Surface Hub 2S 85" overview & tech specs

The 85" version of the Surface Hub family brings the Surface Hub 2S experience to spaces requiring a larger screen such as conference rooms, board rooms, or larger huddle spaces. Surface Hub 2S 85” delivers the following experiences:

  • Designed for group collaboration. Invites simultaneous inking in Microsoft Whiteboard plus larger-than-life remote attendees in Microsoft Teams.
  • Consistent Surface Hub 2S experience. Provides the same premium design, 4K display technology, touch, pen/ink, compute cartridge, and camera support as Surface Hub 2S 50”.
  • Integration with existing and new A/V systems. Combines with Microsoft Teams certified peripherals and integrates with Microsoft Teams Rooms.

Surface Hub 2S 85".

Surface Hub 2S 85" tech specs

Component Description
Dimensions 44.5” x 77.1” x 3.4”
(1130 mm x 1959 mm x 85.6 mm)
Shipping dimensions 89.5” x 62” x 22.8”
(2275 mm x 1573 mm x 580 mm)
Weight 185 lbs (84 kg)
Shipping weight 399 lbs (181 kg)
Resolution 3840 x 2160
Display PixelSense™ Display, 16:9 aspect ratio, 10-bit color, 30.5mm border width, anti-glare, IPS LCD, in-cell touch with 20 simultaneous touch points
Compute Modular Compute Cartridge
Quad-core 8th Generation Intel® Core™ i5 processor, 8GB RAM, 128GB SSD1
Software2 Windows 10 Team OS
Microsoft Teams for Surface Hub
Skype for Business
Microsoft Whiteboard
Microsoft Office (Mobile)
Microsoft Power BI
Connections USB-A
Mini-DisplayPort Video Output
RJ45 Gigabit Ethernet
HDMI Video Input
USB-C® with DisplayPort Input
(3) USB-C® (on display)
Graphics Intel® UHD Graphics 620
Audio/video 100Hz - 12KHz range 3-way stereo speakers, including (2) mid/high-range and (1) mid/low-range in rear bump.
Full band 8-element MEMS microphone array
Microsoft Surface Hub 2 Camera, 4K, USB-C® connection, 90-degree HFOV
Pen Microsoft Surface Hub 2 Pen (active)
Surface Slim Pen compatible
Sensors Doppler occupancy sensor3
Wireless Wi-Fi 5: IEEE 802.11 a/b/g/n/ac compatible
Bluetooth® Wireless 5.0 technology
Miracast Display
Exterior Casing: Precision machined aluminum with mineral-composite resin
Color: Platinum
Physical Buttons: Power, Volume, Source
What’s in the box (1) Surface Hub 2S
(2) Surface Hub 2 Pen
(1) Surface Hub 2 Camera
4m AC Power Cable
Quick Start Guide
Warranty 1-year limited hardware warranty4
BTU 2047 BTU/hr
Input Voltage 50/60Hz 110/230v nominal, 90-265v max
Input power, operating 665 W (745 W Surge Load)
Input Current 7.8 A
Input Power, standby 5 W max

Note

Surface Hub can be used continuously for a maximum of 18 hours a day. To optimize for efficiency, Surface Hub uses smart sensors to turn off the LED screen when presence is no longer detected, which means there is no need to power it down at the end of the day. If the unit is installed in a 24-hour workplace environment, the sensors can be disabled to comply with the 18 hour per day maximum use recommendation. Note that prolonged display of a video signal may cause burned-in or image retention to occur on the screen. To learn more about managing power settings, see:

References

  1. System software and updates use significant storage space. Available storage is subject to change based on system software and updates and apps usage. 1 GB = 1 billion bytes. 1 TB = 1,000 GB. See Surface Storage for more details.
  2. Software license required for some features. Sold separately.
  3. Doppler sensor not available in Hong Kong, India, Kuwait, and Oman.
  4. Microsoft's Limited Warranty is in addition to your consumer law rights.
