Prepare a Red Hat-based virtual machine for Azure

In this article, you will learn how to prepare a Red Hat Enterprise Linux (RHEL) virtual machine for use in Azure. The versions of RHEL that are covered in this article are 6.7+ and 7.1+. The hypervisors for preparation that are covered in this article are Hyper-V, kernel-based virtual machine (KVM), and VMware. For more information about eligibility requirements for participating in Red Hat's Cloud Access program, see Red Hat's Cloud Access website and Running RHEL on Azure.

Prepare a Red Hat-based virtual machine from Hyper-V Manager

Prerequisites

This section assumes that you have already obtained an ISO file from the Red Hat website and installed the RHEL image to a virtual hard disk (VHD). For more details about how to use Hyper-V Manager to install an operating system image, see Install the Hyper-V Role and Configure a Virtual Machine.

RHEL installation notes

  • Azure does not support the VHDX format. Azure supports only fixed VHD. You can use Hyper-V Manager to convert the disk to VHD format, or you can use the convert-vhd cmdlet. If you use VirtualBox, select Fixed size as opposed to the default dynamically allocated option when you create the disk.
  • Azure supports only generation 1 virtual machines. You can convert a generation 1 virtual machine from VHDX to the VHD file format and from dynamically expanding to a fixed-size disk. You can't change a virtual machine's generation. For more information, see Should I create a generation 1 or 2 virtual machine in Hyper-V?.
  • The maximum size that's allowed for the VHD is 1,023 GB.
  • When you install the Linux operating system, we recommend that you use standard partitions rather than Logical Volume Manager (LVM), which is often the default for many installations. This practice will avoid LVM name conflicts with cloned virtual machines, particularly if you ever need to attach an operating system disk to another identical virtual machine for troubleshooting. LVM or RAID may be used on data disks.
  • Kernel support for mounting Universal Disk Format (UDF) file systems is required. At first boot on Azure, the UDF-formatted media that is attached to the guest passes the provisioning configuration to the Linux virtual machine. The Azure Linux Agent must be able to mount the UDF file system to read its configuration and provision the virtual machine.
  • Versions of the Linux kernel that are earlier than 2.6.37 do not support non-uniform memory access (NUMA) on Hyper-V with larger virtual machine sizes. This issue primarily impacts older distributions that use the upstream Red Hat 2.6.32 kernel and was fixed in RHEL 6.6 (kernel-2.6.32-504). Systems that run custom kernels that are older than 2.6.37 or RHEL-based kernels that are older than 2.6.32-504 must set the numa=off boot parameter on the kernel command line in grub.conf. For more information, see Red Hat KB 436883.
  • Do not configure a swap partition on the operating system disk. The Linux Agent can be configured to create a swap file on the temporary resource disk. More information about this can be found in the following steps.
  • All VHDs must have sizes that are multiples of 1 MB.

Prepare a RHEL 6 virtual machine from Hyper-V Manager

  1. In Hyper-V Manager, select the virtual machine.

  2. Click Connect to open a console window for the virtual machine.

  3. In RHEL 6, NetworkManager can interfere with the Azure Linux agent. Uninstall this package by running the following command:

     # sudo rpm -e --nodeps NetworkManager

  4. Create or edit the /etc/sysconfig/network file, and add the following text:

     NETWORKING=yes
     HOSTNAME=localhost.localdomain

  5. Create or edit the /etc/sysconfig/network-scripts/ifcfg-eth0 file, and add the following text:

     DEVICE=eth0
     ONBOOT=yes
     BOOTPROTO=dhcp
     TYPE=Ethernet
     USERCTL=no
     PEERDNS=yes
     IPV6INIT=no

  6. Move (or remove) the udev rules to avoid generating static rules for the Ethernet interface. These rules cause problems when you clone a virtual machine in Microsoft Azure or Hyper-V:

     # sudo ln -s /dev/null /etc/udev/rules.d/75-persistent-net-generator.rules

     # sudo rm -f /etc/udev/rules.d/70-persistent-net.rules

  7. Ensure that the network service will start at boot time by running the following command:

     # sudo chkconfig network on

  8. Register your Red Hat subscription to enable the installation of packages from the RHEL repository by running the following command:

     # sudo subscription-manager register --auto-attach --username=XXX --password=XXX

  9. The WALinuxAgent package, WALinuxAgent-<version>, has been pushed to the Red Hat extras repository. Enable the extras repository by running the following command:

     # subscription-manager repos --enable=rhel-6-server-extras-rpms

  10. Modify the kernel boot line in your grub configuration to include additional kernel parameters for Azure. To do this modification, open /boot/grub/menu.lst in a text editor, and ensure that the default kernel includes the following parameters:

    console=ttyS0 earlyprintk=ttyS0 rootdelay=300


    This will also ensure that all console messages are sent to the first serial port, which can assist Azure support with debugging issues.

