Upload files from your device to the cloud with IoT Hub (.NET)

This tutorial shows you how to use the file upload feature of IoT Hub with the Azure IoT .NET device and service SDKs.

The Send telemetry from a device to an IoT hub quickstart and Send cloud-to-device messages with IoT Hub tutorial show the basic device-to-cloud and cloud-to-device messaging functionality of IoT Hub. The Configure Message Routing with IoT Hub tutorial describes a way to reliably store device-to-cloud messages in Microsoft Azure blob storage. However, in some scenarios you can't easily map the data your devices send into the relatively small device-to-cloud messages that IoT Hub accepts. For example:

  • Large files that contain images

  • Videos

  • Vibration data sampled at high frequency

  • Some form of preprocessed data

These files are typically batch processed in the cloud using tools such as Azure Data Factory or the Hadoop stack. When you need to upload files from a device, however, you can still use the security and reliability of IoT Hub. This tutorial shows you how.

At the end of this tutorial you run two .NET console apps:

  • FileUploadSample. This device app uploads a file to storage using a SAS URI provided by your IoT hub. You'll run this app from the Azure IoT C# samples repository that you download in the prerequisites.

  • ReadFileUploadNotification. This service app receives file upload notifications from your IoT hub. You'll create this app.

Note

IoT Hub supports many device platforms and languages, including C, Java, Python, and JavaScript, through Azure IoT device SDKs. Refer to the Azure IoT Developer Center for step-by-step instructions on how to connect your device to Azure IoT Hub.

Important

File upload functionality on devices that use X.509 certificate authority (CA) authentication is in public preview, and preview mode must be enabled. It is generally available on devices that use X.509 thumbprint authentication or X.509 certificate attestation with Azure Device Provisioning Service. To learn more about X.509 authentication with IoT Hub, see Supported X.509 certificates.

Prerequisites

  • An active Azure account. If you don't have an account, you can create a free account in just a couple of minutes.

  • The sample applications you run in this article are written using C#. For the Azure IoT C# samples, we recommend you have the .NET Core SDK 3.1 or greater on your development machine.

    You can download the .NET Core SDK for multiple platforms from .NET.

    You can verify the current version of the .NET Core SDK on your development machine using the following command:

    dotnet --version

  • Download the Azure IoT C# samples from https://github.com/Azure-Samples/azure-iot-samples-csharp/archive/main.zip and extract the ZIP archive.

  • Make sure that port 8883 is open in your firewall. The sample in this article uses MQTT protocol, which communicates over port 8883. This port may be blocked in some corporate and educational network environments. For more information and ways to work around this issue, see Connecting to IoT Hub (MQTT).

Create an IoT hub

This section describes how to create an IoT hub using the Azure portal.

  1. Sign in to the Azure portal.

  2. From the Azure homepage, select the + Create a resource button, and then enter IoT Hub in the Search the Marketplace field.

  3. Select IoT Hub from the search results, and then select Create.

  4. On the Basics tab, complete the fields as follows:

    • Subscription: Select the subscription to use for your hub.

    • Resource Group: Select a resource group or create a new one. To create a new one, select Create new and fill in the name you want to use. To use an existing resource group, select that resource group. For more information, see Manage Azure Resource Manager resource groups.

    • Region: Select the region in which you want your hub to be located. Select the location closest to you. Some features, such as IoT Hub device streams, are only available in specific regions. For these limited features, you must select one of the supported regions.

    • IoT Hub Name: Enter a name for your hub. This name must be globally unique, with a length between 3 and 50 alphanumeric characters. The name can also include the dash ('-') character.

    Important

    Because the IoT hub will be publicly discoverable as a DNS endpoint, be sure to avoid entering any sensitive or personally identifiable information when you name it.

    Create a hub in the Azure portal.

  5. Select Next: Networking to continue creating your hub.

    Choose the endpoints that devices can use to connect to your IoT Hub. You can select the default setting Public endpoint (all networks), or choose Public endpoint (selected IP ranges), or Private endpoint. Accept the default setting for this example.

    Choose the endpoints that can connect.

  6. Select Next: Management to continue creating your hub.

    Set the size and scale for a new hub using the Azure portal.

