemo method, after the await client.CreateDocumentCollectionIfNotExistsAsync line. This code creates and inserts two documents, one each for the Andersen and Wakefield families.

     Family andersenFamily = new Family
     {
         Id = "AndersenFamily",
         LastName = "Andersen",
         Parents = new Parent[]
         {
             new Parent { FirstName = "Thomas" },
             new Parent { FirstName = "Mary Kay" }
         },
         Children = new Child[]
         {
             new Child
             {
                 FirstName = "Henriette Thaulow",
                 Gender = "female",
                 Grade = 5,
                 Pets = new Pet[]
                 {
                     new Pet { GivenName = "Fluffy" }
                 }
             }
         },
         Address = new Address { State = "WA", County = "King", City = "Seattle" },
         IsRegistered = true
     };

     await CreateFamilyDocumentIfNotExists("FamilyDB", "FamilyCollection", andersenFamily);

     Family wakefieldFamily = new Family
     {
         Id = "WakefieldFamily",
         LastName = "Wakefield",
         Parents = new Parent[]
         {
             new Parent { FamilyName = "Wakefield", FirstName = "Robin" },
             new Parent { FamilyName = "Miller", FirstName = "Ben" }
         },
         Children = new Child[]
         {
             new Child
             {
                 FamilyName = "Merriam",
                 FirstName = "Jesse",
                 Gender = "female",
                 Grade = 8,
                 Pets = new Pet[]
                 {
                     new Pet { GivenName = "Goofy" },
                     new Pet { GivenName = "Shadow" }
                 }
             },
             new Child
             {
                 FamilyName = "Miller",
                 FirstName = "Lisa",
                 Gender = "female",
                 Grade = 1
             }
         },
         Address = new Address { State = "NY", County = "Manhattan", City = "NY" },
         IsRegistered = false
     };

     await CreateFamilyDocumentIfNotExists("FamilyDB", "FamilyCollection", wakefieldFamily);

  4. Press F5 to run your app.

You've successfully created two Azure Cosmos DB documents. You can see the documents under your FamilyDB database and FamilyCollection collection in Data Explorer in the Azure portal.

Diagram illustrating the hierarchical relationship between the account, the online database, the collection, and the documents

Query Azure Cosmos DB resources

Azure Cosmos DB supports rich queries against JSON documents stored in collections. The following sample code uses LINQ and Azure Cosmos DB SQL syntax to run a query against the sample documents.

  1. Copy and paste the following ExecuteSimpleQuery method after the CreateFamilyDocumentIfNotExists method in your code.

     private void ExecuteSimpleQuery(string databaseName, string collectionName)
     {
         // Set some common query options.
         FeedOptions queryOptions = new FeedOptions { MaxItemCount = -1 };

         // Find the Andersen family by its LastName.
         IQueryable<Family> familyQuery = client.CreateDocumentQuery<Family>(
             UriFactory.CreateDocumentCollectionUri(databaseName, collectionName), queryOptions)
             .Where(f => f.LastName == "Andersen");

         // Execute the query synchronously.
         // You could also execute it asynchronously using the IDocumentQuery<T> interface.
         Console.WriteLine("Running LINQ query...");
         foreach (Family family in familyQuery)
         {
             Console.WriteLine($"\tRead {family}");
         }

         // Now execute the same query using direct SQL.
         IQueryable<Family> familyQueryInSql = client.CreateDocumentQuery<Family>(
             UriFactory.CreateDocumentCollectionUri(databaseName, collectionName),
             "SELECT * FROM Family WHERE Family.LastName = 'Andersen'",
             queryOptions);

         Console.WriteLine("Running direct SQL query...");
         foreach (Family family in familyQueryInSql)
         {
             Console.WriteLine($"\tRead {family}");
         }

         Console.WriteLine("Press any key to continue ...");
         Console.ReadKey();
     }

  2. Copy and paste the following code at the end of your GetStartedDemo method, after the await CreateFamilyDocumentIfNotExists("FamilyDB", "FamilyCollection", wakefieldFamily); line.

       ExecuteSimpleQuery("FamilyDB", "FamilyCollection");

  3. Press F5 to run your app.

The preceding query returns the complete item for the Andersen family. You've successfully queried against an Azure Cosmos DB collection.

The following diagram illustrates how the Azure Cosmos DB SQL query syntax calls against the collection. The same logic applies to the LINQ query.

Diagram illustrating the scope and meaning of the query used by the NoSQL tutorial to create a C# console application

The FROM keyword in the SQL query is optional, because Azure Cosmos DB queries are already scoped to a single collection. You can swap FROM Families f with FROM root r, or any other variable name you choose. Azure Cosmos DB will infer that Families, root, or the variable name you choose refers to the current collection.

Update a JSON document

Azure Cosmos DB SQL API supports updating and replacing JSON documents.

  1. Copy and paste the following ReplaceFamilyDocument method after the ExecuteSimpleQuery method in your code.

     private async Task ReplaceFamilyDocument(string databaseName, string collectionName, string familyName, Family updatedFamily)
     {
        await client.ReplaceDocumentAsync(UriFactory.CreateDocumentUri(databaseName, collectionName, familyName), updatedFamily);
        WriteToConsoleAndPromptToContinue($"Replaced Family {familyName}");
     }

  2. Copy and paste the following code at the end of your GetStartedDemo method, after the ExecuteSimpleQuery("FamilyDB", "FamilyCollection"); line. The code updates the data in one of the documents, and then runs the query again to show the changed document.

    // Update the Grade of the Andersen Family child
    andersenFamily.Children[0].Grade = 6;
    await ReplaceFamilyDocument("FamilyDB", "FamilyCollection", "AndersenFamily", andersenFamily);
    ExecuteSimpleQuery("FamilyDB", "FamilyCollection");

  3. Press F5 to run your app.

The query output shows that the Grade for the Andersen Family's child updated from 5 to 6. You've successfully updated and replaced an Azure Cosmos DB document.

Delete a JSON document

Azure Cosmos DB SQL API supports deleting JSON documents.

  1. Copy and paste the following DeleteFamilyDocument method after the ReplaceFamilyDocument method.

     private async Task DeleteFamilyDocument(string databaseName, string collectionName, string documentName)
     {
         await client.DeleteDocumentAsync(UriFactory.CreateDocumentUri(databaseName, collectionName, documentName));
         Console.WriteLine($"Deleted Family {documentName}");
     }

  2. Copy and paste the following code at the end of your GetStartedDemo method, after the second ExecuteSimpleQuery("FamilyDB", "FamilyCollection"); line.

    await DeleteFamilyDocument("FamilyDB", "FamilyCollection", "AndersenFamily");

  3. Press F5 to run your app.

You've successfully deleted an Azure Cosmos DB document.

Delete the database

Delete the database you created to remove it and all its child resources, including the collection and documents.

  1. Copy and paste the following code at the end of your GetStartedDemo method, after the await DeleteFamilyDocument("FamilyDB", "FamilyCollection", "AndersenFamily"); line.

    // Clean up - delete the database
    await client.DeleteDatabaseAsync(UriFactory.CreateDatabaseUri("FamilyDB"));

  2. Press F5 to run your app.

You've successfully deleted the Azure Cosmos DB database. You can see in the Data Explorer for your Azure Cosmos DB account that the FamilyDB database is deleted.

Run the entire C# console app

Press F5 in Visual Studio to build and run the complete C# console app in debug mode. You should see the following output in the console window:

Created Family AndersenFamily
Press any key to continue ...
 Created Family WakefieldFamily
Press any key to continue ...
 Running LINQ query...
        Read {"id":"AndersenFamily","LastName":"Andersen","Parents":[{"FamilyName":null,"FirstName":"Thomas"},{"FamilyName":null,"FirstName":"Mary Kay"}],"Children":[{"FamilyName":null,"FirstName":"Henriette Thaulow","Gender":"female","Grade":5,"Pets":[{"GivenName":"Fluffy"}]}],"Address":{"State":"WA","County":"King","City":"Seattle"},"IsRegistered":true}
Running direct SQL query...
        Read {"id":"AndersenFamily","LastName":"Andersen","Parents":[{"FamilyName":null,"FirstName":"Thomas"},{"FamilyName":null,"FirstName":"Mary Kay"}],"Children":[{"FamilyName":null,"FirstName":"Henriette Thaulow","Gender":"female","Grade":5,"Pets":[{"GivenName":"Fluffy"}]}],"Address":{"State":"WA","County":"King","City":"Seattle"},"IsRegistered":true}
Press any key to continue ...
 Replaced Family AndersenFamily
Press any key to continue ...
 Running LINQ query...
        Read {"id":"AndersenFamily","LastName":"Andersen","Parents":[{"FamilyName":null,"FirstName":"Thomas"},{"FamilyName":null,"FirstName":"Mary Kay"}],"Children":[{"FamilyName":null,"FirstName":"Henriette Thaulow","Gender":"female","Grade":6,"Pets":[{"GivenName":"Fluffy"}]}],"Address":{"State":"WA","County":"King","City":"Seattle"},"IsRegistered":true}
Running direct SQL query...
        Read {"id":"AndersenFamily","LastName":"Andersen","Parents":[{"FamilyName":null,"FirstName":"Thomas"},{"FamilyName":null,"FirstName":"Mary Kay"}],"Children":[{"FamilyName":null,"FirstName":"Henriette Thaulow","Gender":"female","Grade":6,"Pets":[{"GivenName":"Fluffy"}]}],"Address":{"State":"WA","County":"King","City":"Seattle"},"IsRegistered":true}
Press any key to continue ...
 Deleted Family AndersenFamily
End of demo, press any key to exit.

Congratulations! You've completed the tutorial, and have a working C# console app that creates, queries, updates, and deletes Azure Cosmos DB resources.

Next steps
