Naming conventions

This article is a summary of the naming rules and restrictions for Azure resources and a baseline set of recommendations for naming conventions. You can use these recommendations as a starting point for your own conventions specific to your needs.

The choice of a name for any resource in Microsoft Azure is important because:

  • It is difficult to change a name later.
  • Names must meet the requirements of their specific resource type.

Consistent naming conventions make resources easier to locate. They can also indicate the role of a resource in a solution.

The key to success with naming conventions is establishing and following them across your applications and organizations.

Naming subscriptions

When naming Azure subscriptions, verbose names make understanding the context and purpose of each subscription clear. When working in an environment with many subscriptions, following a shared naming convention can improve clarity.

A recommended pattern for naming subscriptions is:

<Company> <Department (optional)> <Product Line (optional)> <Environment>

  • Company would usually be the same for each subscription. However, some companies may have child companies within the organizational structure. These companies may be managed by a central IT group. In these cases, they could be differentiated by having both the parent company name (Contoso) and child company name (Northwind).
  • Department is a name within the organization where a group of individuals work. This item within the namespace as optional.
  • Product line is a specific name for a product or function that is performed from within the department. This is generally optional for internal-facing services and applications. However, it is highly recommended to use for public-facing services that require easy separation and identification (such as for clear separation of billing records).
  • Environment is the name that describes the deployment lifecycle of the applications or services, such as Dev, QA, or Prod.
Company Department Product Line or Service Environment Full Name
Contoso SocialGaming AwesomeService Production Contoso SocialGaming AwesomeService Production
Contoso SocialGaming AwesomeService Dev Contoso SocialGaming AwesomeService Dev
Contoso IT InternalApps Production Contoso IT InternalApps Production
Contoso IT InternalApps Dev Contoso IT InternalApps Dev

For more information on how to organize subscriptions for larger enterprises, read our prescriptive subscription governance guidance.

Use affixes to avoid ambiguity

When naming resources in Azure, it is recommended to use common prefixes or suffixes to identify the type and context of the resource. While all the information about type, metadata, context, is available programmatically, applying common affixes simplifies visual identification. When incorporating affixes into your naming convention, it is important to clearly specify whether the affix is at the beginning of the name (prefix) or at the end (suffix).

For instance, here are two possible names for a service hosting a calculation engine:

  • SvcCalculationEngine (prefix)
  • CalculationEngineSvc (suffix)

Affixes can refer to different aspects that describe the particular resources. The following table shows some examples typically used.

Aspect Example Notes
Environment dev, prod, QA Identifies the environment for the resource
Location uw (US West), ue (US East) Identifies the region into which the resource is deployed
Instance 01, 02 For resources that have more than one named instance (web servers, etc.).
Product or Service service Identifies the product, application, or service that the resource supports
Role sql, web, messaging Identifies the role of the associated resource

When developing a specific naming convention for your company or projects, it is importantly to choose a common set of affixes and their position (suffix or prefix).

Naming Rules and Restrictions

Each resource or service type in Azure enforces a set of naming restrictions and scope; any naming convention or pattern must adhere to the requisite naming rules and scope. For example, while the name of a VM maps to a DNS name (and is thus required to be unique across all of Azure), the name of a VNET is scoped to the Resource Group that it is created within.

In general, avoid having any special characters (- or _) as the first or last character in any name. These characters will cause most validation rules to fail.

Category Service or Entity Scope Length Casing Valid Characters Suggested Pattern Example
Resource Group Resource Group Global 1-64 Case insensitive Alphanumeric, underscore, parentheses, hyphen, an period (except at end) <service short name>-<environment>-rg profx-prod-rg
Resource Group Availability Set Resource Group 1-80 Case insensitive Alphanumeric, underscore, and hyphen <service-short-name>-<context>-as profx-sql-as
General Tag Associated Entity 512 (name), 256 (value) Case insensitive Alphanumeric "key" : "value" "department" : "Central IT"
Compute Virtual Machine Resource Group 1-15 (Windows), 1-64 (Linux) Case insensitive Alphanumeric, underscore, and hyphen <name>-<role>-vm<number> profx-sql-vm1
Compute Function App Global 1-60 Case insensitive Alphanumeric and hyphen <name>-func calcprofit-func
Storage Storage account name (data) Global 3-24 Lower case Alphanumeric <globally unique name><number> (use a function to calculate a unique guid for naming storage accounts) profxdata001
Storage Storage account name (disks) Global 3-24 Lower case Alphanumeric <vm name without dashes>st<number> profxsql001st0
Storage Container name Storage account 3-63 Lower case Alphanumeric and dash <context> logs
Storage Blob name Container 1-1024 Case sensitive Any URL char <variable based on blob usage> <variable based on blob usage>
Storage Queue name Storage account 3-63 Lower case Alphanumeric and dash <service short name>-<context>-<num> awesomeservice-messages-001
Storage Table name Storage account 3-63 Case insensitive Alphanumeric <service short name><context> awesomeservicelogs
Storage File name Storage account 3-63 Lower case Alphanumeric <variable based on blob usage> <variable based on blob usage>
Storage Data Lake Store Global 3-24 Lower case Alphanumeric <name>-dtl telemetry-dtl
Networking Virtual Network (VNet) Resource Group 2-64 Case-insensitive Alphanumeric, dash, underscore, and period <service short name>-vnet profx-vnet
Networking Subnet Parent VNet 2-80 Case-insensitive Alphanumeric, underscore, dash, and period <descriptive context> web
Networking Network Interface Resource Group 1-80 Case-insensitive Alphanumeric, dash, underscore, and period <vmname>-nic<num> profx-sql1-nic1
Networking Network Security Group Resource Group 1-80 Case-insensitive Alphanumeric, dash, underscore, and period <service short name>-<context>-nsg profx-app-nsg
Networking Network Security Group Rule Resource Group 1-80 Case-insensitive Alphanumeric, dash, underscore, and period <descriptive context> sql-allow
Networking Public IP Address Resource Group 1-80 Case-insensitive Alphanumeric, dash, underscore, and period <vm or service name>-pip profx-sql1-pip
Networking Load Balancer Resource Group 1-80 Case-insensitive Alphanumeric, dash, underscore, and period <service or role>-lb profx-lb
Networking Load Balanced Rules Config Load Balancer 1-80 Case-insensitive Alphanumeric, dash, underscore, and period <descriptive context> http
Networking Azure Application Gateway Resource Group 1-80 Case-insensitive Alphanumeric, dash, underscore, and period <service or role>-agw profx-agw
Networking Traffic Manager Profile Resource Group 1-63 Case-insensitive Alphanumeric, dash, and period <descriptive context> app1

