Common query patterns in Azure Stream Analytics

Queries in Azure Stream Analytics are expressed in a SQL-like query language. The language constructs are documented in the Stream Analytics query language reference guide.

The query design can express simple pass-through logic to move event data from one input stream into an output data store, or it can do rich pattern matching and temporal analysis to calculate aggregates over various time windows as in the Build an IoT solution by using Stream Analytics guide. You can join data from multiple inputs to combine streaming events, and you can do lookups against static reference data to enrich the event values. You can also write data to multiple outputs.

This article outlines solutions to several common query patterns based on real-world scenarios.

Supported Data Formats

Azure Stream Analytics supports processing events in CSV, JSON and Avro data formats.

Both JSON and Avro may contain complex types such as nested objects (records) or arrays. For more information on working with these complex data types, refer to the Parsing JSON and AVRO data article.

Send data to multiple outputs

Multiple SELECT statements can be used to output data to different output sinks. For example, one SELECT can output a threshold-based alert while another one can output events to blob storage.

Input:

Make Time
Make1 2015-01-01T00:00:01.0000000Z
Make1 2015-01-01T00:00:02.0000000Z
Make2 2015-01-01T00:00:01.0000000Z
Make2 2015-01-01T00:00:02.0000000Z
Make2 2015-01-01T00:00:03.0000000Z

Output ArchiveOutput:

Make Time
Make1 2015-01-01T00:00:01.0000000Z
Make1 2015-01-01T00:00:02.0000000Z
Make2 2015-01-01T00:00:01.0000000Z
Make2 2015-01-01T00:00:02.0000000Z
Make2 2015-01-01T00:00:03.0000000Z

Output AlertOutput:

Make Time Count
Make2 2015-01-01T00:00:10.0000000Z 3

Query:

SELECT
	*
INTO
	ArchiveOutput
FROM
	Input TIMESTAMP BY Time

SELECT
	Make,
	System.TimeStamp() AS Time,
	COUNT(*) AS [Count]
INTO
	AlertOutput
FROM
	Input TIMESTAMP BY Time
GROUP BY
	Make,
	TumblingWindow(second, 10)
HAVING
	[Count] >= 3

The INTO clause tells Stream Analytics which of the outputs to write the data to. The first SELECT defines a pass-through query that receives data from the input and sends it to the output named ArchiveOutput. The second query does some simple aggregation and filtering before sending the results to a downstream alerting system output called AlertOutput.

Note that the WITH clause can be used to define multiple sub-query blocks. This option has the benefit of opening fewer readers to the input source.

Query:

WITH ReaderQuery AS (
	SELECT
		*
	FROM
		Input TIMESTAMP BY Time
)

SELECT * INTO ArchiveOutput FROM ReaderQuery

SELECT
	Make,
	System.TimeStamp() AS Time,
	COUNT(*) AS [Count]
INTO AlertOutput
FROM ReaderQuery
GROUP BY
	Make,
	TumblingWindow(second, 10)
HAVING [Count] >= 3

For more information, refer to WITH clause.

Simple pass-through query

A simple pass-through query can be used to copy the input stream data into the output. For example, if a stream of data containing real-time vehicle information needs to be saved in a SQL database for letter analysis, a simple pass-through query will do the job.

Input:

Make Time Weight
Make1 2015-01-01T00:00:01.0000000Z "1000"
Make1 2015-01-01T00:00:02.0000000Z "2000"

Output:

Make Time Weight
Make1 2015-01-01T00:00:01.0000000Z "1000"
Make1 2015-01-01T00:00:02.0000000Z "2000"

Query:

SELECT
	*
INTO Output
FROM Input

A SELECT * query projects all the fields of an incoming event and sends them to the output. The same way, SELECT can also be used to only project required fields from the input. In this example, if vehicle Make and Time are the only required fields to be saved, those fields can be specified in the SELECT statement.

Input:

Make Time Weight
Make1 2015-01-01T00:00:01.0000000Z 1000
Make1 2015-01-01T00:00:02.0000000Z 2000
Make2 2015-01-01T00:00:04.0000000Z 1500

Output:

Make Time
Make1 2015-01-01T00:00:01.0000000Z
Make1 2015-01-01T00:00:02.0000000Z
Make2 2015-01-01T00:00:04.0000000Z

Query:

SELECT
	Make, Time
INTO Output
FROM Input

String matching with LIKE and NOT LIKE

LIKE and NOT LIKE can be used to verify if a field matches a certain pattern. For example, a filter can be created to return only the license plates that start with the letter 'A' and end with the number 9.

