In Visual Studio, you can create applications that connect to data in virtually any database product or service, in any format, anywhere—on a local machine, on a local area network, or in a public, private, or hybrid cloud.
The following lists show just a few of the many database and storage systems that can be used from Visual Studio. The Microsoft Azure offerings are data services that include all provisioning and administration of the underlying data store. Azure Tools for Visual Studio is an optional component that enables you to work with Azure data stores directly from Visual Studio. Most of the other SQL and NoSQL database products that are listed here can be hosted on a local machine, on a local network, or in Microsoft Azure on a virtual machine. In this scenario, you are responsible for managing the database itself.
|SQL Database||DocumentDB||Storage (blobs, tables, queues, files)|
|SQL Data Warehouse||SQL Server Stretch Database||StorSimple|
|SQL Server 2005-2016, including Express and LocalDB||Firebird||MariaDB|
Many database vendors and third parties support Visual Studio integration by NuGet packages. You can explore the offerings on nuget.org or through the NuGet Package Manager in Visual Studio (Tools > NuGet Package Manager > Manage NuGet Packages for Solution). Other database products integrate with Visual Studio as an extension. You can browse these offerings in the Visual Studio Gallery by navigating to Tools > Extensions and Updates and then selecting Online in the left pane of the dialog box. For more information, see Installing database systems, tools, and samples.
Extended support for SQL Server 2005 ended on April 12, 2016. There is no guarantee that data tools in Visual Studio 2015 and later will continue to work with SQL Server 2005 after this date. For more information, see the end-of-support announcement for SQL Server 2005.
All .NET data access, including in .NET Core, is based on ADO.NET, a set of classes that defines an interface for accessing any kind of data source, both relational and non-relational. Visual Studio has several tools and designers that work with ADO.NET to help you connect to databases, manipulate the data, and present the data to the user. The documentation in this section describes how to use those tools. You can also program directly against the ADO.NET command objects. For more information about calling the ADO.NET APIs directly, see ADO.NET in the MSDN Library.
For data-access documentation specifically related to ASP.NET, see Working with Data on the ASP.NET site. For a tutorial on using Entity Framework with ASP.NET MVC, see Getting Started with Entity Framework 6 Code First using MVC 5.
Universal Windows Platform (UWP) apps in C# or Visual Basic can use the Microsoft Azure SDK for .NET to access Azure Storage and other Azure services. The Windows.Web.HttpClient class enables communication with any RESTful service. For more information, see How to connect to an HTTP server using Windows.Web.Http.
For data storage on the local machine, the recommended approach is to use SQLite, which runs in the same process as the app. If an object-relational mapping (ORM) layer is required, you can use Entity Framework. For more information, see Data access in the Windows Developer Center.
If you are connecting to Azure services, be sure to download the latest Azure SDK tools.
For a database to be consumable in ADO.NET, it must have a custom ADO.NET data provider or else must expose an ODBC or OLE DB interface. Microsoft provides a list of ADO.NET data providers for SQL Server products as well as ODBC and OLE DB providers.
In .NET, you have three choices for modeling and manipulating data in memory after you have retrieved it from a data source:
The preferred Microsoft ORM technology. You can use it to program against relational data as first-class .NET objects. For new applications, it should be the default first choice when a model is required. It requires custom support from the underlying ADO.NET provider.
LINQ to SQL
An earlier-generation object-relational mapper. It works well for less complex scenarios but is no longer in active development.
The oldest of the three modeling technologies. It is designed primarily for rapid development of "forms over data" applications in which you are not processing huge amounts of data or performing complex queries or transformations. A DataSet object consists of DataTable and DataRow objects that logically resemble SQL database objects much more than .NET objects. For relatively simple applications based on SQL data sources, datasets might still be a good choice.
There is no requirement to use any of these technologies. In some scenarios, especially where performance is critical, you can simply use a DataReader object to read from the database and copy the values that you need into a collection object such as List<T>.
C++ applications that connect to SQL Server should use the Microsoft® ODBC Driver 13.1 for SQL Server in most cases. If the servers are linked, then OLE DB is necessary and for that you use the SQL Server Native Client. You can access other databases by using ODBC or OLE DB drivers directly. ODBC is the current standard database interface, but most database systems provide custom functionality that can't be accessed through the ODBC interface. OLE DB is a legacy COM data-access technology that is still supported but not recommended for new applications. For more information, see Data Access in Visual C++.
C++ programs that consume REST services can use the C++ REST SDK.
C++ programs that work with Microsoft Azure Storage can use the Microsoft Azure Storage Client.
Visual Studio does not provide an ORM layer for C++. ODB is a popular open-source ORM for C++.
For more information about legacy Visual C++ data-access technologies, see Data Access
Install Python Tools for Visual Studio along with your favorite Python framework to create CPython or IronPython (.NET) applications. The Python Tools for Visual Studio website has several tutorials on connecting to data, including Django and SQL Database on Azure, Django and MySQL on Azure and Bottle and MongoDB on Azure.
In this section
Installing database systems, tools, and samples
Discusses how to obtain database products and the Visual Studio extensions or drivers that support them, and where to find sample databases for experimentation and learning purposes.
Visual Studio data tools for .NET
Describes how to use Visual Studio tool windows to connect to data sources, create datasets or Entity Framework models, and bind the data to user interface controls.
Data, Devices, and Analytics
Provides an introduction to the Microsoft intelligent cloud, including Cortana Analytics Suite and support for Internet of Things.
Microsoft Azure Storage
Describes Azure Storage, and how to create applications by using Azure blobs, tables, queues, and files.
Azure SQL Database
Describes how to connect to Azure SQL Database, a relational database as a service.
SQL Server Data Tools
Describes the tools that simplify design, exploration, testing, and deploying of data-connected applications and databases.
Describes the ADO.NET architecture and how to use the ADO.NET classes to manage application data and interact with data sources and XML.
ADO.NET Entity Framework
Describes how to create data applications that allow developers to program against a conceptual model instead of directly against a relational database.
Data in Office Solutions
Contains links to topics that explain how data works in Office solutions. This includes information about schema-oriented programming, data caching, and server-side data access.
LINQ (Language-Integrated Query)
Describes the query capabilities built into C# and Visual Basic, and the common model for querying relational databases, XML documents, datasets, and in-memory collections.
XML Tools in Visual Studio
Discusses working with XML data, debugging XSLT, .NET Framework XML features, and the architecture of XML Query.
XML Documents and Data
Provides an overview to a comprehensive and integrated set of classes that work with XML documents and data in the .NET Framework.
