Scheduler Outbound Authentication

5 minutes to read Contributors
  • Derek Li
  • Kris Ragh
  • krisragh
  • Jared Moore

Scheduler jobs may need to call out to services that require authentication. This way, a called service can determine if the Scheduler job can access its resources. Some of these services include other Azure services, Salesforce.com, Facebook, and secure custom websites.

Adding and Removing Authentication

Adding authentication to a Scheduler job is simple – add a JSON child element authentication to the request element when creating or updating a job. Secrets passed to the Scheduler service in a PUT, PATCH, or POST request – as part of the authentication object – are never returned in responses. In responses, secret information is set to null or may have a public token that represents the authenticated entity.

To remove authentication, PUT or PATCH the job explicitly, setting the authentication object to null. You will not see any authentication properties back in response.

Currently, the only supported authentication types are the ClientCertificate model (for using the SSL/TLS client certificates), the Basic model (for Basic authentication), and the ActiveDirectoryOAuth model (for Active Directory OAuth authentication.)

Request Body for ClientCertificate Authentication

When adding authentication using the ClientCertificate model, specify the following additional elements in the request body.

Element Description
authentication (parent element) Authentication object for using an SSL client certificate.
type Required. Type of authentication.For SSL client certificates, the value must be ClientCertificate.
pfx Required. Base64-encoded contents of the PFX file.
password Required. Password to access the PFX file.

Response Body for ClientCertificate Authentication

When a request is sent with authentication info, the response contains the following authentication-related elements.

Element Description
authentication (parent element) Authentication object for using an SSL client certificate.
type Type of authentication. For SSL client certificates, the value is ClientCertificate.
certificateThumbprint The thumbprint of the certificate.
certificateSubjectName The subject distinguished name of the certificate.
certificateExpiration The expiration date of the certificate.

Sample REST Request for ClientCertificate Authentication

PUT https://management.azure.com/subscriptions/1fe0abdf-581e-4dfe-9ec7-e5cb8e7b205e/resourceGroups/CS-SoutheastAsia-scheduler/providers/Microsoft.Scheduler/jobcollections/southeastasiajc/jobs/httpjob?api-version=2016-01-01 HTTP/1.1
User-Agent: Fiddler
Host: management.azure.com
Authorization: Bearer sometoken
Content-Type: application/json; charset=utf-8

{
  "properties": {
    "startTime": "2015-05-14T14:10:00Z",
    "action": {
      "request": {
        "uri": "https://mywebserviceendpoint.com",
        "method": "GET",
        "headers": {
          "x-ms-version": "2013-03-01"
        },
        "authentication": {
          "type": "clientcertificate",
          "password": "password",
          "pfx": "pfx key"
        }
      },
      "type": "http"
    },
    "recurrence": {
      "frequency": "minute",
      "endTime": "2016-04-10T08:00:00Z",
      "interval": 1
    },
    "state": "enabled",
  }
}

Sample REST Response for ClientCertificate Authentication

HTTP/1.1 200 OK
Cache-Control: no-cache
Pragma: no-cache
Content-Length: 858
Content-Type: application/json; charset=utf-8
Expires: -1
x-ms-request-id: 56c7b40e-721a-437e-88e6-f68562a73aa8
Server: Microsoft-IIS/8.5
X-AspNet-Version: 4.0.30319
X-Powered-By: ASP.NET
x-ms-ratelimit-remaining-subscription-resource-requests: 599
x-ms-correlation-request-id: 1075219e-e879-4030-bc81-094e54fbabce
x-ms-routing-request-id: WESTUS:20160316T190424Z:1075219e-e879-4030-bc81-094e54fbabce
Strict-Transport-Security: max-age=31536000; includeSubDomains
Date: Wed, 16 Mar 2016 19:04:23 GMT

{
  "id": "/subscriptions/1fe0abdf-581e-4dfe-9ec7-e5cb8e7b205e/resourceGroups/CS-SoutheastAsia-scheduler/providers/Microsoft.Scheduler/jobCollections/southeastasiajc/jobs/httpjob",
  "type": "Microsoft.Scheduler/jobCollections/jobs",
  "name": "southeastasiajc/httpjob",
  "properties": {
    "startTime": "2015-05-14T14:10:00Z",
    "action": {
      "request": {
        "uri": "https://mywebserviceendpoint.com",
        "method": "GET",
        "headers": {
          "x-ms-version": "2013-03-01"
        },
        "authentication": {
          "certificateThumbprint": "88105CG9DF9ADE75B835711D899296CB217D7055",
          "certificateExpiration": "2021-01-01T07:00:00Z",
          "certificateSubjectName": "CN=Scheduler Mgmt",
          "type": "ClientCertificate"
        }
      },
      "type": "http"
    },
    "recurrence": {
      "frequency": "minute",
      "endTime": "2016-04-10T08:00:00Z",
      "interval": 1
    },
    "state": "enabled",
    "status": {
      "nextExecutionTime": "2016-03-16T19:05:00Z",
      "executionCount": 0,
      "failureCount": 0,
      "faultedCount": 0
    }
  }
}

Request Body for Basic Authentication

When adding authentication using the Basic model, specify the following additional elements in the request body.