Input:

Make License_plate Time
Make1 ABC-123 2015-01-01T00:00:01.0000000Z
Make2 AAA-999 2015-01-01T00:00:02.0000000Z
Make3 ABC-369 2015-01-01T00:00:03.0000000Z

Output:

Make License_plate Time
Make2 AAA-999 2015-01-01T00:00:02.0000000Z
Make3 ABC-369 2015-01-01T00:00:03.0000000Z

Query:

SELECT
	*
FROM
	Input TIMESTAMP BY Time
WHERE
	License_plate LIKE 'A%9'

Use the LIKE statement to check the License_plate field value. It should start with the letter 'A', then have any string of zero or more characters, ending with the number 9.

Calculation over past events

The LAG function can be used to look at past events within a time window and compare them against the current event. For example, the current car make can be outputted if it is different from the last car that went through the toll.

Input:

Make Time
Make1 2015-01-01T00:00:01.0000000Z
Make2 2015-01-01T00:00:02.0000000Z

Output:

Make Time
Make2 2015-01-01T00:00:02.0000000Z

Query:

SELECT
	Make,
	Time
FROM
	Input TIMESTAMP BY Time
WHERE
	LAG(Make, 1) OVER (LIMIT DURATION(minute, 1)) <> Make

Use LAG to peek into the input stream one event back, retrieving the Make value and comparing it to the Make value of the current event and output the event.

For more information, refer to LAG.

Return the last event in a window

As events are consumed by the system in real-time, there is no function that can determine if an event will be the last one to arrive for that window of time. To achieve this, the input stream needs to be joined with another where the time of an event is the maximum time for all events at that window.

Input:

License_plate Make Time
DXE 5291 Make1 2015-07-27T00:00:05.0000000Z
YZK 5704 Make3 2015-07-27T00:02:17.0000000Z
RMV 8282 Make1 2015-07-27T00:05:01.0000000Z
YHN 6970 Make2 2015-07-27T00:06:00.0000000Z
VFE 1616 Make2 2015-07-27T00:09:31.0000000Z
QYF 9358 Make1 2015-07-27T00:12:02.0000000Z
MDR 6128 Make4 2015-07-27T00:13:45.0000000Z

Output:

License_plate Make Time
VFE 1616 Make2 2015-07-27T00:09:31.0000000Z
MDR 6128 Make4 2015-07-27T00:13:45.0000000Z

Query:

WITH LastInWindow AS
(
	SELECT
		MAX(Time) AS LastEventTime
	FROM
		Input TIMESTAMP BY Time
	GROUP BY
		TumblingWindow(minute, 10)
)

SELECT
	Input.License_plate,
	Input.Make,
	Input.Time
FROM
	Input TIMESTAMP BY Time
	INNER JOIN LastInWindow
	ON DATEDIFF(minute, Input, LastInWindow) BETWEEN 0 AND 10
	AND Input.Time = LastInWindow.LastEventTime

The first step on the query finds the maximum time stamp in 10-minute windows, that is the time stamp of the last event for that window. The second step joins the results of the first query with the original stream to find the event that match the last time stamps in each window.

DATEDIFF is a date-specific function that compares and returns the time difference between two DateTime fields, for more information, refer to date functions.

For more information on joining streams, refer to JOIN.

Data aggregation over time

To compute information over a time window, data can be aggregated together. In this example, a count is computed over the last 10 seconds of time for every specific car make.

Input:

Make Time Weight
Make1 2015-01-01T00:00:01.0000000Z 1000
Make1 2015-01-01T00:00:02.0000000Z 2000
Make2 2015-01-01T00:00:04.0000000Z 1500

Output:

Make Count
Make1 2
Make2 1

Query:

SELECT
	Make,
	COUNT(*) AS Count
FROM
	Input TIMESTAMP BY Time
GROUP BY
	Make,
	TumblingWindow(second, 10)

This aggregation groups the cars by Make and counts them every 10 seconds. The output has the Make and Count of cars that went through the toll.

