Install and configure the Expense Report sample for canvas apps in PowerApps

Step-by-step instructions for installing and configuring the Expense Report sample. You can also preview the sample app here.

Estimated time to complete these steps: 10-15 minutes

Tip

Watch this video for a demonstration of how to use the Expense Report sample app.

Track expense reports from submission to approval. Tally line items as individual expenses accrue and submit for approval when ready. This app requires a small amount of setup to make it your own.

Opening screen of the Expense Report PowerApp

Tip

Watch this video to see how to use the Expense Report PowerApps Sample.

Prerequisites

Create the Expenses SharePoint list

This list stores the expense reports.

  1. Open a web browser and navigate to https://portal.office.com.

  2. Log in with an account that has permission to create lists.

  3. Navigate to the site collection where you want the Expenses list to reside.

  4. Click the gear icon in the top right portion of the web page.

  5. Click Add an app.

  6. In the Find an app textbox, enter Custom.

  7. Click the search icon.

  8. Click the Custom List app.

  9. In the Name textbox, enter Expenses.

    Important

    If you choose a different name for the list make sure you write it down because you will need to substitute it for Expenses everywhere you see it during the installation and configuration process.

  10. Click Create.

Create Cost Center column

  1. Click the Expenses list.
  2. Click the gear icon in the top right portion of the web page.
  3. Click List settings.
  4. Click Create column.
  5. In the Column name textbox enter Cost Center.
  6. In the type of information in this column is radio button list, select Choice.
  7. In the Type each choice on a separate line textbox enter the following values, each on a separate line:
    • Microsoft
    • Contoso
  8. In the Default value textbox, enter Microsoft.
  9. Click OK.

Create Comments column

  1. Click Create column.
  2. In the Column name textbox enter Comments.
  3. In the type of information in this column is radio button list, select Multiple lines of text.
  4. Click OK.

Create Status column

  1. Click the Expenses list.
  2. Click the gear icon in the top right portion of the web page.
  3. Click List settings.
  4. Click Create column.
  5. In the Column name textbox enter Status.
  6. In the type of information in this column is radio button list, select Choice.
  7. In the Type each choice on a separate line textbox enter the following values, each on a separate line:
    • Open
    • Pending
    • Approved
  8. In the Default value textbox, enter Open.
  9. Click OK.

Create ApproverName column

  1. Click Create column.
  2. In the Column name textbox enter ApproverName.
  3. In the type of information in this column is radio button list, select Person or Group.
  4. In the Require that this column contains information radio button list, select Yes.
  5. Click OK.

Create DateSubmitted column

  1. Click Create column.
  2. In the Column name textbox enter DateSubmitted.
  3. In the type of information in this column is radio button list, select Date and Time.
  4. In the Require that this column contains information radio button list, select Yes.
  5. Click OK.

Create StartDate column

  1. Click Create column.
  2. In the Column name textbox enter StartDate.
  3. In the type of information in this column is radio button list, select Date and Time.
  4. In the Require that this column contains information radio button list, select Yes.
  5. Click OK.

Create EndDate column

  1. Click Create column.
  2. In the Column name textbox enter EndDate.
  3. In the type of information in this column is radio button list, select Date and Time.
  4. In the Require that this column contains information radio button list, select Yes.
  5. Click OK.

Create the Line Items SharePoint list

This list stores the lines items associated with expense reports.

  1. Navigate to the same site collection where you created the Expense list.

  2. Click the gear icon in the top right portion of the web page.

  3. Click Add an app.

  4. In the Find an app textbox, enter Custom.

  5. Click the search icon.

  6. Click the Custom List app.

  7. In the Name textbox, enter LineItems.

    Important

    If you choose a different name for the list make sure you write it down because you will need to substitute it for Expense everywhere you see it during the installation and configuration process.

  8. Click Create.

Create Category column

  1. Click the LineItems list.
  2. Click the gear icon in the top right portion of the web page.
  3. Click List settings.
  4. Click Create column.
  5. In the Column name textbox enter Category.
  6. In the type of information in this column is radio button list, select Choice.
  7. In the Type each choice on a separate line textbox enter the following values, each on a separate line:
    • Food & Beverage
    • Transportation
    • Business needs
  8. In the Default value textbox, enter Food & Beverage.
  9. Click OK.

Create Cost column

  1. Click Create column.
  2. In the Column name textbox enter Cost.
  3. In the type of information in this column is radio button list, select Number (1, 10, 100).
  4. In the Require that this column contains information radio button list, select Yes.
  5. Click OK.

Create Date column

  1. Click Create column.
  2. In the Column name textbox enter Date.
  3. In the type of information in this column is radio button list, select Date and Time.
  4. In the Require that this column contains information radio button list, select Yes.
  5. Click OK.

Create Description column

  1. Click Create column.
  2. In the Column name textbox enter Description.
  3. In the type of information in this column is radio button list, select Multiple lines of text.
  4. In the Require that this column contains information radio button list, select Yes.
  5. In the Specify the type of text to allow radio button list, select Plain text.
  6. Click OK.

