Image Service

Every piece of content returned by content APIs contains a field, ImageUrl, that is a direct link to the content's default image, hosted on https://musicimage.xboxlive.com/. This image link generates an image with specific default properties, but it is possible to modify the link in order to change some of the image properties, such as its size. Image resolution is context-aware, so the actual image might change depending on the size parameters used. The details of the image API are shown in this topic.

You should use the image URL given in the response. The URL should not be modified or altered other than with the parameters described below. Any other use of the images will be considered as a breach of the terms of use of the API.

You can optionally append to the URL the parameters shown in the following table.

Argument Type Description
w integer Optional. Image width. Cannot be set without height parameter.
h integer Optional. Image height. Cannot be set without width parameter.
mode string Image resize mode: 1. scale to resize to maximum size which fits dimension without changing the aspect ratio. 2. letterbox to pad to dimension after resize if aspect ratio didn't match. 3. crop to get the required width and height but image is cropped. Defaults to crop if w and h are provided.
background string HTML-compliant color for letterbox resize mode background. Cannot be specified if mode is not set to letterbox. The # character must be URL-encoded when specifying the letterbox background color. For example: https://musicimage.xboxlive.com/content/music.A83EB907-0100-11DB-89CA-0019B92A3933/image?locale=en-US&w=200&h=100&mode=letterbox&background=%23ff00ff

Changing these parameters can trigger different images. The service will always try to provide the best image for the requested ratio.

For example:

Default image:
https://musicimage.xboxlive.com/content/music.24540000-0200-11DB-89CA-0019B92A3933/image?locale=en-US
Default Image

Square image:
https://musicimage.xboxlive.com/content/music.24540000-0200-11DB-89CA-0019B92A3933/image?locale=en-US&w=200&h=200
Square image

Letterboxed:
https://musicimage.xboxlive.com/content/music.24540000-0200-11DB-89CA-0019B92A3933/image?locale=en-US&w=240&h=200&mode=letterbox
Letterboxed
