# ServiceModel Metadata Utility Tool (Svcutil.exe)

The ServiceModel Metadata Utility tool is used to generate service model code from metadata documents, and metadata documents from service model code.

## SvcUtil.exe

The ServiceModel Metadata Utility Tool can be found at the Windows SDK installation location, specifically %ProgramFiles%\Microsoft SDKs\Windows\v6.0\Bin.

### Functionalities

The following table summarizes the various functionalities provided by this tool, and the corresponding topic that discusses how it is used:

Generates code from running services or static metadata documents. Generating a WCF Client from Service Metadata
Exports metadata documents from compiled code. How to: Use Svcutil.exe to Export Metadata from Compiled Service Code
Validates compiled service code. How to: Use Svcutil.exe to Validate Compiled Service Code
Generates serialization code. How to: Improve the Startup Time of WCF Client Applications using the XmlSerializer

Caution

Svcutil overwrites existing files on a disk if the names supplied as parameters are identical. This can include code files, configuration, or metadata files. To avoid this when generating code and configuration files, use the /mergeConfig switch.

In addition, the /r and /ct switches for referencing types are for generating data contracts. These switches do not work when using XmlSerializer.

### Timeout

The tool has a five minute timeout when retrieving metadata. This timeout only applies to retrieving metadata over the network. It does not apply to any processing of that metadata.

### Multi-targeting

The tool does not support multi-targeting. If you want to generate a .NET Framework 4 artifact from svcutil.exe, use the svcutil.exe from the .NET Framework 4 SDK. To generate a .NET Framework 3.5 artifact, use the executable from the .NET Framework 3.5 SDK.

### Accessing WSDL Documents

When you use Svcutil to access a WSDL document that has a reference to a security token service (STS), Svcutil makes a WS-MetadataExchange call to the STS. However, the service can expose its WSDL documents using either WS-MetadataExchange or HTTP GET. Therefore, if the STS has only exposed the WSDL document using HTTP GET, a client written in WinFX will fail. For clients written in .NET Framework 3.5, Svcutil attempts to use both WS-MetadataExchange and HTTP GET to obtain the STS WSDL.

## Using SvcUtil.exe

### Common Usages

The following table shows some commonly used options for this tool:

Option Description
/directory:<directory> Directory to create files in.

Default: The current directory.

Short form: /d
/help Displays the command syntax and options for the tool.

Short form: /?
/noLogo Suppress the copyright and banner message.
/svcutilConfig:<configFile> Specifies a custom configuration file to use instead of the App.config file. This can be used to register system.serviceModel extensions without altering the tool's configuration file.
/target:<output type> Specifies the output to be generated by the tool.

Valid values are code, metadata or xmlSerializer.

Short form: /t

### Code Generation

Svcutil.exe can generate code for service contracts, clients and data types from metadata documents. These metadata documents can be on a durable storage, or be retrieved online. Online retrieval follows either the WS-Metadata Exchange protocol or the DISCO protocol (for details see the Metadata Download section).

You can use the SvcUtil.exe tool to generate service and data contracts based on a predefined WSDL document. Use the /serviceContract switch and specify a URL or file location where the WSDL document can be downloaded or found. This generates the service and data contracts defined in the WSDL document that can then be used to implement a complaint service. For more information, see How to: Retrieve Metadata and Implement a Compliant Service.

For a service with a BasicHttpContextBinding endpoint, Svcutil.exe generates a BasicHttpBinding with the allowCookies attribute set to true instead. The cookies are used for context on the server. If you would like to manage context on the client when the service uses cookies, you can manually modify the configuration to use a context binding.

Caution

Svcutil.exe generates the client based on the WSDL or policy file received from the service. The user principal name (UPN) is generated by concatenating username, "@" and a fully-qualified domain name (FQDN). However, for users who registered on Active Directory, this format is not valid and the UPN generated by the tool causes a failure in Kerberos authentication with the error message "The logon attempt failed". To resolve this problem, you should manually fix the client file generated by this tool.

svcutil.exe [/t:code] <metadataDocumentPath>* | <url>* | <epr>

Argument Description
epr The path to an XML file that contains a WS-Addressing EndpointReference for a service endpoint that supports WS-Metadata Exchange. For more information, see the Metadata Download section.
metadataDocumentPath The path to a metadata document (wsdl or xsd) that contains the contract to import into code (.wsdl, .xsd, .wspolicy, or .wsmex).