    You can accept the default settings here. If desired, you can modify any of the following fields:

    • Pricing and scale tier: Your selected tier. You can choose from several tiers, depending on how many features you want and how many messages you send through your solution per day. The free tier is intended for testing and evaluation. It allows 500 devices to be connected to the hub and up to 8,000 messages per day. Each Azure subscription can create one IoT hub in the free tier.

      If you are working through a Quickstart for IoT Hub device streams, select the free tier.

    • IoT Hub units: The number of messages allowed per unit per day depends on your hub's pricing tier. For example, if you want the hub to support ingress of 700,000 messages, you choose two S1 tier units. For details about the other tier options, see Choosing the right IoT Hub tier.

    • Microsoft Defender for IoT: Turn this on to add an extra layer of threat protection to IoT and your devices. This option is not available for hubs in the free tier. Learn more about security recommendations for IoT Hub in Defender for IoT.

    • Advanced Settings > Device-to-cloud partitions: This property relates the device-to-cloud messages to the number of simultaneous readers of the messages. Most hubs need only four partitions.

  7. Select Next: Tags to continue to the next screen.

    Tags are name/value pairs. You can assign the same tag to multiple resources and resource groups to categorize resources and consolidate billing. In this document, you won't be adding any tags. For more information, see Use tags to organize your Azure resources.

    Assign tags for the hub using the Azure portal.

  8. Select Next: Review + create to review your choices. You see something similar to this screen, but with the values you selected when creating the hub.

    Review information for creating the new hub.

  9. Select Create to start the deployment of your new hub. Your deployment will be in progress a few minutes while the hub is being created. Once the deployment is complete, select Go to resource to open the new hub.

Register a new device in the IoT hub

In this section, you create a device identity in the identity registry in your IoT hub. A device cannot connect to a hub unless it has an entry in the identity registry. For more information, see the IoT Hub developer guide.

  1. In your IoT hub navigation menu, open Devices, then select Add Device to add a device in your IoT hub.

    Screen capture that shows how to create a device identity in the portal

  2. In Create a device, provide a name for your new device, such as myDeviceId, and select Save. This action creates a device identity for your IoT hub. Leave Auto-generate keys checked so that the primary and secondary keys will be generated automatically.

    Screen capture that shows how to add a new device

    Important

    The device ID may be visible in the logs collected for customer support and troubleshooting, so make sure to avoid any sensitive information while naming it.

  3. After the device is created, open the device from the list in the Devices pane. Copy the Primary Connection String. This connection string is used by device code to communicate with the hub.

    By default, the keys and connection strings are masked as they are sensitive information. If you click the eye icon, they are revealed. It is not necessary to reveal them to copy them with the copy button.

    Screen capture that shows the device connection string

Note

The IoT Hub identity registry only stores device identities to enable secure access to the IoT hub. It stores device IDs and keys to use as security credentials, and an enabled/disabled flag that you can use to disable access for an individual device. If your application needs to store other device-specific metadata, it should use an application-specific store. For more information, see IoT Hub developer guide.

Associate an Azure Storage account to IoT Hub

To upload files from a device, you must have an Azure Storage account and Azure Blob Storage container associated with your IoT hub. Once you associate the storage account and container with your IoT hub, your IoT hub can provide the elements of a SAS URI when requested by a device. The device can then use these elements to construct the SAS URI that it uses to authenticate with Azure Storage and upload files to the blob container.

To associate an Azure Storage account with your IoT hub:

  1. Under Hub settings, select File upload on the left-pane of your IoT hub.

    Screen capture showing select file upload settings from the portal.

  2. On the File upload pane, select Azure Storage Container. For this article, it's recommended that your storage account and IoT Hub be located in the same region.

    • If you already have a storage account you want to use, select it from the list.

    • To create a new storage account, select +Storage account. Provide a name for the storage account and make sure the Location is set to the same region as your IoT hub, then select OK. The new account is created in the same resource group as your IoT hub. When the deployment completes, select the storage account from the list.

    After you select the storage account, the Containers pane opens.

  3. On the Containers pane, select the blob container.

    • If you already have a blob container you want to use, select it from the list and click Select.

