How to change the export resolution of a PowerPoint slide

You can change the export resolution in Microsoft PowerPoint by saving a slide in a picture format. There are two steps to this process: using the system registry to change the default resolution setting for exported slides, and then actually saving the slide as a picture at the new resolution.

Step 1: Change the export resolution setting

Important

Follow the steps in this section carefully. Serious problems might occur if you modify the registry incorrectly. Before you modify it, back up the registry for restoration in case problems occur.

By default, the export resolution of a PowerPoint slide that you want to save as a picture is 96 dots per inch (dpi). To change the export resolution, follow these steps:

  1. Exit all Windows-based programs.

  2. Right-click the Start button and then Run. (In Windows 7, select Start, and then Run.)

  3. In the Open box, type regedit, and then select OK.

  4. Locate one of the following registry subkeys, depending on the version of PowerPoint that you're using:

    PowerPoint 2016

    HKEY_CURRENT_USER\Software\Microsoft\Office\16.0\PowerPoint\Options

    PowerPoint 2013

    HKEY_CURRENT_USER\Software\Microsoft\Office\15.0\PowerPoint\Options

    PowerPoint 2010

    HKEY_CURRENT_USER\Software\Microsoft\Office\14.0\PowerPoint\Options

    PowerPoint 2007

    HKEY_CURRENT_USER\Software\Microsoft\Office\12.0\PowerPoint\Options

    PowerPoint 2003

    HKEY_CURRENT_USER\Software\Microsoft\Office\11.0\PowerPoint\Options

  5. Click the Options subkey, point to New on the Edit menu, and then click DWORD Value.

  6. Type ExportBitmapResolution, and then press Enter.

  7. Make sure that ExportBitmapResolution is selected, and then click Modify on the Edit menu.

  8. In the Edit DWORD Value dialog box, select Decimal.

  9. In the Value data box, type the value of the resolution that you want such as 300. Or, use the parameters in the following table.

    Decimal value Full-screen pixels (horizontal × vertical) Widescreen pixels (horizontal × vertical) Dots per inch (horizontal and vertical)
    50 500 × 375 667 × 375 50 dpi
    96 (default) 960 × 720 1280 × 720 96 dpi
    100 1000 × 750 1333 × 750 100 dpi
    150 1500 × 1125 2000 × 1125 150 dpi
    200 2000 × 1500 2667 × 1500 200 dpi
    250 2500 × 1875 3333 × 1875 250 dpi
    300 3000 × 2250 4000 × 2250 300 dpi

    Note

    See the Limitations section for more information when you set this value.

  10. Select OK.

  11. On the File menu, select Exit to exit Registry Editor.

Step 2: Export the slide as a picture

  1. In PowerPoint, open your slide presentation, and then open the slide that you want to export.

  2. On the File menu, select Save As.

  3. In the Save as type box, select one of the following picture formats:

    • GIF Graphics Interchange Format (.gif)
    • JPEG File Interchange Format (*.jpg)
    • PNG Portable Network Graphics Format (*.png)
    • TIFF Tag Image File Format (*.tif)
    • Device Independent Bitmap (*.bmp)
    • Windows Metafile (*.wmf)
    • Enhanced Windows Metafile (*.emf)

Note

You may want to change the picture's save location in the Save in box. You may also want to change the name of the picture in the File name box.

  1. Select Save. You will be prompted with the following dialog box:

    Select Current Slide Only.

    Select Current Slide Only. The slide is saved in the new format and resolution, in the location that you specified in the Save in box.

  2. To verify that the slide is saved in the resolution that you specified, right-click the picture, and then select Properties.

Limitations

When you set the ExportBitmapResolution registry value in PowerPoint, there's a maximum DPI limitation to consider for some versions of PowerPoint.

Maximum DPI is dependent upon the slide size. The formula is: maxdpi = (sqrt(100,000,000 / (slide with * slide height)), where slide width/height are in inches.

For example, for a standard 13.3” x 7.5” slide, the equation would be: sqrt(100,000,000 / (13.333 * 7.5) ) = 1000.

PowerPoint 2019, 2016, 2013, and 365

There is no fixed DPI limit. Slide export is only limited by how big the resulting bitmap gets. PowerPoint can support creating bitmaps up to ~100,000,000 pixels (width x height). For standard widescreen slides (13.3” x 7.5”) this means a maximum DPI of 1000. For the old style 10” x 7.5” slides this means a maximum of 1155 DPI, but depending on slide size, this can be more or less.

PowerPoint 2010 and older

The maximum resolution that PowerPoint can export is 3072 pixels, based on the longest edge of the slide. For example, the standard 10" × 7.5" slide has a maximum effective DPI value of 307. The 3070-pixel result (10 × 307 = 3070) falls within the 3072 limit. However, any DPI setting that's greater than 307 for a standard slide reverts to the limit of 3072.

Decimal value Pixels (horizontal × vertical) Dots per inch (horizontal and vertical)
307 3072 × 2304 307 dpi

The 3072-pixel limit also applies to saving the slide programmatically.

For example, the following code programmatically saves a picture with dimensions of 3072 × 2304 pixels:

ActiveWindow.Selection.SlideRange(1).export
"c:\<filename>.jpg","JPG",4000,3000

More information

For information about changing the size of your slides, see Change the size of your slides.