Element Description
authentication (parent element) Authentication object for using Basic authentication.
type Required. Type of authentication. For Basic authentication, the value must be Basic.
username Required. Username to authenticate.
password Required. Password to authenticate.

Response Body for Basic Authentication

When a request is sent with authentication info, the response contains the following authentication-related elements.

Element Description
authentication (parent element) Authentication object for using Basic authentication.
type Type of authentication. For Basic authentication, the value is Basic.
username The authenticated username.

Sample REST Request for Basic Authentication

PUT https://management.azure.com/subscriptions/1d908808-e491-4fe5-b97e-29886e18efd4/resourceGroups/CS-SoutheastAsia-scheduler/providers/Microsoft.Scheduler/jobcollections/southeastasiajc/jobs/httpjob?api-version=2016-01-01 HTTP/1.1
User-Agent: Fiddler
Host: management.azure.com
Authorization: Bearer sometoken
Content-Length: 562
Content-Type: application/json; charset=utf-8

{
  "properties": {
    "startTime": "2015-05-14T14:10:00Z",
    "action": {
      "request": {
        "uri": "https://mywebserviceendpoint.com",
        "method": "GET",
        "headers": {
          "x-ms-version": "2013-03-01"
        },
        "authentication": {
          "type": "basic",
          "username": "user",
          "password": "password"
        }
      },
      "type": "http"
    },
    "recurrence": {
      "frequency": "minute",
      "endTime": "2016-04-10T08:00:00Z",
      "interval": 1
    },
    "state": "enabled",
  }
}

Sample REST Response for Basic Authentication

HTTP/1.1 200 OK
Cache-Control: no-cache
Pragma: no-cache
Content-Length: 701
Content-Type: application/json; charset=utf-8
Expires: -1
x-ms-request-id: a2dcb9cd-1aea-4887-8893-d81273a8cf04
Server: Microsoft-IIS/8.5
X-AspNet-Version: 4.0.30319
X-Powered-By: ASP.NET
x-ms-ratelimit-remaining-subscription-resource-requests: 599
x-ms-correlation-request-id: 7816f222-6ea7-468d-b919-e6ddebbd7e95
x-ms-routing-request-id: WESTUS:20160316T190506Z:7816f222-6ea7-468d-b919-e6ddebbd7e95
Strict-Transport-Security: max-age=31536000; includeSubDomains
Date: Wed, 16 Mar 2016 19:05:06 GMT

{
   "id":"/subscriptions/1d908808-e491-4fe5-b97e-29886e18efd4/resourceGroups/CS-SoutheastAsia-scheduler/providers/Microsoft.Scheduler/jobCollections/southeastasiajc/jobs/httpjob",
   "type":"Microsoft.Scheduler/jobCollections/jobs",
   "name":"southeastasiajc/httpjob",
   "properties":{
      "startTime":"2015-05-14T14:10:00Z",
      "action":{
         "request":{
            "uri":"https://mywebserviceendpoint.com",
            "method":"GET",
            "headers":{
               "x-ms-version":"2013-03-01"
            },
            "authentication":{
               "username":"user1",
               "type":"Basic"
            }
         },
         "type":"http"
      },
      "recurrence":{
         "frequency":"minute",
         "endTime":"2016-04-10T08:00:00Z",
         "interval":1
      },
      "state":"enabled",
      "status":{
         "nextExecutionTime":"2016-03-16T19:06:00Z",
         "executionCount":0,
         "failureCount":0,
         "faultedCount":0
      }
   }
}

Request Body for ActiveDirectoryOAuth Authentication

When adding authentication using the ActiveDirectoryOAuth model, specify the following additional elements in the request body.

Element Description
authentication (parent element) Authentication object for using ActiveDirectoryOAuth authentication.
type Required. Type of authentication. For ActiveDirectoryOAuth authentication, the value must be ActiveDirectoryOAuth.
tenant Required. The tenant identifier for the Azure AD tenant.
audience Required. This is set to https://management.core.windows.net/.
clientId Required. Provide the client identifier for the Azure AD application.
secret Required. Secret of the client that is requesting the token.