    • To create a new blob container, select + Container. Provide a name for the new container. For the purposes of this article, you can leave all other fields at their default. Select Create. When the deployment completes, select the container from the list and click Select.

  4. Back on the File upload pane, make sure that file notifications are set to On. You can leave all other settings at their defaults. Select Save and wait for the settings to complete before moving on to the next section.

    Screen capture showing confirm file upload settings in the portal.

For more detailed instructions on how to create an Azure Storage account, see Create a storage account. For more detailed instructions on how to associate a storage account and blob container with an IoT hub, see Configure file uploads using the Azure portal.

Upload file from a device app

In this article, you'll use a sample from the Azure IoT C# samples repository you downloaded earlier as the device app. You can open the files below using Visual Studio, Visual Studio Code, or a text editor of your choice.

The sample is located in the azure-iot-samples-csharp-main\iot-hub\Samples\device\FileUploadSample under the folder where you extracted the Azure IoT C# samples.

Examine the code in FileUpLoadSample.cs. This file contains the main sample logic. After creating an IoT Hub device client, it follows the standard three-part procedure for uploading files from a device:

  1. The code calls the GetFileUploadSasUriAsync method on the device client to get a SAS URI from the IoT hub:

    var fileUploadSasUriRequest = new FileUploadSasUriRequest
    {
        BlobName = fileName
    };

    // Lines removed for clarity

    FileUploadSasUriResponse sasUri = await _deviceClient.GetFileUploadSasUriAsync(fileUploadSasUriRequest);
    Uri uploadUri = sasUri.GetBlobUri();

  2. The code uses the SAS URI to upload the file to Azure storage. In this sample, it uses the SAS URI to create an Azure storage block blob client and uploads the file:

    var blockBlobClient = new BlockBlobClient(uploadUri);
    await blockBlobClient.UploadAsync(fileStreamSource, new BlobUploadOptions());

  3. The code notifies the IoT hub that it has completed the upload. This tells the IoT hub that it can release resources associated with the upload (the SAS URI). If file upload notifications are enabled, the IoT hub will send a notification message to backend services.

    var successfulFileUploadCompletionNotification = new FileUploadCompletionNotification
    {
        // Mandatory. Must be the same value as the correlation id returned in the sas uri response
        CorrelationId = sasUri.CorrelationId,

        // Mandatory. Will be present when service client receives this file upload notification
        IsSuccess = true,

        // Optional, user defined status code. Will be present when service client receives this file upload notification
        StatusCode = 200,

        // Optional, user-defined status description. Will be present when service client receives this file upload notification
        StatusDescription = "Success"
    };

    await _deviceClient.CompleteFileUploadAsync(successfulFileUploadCompletionNotification);


If you examine the parameter.cs file, you'll see that:

  • The sample requires you to pass a parameter, p, which takes a device connection string.

  • By default, the device sample uses the MQTT protocol to communicate with IoT Hub. You can use the parameter t to change this transport protocol. Be aware that, regardless of this selection, the Azure blob client always uses HTTPS as the protocol to upload the file Azure storage.

Get the IoT hub connection string

In this article, you create a backend service to receive file upload notification messages from your IoT hub. To receive file upload notification messages, your service needs the service connect permission. By default, every IoT Hub is created with a shared access policy named service that grants this permission.

To get the IoT Hub connection string for the service policy, follow these steps:

  1. In the Azure portal, select Resource groups. Select the resource group where your hub is located, and then select your hub from the list of resources.

  2. On the left-side pane of your IoT hub, select Shared access policies.

  3. From the list of policies, select the service policy.

  4. Under Shared access keys, select the copy icon for the Primary connection string and save the value.

Screenshot that shows how to retrieve the connection string

For more information about IoT Hub shared access policies and permissions, see Access control and permissions.

Receive a file upload notification

In this section, you create a C# console app that receives file upload notification messages from your IoT hub.