Svcutil follows imports and includes when you specify a remote URL for metadata. However, if you want to process metadata files on the local file system, you must specify all files in this argument. In this way, you can use Svcutil in a build environment where you cannot have network dependencies. You can use wildcards (*.xsd, *.wsdl) for this argument.
url The URL to a service endpoint that provides metadata or to a metadata document hosted online. For more information on how these documents are retrieved, see the Metadata Download section.
Option Description
/async Generates both synchronous and asynchronous method signatures.

Default: generate only synchronous method signatures.

Short Form: /a
/collectionType:<type> Specifies the list collection type for a WCF client.

Default: collection type is System.Array.

Short Form: /ct
/config:<configFile> Specifies the filename for the generated configuration file.

Default: output.config
/dataContractOnly Generates code for data contract types only. Service Contract types are not generated.

You should only specify local metadata files for this option.

Short Form: /dconly
/enableDataBinding Implements the INotifyPropertyChanged interface on all Data Contract types to enable data binding.

Short Form: /edb
/excludeType:<type> Specifies a fully-qualified or assembly-qualified type name to be excluded from referenced contract types.

When using this switch together with /r from separate DLLs, the full name of the XSD class is referenced.

Short Form: /et
/importXmlTypes Configures the Data Contract serializer to import non-Data Contract types as IXmlSerializable types.
/internal Generates classes that are marked as internal. Default: generate public classes only.

Short Form: /i
/language:<language> Specifies the programming language to use for code generation. You should provide either a language name registered in the Machine.config file, or the fully qualified name of a class that inherits from CodeDomProvider.

Values: c#, cs, csharp, vb, visualbasic, c++, cpp

Default: csharp

Short form: /l
/mergeConfig Merges the generated configuration into an existing file, instead of overwriting the existing file.
/messageContract Generates Message Contract types.

Short Form: /mc
/namespace:<string,string> Specifies a mapping from a WSDL or XML Schema targetNamespace to a CLR namespace. Using '*' for the targetNamespace maps all targetNamespaces without an explicit mapping to that CLR namespace.

To make sure that the message contract name does not collide with operation name, you should either qualify the type reference with ::, or make sure the names are unique.

Default: Derived from the target namespace of the schema document for Data Contracts. The default namespace is used for all other generated types.

Short Form: /n Note: When generating types to use with XmlSerializer, only a single namespace mapping is supported. All generated types will either be in the default namespace or the namespace specified by '*'.
/noConfig Do not generate configuration files.
/noStdLib Do not reference standard libraries.

Default: Mscorlib.dll and System.servicemodel.dll are referenced.
/out:<file> Specifies the file name for the generated code.

Default: Derived from the WSDL definition name, WSDL service name or target namespace of one of the schemas.

Short form: /o
/reference:<file path> References types in the specified assembly. When generating clients, use this option to specify assemblies that might contain types that represent the metadata being imported.

You cannot specify message contracts and XmlSerializer types using this switch.

If DateTimeOffset referenced, this type is used instead of generating a new type. If the application is written using .NET Framework 3.5, SvcUtil.exe references DateTimeOffset automatically.

Short Form: /r
/serializable Generates classes marked with the Serializable Attribute.

Short Form: /s
/serviceContract Generate code for service contracts only. Client class and configuration will not be generated

Short Form: /sc
/serializer:Auto Automatically select the serializer. This tries to use the Data Contract serializer and uses the XmlSerializer if that fails.

Short Form: /ser
/serializer:DataContractSerializer Generates data types that use the Data Contract Serializer for serialization and deserialization.

Short Form: /ser:DataContractSerializer
/serializer:XmlSerializer Generates data types that use the XmlSerializer for serialization and deserialization.

Short Form: /ser:XmlSerializer
/targetClientVersion Specify which version of .NET Framework the application is targeting. Valid values are Version30 and Version35. The default value is Version30.

Short Form: /tcv

Version30: Use /tcv:Version30 if you are generating code for clients that use WinFX.

Version35: Use /tcv:Version35 if you are generating code for clients that use .NET Framework 3.5. When using /tcv:Version35 with the /async switch, both event-based and callback/delegate-based asynchronous methods are generated. In addition, support for LINQ-enabled DataSets and DateTimeOffset is enabled.
/wrapped Controls whether special-casing is used for document-literal styled documents with wrapped parameters. Use the /wrapped switch with the Service Model Metadata Utility Tool (Svcutil.exe) tool to specify normal casing.