    In addition, we recommended that you remove the following parameters:

    rhgb quiet crashkernel=auto


    Graphical and quiet boot are not useful in a cloud environment where we want all the logs to be sent to the serial port. You can leave the crashkernel option configured if desired. Note that this parameter reduces the amount of available memory in the virtual machine by 128 MB or more. This configuration might be problematic on smaller virtual machine sizes.

    Important

    RHEL 6.5 and earlier must also set the numa=off kernel parameter. See Red Hat KB 436883.

  11. Ensure that the secure shell (SSH) server is installed and configured to start at boot time, which is usually the default. Modify /etc/ssh/sshd_config to include the following line:

    ClientAliveInterval 180

  12. Install the Azure Linux Agent by running the following command:

    # sudo yum install WALinuxAgent

    # sudo chkconfig waagent on


    Installing the WALinuxAgent package removes the NetworkManager and NetworkManager-gnome packages if they were not already removed in step 3.

  13. Do not create swap space on the operating system disk.

    The Azure Linux Agent can automatically configure swap space by using the local resource disk that is attached to the virtual machine after the virtual machine is provisioned on Azure. Note that the local resource disk is a temporary disk and that it might be emptied when the virtual machine is deprovisioned. After you install the Azure Linux Agent in the previous step, modify the following parameters in /etc/waagent.conf appropriately:

    ResourceDisk.Format=y
    ResourceDisk.Filesystem=ext4
    ResourceDisk.MountPoint=/mnt/resource
    ResourceDisk.EnableSwap=y
    ResourceDisk.SwapSizeMB=2048    ## NOTE: set this to whatever you need it to be.

  14. Unregister the subscription (if necessary) by running the following command:

    # sudo subscription-manager unregister

  15. Run the following commands to deprovision the virtual machine and prepare it for provisioning on Azure:

    # sudo waagent -force -deprovision

    # export HISTSIZE=0

    # logout

  16. Click Action > Shut Down in Hyper-V Manager. Your Linux VHD is now ready to be uploaded to Azure.

Prepare a RHEL 7 virtual machine from Hyper-V Manager

  1. In Hyper-V Manager, select the virtual machine.

  2. Click Connect to open a console window for the virtual machine.

  3. Create or edit the /etc/sysconfig/network file, and add the following text:

     NETWORKING=yes
     HOSTNAME=localhost.localdomain

  4. Create or edit the /etc/sysconfig/network-scripts/ifcfg-eth0 file, and add the following text:

     DEVICE=eth0
     ONBOOT=yes
     BOOTPROTO=dhcp
     TYPE=Ethernet
     USERCTL=no
     PEERDNS=yes
     IPV6INIT=no
     NM_CONTROLLED=no

  5. Ensure that the network service will start at boot time by running the following command:

     # sudo chkconfig network on

  6. Register your Red Hat subscription to enable the installation of packages from the RHEL repository by running the following command:

     # sudo subscription-manager register --auto-attach --username=XXX --password=XXX

  7. Modify the kernel boot line in your grub configuration to include additional kernel parameters for Azure. To do this modification, open /etc/default/grub in a text editor, and edit the GRUB_CMDLINE_LINUX parameter. For example:

     GRUB_CMDLINE_LINUX="rootdelay=300 console=ttyS0 earlyprintk=ttyS0 net.ifnames=0"


    This will also ensure that all console messages are sent to the first serial port, which can assist Azure support with debugging issues. This configuration also turns off the new RHEL 7 naming conventions for NICs. In addition, we recommend that you remove the following parameters:

     rhgb quiet crashkernel=auto


    Graphical and quiet boot are not useful in a cloud environment where we want all the logs to be sent to the serial port. You can leave the crashkernel option configured if desired. Note that this parameter reduces the amount of available memory in the virtual machine by 128 MB or more, which might be problematic on smaller virtual machine sizes.

  8. After you are done editing /etc/default/grub, run the following command to rebuild the grub configuration:

     # sudo grub2-mkconfig -o /boot/grub2/grub.cfg

  9. Ensure that the SSH server is installed and configured to start at boot time, which is usually the default. Modify /etc/ssh/sshd_config to include the following line:

     ClientAliveInterval 180

  10. The WALinuxAgent package, WALinuxAgent-<version>, has been pushed to the Red Hat extras repository. Enable the extras repository by running the following command:

    # subscription-manager repos --enable=rhel-7-server-extras-rpms

  11. Install the Azure Linux Agent by running the following command:

    # sudo yum install WALinuxAgent

    # sudo systemctl enable waagent.service

  12. Do not create swap space on the operating system disk.

    The Azure Linux Agent can automatically configure swap space by using the local resource disk that is attached to the virtual machine after the virtual machine is provisioned on Azure. Note that the local resource disk is a temporary disk, and it might be emptied when the virtual machine is deprovisioned. After you install the Azure Linux Agent in the previous step, modify the following parameters in /etc/waagent.conf appropriately:

    ResourceDisk.Format=y
    ResourceDisk.Filesystem=ext4
    ResourceDisk.MountPoint=/mnt/resource
    ResourceDisk.EnableSwap=y
    ResourceDisk.SwapSizeMB=2048    ## NOTE: set this to whatever you need it to be.

  13. If you want to unregister the subscription, run the following command:

    # sudo subscription-manager unregister

  14. Run the following commands to deprovision the virtual machine and prepare it for provisioning on Azure:

    # sudo waagent -force -deprovision

    # export HISTSIZE=0

    # logout

  15. Click Action > Shut Down in Hyper-V Manager. Your Linux VHD is now ready to be uploaded to Azure.

Prepare a Red Hat-based virtual machine from KVM

Prepare a RHEL 6 virtual machine from KVM

  1. Download the KVM image of RHEL 6 from the Red Hat website.

  2. Set a root password.

    Generate an encrypted password, and copy the output of the command:

     # openssl passwd -1 changeme


    Set a root password with guestfish:

     # guestfish --rw -a <image-name>
     > <fs> run
     > <fs> list-filesystems
     > <fs> mount /dev/sda1 /
     > <fs> vi /etc/shadow
     > <fs> exit


    Change the second field of the root user from "!!" to the encrypted password.

  3. Create a virtual machine in KVM from the qcow2 image. Set the disk type to qcow2, and set the virtual network interface device model to virtio. Then, start the virtual machine, and sign in as root.

  4. Create or edit the /etc/sysconfig/network file, and add the following text:

     NETWORKING=yes
     HOSTNAME=localhost.localdomain

  5. Create or edit the /etc/sysconfig/network-scripts/ifcfg-eth0 file, and add the following text:

     DEVICE=eth0
     ONBOOT=yes
     BOOTPROTO=dhcp
     TYPE=Ethernet
     USERCTL=no
     PEERDNS=yes
     IPV6INIT=no

  6. Move (or remove) the udev rules to avoid generating static rules for the Ethernet interface. These rules cause problems when you clone a virtual machine in Azure or Hyper-V:

     # sudo ln -s /dev/null /etc/udev/rules.d/75-persistent-net-generator.rules

     # sudo rm -f /etc/udev/rules.d/70-persistent-net.rules

  7. Ensure that the network service will start at boot time by running the following command:

     # chkconfig network on

  8. Register your Red Hat subscription to enable the installation of packages from the RHEL repository by running the following command:

     # subscription-manager register --auto-attach --username=XXX --password=XXX

  9. Modify the kernel boot line in your grub configuration to include additional kernel parameters for Azure. To do this configuration, open /boot/grub/menu.lst in a text editor, and ensure that the default kernel includes the following parameters:

     console=ttyS0 earlyprintk=ttyS0 rootdelay=300


    This will also ensure that all console messages are sent to the first serial port, which can assist Azure support with debugging issues.

    In addition, we recommend that you remove the following parameters:

     rhgb quiet crashkernel=auto


    Graphical and quiet boot are not useful in a cloud environment where we want all the logs to be sent to the serial port. You can leave the crashkernel option configured if desired. Note that this parameter reduces the amount of available memory in the virtual machine by 128 MB or more, which might be problematic on smaller virtual machine sizes.

    Important

    RHEL 6.5 and earlier must also set the numa=off kernel parameter. See Red Hat KB 436883.

  10. Add Hyper-V modules to initramfs:

    Edit /etc/dracut.conf, and add the following content:

    add_drivers+="hv_vmbus hv_netvsc hv_storvsc"


    Rebuild initramfs:

    # dracut -f -v

  11. Uninstall cloud-init:

    # yum remove cloud-init

  12. Ensure that the SSH server is installed and configured to start at boot time:

    # chkconfig sshd on


    Modify /etc/ssh/sshd_config to include the following lines:

    PasswordAuthentication yes
    ClientAliveInterval 180

  13. The WALinuxAgent package, WALinuxAgent-<version>, has been pushed to the Red Hat extras repository. Enable the extras repository by running the following command:

    # subscription-manager repos --enable=rhel-6-server-extras-rpms

  14. Install the Azure Linux Agent by running the following command:

    # yum install WALinuxAgent

    # chkconfig waagent on

  15. The Azure Linux Agent can automatically configure swap space by using the local resource disk that is attached to the virtual machine after the virtual machine is provisioned on Azure. Note that the local resource disk is a temporary disk, and it might be emptied when the virtual machine is deprovisioned. After you install the Azure Linux Agent in the previous step, modify the following parameters in /etc/waagent.conf appropriately:

    ResourceDisk.Format=y
    ResourceDisk.Filesystem=ext4
    ResourceDisk.MountPoint=/mnt/resource
    ResourceDisk.EnableSwap=y
    ResourceDisk.SwapSizeMB=2048    ## NOTE: set this to whatever you need it to be.

