Configure unit tests by using a .runsettings file

Unit tests in Visual Studio can be configured by using a .runsettings file. For example, you can change the .NET Framework version on which the tests are run, the directory for the test results, or the data that's collected during a test run.


The file name doesn't matter, as long as you use the extension '.runsettings'.

If you don't require any special configuration, you don't need a .runsettings file. The most common use of a .runsettings file is to customize Code coverage analysis.

Customize tests

  1. Add an XML file to your Visual Studio solution and rename it to test.runsettings.

  2. Replace the file contents with the XML from the example that follows, and customize it as needed.

  3. On the Test menu, choose Test Settings > Select Test Settings File.

You can create more than one .runsettings file in your solution, and enable or disable them at different times by using the Test Settings menu.

Enabling a run settings file

Example .runsettings file

Following is a typical .runsettings file. Each element of the file is optional, because every value has a default.

<?xml version="1.0" encoding="utf-8"?>
  <!-- Configurations that affect the Test Framework -->
    <!-- Path relative to solution directory -->

    <!-- x86 or x64
      - You can also change it from menu Test, Test Settings, Default Processor Architecture -->

    <!-- Framework35 | [Framework40] | Framework45 -->

    <!-- Path to Test Adapters -->

     <!--TestSessionTimeout is only available with Visual Studio 2017 version 15.5 and higher -->
     <!-- Specify timeout in milliseconds. A valid value should be greater than 0 -->

  <!-- Configurations for data collectors -->
      <DataCollector friendlyName="Code Coverage" uri="datacollector://Microsoft/CodeCoverage/2.0" assemblyQualifiedName="Microsoft.VisualStudio.Coverage.DynamicCoverageDataCollector, Microsoft.VisualStudio.TraceCollector, Version=, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a">

            <!-- We recommend you do not change the following values: -->


      <!--Video data collector is only available with Visual Studio 2017 version 15.5 and higher -->
      <DataCollector uri="datacollector://microsoft/VideoRecorder/1.0" assemblyQualifiedName="Microsoft.VisualStudio.TestTools.DataCollection.VideoRecorder.VideoRecorderDataCollector, Microsoft.VisualStudio.TestTools.DataCollection.VideoRecorder, Version=, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a" friendlyName="Screen and Voice Recorder">


  <!-- Parameters used by tests at runtime -->
    <Parameter name="webAppUrl" value="http://localhost" />
    <Parameter name="webAppUserName" value="Admin" />
    <Parameter name="webAppPassword" value="Password" />

  <!-- Adapter Specific sections -->

  <!-- MSTest adapter -->
      <Directory Path="D:\myfolder\bin\" includeSubDirectories="false"/>


The .runsettings file is also used to configure Code coverage analysis.

The remainder of this article describes the file content.

Edit your .runsettings file

The sections that follow detail the elements of a .runsettings file.

Test run configuration

Node Default Values
ResultsDirectory The directory where test results are placed.
TargetFrameworkVersion Framework40 Framework35, Framework40, Framework45

This setting specifies which version of the unit test framework is used to discover and execute the tests. It can be different from the version of the .NET platform that you specify in the build properties of the unit test project.
TargetPlatform x86 x86, x64
TreatTestAdapterErrorsAsWarnings false false, true
TestAdaptersPaths One or multiple paths to the directory where the TestAdapters are located
MaxCpuCount 1 This setting controls the degree of parallel test execution when running unit tests, using available cores on the machine. The test execution engine starts as a distinct process on each available core, and gives each core a container with tests to run. A container can be an assembly, DLL, or relevant artifact. The test container is the scheduling unit. In each container, the tests are run according to the test framework. If there are many containers, then as processes finish executing the tests in a container, they are given the next available container.

MaxCpuCount can be:

n, where 1 <= n <= number of cores: up to n processes will be launched

n, where n = any other value: the number of processes launched will be up to as many as available cores on the machine
TestSessionTimeout Allows users to terminate a test session when it exceeds a given timeout. Setting a timeout ensures that resources are well consumed and test sessions are constrained to a set time. The setting is available in Visual Studio 2017 version 15.5 and later.

Diagnostic Data Adapters (Data Collectors)

The DataCollectors element specifies settings of diagnostic data adapters. Diagnostic data adapters gather additional information about the environment and the application under test. Each adapter has default settings, and you only have to provide settings if you don't want to use the defaults.

Code coverage adapter

The code coverage data collector creates a log of which parts of the application code have been exercised in the test. For more information about customizing the settings for code coverage, see Customizing Code Coverage Analysis.

Video data collector

The video data collector captures a screen recording when tests are run. This recording is useful for troubleshooting UI tests. Video data collector is available in Visual Studio 2017 version 15.5 and later.

To customize any other type of diagnostic data adapter, you must use a test settings file.


TestRunParameters provides a way to define variables and values that are available to the tests at runtime. These variables can be accessed by using the TestContext object.

public void HomePageTest()
    string appURL = TestContext.Properties["webAppUrl"];

To use TestContext, add a private TestContext field and a public TestContext property to your test class.

MSTest Run Settings

These settings are specific to the test adapter that runs test methods that have the [TestMethod] attribute.

Configuration Default Values
ForcedLegacyMode false In Visual Studio 2012, the MSTest adapter was optimized to make it faster and more scalable. Some behavior, such as the order in which tests are run, might not be exactly as it was in previous editions of Visual Studio. Set this value true to use the older test adapter.

For example, you might use this setting if you have an app.config file specified for a unit test.

We recommend that you consider refactoring your tests to allow you to use the newer adapter.
IgnoreTestImpact false The test impact feature prioritizes tests that are affected by recent changes, when run in MSTest or from Microsoft Test Manager. This setting deactivates the feature. For more information, see How to: Collect Data to Check Which Tests Should be Run After Code Changes.
SettingsFile You can specify a test settings file to use with the MS Test adapter here. You can also specify a test settings file using the menu Test, Test Settings, Select Test Settings File.

If you specify this value, you must also set the ForcedlegacyMode to true.

<RunSettings> <MSTest> <SettingsFile>my.testsettings</SettingsFile> <ForcedLegacyMode>true</ForcedLegacyMode> </MSTest> </RunSettings>
KeepExecutorAliveAfterLegacyRun false After a test run is completed, MSTest is shut down. Any process that is launched as part of the test is also killed. If you want to keep the test executor alive, turn this configuration to true.

For example, you could use this setting to keep the browser running between coded UI tests.
DeploymentEnabled true If you set the value to false, deployment items that you have specified in your test method will not be copied to the deployment directory.
CaptureTraceOutput true You can write to the debug trace from your Test method using Trace.WriteLine. Using this configuration, you can turn off these debug traces.
DeleteDeploymentDirectoryAfterTestRunIsComplete true You can retain the Deployment Directory after a test run by setting this value to false.
MapInconclusiveToFailed false If a test returns with an inconclusive status, it is usually mapped to Skipped status in Test Explorer. If you want Inconclusive tests to be shown as Failed, use this configuration.
InProcMode false If you want your tests to be run in the same process as the MS Test adapter, set this value to true. This setting provides a minor performance gain. But if a test exits with an exception, the other tests will not continue.
AssemblyResolution false You can specify paths to additional assemblies when finding and running unit tests. For example, use these paths for dependency assemblies that don't reside in the same directory as the test assembly. To specify a path, use a "Directory Path" element. Paths can contain environment variables.

<AssemblyResolution> <Directory Path="D:\myfolder\bin\" includeSubDirectories="false"/> </AssemblyResolution>