TumblingWindow is a windowing function used to group events together. An aggregation can be applied over all grouped events. For more information, see windowing functions.

For more information on aggregation, refer to aggregate functions.

Periodically output values

In case of irregular or missing events, a regular interval output can be generated from a more sparse data input. For example, generate an event every 5 seconds that reports the most recently seen data point.

Input:

Time Value
"2014-01-01T06:01:00" 1
"2014-01-01T06:01:05" 2
"2014-01-01T06:01:10" 3
"2014-01-01T06:01:15" 4
"2014-01-01T06:01:30" 5
"2014-01-01T06:01:35" 6

Output (first 10 rows):

Window_end Last_event.Time Last_event.Value
2014-01-01T14:01:00.000Z 2014-01-01T14:01:00.000Z 1
2014-01-01T14:01:05.000Z 2014-01-01T14:01:05.000Z 2
2014-01-01T14:01:10.000Z 2014-01-01T14:01:10.000Z 3
2014-01-01T14:01:15.000Z 2014-01-01T14:01:15.000Z 4
2014-01-01T14:01:20.000Z 2014-01-01T14:01:15.000Z 4
2014-01-01T14:01:25.000Z 2014-01-01T14:01:15.000Z 4
2014-01-01T14:01:30.000Z 2014-01-01T14:01:30.000Z 5
2014-01-01T14:01:35.000Z 2014-01-01T14:01:35.000Z 6
2014-01-01T14:01:40.000Z 2014-01-01T14:01:35.000Z 6
2014-01-01T14:01:45.000Z 2014-01-01T14:01:35.000Z 6

Query:

SELECT
	System.Timestamp() AS Window_end,
	TopOne() OVER (ORDER BY Time DESC) AS Last_event
FROM
	Input TIMESTAMP BY Time
GROUP BY
	HOPPINGWINDOW(second, 300, 5)

This query generates events every 5 seconds and outputs the last event that was received previously. The HOPPINGWINDOW duration determines how far back the query looks to find the latest event.

For more information, refer to Hopping window.

Correlate events in a stream

Correlating events in the same stream can be done by looking at past events using the LAG function. For example, an output can be generated every time two consecutive cars from the same Make go through the toll for the last 90 seconds.

Input:

Make License_plate Time
Make1 ABC-123 2015-01-01T00:00:01.0000000Z
Make1 AAA-999 2015-01-01T00:00:02.0000000Z
Make2 DEF-987 2015-01-01T00:00:03.0000000Z
Make1 GHI-345 2015-01-01T00:00:04.0000000Z

Output:

Make Time Current_car_license_plate First_car_license_plate First_car_time
Make1 2015-01-01T00:00:02.0000000Z AAA-999 ABC-123 2015-01-01T00:00:01.0000000Z

Query:

SELECT
	Make,
	Time,
	License_plate AS Current_car_license_plate,
	LAG(License_plate, 1) OVER (LIMIT DURATION(second, 90)) AS First_car_license_plate,
	LAG(Time, 1) OVER (LIMIT DURATION(second, 90)) AS First_car_time
FROM
	Input TIMESTAMP BY Time
WHERE
	LAG(Make, 1) OVER (LIMIT DURATION(second, 90)) = Make

The LAG function can look into the input stream one event back and retrieve the Make value, comparing that with the Make value of the current event. Once the condition is met, data from the previous event can be projected using LAG in the SELECT statement.

For more information, refer to LAG.

Detect the duration between events

The duration of an event can be computed by looking at the last Start event once an End event is received. This query can be useful to determine the time a user spends on a page or a feature.

Input:

User Feature Event Time
user@location.com RightMenu Start 2015-01-01T00:00:01.0000000Z
user@location.com RightMenu End 2015-01-01T00:00:08.0000000Z

Output:

User Feature Duration
user@location.com RightMenu 7

Query:

SELECT
	[user],
	feature,
	DATEDIFF(
		second,
		LAST(Time) OVER (PARTITION BY [user], feature LIMIT DURATION(hour, 1) WHEN Event = 'start'),
		Time) as duration
FROM input TIMESTAMP BY Time
WHERE
	Event = 'end'

The LAST function can be used to retrieve the last event within a specific condition. In this example, the condition is an event of type Start, partitioning the search by PARTITION BY user and feature. This way, every user and feature is treated independently when searching for the Start event. LIMIT DURATION limits the search back in time to 1 hour between the End and Start events.

Count unique values

COUNT and DISTINCT can be used to count the number of unique field values that appear in the stream within a time window. A query can be created to calculate how many unique Makes of cars passed through the toll booth in a 2-second window.

Input:

Make Time
Make1 2015-01-01T00:00:01.0000000Z
Make1 2015-01-01T00:00:02.0000000Z
Make2 2015-01-01T00:00:01.0000000Z
Make2 2015-01-01T00:00:02.0000000Z
Make2 2015-01-01T00:00:03.0000000Z

Output:

Count_make Time
2 2015-01-01T00:00:02.000Z
1 2015-01-01T00:00:04.000Z

Query:

SELECT
     COUNT(DISTINCT Make) AS Count_make,
     System.TIMESTAMP() AS Time
FROM Input TIMESTAMP BY TIME
GROUP BY
     TumblingWindow(second, 2)

COUNT(DISTINCT Make) returns the count of distinct values in the Make column within a time window. For more information, refer to COUNT aggregate function.

Retrieve the first event in a window

IsFirst can be used to retrieve the first event in a time window. For example, outputting the first car information at every 10-minute interval.

Input:

License_plate Make Time
DXE 5291 Make1 2015-07-27T00:00:05.0000000Z
YZK 5704 Make3 2015-07-27T00:02:17.0000000Z
RMV 8282 Make1 2015-07-27T00:05:01.0000000Z
YHN 6970 Make2 2015-07-27T00:06:00.0000000Z
VFE 1616 Make2 2015-07-27T00:09:31.0000000Z
QYF 9358 Make1 2015-07-27T00:12:02.0000000Z
MDR 6128 Make4 2015-07-27T00:13:45.0000000Z

Output:

License_plate Make Time
DXE 5291 Make1 2015-07-27T00:00:05.0000000Z
QYF 9358 Make1 2015-07-27T00:12:02.0000000Z

Query:

SELECT
	License_plate,
	Make,
	Time
FROM
	Input TIMESTAMP BY Time
WHERE
	IsFirst(minute, 10) = 1

IsFirst can also partition the data and calculate the first event to each specific car Make found at every 10-minute interval.

Output:

License_plate Make Time
DXE 5291 Make1 2015-07-27T00:00:05.0000000Z
YZK 5704 Make3 2015-07-27T00:02:17.0000000Z
YHN 6970 Make2 2015-07-27T00:06:00.0000000Z
QYF 9358 Make1 2015-07-27T00:12:02.0000000Z
MDR 6128 Make4 2015-07-27T00:13:45.0000000Z

Query:

SELECT
	License_plate,
	Make,
	Time
FROM
	Input TIMESTAMP BY Time
WHERE
	IsFirst(minute, 10) OVER (PARTITION BY Make) = 1

For more information, refer to IsFirst.

Remove duplicate events in a window

When performing an operation such as calculating averages over events in a given time window, duplicate events should be filtered. In the following example, the second event is a duplicate of the first.

Input:

DeviceId Time Attribute Value
1 2018-07-27T00:00:01.0000000Z Temperature 50
1 2018-07-27T00:00:01.0000000Z Temperature 50
2 2018-07-27T00:00:01.0000000Z Temperature 40
1 2018-07-27T00:00:05.0000000Z Temperature 60
2 2018-07-27T00:00:05.0000000Z Temperature 50
1 2018-07-27T00:00:10.0000000Z Temperature 100

Output:

AverageValue DeviceId
70 1
45 2

Query:

With Temp AS (
SELECT
	COUNT(DISTINCT Time) AS CountTime,
	Value,
	DeviceId
FROM
	Input TIMESTAMP BY Time
GROUP BY
	Value,
	DeviceId,
	SYSTEM.TIMESTAMP()
)

SELECT
    AVG(Value) AS AverageValue, DeviceId
INTO Output
FROM Temp
GROUP BY DeviceId,TumblingWindow(minute, 5)

COUNT(DISTINCT Time) returns the number of distinct values in the Time column within a time window. The output of the first step can then be used to compute the average per device, by discarding duplicates.

For more information, refer to COUNT(DISTINCT Time).

Specify logic for different cases/values (CASE statements)

CASE statements can provide different computations for different fields, based on particular criterion. For example, assign lane 'A' to cars of Make1 and lane 'B' to any other make.

Input:

Make Time
Make1 2015-01-01T00:00:01.0000000Z
Make2 2015-01-01T00:00:02.0000000Z
Make2 2015-01-01T00:00:03.0000000Z

Output:

Make Dispatch_to_lane Time
Make1 "A" 2015-01-01T00:00:01.0000000Z
Make2 "B" 2015-01-01T00:00:02.0000000Z

Solution:

SELECT
	Make
	CASE
		WHEN Make = "Make1" THEN "A"
		ELSE "B"
	END AS Dispatch_to_lane,
	System.TimeStamp() AS Time
FROM
	Input TIMESTAMP BY Time

The CASE expression compares an expression to a set of simple expressions to determine its result. In this example, vehicles of Make1 are dispatched to lane 'A' while vehicles of any other make will be assigned lane 'B'.

For more information, refer to case expression.

Data conversion

Data can be cast in real-time using the CAST method. For example, car weight can be converted from type nvarchar(max) to type bigint and be used on a numeric calculation.

Input:

Make Time Weight
Make1 2015-01-01T00:00:01.0000000Z "1000"
Make1 2015-01-01T00:00:02.0000000Z "2000"

Output:

Make Weight
Make1 3000

Query:

SELECT
	Make,
	SUM(CAST(Weight AS BIGINT)) AS Weight
FROM
	Input TIMESTAMP BY Time
GROUP BY
	Make,
	TumblingWindow(second, 10)

Use a CAST statement to specify its data type. See the list of supported data types on Data types (Azure Stream Analytics).

For more information on data conversion functions.

Detect the duration of a condition

For conditions that span through multiple events the LAG function can be used to identify the duration of that condition. For example, suppose that a bug resulted in all cars having an incorrect weight (above 20,000 pounds), and the duration of that bug must be computed.

Input:

Make Time Weight
Make1 2015-01-01T00:00:01.0000000Z 2000
Make2 2015-01-01T00:00:02.0000000Z 25000
Make1 2015-01-01T00:00:03.0000000Z 26000
Make2 2015-01-01T00:00:04.0000000Z 25000
Make1 2015-01-01T00:00:05.0000000Z 26000
Make2 2015-01-01T00:00:06.0000000Z 25000
Make1 2015-01-01T00:00:07.0000000Z 26000
Make2 2015-01-01T00:00:08.0000000Z 2000

Output:

Start_fault End_fault
2015-01-01T00:00:02.000Z 2015-01-01T00:00:07.000Z

Query:

WITH SelectPreviousEvent AS
(
SELECT
	*,
	LAG([time]) OVER (LIMIT DURATION(hour, 24)) as previous_time,
	LAG([weight]) OVER (LIMIT DURATION(hour, 24)) as previous_weight
FROM input TIMESTAMP BY [time]
)

SELECT
	LAG(time) OVER (LIMIT DURATION(hour, 24) WHEN previous_weight < 20000 ) [Start_fault],
	previous_time [End_fault]
FROM SelectPreviousEvent
WHERE
	[weight] < 20000
	AND previous_weight > 20000

The first SELECT statement correlates the current weight measurement with the previous measurement, projecting it together with the current measurement. The second SELECT looks back to the last event where the previous_weight is less than 20000, where the current weight is smaller than 20000 and the previous_weight of the current event was bigger than 20000.

The End_fault is the current non-faulty event where the previous event was faulty, and the Start_fault is the last non-faulty event before that.

Process events with independent time (Substreams)

Events can arrive late or out of order due to clock skews between event producers, clock skews between partitions, or network latency. For example, the device clock for TollID 2 is five seconds behind TollID 1, and the device clock for TollID 3 is ten seconds behind TollID 1. A computation can happen independently for each toll, considering only its own clock data as a timestamp.