Note

Virtual machines in Azure have two distinct names: virtual machine name, and host name. When you create a VM in the portal, the same name is used for both the host name, and the virtual machine resource name. The restrictions above are for the host name. The actual resource name can have up to 64 characters.

Microsoft adds new services to Azure frequently. The table above covers the most commonly used services in Networking, Compute, and Storage. For other services, consider an appropriate 3-letter suffix.

Organizing resources with tags

The Azure Resource Manager supports tagging entities with arbitrary text strings to identify context and streamline automation. For example, the tag "sqlVersion: "sql2014ee" could identify VMs in a deployment running SQL Server 2014 Enterprise Edition for running an automated script against them. Tags should be used to augment and enhance context along side of the naming conventions chosen.

Tip

One other advantage of tags is that tags span resource groups, allowing you to link and correlate entities across disparate deployments.

Each resource or resource group can have a maximum of 15 tags. The tag name is limited to 512 characters, and the tag value is limited to 256 characters.

For more information on resource tagging, refer to Using tags to organize your Azure resources.

Some of the common tagging use cases are:

  • Billing; Grouping resources and associating them with billing or charge back codes.
  • Service Context Identification; Identify groups of resources across Resource Groups for common operations and grouping
  • Access Control and Security Context; Administrative role identification based on portfolio, system, service, app, instance, etc.

Tip

Tag early - tag often. Better to have a baseline tagging scheme in place and adjust over time rather than having to retrofit after the fact.

An example of some common tagging approaches:

Tag Name Key Example Comment
Bill To / Internal Chargeback ID billTo IT-Chargeback-1234 An internal I/O or billing code
Operator or Directly Responsible Individual (DRI) managedBy joe@contoso.com Alias or email address
Project Name project-name myproject Name of the project or product line
Project Version project-version 3.4 Version of the project or product line
Environment environment <Production, Staging, QA > Environmental identifier
Tier tier Front End, Back End, Data Tier or role/context identification
Data Profile dataProfile Public, Confidential, Restricted, Internal Sensitivity of data stored in the resource

Tips and tricks

Some types of resources may require additional care on naming and conventions.

Virtual machines

Especially in larger topologies, carefully naming virtual machines streamlines identifying the role and purpose of each machine, and enabling more predictable scripting.

Storage accounts and storage entities

There are two primary use cases for storage accounts - backing disks for VMs, and storing data in blobs, queues and tables. Storage accounts used for VM disks should follow the naming convention of associating them with the parent VM name (and with the potential need for multiple storage accounts for high-end VM SKUs, also apply a number suffix).

Tip

Storage accounts - whether for data or disks - should follow a naming convention that allows for multiple storage accounts to be leveraged (i.e. always using a numeric suffix).

It's possible to configure a custom domain name for accessing blob data in your Azure Storage account. The default endpoint for the Blob service is https://.blob.core.windows.net`.

But if you map a custom domain (such as www.contoso.com) to the blob endpoint for your storage account, you can also access blob data in your storage account by using that domain. For example, with a custom domain name, http://mystorage.blob.core.windows.net/mycontainer/myblob could be accessed as http://www.contoso.com/mycontainer/myblob.

For more information about configuring this feature, refer to Configure a custom domain name for your Blob storage endpoint.

For more information on naming blobs, containers and tables, refer to the following list:

A blob name can contain any combination of characters, but reserved URL characters must be properly escaped. Avoid blob names that end with a period (.), a forward slash (/), or a sequence or combination of the two. By convention, the forward slash is the virtual directory separator. Do not use a backward slash (\) in a blob name. The client APIs may allow it, but then fail to hash properly, and the signatures will not match.

It is not possible to modify the name of a storage account or container after it has been created. If you want to use a new name, you must delete it and create a new one.

Tip

We recommend that you establish a naming convention for all storage accounts and types before embarking on the development of a new service or application.