Note

When the service binding is one of the system-provided bindings (see System-Provided Bindings), and the ProtectionLevel property is set to either None or Sign, Svcutil generates a configuration file using the <customBinding> element instead of the expected system-provided element. For example, if the service uses the <wsHttpBinding> element with the ProtectionLevel set to Sign, the generated configuration has <customBinding> in the bindings section instead of <wsHttpBinding>. For more information about the protection level, see Understanding Protection Level.

Svcutil.exe can export metadata for services, contracts and data types in compiled assemblies. To export metadata for a service, you must use the /serviceName option to specify the service you would like to export. To export all data contract types within an assembly, you should use the /dataContractOnly option. By default, metadata is exported for all service contracts in the input assemblies.

svcutil.exe [/t:metadata] [/serviceName:<serviceConfigName>] [/dataContractOnly] <assemblyPath>*

Argument Description
assemblyPath Specifies the path to an assembly that contains services, contracts or data contract types to be exported. Standard command line wildcards can be used to provide multiple files as input.
Option Description
/serviceName:<serviceConfigName> Specifies the configuration name of a service to be exported. If this option is used, an executable assembly with an associated configuration file must be passed as input. Svcutil.exe searches all associated configuration files for the service configuration. If the configuration files contain any extension types, the assemblies that contain these types must either be in the GAC or explicitly provided using the /reference option.
/reference:<file path> Adds the specified assembly to the set of assemblies used for resolving type references. If you are exporting or validating a service that uses 3rd-party extensions (Behaviors, Bindings and BindingElements) registered in configuration, use this option to locate extension assemblies that are not in the GAC.

Short Form: /r
/dataContractOnly Operates on data contract types only. Service Contracts are not processed.

You should only specify local metadata files for this option.

Short Form: /dconly
/excludeType:<type> Specifies the fully-qualified or assembly-qualified name of a type to be excluded from export. This option can be used when exporting metadata for a service, or a set of service contracts to exclude types from being exported. This option cannot be used together with the /dconly option.

When you have a single assembly containing multiple services, and each uses separate classes with the same XSD name, you should specify the service name instead of the XSD class name for this switch.

XSD or data contract types are not supported.

Short Form: /et

### Service Validation

Validation can be used to detect errors in service implementations without hosting the service. You must use the /serviceName option to indicate the service you want to validate.

svcutil.exe /validate /serviceName:<serviceConfigName> <assemblyPath>*

Argument Description
assemblyPath Specifies the path to an assembly that contains service types to be validated. The assembly must have an associated configuration file to provide service configuration. Standard command-line wildcards can be used to provide multiple assemblies.
Option Description
/validate Validates a service implementation specified by the /serviceName option. If this option is used, an executable assembly with an associated configuration file must be passed as input.

Short Form: /v
/serviceName:<serviceConfigName> Specifies the configuration name of a service to be validated. Svcutil.exe searches all associated configuration files of all input assemblies for the service configuration. If the configuration files contain any extension types, the assemblies that contains these types must either be in the GAC or explicitly provided using the /reference option.
/reference:<file path> Adds the specified assembly to the set of assemblies used for resolving type references. If you are exporting or validating a service that uses 3rd-party extensions (Behaviors, Bindings and BindingElements) registered in configuration, use this option to locate extension assemblies that are not in the GAC.

Short Form: /r
/dataContractOnly Operates on data contract types only. Service Contracts are not processed.

You should only specify local metadata files for this option.

Short Form: /dconly
/excludeType:<type> Specifies the fully-qualified or assembly-qualified name of a type to be excluded from validation.

Short Form: /et

Svcutil.exe can be used to download metadata from running services, and save the metadata to local files. To download metadata, you must specify the /t:metadata option. Otherwise, client code is generated. For HTTP and HTTPS URL schemes, Svcutil.exe attempts to retrieve metadata using WS-Metadata Exchange and DISCO. For all other URL schemes, Svcutil.exe only uses WS-Metadata Exchange.

• MEX (WS-Transfer) request to the supplied address

• MEX request to the supplied address with /mex appended

• DISCO request (using the DiscoveryClientProtocol from ASMX) to the supplied address.