Input:

LicensePlate Make Time TollID
DXE 5291 Make1 2015-07-27T00:00:01.0000000Z 1
YHN 6970 Make2 2015-07-27T00:00:05.0000000Z 1
QYF 9358 Make1 2015-07-27T00:00:01.0000000Z 2
GXF 9462 Make3 2015-07-27T00:00:04.0000000Z 2
VFE 1616 Make2 2015-07-27T00:00:10.0000000Z 1
RMV 8282 Make1 2015-07-27T00:00:03.0000000Z 3
MDR 6128 Make3 2015-07-27T00:00:11.0000000Z 2
YZK 5704 Make4 2015-07-27T00:00:07.0000000Z 3

Output:

TollID Count
1 2
2 2
1 1
3 1
2 1
3 1

Query:

SELECT
      TollId,
      COUNT(*) AS Count
FROM input
      TIMESTAMP BY Time OVER TollId
GROUP BY TUMBLINGWINDOW(second, 5), TollId

The TIMESTAMP OVER BY clause looks at each device timeline independently using substreams. The output event for each TollID is generated as they are computed, meaning that the events are in order with respect to each TollID instead of being reordered as if all devices were on the same clock.

For more information, refer to TIMESTAMP BY OVER.

Session Windows

A Session Window is a window that keeps expanding as events occur and closes for computation if no event is received after a specific amount of time or if the window reaches its maximum duration. This window is particularly useful when computing user interaction data. A window starts when a user starts interacting with the system and closes when no more events are observed, meaning, the user has stopped interacting. For example, a user is interacting with a web page where the number of clicks is logged, a Session Window can be used to find out how long the user interacted with the site.

Input:

User_id Time URL
0 2017-01-26T00:00:00.0000000Z "www.example.com/a.html"
0 2017-01-26T00:00:20.0000000Z "www.example.com/b.html"
1 2017-01-26T00:00:55.0000000Z "www.example.com/c.html"
0 2017-01-26T00:01:10.0000000Z "www.example.com/d.html"
1 2017-01-26T00:01:15.0000000Z "www.example.com/e.html"

Output:

User_id StartTime EndTime Duration_in_seconds
0 2017-01-26T00:00:00.0000000Z 2017-01-26T00:01:10.0000000Z 70
1 2017-01-26T00:00:55.0000000Z 2017-01-26T00:01:15.0000000Z 20

Query:

SELECT
	user_id,
	MIN(time) as StartTime,
	MAX(time) as EndTime,
	DATEDIFF(second, MIN(time), MAX(time)) AS duration_in_seconds
FROM input TIMESTAMP BY time
GROUP BY
	user_id,
	SessionWindow(minute, 1, 60) OVER (PARTITION BY user_id)

The SELECT projects the data relevant to the user interaction, together with the duration of the interaction. Grouping the data by user and a SessionWindow that closes if no interaction happens within 1 minute, with a maximum window size of 60 minutes.

For more information on SessionWindow, refer to Session Window .

Language extensibility with User Defined Function in JavaScript and C#

Azure Stream Analytics query language can be extended with custom functions written either in JavaScript or C# language. User Defined Functions (UDF) are custom/complex computations that cannot be easily expressed using the SQL language. These UDFs can be defined once and used multiple times within a query. For example, an UDF can be used to convert a hexadecimal nvarchar(max) value to an bigint value.

Input:

Device_id HexValue
1 "B4"
2 "11B"
3 "121"

Output:

Device_id Decimal
1 180
2 283
3 289
function hex2Int(hexValue){
	return parseInt(hexValue, 16);
}
public static class MyUdfClass {
	public static long Hex2Int(string hexValue){
		return int.Parse(hexValue, System.Globalization.NumberStyles.HexNumber);
	}
}
SELECT
	Device_id,
	udf.Hex2Int(HexValue) AS Decimal
From
	Input

The User Defined Function will compute the bigint value from the HexValue on every event consumed.

For more information, refer to JavaScript and C#.

Advanced pattern matching with MATCH_RECOGNIZE

MATCH_RECOGNIZE is an advanced pattern matching mechanism that can be used to match a sequence of events to a well-defined regular expression pattern. For example, an ATM is being monitored at real time for failures, during the operation of the ATM if there are two consecutive warning messages the administrator needs to be notified.

