Name resolution for resources in Azure virtual networks

Depending on how you use Azure to host IaaS, PaaS, and hybrid solutions, you might need to allow the virtual machines (VMs), and other resources deployed in a virtual network to communicate with each other. Although you can enable communication by using IP addresses, it is much simpler to use names that can be easily remembered, and do not change.

When resources deployed in virtual networks need to resolve domain names to internal IP addresses, they can use one of two methods:

The type of name resolution you use depends on how your resources need to communicate with each other. The following table illustrates scenarios and corresponding name resolution solutions:

Note

Depending on your scenario, you may want to use the Azure DNS Private Zones feature, which is currently in Public Preview. For more information, see Using Azure DNS for private domains.

Scenario Solution Suffix
Name resolution between VMs located in the same virtual network, or Azure Cloud Services role instances in the same cloud service. Azure DNS Private Zones or Azure-provided name resolution Hostname or FQDN
Name resolution between VMs in different virtual networks or role instances in different cloud services. Azure DNS Private Zones or, Customer-managed DNS servers forwarding queries between virtual networks for resolution by Azure (DNS proxy). See Name resolution using your own DNS server. FQDN only
Name resolution from an Azure App Service (Web App, Function, or Bot) using virtual network integration to role instances or VMs in the same virtual network. Customer-managed DNS servers forwarding queries between virtual networks for resolution by Azure (DNS proxy). See Name resolution using your own DNS server. FQDN only
Name resolution from App Service Web Apps to VMs in the same virtual network. Customer-managed DNS servers forwarding queries between virtual networks for resolution by Azure (DNS proxy). See Name resolution using your own DNS server. FQDN only
Name resolution from App Service Web Apps in one virtual network to VMs in a different virtual network. Customer-managed DNS servers forwarding queries between virtual networks for resolution by Azure (DNS proxy). See Name resolution using your own DNS server. FQDN only
Resolution of on-premises computer and service names from VMs or role instances in Azure. Customer-managed DNS servers (on-premises domain controller, local read-only domain controller, or a DNS secondary synced using zone transfers, for example). See Name resolution using your own DNS server. FQDN only
Resolution of Azure hostnames from on-premises computers. Forward queries to a customer-managed DNS proxy server in the corresponding virtual network, the proxy server forwards queries to Azure for resolution. See Name resolution using your own DNS server. FQDN only
Reverse DNS for internal IPs. Name resolution using your own DNS server. Not applicable
Name resolution between VMs or role instances located in different cloud services, not in a virtual network. Not applicable. Connectivity between VMs and role instances in different cloud services is not supported outside a virtual network. Not applicable

Azure-provided name resolution

Along with resolution of public DNS names, Azure provides internal name resolution for VMs and role instances that reside within the same virtual network or cloud service. VMs and instances in a cloud service share the same DNS suffix, so the host name alone is sufficient. But in virtual networks deployed using the classic deployment model, different cloud services have different DNS suffixes. In this situation, you need the FQDN to resolve names between different cloud services. In virtual networks deployed using the Azure Resource Manager deployment model, the DNS suffix is consistent across the virtual network, so the FQDN is not needed. DNS names can be assigned to both VMs and network interfaces. Although Azure-provided name resolution does not require any configuration, it is not the appropriate choice for all deployment scenarios, as detailed in the previous table.

Note

When using cloud services web and worker roles, you can also access the internal IP addresses of role instances using the Azure Service Management REST API. For more information, see the Service Management REST API Reference. The address is based on the role name and instance number.

Features

Azure-provided name resolution includes the following features:

  • Ease of use. No configuration is required.
  • High availability. You don't need to create and manage clusters of your own DNS servers.
  • You can use the service in conjunction with your own DNS servers, to resolve both on-premises and Azure host names.
  • You can use name resolution between VMs and role instances within the same cloud service, without the need for an FQDN.
  • You can use name resolution between VMs in virtual networks that use the Azure Resource Manager deployment model, without need for an FQDN. Virtual networks in the classic deployment model require an FQDN when you are resolving names in different cloud services.
  • You can use host names that best describe your deployments, rather than working with auto-generated names.

Considerations

Points to consider when you are using Azure-provided name resolution:

  • The Azure-created DNS suffix cannot be modified.
  • You cannot manually register your own records.
  • WINS and NetBIOS are not supported. You cannot see your VMs in Windows Explorer.
  • Host names must be DNS-compatible. Names must use only 0-9, a-z, and '-', and cannot start or end with a '-'.
  • DNS query traffic is throttled for each VM. Throttling shouldn't impact most applications. If request throttling is observed, ensure that client-side caching is enabled. For more information, see DNS client configuration.
  • Only VMs in the first 180 cloud services are registered for each virtual network in a classic deployment model. This limit does not apply to virtual networks in Azure Resource Manager.