By default, Svcutil.exe uses the bindings defined in the MetadataExchangeBindings class to make MEX requests. To configure the binding used for WS-Metadata Exchange, you must define a client endpoint in configuration that uses the IMetadataExchange contract. This can be defined either in the configuration file of Svcutil.exe, or in another configuration file specified using the /svcutilConfig option.

svcutil.exe /t:metadata <url>* | <epr>

Argument Description
url The URL to a service endpoint that provides metadata or to a metadata document hosted online.
epr The path to an XML file that contains a WS-Addressing EndpointReference for a service endpoint that supports WS-Metadata Exchange.

### XmlSerializer Type Generation

Services and client applications that use data types that are serializable using the XmlSerializer generate and compile serialization code for those data types at runtime, which can result in slow start-up performance.

Note

Pre-generated serialization code can only be used in client applications and not in services.

Svcutil.exe can generate the necessary C# serialization code from the compiled assemblies for the application, thus improving start-up performance for these applications. For more information, see How to: Improve the Startup Time of WCF Client Applications using the XmlSerializer.

Note

Svcutil.exe only generates code for types used by Service Contracts found in the input assemblies.

svcutil.exe /t:xmlSerializer <assemblyPath>*

Argument Description
assemblyPath Specifies the path to an assembly that contains service contract types. Serialization types are generated for all Xml Serializable types in each contract.
Option Description
/reference:<file path> Adds the specified assembly to the set of assemblies used for resolving type references.

Short Form: /r
/excludeType:<type> Specifies the fully-qualified or assembly-qualified name of a type to be excluded from export or validation.

Short Form: /et
/out:<file> Specifies the filename for the generated code. This option is ignored when multiple assemblies are passed as input to the tool.

Default: Derived from the assembly name.

Short Form: /o
/UseSerializerForFaults Specifies that the XmlSerializer should be used for reading and writing faults, instead of the default DataContractSerializer.

## Examples

The following command generates client code from a running service or online metadata documents.

svcutil http://service/metadataEndpoint

The following command generates client code from local metadata documents.

svcutil *.wsdl *.xsd /language:C#

The following command generates data contract types in Visual Basic from local schema documents.

svcutil /dconly *.xsd /language:VB

svcutil /t:metadata http://service/metadataEndpoint

The following command generates metadata documents for service contracts and associated types in an assembly.

svcutil myAssembly.dll

The following command generates metadata documents for a service, and all associated service contracts and data types in an assembly.

svcutil myServiceHost.exe /serviceName:myServiceName

The following command generates metadata documents for data types in an assembly.

svcutil myServiceHost.exe /dconly

The following command verifies service hosting.

svcutil /validate /serviceName:myServiceName myServiceHost.exe

The following command generates serialization types for XmlSerializer types used by any service contracts in the assembly.

svcutil /t:xmlserializer myContractLibrary.exe

## Maximum Nametable Character Count Quota

When using svcutil to generate metadata for a service, you may get the following message:

Error: Cannot obtain Metadata from http://localhost:8000/somesservice/mex The maximum nametable character count quota (16384) has been exceeded while reading XML data. The nametable is a data structure used to store strings encountered during XML processing - long XML documents with non-repeating element names, attribute names and attribute values may trigger this quota. This quota may be increased by changing the MaxNameTableCharCount property on the XmlDictionaryReaderQuotas object used when creating the XML reader.

This error can be caused by a service that returns a large WSDL file when you request its metadata. The problem is that the character quota for the svcutil.exe tool is exceeded. This value is set to help prevent denial of service (dos) attacks. You can increase this quota by specifying the following config file for svcutil.

The following config file shows how to set the reader quotas for svcutil

<?xml version="1.0" encoding="utf-8"?>
<configuration>
<system.serviceModel>
<bindings>
<customBinding>
<binding name="MyBinding">
<textMessageEncoding>
</textMessageEncoding>
</binding>
</customBinding>
</bindings>
<client>
<endpoint binding="customBinding" bindingConfiguration="MyBinding"
name="http" />
</client>
</system.serviceModel>
</configuration>


Create a new file called svcutil.exe.config and copy the XML example code into it. Then place the file in the same directory as svcutil.exe. The next time svcutil.exe is run it will pick up the new settings.

## Security Concerns

You should use the appropriate Access Control List (ACL) to protect Svcutil.exe's installation folder, Svcutil.config, and files being pointed to by /svcutilConfig. This can prevent malicious extensions from being registered and run.

In addition, to minimize the chance that security be compromised, you should not add untrusted extensions to be part of the system or use untrusted code providers with Svcutil.exe.

Finally, you should not use the tool in the middle-tier of your application, as it may cause denial-of-service to the current process.