Determining your Tenant Identifier

You can find the tenant identifier for the Azure AD tenant by running Get-AzureAccount in Azure PowerShell.

Response Body for ActiveDirectoryOAuth Authentication

When a request is sent with authentication info, the response contains the following authentication-related elements.

Element Description
authentication (parent element) Authentication object for using ActiveDirectoryOAuth authentication.
type Type of authentication. For ActiveDirectoryOAuth authentication, the value is ActiveDirectoryOAuth.
tenant The tenant identifier for the Azure AD tenant.
audience This is set to https://management.core.windows.net/.
clientId The client identifier for the Azure AD application.

Sample REST Request for ActiveDirectoryOAuth Authentication

PUT https://management.azure.com/subscriptions/1d908808-e491-4fe5-b97e-29886e18efd4/resourceGroups/CS-SoutheastAsia-scheduler/providers/Microsoft.Scheduler/jobcollections/southeastasiajc/jobs/httpjob?api-version=2016-01-01 HTTP/1.1
User-Agent: Fiddler
Host: management.azure.com
Authorization: Bearer sometoken
Content-Length: 757
Content-Type: application/json; charset=utf-8

{
  "properties": {
    "startTime": "2015-05-14T14:10:00Z",
    "action": {
      "request": {
        "uri": "https://mywebserviceendpoint.com",
        "method": "GET",
        "headers": {
          "x-ms-version": "2013-03-01"
        },
        "authentication": {
          "tenant":"microsoft.onmicrosoft.com",
          "audience":"https://management.core.windows.net/",
          "clientId":"dc23e764-9be6-4a33-9b9a-c46e36f0c137",
          "secret": "G6u071r8Gjw4V4KSibnb+VK4+tX399hkHaj7LOyHuj5=",
          "type":"ActiveDirectoryOAuth"
        }
      },
      "type": "http"
    },
    "recurrence": {
      "frequency": "minute",
      "endTime": "2016-04-10T08:00:00Z",
      "interval": 1
    },
    "state": "enabled",
  }
}

Sample REST Response for ActiveDirectoryOAuth Authentication

HTTP/1.1 200 OK
Cache-Control: no-cache
Pragma: no-cache
Content-Length: 885
Content-Type: application/json; charset=utf-8
Expires: -1
x-ms-request-id: 86d8e9fd-ac0d-4bed-9420-9baba1af3251
Server: Microsoft-IIS/8.5
X-AspNet-Version: 4.0.30319
X-Powered-By: ASP.NET
x-ms-ratelimit-remaining-subscription-resource-requests: 599
x-ms-correlation-request-id: 5183bbf4-9fa1-44bb-98c6-6872e3f2e7ce
x-ms-routing-request-id: WESTUS:20160316T191003Z:5183bbf4-9fa1-44bb-98c6-6872e3f2e7ce
Strict-Transport-Security: max-age=31536000; includeSubDomains
Date: Wed, 16 Mar 2016 19:10:02 GMT

{
   "id":"/subscriptions/1d908808-e491-4fe5-b97e-29886e18efd4/resourceGroups/CS-SoutheastAsia-scheduler/providers/Microsoft.Scheduler/jobCollections/southeastasiajc/jobs/httpjob",
   "type":"Microsoft.Scheduler/jobCollections/jobs",
   "name":"southeastasiajc/httpjob",
   "properties":{
      "startTime":"2015-05-14T14:10:00Z",
      "action":{
         "request":{
            "uri":"https://mywebserviceendpoint.com",
            "method":"GET",
            "headers":{
               "x-ms-version":"2013-03-01"
            },
            "authentication":{
               "tenant":"microsoft.onmicrosoft.com",
               "audience":"https://management.core.windows.net/",
               "clientId":"dc23e764-9be6-4a33-9b9a-c46e36f0c137",
               "type":"ActiveDirectoryOAuth"
            }
         },
         "type":"http"
      },
      "recurrence":{
         "frequency":"minute",
         "endTime":"2016-04-10T08:00:00Z",
         "interval":1
      },
      "state":"enabled",
      "status":{
         "lastExecutionTime":"2016-03-16T19:10:00.3762123Z",
         "nextExecutionTime":"2016-03-16T19:11:00Z",
         "executionCount":5,
         "failureCount":5,
         "faultedCount":1
      }
   }
}
