User Specific Views

Earlier if Adaptive Cards was sent in a Teams conversation, all users see the exact same card content. With the introduction of the Universal Actions model and refresh for Adaptive Cards, bot developers can now provide User Specific Views of Adaptive Cards to users. The same Adaptive Card can now refresh to a User Specific Adaptive Card. Maximum 60 different users can see a different version of the card with additional information or actions. This provides powerful scenarios like approvals, poll creator controls, ticketing, incident management, and project management cards.

For example, Megan, a safety inspector at Contoso, wants to create an incident and assign it to Alex. She also wants everyone in the team to be aware about the incident. Megan uses Contoso incident reporting message extension powered by Universal Actions for Adaptive Cards.

User Specific Views for Adaptive Cards

The following code provides an example of Adaptive Cards:

{
  "$schema": "http://adaptivecards.io/schemas/adaptive-card.json",
  "type": "AdaptiveCard",
  "originator":"c9b4352b-a76b-43b9-88ff-80edddaa243b",
  "version": "1.4",
  "refresh": {
    "action": {
      "type": "Action.Execute",
      "title": "Refresh",
      "verb": "editOrResolveView",
      "data": {
              "refresh info": "<refresh info>"
    },
    "userIds": ["<Megan's user MRI>", "<Alex's user MRI>"]
  },
  "body": [
    {
      "type": "TextBlock",
      "text": "Incident 1234"
    },
    {
      "type": "TextBlock",
      "text": "Incident details: <incident details>"
    }
  ]
}

To send Adaptive Cards, refresh User Specific Views, and invoke requests to the bot

  1. When Megan creates a new incident, the bot sends the Adaptive Card or common card with incident details in the Teams conversation.
  2. Now this card automatically refreshes to User Specific View for Megan and Alex. Alex's and Megan's user MRIs are added in userIds property of refresh property of the Adaptive Card JSON. The card remains the same for other users in the conversation.
  3. For Megan, automatic refresh triggers an adaptiveCard/action invoke request to the bot. The bot can return an incident creator card with Edit button as a response to this invoke request.
  4. Similarly for Alex, automatic refresh triggers another adaptiveCard/action invoke request to the bot. The bot can return an incident owner card Resolve button as a response to this invoke request.

Invoke request sent from Teams client to the bot

The following code provides an example of an invoke request sent from Alex's and Megan's Teams client to the bot:

{
  "type": "invoke",
  "name": "adaptiveCard/action",

  // ... other properties omitted for brevity

  "value": {
    "action": {
      "type": "Action.Execute",
      "id": "",
      "verb": "editOrResolveView",
      "data": { 
            "refresh info": "<refresh info>"
      }
    },
    "trigger": "automatic"
  }
}

adaptiveCard/action invoke response card

The following code provides an example of an adaptiveCard/action invoke response card for Megan:

{
  "$schema": "http://adaptivecards.io/schemas/adaptive-card.json",
  "type": "AdaptiveCard",
  "originator":"c9b4352b-a76b-43b9-88ff-80edddaa243b",
  "version": "1.4",
  "refresh": {
    "action": {
      "type": "Action.Execute",
      "title": "Refresh",
      "verb": "editOrResolveView"
    },
    "userIds": ["<Megan's user MRI>", "<Alex's user MRI>"]
  },
  "body": [
    {
      "type": "TextBlock",
      "text": "Incident 1234"
    },
    {
      "type": "TextBlock",
      "text": "Incident details: <incident details>"
    }
  ],
  "actions": [
    {
      "type": "Action.Execute",
      "title": "Edit",
      "verb": "edit",
      "data": {
            "additional info": "<additional info>",
            ...
      }
    }
  ]
}

adaptiveCard/action invoke response card for Alex

The following code provides an example of an adaptiveCard/action invoke response card for Alex:

{
  "$schema": "http://adaptivecards.io/schemas/adaptive-card.json",
  "type": "AdaptiveCard",
  "originator":"c9b4352b-a76b-43b9-88ff-80edddaa243b",
  "version": "1.4",
  "refresh": {
    "action": {
      "type": "Action.Execute",
      "title": "Refresh",
      "verb": "editOrResolveView"
    },
    "userIds": ["<Megan's user MRI>", "<Alex's user MRI>"]
  },
  "body": [
    {
      "type": "TextBlock",
      "text": "Incident 1234"
    },
    {
      "type": "TextBlock",
      "text": "Incident details: <incident details>"
    }
  ],
  "actions": [
    {
      "type": "Action.Execute",
      "title": "Resolve",
      "verb": "resolve",
      "data": {
            "additional info": "<additional info>",
            ...
      }
    }
  ]
}

Invoke response to return Adaptive Cards

The following code provides an example of an invoke response to return Adaptive Cards:

string cardJson = "<adaptive card json>";
var card = JsonConvert.DeserializeObject(cardJson);

var adaptiveCardResponse = JObject.FromObject(new
 {
    statusCode = 200,
    type = "application/vnd.microsoft.adaptive.card",
    value = card
 });

Card design guidelines to keep in mind while designing User Specific Views:

  • You can create a maximum of 60 User Specific Views for a particular card sent to a chat or channel by specifying their userIds in the refresh section.
  • Base Card: The base version of the card that the bot developer sends to the chat. This is the version of the Adaptive Card for all users who are not specified in the userIds section.
  • A message update can be used to update the base card and simultaneously refresh the User Specific Card. Opening the chat or channel also refreshes the card for users with refresh enabled.
  • For scenarios with larger groups where users switch to a view on action, which needs dynamic updates for responders, you can keep adding up to 60 users to the userIds list. You can remove the first responder from the list when the 61st user responds. For the users who get removed from the userIds list, you can provide a manual refresh button or use the refresh button in the message options menu to get the latest result.
  • Give a prompt to users to get a User Specific View, where they see only a particular view of the card or some actions.