Create ReportID column

  1. Click Create column.
  2. In the Column name textbox enter ReportID.
  3. In the type of information in this column is radio button list, select Lookup (information already on this site).
  4. In the Require that this column contains information radio button list, select Yes.
  5. In the Get information from dropdown list, select the Expense list you created.
  6. In the In this column dropdown list, select ID.
  7. Click OK.

Edit Title column

  1. Click the Title column link.
  2. In the Require that this column contains information radio button list, select No.
  3. Click OK.

Download the Expense Report PowerApp

  1. In a web browser, navigate to the following link:

    http://pappsfeprodwestuscontent.blob.core.windows.net/sampleapps/myexpenses/docs/MyExpenses(SP_List).zip.

  2. Download the Expense Report PowerApps Sample package and save it to your machine.

Create connections

  1. In a web browser, navigate to web.powerapps.com.
  2. Sign in by providing the same credentials that you used to sign up.
  3. In the menu on the left, select Connections.

Create Approvals connection

  1. Click + New connection.
  2. In the Search textbox, enter Approvals.
  3. Select Approvals in the list.
  4. Click Create.

Create Office 365 Outlook connection

  1. Click + New connection.
  2. In the Search textbox, enter Office 365 Outlook.
  3. Select Office 365 Outlook in the list.
  4. Click Create.
  5. In the popup window, select the account you logged in with.

Create SharePoint connection

  1. Click + New connection.
  2. In the Search textbox, enter SharePoint.
  3. Select SharePoint in the list.
  4. Click Create.
  5. In the popup window, select the account you logged in with.

Import the Expense Report PowerApp

  1. In a web browser, navigate to https://web.powerapps.com.

  2. Sign in by providing the same credentials that you used to sign up.

  3. In the menu on the left, select Apps.

  4. Click Import package(preview).

    Import package screen

  5. Click the Upload button and select the PowerApp package you downloaded in previous steps.

  6. For the App and Flow resource types, set IMPORT SETUP to Create as new.

  7. For the SharePoint and Outlook connections, set IMPORT SETUP to Select during import.

    Import settings screen

  8. Click the red icon for the SharePoint Connection.

  9. In the connections list, click the item with your username.

    Import settings screen

  10. Click Save.

  11. Click the red icon for the Approval Connection.

  12. In the connections list, click the item with your username.

    Import settings screen

  13. Click Save.

  14. Click the red icon for the Office 365 Outlook Connection.

  15. In the connections list, click the item with your username.

    Import settings screen

  16. Click Save.

    Tip

    When you are done, it will look like this:

    Import settings screen

  17. Click Import and wait until the process is complete.

    Import settings screen

Configure the PowerApp to use the SharePoint lists

  1. In the web browser, click Apps.
  2. Click the ellipses next to the Expense Report PowerApp.
  3. Click Edit on the web.
  4. Click Allow.

Delete connections

  1. Click View.
  2. Click Data sources.
  3. In the Data pane, click the ellipses next to Expenses.
  4. Click Remove.
  5. In the Data pane, click the ellipses next to LineItems.
  6. Click Remove.

Expenses list

  1. Click View.

  2. Click Data sources.

  3. In the Data pane, click + Add data source.

  4. Click + New connection.

  5. Select SharePoint.

  6. Click Create.

  7. In the Recent sites list, select the SharePoint site where you created the Expenses List.

    Tip

    If the site does not appear in the list, enter the URL to the SharePoint site in the textbox and click, Go.

  8. In the Search textbox at the top of the list enter Expenses.

  9. Check the checkbox next to the Expenses list.

  10. Click Connect.

LineItems list

  1. Click View.

  2. Click Data sources.

  3. In the Data pane, click + Add data source.

  4. Click + New connection.

  5. Select SharePoint.

  6. Click Create.

  7. In the Recent sites list, select the SharePoint site where you created the LineItems List.

    Tip

    If the site does not appear in the list, enter the URL to the SharePoint site in the textbox and click, Go.

  8. In the Search textbox at the top of the list enter LineItems.

  9. Check the checkbox next to the LineItems list.

  10. Click Connect.

  11. Click File.

  12. Click Save.

  13. Click Publish.

  14. Click Publish this version.

Modify the Flow

  1. In the menu on the left, click Flows.

  2. If prompted to sign in, sign in by providing the same credentials that you used to sign up.

  3. Select My flows in the top menu.

  4. Next to the ApproveExpense Flow, click the pencil icon.

    Edit Flow screen

  5. Expand the Get items action.

  6. Change the Site Address and List Name to match the Expense SharePoint list you created.

    Edit Flow screen

    Tip

    You don’t need to type it manually, you can choose it in the dropdown lists.

  7. Expand the Condition.

  8. Expand the If yes section.

  9. Expand the Change item status to Approved action.

  10. Change the Site Address and List Name to match the Expense SharePoint list you created.

    Edit Flow screen

    Tip

    You don’t need to type it manually, you can choose it in the dropdown lists.

  11. Expand the If no section.

  12. Expand the Change item status to Open action.

  13. Change the Site Address and List Name to match the Expense SharePoint list you created.

    Edit Flow screen

    Tip

    You don’t need to type it manually, you can choose it in the dropdown lists.

  14. Click Update flow.

Play the PowerApp

  1. In the web browser, click Apps.
  2. Click the ellipses next to the Expense Report PowerApp.
  3. Click Open.

Next steps
