Limits, quotas, and throttle thresholds in Azure Scheduler

Important

Azure Logic Apps is replacing Azure Scheduler, which is being retired. To schedule jobs, try Azure Logic Apps instead.

Limits, quotas, and thresholds

The following table describes each of the major quotas, limits, defaults, and throttles in Azure Scheduler.

Resource Limit Description
Job size The maximum job size is 16K. If a PUT or a PATCH operation results in a job size larger than this limit, a 400 Bad Request status code is returned.
Job collections The maximum number of job collections per Azure subscription is 200,000.
Jobs per collection By default, the maximum number of jobs is five jobs in a free job collection and 50 jobs in a standard job collection.

You can change the maximum number of jobs on a job collection. All jobs in a job collection are limited to the value set on the job collection. If you attempt to create more jobs than the maximum jobs quota, the request fails with a 409 Conflict status code.

Time to start time The maximum "time to start time" is 18 months.
Recurrence span The maximum recurrence span is 18 months.
Frequency By default, the maximum frequency quota is one hour in a free job collection and one minute in a standard job collection.

You can make the maximum frequency on a job collection lower than the maximum. All jobs in the job collection are limited to the value set on the job collection. If you attempt to create a job with a higher frequency than the maximum frequency on the job collection, the request fails with a 409 Conflict status code.

Body size The maximum body size for a request is 8192 chars.
Request URL size The maximum size for a request URL is 2048 chars.
Header count The maximum header count is 50 headers.
Aggregate header size The maximum aggregate header size is 4096 chars.
Timeout The request timeout is static (not configurable) and is 60 seconds for HTTP actions. For longer running operations, follow the HTTP asynchronous protocols. For example, return a 202 immediately but continue working in the background.
Job history The maximum response body stored in job history is 2048 bytes.
Job history retention Job history is kept for up to 2 months or up to the last 1000 executions.
Completed and faulted job retention Completed and faulted jobs are kept for 60 days.

x-ms-request-id header

Every request made against the Scheduler service returns a response header named x-ms-request-id. This header contains an opaque value that uniquely identifies the request. So, if a request consistently fails, and you confirmed the request is properly formatted, you can report the error to Microsoft by providing the x-ms-request-id response header value and including these details:

  • The x-ms-request-id value
  • The approximate time when the request was made
  • The identifiers for the Azure subscription, job collection, and job
  • The type of operation that the request attempted

See also