Input:

ATM_id Operation_id Return_Code Time
1 "Entering Pin" "Success" 2017-01-26T00:10:00.0000000Z
2 "Opening Money Slot" "Success" 2017-01-26T00:10:07.0000000Z
2 "Closing Money Slot" "Success" 2017-01-26T00:10:11.0000000Z
1 "Entering Withdraw Quantity" "Success" 2017-01-26T00:10:08.0000000Z
1 "Opening Money Slot" "Warning" 2017-01-26T00:10:14.0000000Z
1 "Printing Bank Balance" "Warning" 2017-01-26T00:10:19.0000000Z

Output:

ATM_id First_Warning_Operation_id Warning_Time
1 "Opening Money Slot" 2017-01-26T00:10:14.0000000Z
SELECT *
FROM input TIMESTAMP BY time OVER ATM_id
MATCH_RECOGNIZE (
	LIMIT DURATION(minute, 1)
	PARTITON BY ATM_id
	MEASURES
		First(Warning.ATM_id) AS ATM_id,
		First(Warning.Operation_Id) AS First_Warning_Operation_id,
		First(Warning.Time) AS Warning_Time
	AFTER MATCH SKIP TO NEXT ROW
	PATTERN (Success* Warning{2,})
	DEFINE
		Success AS Succes.Return_Code = 'Success',
		Failure AS Warning.Return_Code <> 'Success'
) AS patternMatch

This query matches at least two consecutive failure events and generate an alarm when the conditions are met. PATTERN defines the regular expression to be used on the matching, in this case, any number of successful operations followed by at least two consecutive failures. Success and Failure are defined using Return_Code value and once the condition is met, the MEASURES are projected with ATM_id, the first warning operation and first warning time.

For more information, refer to MATCH_RECOGNIZE.

Geofencing and geospatial queries

Azure Stream Analytics provides built-in geospatial functions that can be used to implement scenarios such as fleet management, ride sharing, connected cars, and asset tracking. Geospatial data can be ingested in either GeoJSON or WKT formats as part of event stream or reference data. For example, a company that is specialized in manufacturing machines for printing passports, lease their machines to governments and consulates. The location of those machines is heavily controlled as to avoid the misplacing and possible use for counterfeiting of passports. Each machine is fitted with a GPS tracker, that information is relayed back to an Azure Stream Analytics job. The manufacture would like to keep track of the location of those machines and be alerted if one of them leaves an authorized area, this way they can remotely disable, alert authorities and retrieve the equipment.

Input:

Equipment_id Equipment_current_location Time
1 "POINT(-122.13288797982818 47.64082002051315)" 2017-01-26T00:10:00.0000000Z
1 "POINT(-122.13307252987875 47.64081350934929)" 2017-01-26T00:11:00.0000000Z
1 "POINT(-122.13308862313283 47.6406508603241)" 2017-01-26T00:12:00.0000000Z
1 "POINT(-122.13341048821462 47.64043760861279)" 2017-01-26T00:13:00.0000000Z

Reference Data Input:

Equipment_id Equipment_lease_location
1 "POLYGON((-122.13326028450979 47.6409833866794,-122.13261655434621 47.6409833866794,-122.13261655434621 47.64061471602751,-122.13326028450979 47.64061471602751,-122.13326028450979 47.6409833866794))"

Output:

Equipment_id Equipment_alert_location Time
1 "POINT(-122.13341048821462 47.64043760861279)" 2017-01-26T00:13:00.0000000Z
SELECT
	input.Equipment_id AS Equipment_id,
	input.Equipment_current_location AS Equipment_current_location,
	input.Time AS Time
FROM input TIMESTAMP BY time
JOIN
	referenceInput
	ON input.Equipment_id = referenceInput.Equipment_id
	WHERE
		ST_WITHIN(input.Equipment_currenct_location, referenceInput.Equipment_lease_location) = 1

The query enables the manufacturer to monitor the machines location automatically, getting alerts when a machine leaves the allowed geofence. The built-in geospatial function allows users to use GPS data within the query without third-party libraries.

For more information, refer to the Geofencing and geospatial aggregation scenarios with Azure Stream Analytics article.

Get help

For further assistance, try our Microsoft Q&A question page for Azure Stream Analytics.

Next steps
