Basic Availability Groups (Always On Availability Groups)
Always On Basic Availability Groups provide a high availability solution for SQL Server 2016 and SQL Server 2017 Standard Edition. A basic availability group supports a failover environment for a single database. It is created and managed much like traditional (advanced) Always On Availability Groups (SQL Server) with Enterprise Edition. The differences and limitations of basic availability groups are summarized in this document.
Always On Basic Availability Groups replaces the deprecated Database Mirroring feature and provides a similar level of feature support. Basic availability groups enable a primary database to maintain a single replica. This replica can use either synchronous-commit mode or asynchronous-commit mode. For more information about availability modes, see Availability Modes (Always On Availability Groups). The secondary replica remains inactive unless there is a need to failover. This failover reverses the primary and secondary role assignments, causing the secondary replica to become the primary active database. For more information on failover, see Failover and Failover Modes (Always On Availability Groups). Basic availability groups can operate in a hybrid environment that spans on-premises and Microsoft Azure.
Basic availability groups use a subset of features compared to advanced availability groups on SQL Server 2016 Enterprise Edition. Basic availability groups include the following limitations:
Limit of two replicas (primary and secondary).
No read access on secondary replica.
No backups on secondary replica.
No integrity checks on secondary replicas.
No support for replicas hosted on servers running a version of SQL Server prior to SQL Server 2016 Community Technology Preview 3 (CTP3).
Support for one availability database.
Basic availability groups cannot be upgraded to advanced availability groups. The group must be dropped and re-added to a group that contains servers running only SQL Server 2016 Enterprise Edition.
Basic availability groups are only supported for Standard Edition servers.
Basic availability groups can not be part of a distributed availability group.
An Always On basic availability group can be created on any two SQL Server 2016 Standard Edition servers. When you create a basic availability group, you must specify both replicas during creation.
To create a basic availability group, use the CREATE AVAILABILITY GROUP transact-SQL command and specify the WITH BASIC option (the default is ADVANCED). For more information, see CREATE AVAILABILITY GROUP (Transact-SQL). At this time, there is no UI support to create basic availability groups in SQL Server Management Studio.
The limitations of basic availability groups apply to the CREATE AVAILABILITY GROUP command when WITH BASIC is specified. For example, you will get an error if you attempt to create a basic availability group that permits read access. Other limitations apply in the same manner. Refer to the Limitations section of this topic for details.