  1. Open a command window and go to the folder where you want to create the project. Create a folder named ReadFileUploadNotifications and change directories to that folder.

    mkdir ReadFileUploadNotification
    cd ReadFileUploadNotification

  2. Run the following command to create a C# console project. After running the command, the folder will contain a Program.cs file and a ReadFileUploadNotification.csproj file.

    dotnet new console --language c#

  3. Run the following command to add the Microsoft.Azure.Devices package to the project file. This package is the Azure IoT .NET service SDK.

    dotnet add package Microsoft.Azure.Devices

  4. Open the Program.cs file and add the following statement at the top of the file:

    using Microsoft.Azure.Devices;

  5. Add the following fields to the Program class. Replace the {iot hub connection string} placeholder value with the IoT hub connection string that you copied previously in Get the IoT hub connection string:

    static ServiceClient serviceClient;
    static string connectionString = "{iot hub connection string}";

  6. Add the following method to the Program class:

    private async static void ReceiveFileUploadNotificationAsync()
    {
        var notificationReceiver = serviceClient.GetFileNotificationReceiver();
        Console.WriteLine("\nReceiving file upload notification from service");
        while (true)
        {
            var fileUploadNotification = await notificationReceiver.ReceiveAsync();
            if (fileUploadNotification == null) continue;
            Console.ForegroundColor = ConsoleColor.Yellow;
            Console.WriteLine("Received file upload notification: {0}",
              string.Join(", ", fileUploadNotification.BlobName));
            Console.ResetColor();
            await notificationReceiver.CompleteAsync(fileUploadNotification);
        }
    }


    Note this receive pattern is the same one used to receive cloud-to-device messages from the device app.

  7. Finally, replace the lines in the Main method with the following:

    Console.WriteLine("Receive file upload notifications\n");
    serviceClient = ServiceClient.CreateFromConnectionString(connectionString);
    ReceiveFileUploadNotificationAsync();
    Console.WriteLine("Press Enter to exit\n");
    Console.ReadLine();


Run the applications

Now you're ready to run the applications.

  1. First, run the service app to receive file upload notifications from the IoT hub. At your command prompt in the ReadFileUploadNotification folder, run the following commands:

    dotnet restore
    dotnet run


    The app starts and waits for a file upload notification from your IoT hub:

    Receive file upload notifications


    Receiving file upload notification from service
    Press Enter to exit

  2. Next, run the device app to upload the file to Azure storage. Open a new command prompt and change folders to the azure-iot-samples-csharp-main\iot-hub\Samples\device\FileUploadSample under the folder where you expanded the Azure IoT C# samples. Run the following commands. Replace the {Your device connection string} placeholder value in the second command with the device connection string you copied previously in Register a new device in the IoT hub.

    dotnet restore
    dotnet run --p "{Your device connection string}"


    The following output is from the device app after the upload has completed:

      Uploading file TestPayload.txt
      Getting SAS URI from IoT Hub to use when uploading the file...
      Successfully got SAS URI (https://contosostorage.blob.core.windows.net/contosocontainer/MyDevice%2FTestPayload.txt?sv=2018-03-28&sr=b&sig=x0G1Baf%2BAjR%2BTg3nW34zDNKs07p6dLzkxvZ3ZSmjIhw%3D&se=2021-05-04T16%3A40%3A52Z&sp=rw) from IoT Hub
      Uploading file TestPayload.txt using the Azure Storage SDK and the retrieved SAS URI for authentication
      Successfully uploaded the file to Azure Storage
      Notified IoT Hub that the file upload succeeded and that the SAS URI can be freed.
      Time to upload file: 00:00:01.5077954.
      Done.

  3. Notice that the service app shows that it has received the file upload notification:

    Receive file upload notifications


    Receiving file upload notification from service
    Press Enter to exit

    Received file upload notification: myDeviceId/TestPayload.txt


Verify the file upload

You can use the portal to view the uploaded file in the storage container you configured:

  1. Navigate to your storage account in Azure portal.

  2. On the left pane of your storage account, select Containers.

  3. Select the container you uploaded the file to.

  4. Select the folder named after your device.

  5. Select the blob that you uploaded your file to. In this article, it's the blob named TestPayload.txt.

    Screenshot of selecting the uploaded file in the Azure portal.

  6. View the blob properties on the page that opens. You can select Download to download the file and view its contents locally.

Next steps

In this tutorial, you learned how to use the file upload feature of IoT Hub to simplify file uploads from devices. You can continue to explore this feature with the following articles:
