Tutorial: Get started with extending U-SQL with R

The following example illustrates the basic steps for deploying R code:

  • Use the REFERENCE ASSEMBLY statement to enable R extensions for the U-SQL Script.
  • Use theREDUCE operation to partition the input data on a key.
  • The R extensions for U-SQL include a built-in reducer (Extension.R.Reducer) that runs R code on each vertex assigned to the reducer.
  • Usage of dedicated named data frames called inputFromUSQL and outputToUSQLrespectively to pass data between U-SQL and R. Input and output DataFrame identifier names are fixed (that is, users cannot change these predefined names of input and output DataFrame identifiers).

Embedding R code in the U-SQL script

You can inline the R code your U-SQL script by using the command parameter of the Extension.R.Reducer. For example, you can declare the R script as a string variable and pass it as a parameter to the Reducer.

REFERENCE ASSEMBLY [ExtR];

DECLARE @myRScript = @"
inputFromUSQL$Species = as.factor(inputFromUSQL$Species)
lm.fit=lm(unclass(Species)~.-Par, data=inputFromUSQL)
#do not return readonly columns and make sure that the column names are the same in usql and r scripts,
outputToUSQL=data.frame(summary(lm.fit)$coefficients)
colnames(outputToUSQL) <- c(""Estimate"", ""StdError"", ""tValue"", ""Pr"")
outputToUSQL
";

@RScriptOutput = REDUCE … USING new Extension.R.Reducer(command:@myRScript, rReturnType:"dataframe");

Keep the R code in a separate file and reference it the U-SQL script

The following example illustrates a more complex usage. In this case, the R code is deployed as a RESOURCE that is the U-SQL script.

Save this R code as a separate file.

load("my_model_LM_Iris.rda")
outputToUSQL=data.frame(predict(lm.fit, inputFromUSQL, interval="confidence"))

Use a U-SQL script to deploy that R script with the DEPLOY RESOURCE statement.

REFERENCE ASSEMBLY [ExtR];

DEPLOY RESOURCE @"/usqlext/samples/R/RinUSQL_PredictUsingLinearModelasDF.R";
DEPLOY RESOURCE @"/usqlext/samples/R/my_model_LM_Iris.rda";
DECLARE @IrisData string = @"/usqlext/samples/R/iris.csv";
DECLARE @OutputFilePredictions string = @"/my/R/Output/LMPredictionsIris.txt";
DECLARE @PartitionCount int = 10;

@InputData =
    EXTRACT
        SepalLength double,
        SepalWidth double,
        PetalLength double,
        PetalWidth double,
        Species string
    FROM @IrisData
    USING Extractors.Csv();

@ExtendedData =
    SELECT
        Extension.R.RandomNumberGenerator.GetRandomNumber(@PartitionCount) AS Par,
        SepalLength,
        SepalWidth,
        PetalLength,
        PetalWidth
    FROM @InputData;

// Predict Species

@RScriptOutput = REDUCE @ExtendedData ON Par
    PRODUCE Par, fit double, lwr double, upr double
    READONLY Par
    USING new Extension.R.Reducer(scriptFile:"RinUSQL_PredictUsingLinearModelasDF.R", rReturnType:"dataframe", stringsAsFactors:false);
    OUTPUT @RScriptOutput TO @OutputFilePredictions USING Outputters.Tsv();

How R Integrates with U-SQL

Datatypes

  • String and numeric columns from U-SQL are converted as-is between R DataFrame and U-SQL [supported types: double, string, bool, integer, byte].
  • The Factor datatype is not supported in U-SQL.
  • byte[] must be serialized as a base64-encoded string.
  • U-SQL strings can be converted to factors in R code, once U-SQL create R input dataframe or by setting the reducer parameter stringsAsFactors: true.

Schemas

  • U-SQL datasets cannot have duplicate column names.
  • U-SQL datasets column names must be strings.
  • Column names must be the same in U-SQL and R scripts.
  • Readonly column cannot be part of the output dataframe. Because readonly columns are automatically injected back in the U-SQL table if it is a part of output schema of UDO.

Functional limitations

  • The R Engine can't be instantiated twice in the same process.
  • Currently, U-SQL does not support Combiner UDOs for prediction using partitioned models generated using Reducer UDOs. Users can declare the partitioned models as resource and use them in their R Script (see sample code ExtR_PredictUsingLMRawStringReducer.usql)

R Versions

Only R 3.2.2 is supported.

Standard R modules

base
boot
Class
Cluster
codetools
compiler
datasets
doParallel
doRSR
foreach
foreign
Graphics
grDevices
grid
iterators
KernSmooth
lattice
MASS
Matrix
Methods
mgcv
nlme
Nnet
Parallel
pkgXMLBuilder
RevoIOQ
revoIpe
RevoMods
RevoPemaR
RevoRpeConnector
RevoRsrConnector
RevoScaleR
RevoTreeView
RevoUtils
RevoUtilsMath
Rpart
RUnit
spatial
splines
Stats
stats4
survival
Tcltk
Tools
translations
utils
XML

Input and Output size limitations

Every vertex has a limited amount of memory assigned to it. Because the input and output DataFrames must exist in memory in the R code, the total size for the input and output cannot exceed 500 MB.

Sample Code

More sample code is available in your Data Lake Store account after you install the U-SQL Advanced Analytics extensions. The path for more sample code is: <your_account_address>/usqlext/samples/R.

Deploying Custom R modules with U-SQL

First, create an R custom module and zip it and then upload the zipped R custom module file to your ADL store. In the example, we will upload magittr_1.5.zip to the root of the default ADLS account for the ADLA account we are using. Once you upload the module to ADL store, declare it as use DEPLOY RESOURCE to make it available in your U-SQL script and call install.packages to install it.

REFERENCE ASSEMBLY [ExtR];
DEPLOY RESOURCE @"/magrittr_1.5.zip";

DECLARE @IrisData string =  @"/usqlext/samples/R/iris.csv";
DECLARE @OutputFileModelSummary string = @"/R/Output/CustomePackages.txt";

// R script to run
DECLARE @myRScript = @"
# install the magrittr package,
install.packages('magrittr_1.5.zip', repos = NULL),
# load the magrittr package,
require(magrittr),
# demonstrate use of the magrittr package,
2 %>% sqrt
";

@InputData =
EXTRACT SepalLength double,
SepalWidth double,
PetalLength double,
PetalWidth double,
Species string
FROM @IrisData
USING Extractors.Csv();

@ExtendedData =
SELECT 0 AS Par,
*
FROM @InputData;

@RScriptOutput = REDUCE @ExtendedData ON Par
PRODUCE Par, RowId int, ROutput string
READONLY Par
USING new Extension.R.Reducer(command:@myRScript, rReturnType:"charactermatrix");

OUTPUT @RScriptOutput TO @OutputFileModelSummary USING Outputters.Tsv();