  16. Unregister the subscription (if necessary) by running the following command:

    # subscription-manager unregister

  17. Run the following commands to deprovision the virtual machine and prepare it for provisioning on Azure:

    # waagent -force -deprovision

    # export HISTSIZE=0

    # logout

  18. Shut down the virtual machine in KVM.

  19. Convert the qcow2 image to the VHD format.

Note

There is a known bug in qemu-img versions >=2.2.1 that results in an improperly formatted VHD. The issue has been fixed in QEMU 2.6. It is recommended to use either qemu-img 2.2.0 or lower, or update to 2.6 or higher. Reference: https://bugs.launchpad.net/qemu/+bug/1490611.

First convert the image to raw format:

    # qemu-img convert -f qcow2 -O raw rhel-6.9.qcow2 rhel-6.9.raw

Make sure that the size of the raw image is aligned with 1 MB. Otherwise, round up the size to align with 1 MB:

    # MB=$((1024*1024))
    # size=$(qemu-img info -f raw --output json "rhel-6.9.raw" | \
      gawk 'match($0, /"virtual-size": ([0-9]+),/, val) {print val[1]}')

    # rounded_size=$((($size/$MB + 1)*$MB))
    # qemu-img resize rhel-6.9.raw $rounded_size

Convert the raw disk to a fixed-sized VHD:

    # qemu-img convert -f raw -o subformat=fixed -O vpc rhel-6.9.raw rhel-6.9.vhd

Or, with qemu version **2.6+** include the `force_size` option:

    # qemu-img convert -f raw -o subformat=fixed,force_size -O vpc rhel-6.9.raw rhel-6.9.vhd

Prepare a RHEL 7 virtual machine from KVM

  1. Download the KVM image of RHEL 7 from the Red Hat website. This procedure uses RHEL 7 as the example.

  2. Set a root password.

    Generate an encrypted password, and copy the output of the command:

     # openssl passwd -1 changeme


    Set a root password with guestfish:

     # guestfish --rw -a <image-name>
     > <fs> run
     > <fs> list-filesystems
     > <fs> mount /dev/sda1 /
     > <fs> vi /etc/shadow
     > <fs> exit


    Change the second field of root user from "!!" to the encrypted password.

  3. Create a virtual machine in KVM from the qcow2 image. Set the disk type to qcow2, and set the virtual network interface device model to virtio. Then, start the virtual machine, and sign in as root.

  4. Create or edit the /etc/sysconfig/network file, and add the following text:

     NETWORKING=yes
     HOSTNAME=localhost.localdomain

  5. Create or edit the /etc/sysconfig/network-scripts/ifcfg-eth0 file, and add the following text:

     DEVICE=eth0
     ONBOOT=yes
     BOOTPROTO=dhcp
     TYPE=Ethernet
     USERCTL=no
     PEERDNS=yes
     IPV6INIT=no
     NM_CONTROLLED=no

  6. Ensure that the network service will start at boot time by running the following command:

     # chkconfig network on

  7. Register your Red Hat subscription to enable installation of packages from the RHEL repository by running the following command:

     # subscription-manager register --auto-attach --username=XXX --password=XXX

  8. Modify the kernel boot line in your grub configuration to include additional kernel parameters for Azure. To do this configuration, open /etc/default/grub in a text editor, and edit the GRUB_CMDLINE_LINUX parameter. For example:

     GRUB_CMDLINE_LINUX="rootdelay=300 console=ttyS0 earlyprintk=ttyS0 net.ifnames=0"


    This command also ensures that all console messages are sent to the first serial port, which can assist Azure support with debugging issues. The command also turns off the new RHEL 7 naming conventions for NICs. In addition, we recommend that you remove the following parameters:

     rhgb quiet crashkernel=auto


    Graphical and quiet boot are not useful in a cloud environment where we want all the logs to be sent to the serial port. You can leave the crashkernel option configured if desired. Note that this parameter reduces the amount of available memory in the virtual machine by 128 MB or more, which might be problematic on smaller virtual machine sizes.

  9. After you are done editing /etc/default/grub, run the following command to rebuild the grub configuration:

     # grub2-mkconfig -o /boot/grub2/grub.cfg

  10. Add Hyper-V modules into initramfs.

    Edit /etc/dracut.conf and add content:

    add_drivers+="hv_vmbus hv_netvsc hv_storvsc"


    Rebuild initramfs:

    # dracut -f -v

  11. Uninstall cloud-init:

    # yum remove cloud-init

  12. Ensure that the SSH server is installed and configured to start at boot time:

    # systemctl enable sshd


    Modify /etc/ssh/sshd_config to include the following lines:

    PasswordAuthentication yes
    ClientAliveInterval 180

  13. The WALinuxAgent package, WALinuxAgent-<version>, has been pushed to the Red Hat extras repository. Enable the extras repository by running the following command:

    # subscription-manager repos --enable=rhel-7-server-extras-rpms

  14. Install the Azure Linux Agent by running the following command:

    # yum install WALinuxAgent


    Enable the waagent service:

    # systemctl enable waagent.service

  15. Do not create swap space on the operating system disk.

    The Azure Linux Agent can automatically configure swap space by using the local resource disk that is attached to the virtual machine after the virtual machine is provisioned on Azure. Note that the local resource disk is a temporary disk, and it might be emptied when the virtual machine is deprovisioned. After you install the Azure Linux Agent in the previous step, modify the following parameters in /etc/waagent.conf appropriately:

    ResourceDisk.Format=y
    ResourceDisk.Filesystem=ext4
    ResourceDisk.MountPoint=/mnt/resource
    ResourceDisk.EnableSwap=y
    ResourceDisk.SwapSizeMB=2048    ## NOTE: set this to whatever you need it to be.

  16. Unregister the subscription (if necessary) by running the following command:

    # subscription-manager unregister

  17. Run the following commands to deprovision the virtual machine and prepare it for provisioning on Azure:

    # sudo waagent -force -deprovision

    # export HISTSIZE=0

    # logout

  18. Shut down the virtual machine in KVM.

  19. Convert the qcow2 image to the VHD format.

Note

There is a known bug in qemu-img versions >=2.2.1 that results in an improperly formatted VHD. The issue has been fixed in QEMU 2.6. It is recommended to use either qemu-img 2.2.0 or lower, or update to 2.6 or higher. Reference: https://bugs.launchpad.net/qemu/+bug/1490611.

First convert the image to raw format:

    # qemu-img convert -f qcow2 -O raw rhel-7.4.qcow2 rhel-7.4.raw

Make sure that the size of the raw image is aligned with 1 MB. Otherwise, round up the size to align with 1 MB:

    # MB=$((1024*1024))
    # size=$(qemu-img info -f raw --output json "rhel-7.4.raw" | \
      gawk 'match($0, /"virtual-size": ([0-9]+),/, val) {print val[1]}')

    # rounded_size=$((($size/$MB + 1)*$MB))
    # qemu-img resize rhel-7.4.raw $rounded_size

Convert the raw disk to a fixed-sized VHD:

    # qemu-img convert -f raw -o subformat=fixed -O vpc rhel-7.4.raw rhel-7.4.vhd

Or, with qemu version **2.6+** include the `force_size` option:

    # qemu-img convert -f raw -o subformat=fixed,force_size -O vpc rhel-7.4.raw rhel-7.4.vhd

Prepare a Red Hat-based virtual machine from VMware

Prerequisites

This section assumes that you have already installed a RHEL virtual machine in VMware. For details about how to install an operating system in VMware, see VMware Guest Operating System Installation Guide.

  • When you install the Linux operating system, we recommend that you use standard partitions rather than LVM, which is often the default for many installations. This will avoid LVM name conflicts with cloned virtual machine, particularly if an operating system disk ever needs to be attached to another virtual machine for troubleshooting. LVM or RAID can be used on data disks if preferred.
  • Do not configure a swap partition on the operating system disk. You can configure the Linux agent to create a swap file on the temporary resource disk. You can find more information about this in the steps that follow.
  • When you create the virtual hard disk, select Store virtual disk as a single file.

Prepare a RHEL 6 virtual machine from VMware

  1. In RHEL 6, NetworkManager can interfere with the Azure Linux agent. Uninstall this package by running the following command:

     # sudo rpm -e --nodeps NetworkManager

  2. Create a file named network in the /etc/sysconfig/ directory that contains the following text:

     NETWORKING=yes
     HOSTNAME=localhost.localdomain

  3. Create or edit the /etc/sysconfig/network-scripts/ifcfg-eth0 file, and add the following text:

     DEVICE=eth0
     ONBOOT=yes
     BOOTPROTO=dhcp
     TYPE=Ethernet
     USERCTL=no
     PEERDNS=yes
     IPV6INIT=no

  4. Move (or remove) the udev rules to avoid generating static rules for the Ethernet interface. These rules cause problems when you clone a virtual machine in Azure or Hyper-V:

     # sudo ln -s /dev/null /etc/udev/rules.d/75-persistent-net-generator.rules

     # sudo rm -f /etc/udev/rules.d/70-persistent-net.rules

  5. Ensure that the network service will start at boot time by running the following command:

     # sudo chkconfig network on

  6. Register your Red Hat subscription to enable the installation of packages from the RHEL repository by running the following command:

     # sudo subscription-manager register --auto-attach --username=XXX --password=XXX

  7. The WALinuxAgent package, WALinuxAgent-<version>, has been pushed to the Red Hat extras repository. Enable the extras repository by running the following command:

     # subscription-manager repos --enable=rhel-6-server-extras-rpms

  8. Modify the kernel boot line in your grub configuration to include additional kernel parameters for Azure. To do this, open /etc/default/grub in a text editor, and edit the GRUB_CMDLINE_LINUX parameter. For example:

     GRUB_CMDLINE_LINUX="rootdelay=300 console=ttyS0 earlyprintk=ttyS0"


    This will also ensure that all console messages are sent to the first serial port, which can assist Azure support with debugging issues. In addition, we recommend that you remove the following parameters:

     rhgb quiet crashkernel=auto


    Graphical and quiet boot are not useful in a cloud environment where we want all the logs to be sent to the serial port. You can leave the crashkernel option configured if desired. Note that this parameter reduces the amount of available memory in the virtual machine by 128 MB or more, which might be problematic on smaller virtual machine sizes.

  9. Add Hyper-V modules to initramfs:

    Edit /etc/dracut.conf, and add the following content:

     add_drivers+="hv_vmbus hv_netvsc hv_storvsc"


    Rebuild initramfs:

     # dracut -f -v

  10. Ensure that the SSH server is installed and configured to start at boot time, which is usually the default. Modify /etc/ssh/sshd_config to include the following line:

    ClientAliveInterval 180

  11. Install the Azure Linux Agent by running the following command:

    # sudo yum install WALinuxAgent

    # sudo chkconfig waagent on

  12. Do not create swap space on the operating system disk.

    The Azure Linux Agent can automatically configure swap space by using the local resource disk that is attached to the virtual machine after the virtual machine is provisioned on Azure. Note that the local resource disk is a temporary disk, and it might be emptied when the virtual machine is deprovisioned. After you install the Azure Linux Agent in the previous step, modify the following parameters in /etc/waagent.conf appropriately:

    ResourceDisk.Format=y
    ResourceDisk.Filesystem=ext4
    ResourceDisk.MountPoint=/mnt/resource
    ResourceDisk.EnableSwap=y
    ResourceDisk.SwapSizeMB=2048    ## NOTE: set this to whatever you need it to be.

  13. Unregister the subscription (if necessary) by running the following command:

    # sudo subscription-manager unregister

  14. Run the following commands to deprovision the virtual machine and prepare it for provisioning on Azure:

    # sudo waagent -force -deprovision

    # export HISTSIZE=0

    # logout

  15. Shut down the virtual machine, and convert the VMDK file to a .vhd file.

Note

There is a known bug in qemu-img versions >=2.2.1 that results in an improperly formatted VHD. The issue has been fixed in QEMU 2.6. It is recommended to use either qemu-img 2.2.0 or lower, or update to 2.6 or higher. Reference: https://bugs.launchpad.net/qemu/+bug/1490611.

First convert the image to raw format:

    # qemu-img convert -f vmdk -O raw rhel-6.9.vmdk rhel-6.9.raw

Make sure that the size of the raw image is aligned with 1 MB. Otherwise, round up the size to align with 1 MB:

    # MB=$((1024*1024))
    # size=$(qemu-img info -f raw --output json "rhel-6.9.raw" | \
      gawk 'match($0, /"virtual-size": ([0-9]+),/, val) {print val[1]}')

    # rounded_size=$((($size/$MB + 1)*$MB))
    # qemu-img resize rhel-6.9.raw $rounded_size

Convert the raw disk to a fixed-sized VHD:

    # qemu-img convert -f raw -o subformat=fixed -O vpc rhel-6.9.raw rhel-6.9.vhd

Or, with qemu version **2.6+** include the `force_size` option:

    # qemu-img convert -f raw -o subformat=fixed,force_size -O vpc rhel-6.9.raw rhel-6.9.vhd

Prepare a RHEL 7 virtual machine from VMware

  1. Create or edit the /etc/sysconfig/network file, and add the following text:

     NETWORKING=yes
     HOSTNAME=localhost.localdomain

  2. Create or edit the /etc/sysconfig/network-scripts/ifcfg-eth0 file, and add the following text:

     DEVICE=eth0
     ONBOOT=yes
     BOOTPROTO=dhcp
     TYPE=Ethernet
     USERCTL=no
     PEERDNS=yes
     IPV6INIT=no
     NM_CONTROLLED=no

  3. Ensure that the network service will start at boot time by running the following command:

     # sudo chkconfig network on

  4. Register your Red Hat subscription to enable the installation of packages from the RHEL repository by running the following command:

     # sudo subscription-manager register --auto-attach --username=XXX --password=XXX

  5. Modify the kernel boot line in your grub configuration to include additional kernel parameters for Azure. To do this modification, open /etc/default/grub in a text editor, and edit the GRUB_CMDLINE_LINUX parameter. For example:

     GRUB_CMDLINE_LINUX="rootdelay=300 console=ttyS0 earlyprintk=ttyS0 net.ifnames=0"


    This configuration also ensures that all console messages are sent to the first serial port, which can assist Azure support with debugging issues. It also turns off the new RHEL 7 naming conventions for NICs. In addition, we recommend that you remove the following parameters:

     rhgb quiet crashkernel=auto


    Graphical and quiet boot are not useful in a cloud environment where we want all the logs to be sent to the serial port. You can leave the crashkernel option configured if desired. Note that this parameter reduces the amount of available memory in the virtual machine by 128 MB or more, which might be problematic on smaller virtual machine sizes.

  6. After you are done editing /etc/default/grub, run the following command to rebuild the grub configuration:

     # sudo grub2-mkconfig -o /boot/grub2/grub.cfg

  7. Add Hyper-V modules to initramfs.

    Edit /etc/dracut.conf, add content:

     add_drivers+="hv_vmbus hv_netvsc hv_storvsc"


    Rebuild initramfs:

     # dracut -f -v

  8. Ensure that the SSH server is installed and configured to start at boot time. This setting is usually the default. Modify /etc/ssh/sshd_config to include the following line:

     ClientAliveInterval 180

  9. The WALinuxAgent package, WALinuxAgent-<version>, has been pushed to the Red Hat extras repository. Enable the extras repository by running the following command:

     # subscription-manager repos --enable=rhel-7-server-extras-rpms

  10. Install the Azure Linux Agent by running the following command:

    # sudo yum install WALinuxAgent

    # sudo systemctl enable waagent.service

  11. Do not create swap space on the operating system disk.

    The Azure Linux Agent can automatically configure swap space by using the local resource disk that is attached to the virtual machine after the virtual machine is provisioned on Azure. Note that the local resource disk is a temporary disk, and it might be emptied when the virtual machine is deprovisioned. After you install the Azure Linux Agent in the previous step, modify the following parameters in /etc/waagent.conf appropriately:

    ResourceDisk.Format=y
    ResourceDisk.Filesystem=ext4
    ResourceDisk.MountPoint=/mnt/resource
    ResourceDisk.EnableSwap=y
    ResourceDisk.SwapSizeMB=2048    ## NOTE: set this to whatever you need it to be.

  12. If you want to unregister the subscription, run the following command:

    # sudo subscription-manager unregister

  13. Run the following commands to deprovision the virtual machine and prepare it for provisioning on Azure:

    # sudo waagent -force -deprovision

    # export HISTSIZE=0

    # logout

  14. Shut down the virtual machine, and convert the VMDK file to the VHD format.

Note

There is a known bug in qemu-img versions >=2.2.1 that results in an improperly formatted VHD. The issue has been fixed in QEMU 2.6. It is recommended to use either qemu-img 2.2.0 or lower, or update to 2.6 or higher. Reference: https://bugs.launchpad.net/qemu/+bug/1490611.

First convert the image to raw format:

    # qemu-img convert -f vmdk -O raw rhel-7.4.vmdk rhel-7.4.raw

Make sure that the size of the raw image is aligned with 1 MB. Otherwise, round up the size to align with 1 MB:

    # MB=$((1024*1024))
    # size=$(qemu-img info -f raw --output json "rhel-7.4.raw" | \
      gawk 'match($0, /"virtual-size": ([0-9]+),/, val) {print val[1]}')

    # rounded_size=$((($size/$MB + 1)*$MB))
    # qemu-img resize rhel-7.4.raw $rounded_size

Convert the raw disk to a fixed-sized VHD:

    # qemu-img convert -f raw -o subformat=fixed -O vpc rhel-7.4.raw rhel-7.4.vhd

Or, with qemu version **2.6+** include the `force_size` option:

    # qemu-img convert -f raw -o subformat=fixed,force_size -O vpc rhel-7.4.raw rhel-7.4.vhd

Prepare a Red Hat-based virtual machine from an ISO by using a kickstart file automatically

Prepare a RHEL 7 virtual machine from a kickstart file

  1. Create a kickstart file that includes the following content, and save the file. For details about kickstart installation, see the Kickstart Installation Guide.

    # Kickstart for provisioning a RHEL 7 Azure VM

    # System authorization information
      auth --enableshadow --passalgo=sha512

    # Use graphical install
    text

    # Do not run the Setup Agent on first boot
    firstboot --disable

    # Keyboard layouts
    keyboard --vckeymap=us --xlayouts='us'

    # System language
    lang en_US.UTF-8

    # Network information
    network  --bootproto=dhcp

    # Root password
    rootpw --plaintext "to_be_disabled"

    # System services
    services --enabled="sshd,waagent,NetworkManager"

    # System timezone
    timezone Etc/UTC --isUtc --ntpservers 0.rhel.pool.ntp.org,1.rhel.pool.ntp.org,2.rhel.pool.ntp.org,3.rhel.pool.ntp.org

    # Partition clearing information
    clearpart --all --initlabel

    # Clear the MBR
    zerombr

    # Disk partitioning information
    part /boot --fstype="xfs" --size=500
    part / --fstyp="xfs" --size=1 --grow --asprimary

    # System bootloader configuration
    bootloader --location=mbr

    # Firewall configuration
    firewall --disabled

    # Enable SELinux
    selinux --enforcing

    # Don't configure X
    skipx

    # Power down the machine after install
    poweroff

    %packages
    @base
    @console-internet
    chrony
    sudo
    parted
    -dracut-config-rescue

    %end

    %post --log=/var/log/anaconda/post-install.log

    #!/bin/bash

    # Register Red Hat Subscription
    subscription-manager register --username=XXX --password=XXX --auto-attach --force

    # Install latest repo update
    yum update -y

    # Enable extras repo
    subscription-manager repos --enable=rhel-7-server-extras-rpms

    # Install WALinuxAgent
    yum install -y WALinuxAgent

    # Unregister Red Hat subscription
    subscription-manager unregister

    # Enable waaagent at boot-up
    systemctl enable waagent

    # Disable the root account
    usermod root -p '!!'

    # Configure swap in WALinuxAgent
    sed -i 's/^\(ResourceDisk\.EnableSwap\)=[Nn]$/\1=y/g' /etc/waagent.conf
    sed -i 's/^\(ResourceDisk\.SwapSizeMB\)=[0-9]*$/\1=2048/g' /etc/waagent.conf

    # Set the cmdline
    sed -i 's/^\(GRUB_CMDLINE_LINUX\)=".*"$/\1="console=tty1 console=ttyS0 earlyprintk=ttyS0 rootdelay=300"/g' /etc/default/grub

    # Enable SSH keepalive
    sed -i 's/^#\(ClientAliveInterval\).*$/\1 180/g' /etc/ssh/sshd_config

    # Build the grub cfg
    grub2-mkconfig -o /boot/grub2/grub.cfg

    # Configure network
    cat << EOF > /etc/sysconfig/network-scripts/ifcfg-eth0
    DEVICE=eth0
    ONBOOT=yes
    BOOTPROTO=dhcp
    TYPE=Ethernet
    USERCTL=no
    PEERDNS=yes
    IPV6INIT=no
    NM_CONTROLLED=no
    EOF

    # Deprovision and prepare for Azure
    waagent -force -deprovision

    %end

  2. Place the kickstart file where the installation system can access it.

  3. In Hyper-V Manager, create a new virtual machine. On the Connect Virtual Hard Disk page, select Attach a virtual hard disk later, and complete the New Virtual Machine Wizard.

  4. Open the virtual machine settings:

    a. Attach a new virtual hard disk to the virtual machine. Make sure to select VHD Format and Fixed Size.

    b. Attach the installation ISO to the DVD drive.

    c. Set the BIOS to boot from CD.

  5. Start the virtual machine. When the installation guide appears, press Tab to configure the boot options.

  6. Enter inst.ks=<the location of the kickstart file> at the end of the boot options, and press Enter.

  7. Wait for the installation to finish. When it's finished, the virtual machine will be shut down automatically. Your Linux VHD is now ready to be uploaded to Azure.

Known issues

The Hyper-V driver could not be included in the initial RAM disk when using a non-Hyper-V hypervisor

In some cases, Linux installers might not include the drivers for Hyper-V in the initial RAM disk (initrd or initramfs) unless Linux detects that it is running in a Hyper-V environment.

When you're using a different virtualization system (that is, Virtualbox, Xen, etc.) to prepare your Linux image, you might need to rebuild initrd to ensure that at least the hv_vmbus and hv_storvsc kernel modules are available on the initial RAM disk. This is a known issue at least on systems that are based on the upstream Red Hat distribution.

To resolve this issue, add Hyper-V modules to initramfs and rebuild it:

Edit /etc/dracut.conf, and add the following content:

    add_drivers+="hv_vmbus hv_netvsc hv_storvsc"

Rebuild initramfs:

    # dracut -f -v

For more details, see the information about rebuilding initramfs.

Next steps

You're now ready to use your Red Hat Enterprise Linux virtual hard disk to create new virtual machines in Azure. If this is the first time that you're uploading the .vhd file to Azure, see steps 2 and 3 in Creating and uploading a virtual hard disk that contains the Linux operating system.

For more details about the hypervisors that are certified to run Red Hat Enterprise Linux, see the Red Hat website.
