Building Microsoft Teams Tabs using SharePoint Framework

Starting with SharePoint Framework v1.8, you can build tabs for Microsoft Teams using SharePoint Framework tooling and use SharePoint as a host for your solutions

There are following benefits on using SharePoint Framework as the platform for your Microsoft Teams tabs:

  • The development model is similar to SharePoint Framework web parts
  • Technically any web part can be exposed as a tab in Microsoft Teams
  • You have difference scoping options on exposing your custom tab as a web part and tab in your tenant
  • Your tab will be executed in the context of the underlaying SharePoint site behind of the specific team. This means that you can take advantage of any SharePoint specific APIs or functionalities in your web part.

Development process

Important

Sync to Teams functionality does not currently work and will be fixed within upcoming days. Please refer to Creating a team manifest manually for a web part to proceed for now and follow the steps in the 'Alternative deployment options' section of this article.

You can start developing Microsoft Teams tabs simply by using the SharePoint Framework 1.8 or later packages. High level steps to get started are as follows.

  1. Start the SharePoint Framework Yeoman generator

    yo @microsoft/sharepoint

  2. Create a solution with a client-side web part

  3. Add "TeamsTab" to the supportedHosts property of the web part manifest:

    "supportedHosts": ["SharePointWebPart","TeamsTab"],

  4. Deploy the web part using tenant-scoped deployment option to your SharePoint app catalog

  5. Synchronize your solution with teams by clicking the sync button in the ribbon with the solution highlighted

    Sync To Teams

Note

You can also follow the detailed steps to get started from the Building Microsoft Teams tab using SharePoint Framework tutorial.

Deployment options

There are few different options on getting the developed Microsoft Teams tab deployed. As both SharePoint and Microsoft Teams have their own app catalog, deployment requires operations on both services. Visibility of the new functionality can be controlled by the deployment steps taken.

If you want to make a solution available to all teams in your organization, the easiest is to use the steps above.

If you however want to make a solution only available to a specific team you will have to step specific manual steps as described below.

Tenant deployment

The easiest way to deploy a SharePoint Framework solution is by following the steps above: you synchronize your solution with the teams app catalog by means of clicking the ribbon button. This will make your solution available for all users in your tenant and Microsoft Teams teams.

Alternative deployment options

There is an alternative way to deploy your solution which will for instance allow you to make a solution available only to one specific team in your tenant. Please refer to Create Microsoft Teams manifest manually for a web part and deploy it to Microsoft Teams how to create the manifest.

  1. Locate the Teams folder in your project folder:

    Solution structure

  2. Notice that there are 2 image files in there. Add the manifest file you created as described in Create Microsoft Teams manifest manually for a web part and deploy it to Microsoft Teams to this folder and call it manifest.json.

  3. In the JSON above we inserted some placeholders. Replace them as follows (notice that placeholders can occur several times):

    Placeholder Value
    [YourWebPartTitle] Enter the name of your package. For instance 'Leads'.
    [YourWebPartId] Replace this with the id/guid of your web part. You can find this id in the manifest of the webpart.
    [YourDescription] Replace this with the description of your solution.
  4. Build your solution the normal way using gulp bundle --ship and gulp package-solution --ship

  5. After you added the manifest to the folder, zip the -contents- of the folder into a zip file. This means that the zip file should only contain the manifest.json and the 2 images.

  6. Add your solution to the app catalog and make sure to check Make this solution available to all sites in the organization

Turn on side loading of external apps in Teams

In order to upload an app for a specific team, you will have to enable side loading. The following configuration steps must be performed only once in a tenant.

  1. Navigate to the Microsoft 365 Admin center by selecting Admin from the app launcher.

    Moving to admin UI

  2. Choose Settings and Services & add-ins from the left menu

  3. Select Microsoft Teams from the list of services you want to manage

    Moving to admin UI

  4. Extend the Apps section under Tenant-wide settings

    Moving to admin UI

  5. Ensure that Allow sideloading of external apps setting is enabled

    Moving to admin UI

  6. Click Save.

    Note

    The side loading configuation to be done only once in a tenant which you are using. More content on preparing your Office 365 tenant for Microsoft Teams development from the Microsoft Teams developer documentation.

  7. Move to your Microsoft Teams instance by selecting Teams in the app launcher.

    Zip file in explorer

  8. Choose a Team which you want to use for testing the capability and select Manage team from the ... menu.

    Manage Team

  9. Move to Apps tab

  10. Choose Upload a custom app from the bottom right corner

    Note

    If this setting is not available, side loading is not enabled in the tenant which you are using. Double check the settings from the tenant admin UIs.

  11. Upload the zip file your created earlier from the Teams folder under your newly created solution and ensure that it's properly visible in the list of Apps. Notice how the custom image is visible with the description of the solution.

    Manage Team

  12. Move to a channel in the Team where you just uploaded the solution. In below picture we have activated the General channel in Team

    Channel activated

  13. Click + to add a new tab on the channel

  14. Click your custom Tab called MyFirstTeamTab in the list

    Add a tab

  15. Notice how you can parametrize the tab instance based on the exposed properties. Click Save

    Add a tab

See following resources for additional details around the different options in both systems:

Detecting if web part is in Teams context

Page context in a web part has by default a reference to the Teams JavaScript SDK, so that you can easily get access on the Teams context when your web part is rendered as a tab.

    this.context.microsoftTeams

Note

See more information around th Microsoft Teams tab context from the Microsoft Teams development documentation.

See also