DNS client configuration

This section covers client-side caching and client-side retries.

Client-side caching

Not every DNS query needs to be sent across the network. Client-side caching helps reduce latency and improve resilience to network blips, by resolving recurring DNS queries from a local cache. DNS records contain a time-to-live (TTL) mechanism, which allows the cache to store the record for as long as possible without impacting record freshness. Thus, client-side caching is suitable for most situations.

The default Windows DNS client has a DNS cache built-in. Some Linux distributions do not include caching by default. If you find that there isn't a local cache already, add a DNS cache to each Linux VM.

There are a number of different DNS caching packages available (such as dnsmasq). Here's how to install dnsmasq on the most common distributions:

  • Ubuntu (uses resolvconf):
    • Install the dnsmasq package with sudo apt-get install dnsmasq.
  • SUSE (uses netconf):
    • Install the dnsmasq package with sudo zypper install dnsmasq.
    • Enable the dnsmasq service with systemctl enable dnsmasq.service.
    • Start the dnsmasq service with systemctl start dnsmasq.service.
    • Edit /etc/sysconfig/network/config, and change NETCONFIG_DNS_FORWARDER="" to dnsmasq.
    • Update resolv.conf with netconfig update, to set the cache as the local DNS resolver.
  • OpenLogic (uses NetworkManager):
    • Install the dnsmasq package with sudo yum install dnsmasq.
    • Enable the dnsmasq service with systemctl enable dnsmasq.service.
    • Start the dnsmasq service with systemctl start dnsmasq.service.
    • Add prepend domain-name-servers 127.0.0.1; to /etc/dhclient-eth0.conf.
    • Restart the network service with service network restart, to set the cache as the local DNS resolver.

Note

The dnsmasq package is only one of many DNS caches available for Linux. Before using it, check its suitability for your particular needs, and check that no other cache is installed.

Client-side retries

DNS is primarily a UDP protocol. Because the UDP protocol doesn't guarantee message delivery, retry logic is handled in the DNS protocol itself. Each DNS client (operating system) can exhibit different retry logic, depending on the creator's preference:

  • Windows operating systems retry after one second, and then again after another two seconds, four seconds, and another four seconds.
  • The default Linux setup retries after five seconds. We recommend changing the retry specifications to five times, at one-second intervals.

Check the current settings on a Linux VM with cat /etc/resolv.conf. Look at the options line, for example:

options timeout:1 attempts:5

The resolv.conf file is usually auto-generated, and should not be edited. The specific steps for adding the options line vary by distribution:

  • Ubuntu (uses resolvconf):
    1. Add the options line to /etc/resolveconf/resolv.conf.d/head.
    2. Run resolvconf -u to update.
  • SUSE (uses netconf):
    1. Add timeout:1 attempts:5 to the NETCONFIG_DNS_RESOLVER_OPTIONS="" parameter in /etc/sysconfig/network/config.
    2. Run netconfig update to update.
  • OpenLogic (uses NetworkManager):
    1. Add echo "options timeout:1 attempts:5" to /etc/NetworkManager/dispatcher.d/11-dhclient.
    2. Update with service network restart.

Name resolution that uses your own DNS server

This section covers VMs, role instances, and web apps.

VMs and role instances

Your name resolution needs might go beyond the features provided by Azure. For example, you might need to use Microsoft Windows Server Active Directory domains, resolve DNS names between virtual networks. To cover these scenarios, Azure provides the ability for you to use your own DNS servers.

DNS servers within a virtual network can forward DNS queries to the recursive resolvers in Azure. This enables you to resolve host names within that virtual network. For example, a domain controller (DC) running in Azure can respond to DNS queries for its domains, and forward all other queries to Azure. Forwarding queries allows VMs to see both your on-premises resources (via the DC) and Azure-provided host names (via the forwarder). Access to the recursive resolvers in Azure is provided via the virtual IP 168.63.129.16.

DNS forwarding also enables DNS resolution between virtual networks, and allows your on-premises machines to resolve Azure-provided host names. In order to resolve a VM's host name, the DNS server VM must reside in the same virtual network, and be configured to forward host name queries to Azure. Because the DNS suffix is different in each virtual network, you can use conditional forwarding rules to send DNS queries to the correct virtual network for resolution. The following image shows two virtual networks and an on-premises network doing DNS resolution between virtual networks, by using this method. An example DNS forwarder is available in the Azure Quickstart Templates gallery and GitHub.

