Azure Service Bus Geo-disaster recovery
When entire Azure regions or datacenters (if no availability zones are used) experience downtime, it is critical for data processing to continue to operate in a different region or datacenter. As such, Geo-disaster recovery is an important feature for any enterprise. Azure Service Bus supports geo-disaster recovery at the namespace level.
The Geo-disaster recovery feature is globally available for the Service Bus Premium SKU.
Geo-Disaster recovery currently only ensures that the metadata (Queues, Topics, Subscriptions, Filters) are copied over from the primary namespace to secondary namespace when paired.
Outages and disasters
It's important to note the distinction between "outages" and "disasters."
An outage is the temporary unavailability of Azure Service Bus, and can affect some components of the service, such as a messaging store, or even the entire datacenter. However, after the problem is fixed, Service Bus becomes available again. Typically, an outage does not cause the loss of messages or other data. An example of such an outage might be a power failure in the datacenter. Some outages are only short connection losses due to transient or network issues.
A disaster is defined as the permanent, or longer-term loss of a Service Bus cluster, Azure region, or datacenter. The region or datacenter may or may not become available again, or may be down for hours or days. Examples of such disasters are fire, flooding, or earthquake. A disaster that becomes permanent might cause the loss of some messages, events, or other data. However, in most cases there should be no data loss and messages can be recovered once the data center is back up.
The Geo-disaster recovery feature of Azure Service Bus is a disaster recovery solution. The concepts and workflow described in this article apply to disaster scenarios, and not to transient, or temporary outages. For a detailed discussion of disaster recovery in Microsoft Azure, see this article.
Basic concepts and terms
The disaster recovery feature implements metadata disaster recovery, and relies on primary and secondary disaster recovery namespaces. Note that the Geo-disaster recovery feature is available for the Premium SKU only. You do not need to make any connection string changes, as the connection is made via an alias.
The following terms are used in this article:
Alias: The name for a disaster recovery configuration that you set up. The alias provides a single stable Fully Qualified Domain Name (FQDN) connection string. Applications use this alias connection string to connect to a namespace. Using an alias ensures that the connection string is unchanged when the failover is triggered.
Primary/secondary namespace: The namespaces that correspond to the alias. The primary namespace is "active" and receives messages (this can be an existing or new namespace). The secondary namespace is "passive" and does not receive messages. The metadata between both is in sync, so both can seamlessly accept messages without any application code or connection string changes. To ensure that only the active namespace receives messages, you must use the alias.
Metadata: Entities such as queues, topics, and subscriptions; and their properties of the service that are associated with the namespace. Note that only entities and their settings are replicated automatically. Messages are not replicated.
Failover: The process of activating the secondary namespace.
The following section is an overview to setup pairing between the namespaces.
The setup process is as follows -
Provision a Primary Service Bus Premium Namespace.
Provision a Secondary Service Bus Premium Namespace in a region different from where the primary namespace is provisioned. This will help allow fault isolation across different datacenter regions.
Create pairing between the Primary namespace and Secondary namespace to obtain the alias.
Use the alias obtained in step 3 to connect your client applications to the Geo-DR enabled primary namespace. Initially, the alias points to the primary namespace.
[Optional] Add some monitoring to detect if a failover is necessary.
A failover is triggered manually by the customer (either explicitly through a command, or through client owned business logic that triggers the command) and never by Azure. This gives the customer full ownership and visibility for outage resolution on Azure's backbone.
After the failover is triggered -
The alias connection string is updated to point to the Secondary Premium namespace.
Clients(senders and receivers) automatically connect to the Secondary namespace.
The existing pairing between Primary and Secondary premium namespace is broken.
Once the failover is initiated -
If another outage occurs, you want to be able to fail over again. Therefore, set up another passive namespace and update the pairing.
Pull messages from the former primary namespace once it is available again. After that, use that namespace for regular messaging outside of your geo-recovery setup, or delete the old primary namespace.
Only fail forward semantics are supported. In this scenario, you fail over and then re-pair with a new namespace. Failing back is not supported; for example, in a SQL cluster.
You can automate failover either with monitoring systems, or with custom-built monitoring solutions. However, such automation takes extra planning and work, which is out of the scope of this article.
If you made a mistake; for example, you paired the wrong regions during the initial setup, you can break the pairing of the two namespaces at any time. If you want to use the paired namespaces as regular namespaces, delete the alias.
Use existing namespace as alias
If you have a scenario in which you cannot change the connections of producers and consumers, you can reuse your namespace name as the alias name. See the sample code on GitHub here.
The samples on GitHub show how to set up and initiate a failover. These samples demonstrate the following concepts:
- A .NET sample and settings that are required in Azure Active Directory to use Azure Resource Manager with Service Bus, to set up and enable Geo-disaster recovery.
- Steps required to execute the sample code.
- How to use an existing namespace as an alias.
- Steps to alternatively enable Geo-disaster recovery via PowerShell or CLI.
- Send and receive from the current primary or secondary namespace using the alias.
Note the following considerations to keep in mind with this release:
In your failover planning, you should also consider the time factor. For example, if you lose connectivity for longer than 15 to 20 minutes, you might decide to initiate the failover.
The fact that no data is replicated means that currently active sessions are not replicated. Additionally, duplicate detection and scheduled messages may not work. New sessions, new scheduled messages and new duplicates will work.
Failing over a complex distributed infrastructure should be rehearsed at least once.
Synchronizing entities can take some time, approximately 50-100 entities per minute. Subscriptions and rules also count as entities.
The Service Bus Premium SKU also supports Availability Zones, providing fault-isolated locations within an Azure region.
The Availability Zones support for Azure Service Bus Premium is only available in Azure regions where availability zones are present.
You can enable Availability Zones on new namespaces only, using the Azure portal. Service Bus does not support migration of existing namespaces. You cannot disable zone redundancy after enabling it on your namespace.
- See the Geo-disaster recovery REST API reference here.
- Run the Geo-disaster recovery sample on GitHub.
- See the Geo-disaster recovery sample that sends messages to an alias.