Note

A role instance can perform name resolution of VMs within the same virtual network. It does so by using the FQDN, which consists of the VM's host name and internal.cloudapp.net DNS suffix. However, in this case, name resolution is only successful if the role instance has the VM name defined in the Role Schema (.cscfg file).

Role instances that need to perform name resolution of VMs in another virtual network (FQDN by using the internal.cloudapp.net suffix) have to do so by using the method described in this section (custom DNS servers forwarding between the two virtual networks).

Diagram of DNS between virtual networks

When you are using Azure-provided name resolution, Azure Dynamic Host Configuration Protocol (DHCP) provides an internal DNS suffix (.internal.cloudapp.net) to each VM. This suffix enables host name resolution because the host name records are in the internal.cloudapp.net zone. When you are using your own name resolution solution, this suffix is not supplied to VMs because it interferes with other DNS architectures (like domain-joined scenarios). Instead, Azure provides a non-functioning placeholder (reddog.microsoft.com).

If necessary, you can determine the internal DNS suffix by using PowerShell or the API:

If forwarding queries to Azure doesn't suit your needs, you should provide your own DNS solution. Your DNS solution needs to:

  • Provide appropriate host name resolution, via DDNS, for example. If you are using DDNS, you might need to disable DNS record scavenging. Azure DHCP leases are long, and scavenging might remove DNS records prematurely.
  • Provide appropriate recursive resolution to allow resolution of external domain names.
  • Be accessible (TCP and UDP on port 53) from the clients it serves, and be able to access the internet.
  • Be secured against access from the internet, to mitigate threats posed by external agents.

Note

For best performance, when you are using Azure VMs as DNS servers, IPv6 should be disabled. A public IP address should be assigned to each DNS server VM. For additional performance analysis and optimizations when you are using Windows Server as your DNS server, see Name resolution performance of a recursive Windows DNS Server 2012 R2.

Web apps

Suppose you need to perform name resolution from your web app built by using App Service, linked to a virtual network, to VMs in the same virtual network. In addition to setting up a custom DNS server that has a DNS forwarder that forwards queries to Azure (virtual IP 168.63.129.16), perform the following steps:

  1. Enable virtual network integration for your web app, if not done already, as described in Integrate your app with a virtual network.
  2. In the Azure portal, for the App Service plan hosting the web app, select Sync Network under Networking, Virtual Network Integration.

    Screenshot of virtual network name resolution

If you need to perform name resolution from your web app built by using App Service, linked to a virtual network, to VMs in a different virtual network, you have to use custom DNS servers on both virtual networks, as follows:

  • Set up a DNS server in your target virtual network, on a VM that can also forward queries to the recursive resolver in Azure (virtual IP 168.63.129.16). An example DNS forwarder is available in the Azure Quickstart Templates gallery and GitHub.
  • Set up a DNS forwarder in the source virtual network on a VM. Configure this DNS forwarder to forward queries to the DNS server in your target virtual network.
  • Configure your source DNS server in your source virtual network’s settings.
  • Enable virtual network integration for your web app to link to the source virtual network, following the instructions in Integrate your app with a virtual network.
  • In the Azure portal, for the App Service plan hosting the web app, select Sync Network under Networking, Virtual Network Integration.

Specify DNS servers

When you are using your own DNS servers, Azure provides the ability to specify multiple DNS servers per virtual network. You can also specify multiple DNS servers per network interface (for Azure Resource Manager), or per cloud service (for the classic deployment model). DNS servers specified for a network interface or cloud service get precedence over DNS servers specified for the virtual network.

Note

Network connection properties, such as DNS server IPs, should not be edited directly within Windows VMs. This is because they might get erased during service heal when the virtual network adaptor gets replaced.

When you are using the Azure Resource Manager deployment model, you can specify DNS servers for a virtual network and a network interface. For details, see Manage a virtual network and Manage a network interface.

When you are using the classic deployment model, you can specify DNS servers for the virtual network in the Azure portal or the Network Configuration file. For cloud services, you can specify DNS servers via the Service Configuration file or by using PowerShell, with New-AzureVM.

Note

If you change the DNS settings for a virtual network or virtual machine that is already deployed, you need to restart each affected VM for the changes to take effect.

Next steps

Azure Resource Manager deployment model:

Classic deployment model:
