Tutorial: Migrate your data to Cassandra API account in Azure Cosmos DB

As a developer, you might have existing Cassandra workloads that are running on-premises or in the cloud, and you might want to migrate them to Azure. You can migrate such workloads to a Cassandra API account in Azure Cosmos DB. This tutorial provides instructions on different options available to migrate Apache Cassandra data into the Cassandra API account in Azure Cosmos DB.

This tutorial covers the following tasks:

  • Plan for migration
  • Prerequisites for migration
  • Migrate data using cqlsh COPY command
  • Migrate data using Spark

If you don’t have an Azure subscription, create a free account before you begin.

Prerequisites for migration

  • Estimate your throughput needs: Before migrating data to the Cassandra API account in Azure Cosmos DB, you should estimate the throughput needs of your workload. In general, it's recommended to start with the average throughput required by the CRUD operations and then include the additional throughput required for the Extract Transform Load (ETL) or spiky operations. You need the following details to plan for migration:

    • Existing data size or estimated data size: Defines the minimum database size and throughput requirement. If you are estimating data size for a new application, you can assume that the data is uniformly distributed across the rows and estimate the value by multiplying with the data size.

    • Required throughput: Approximate read (query/get) and write (update/delete/insert) throughput rate. This value is required to compute the required request units along with steady state data size.

    • The schema: Connect to your existing Cassandra cluster through cqlsh and export the schema from Cassandra:

      cqlsh [IP] "-e DESC SCHEMA" > orig_schema.cql


      After you identify the requirements of your existing workload, you should create an Azure Cosmos account, database, and containers according to the gathered throughput requirements.

    • Determine the RU charge for an operation: You can determine the RUs by using any of the SDKs supported by the Cassandra API. This example shows the .NET version of getting RU charges.

      var tableInsertStatement = table.Insert(sampleEntity);
      var insertResult = await tableInsertStatement.ExecuteAsync();

      foreach (string key in insertResult.Info.IncomingPayload)
        {
           byte[] valueInBytes = customPayload[key];
           double value = Encoding.UTF8.GetString(valueInBytes);
           Console.WriteLine($"CustomPayload:  {key}: {value}");
        }

  • Allocate the required throughput: Azure Cosmos DB can automatically scale storage and throughput as your requirements grow. You can estimate your throughput needs by using the Azure Cosmos DB request unit calculator.

  • Create tables in the Cassandra API account: Before you start migrating data, pre-create all your tables from the Azure portal or from cqlsh. If you are migrating to an Azure Cosmos account that has database level throughput, make sure to provide a partition key when creating the Azure Cosmos containers.

  • Increase throughput: The duration of your data migration depends on the amount of throughput you provisioned for the tables in Azure Cosmos DB. Increase the throughput for the duration of migration. With the higher throughput, you can avoid rate limiting and migrate in less time. After you've completed the migration, decrease the throughput to save costs. It’s also recommended to have the Azure Cosmos account in the same region as your source database.

  • Enable SSL: Azure Cosmos DB has strict security requirements and standards. Be sure to enable SSL when you interact with your account. When you use CQL with SSH, you have an option to provide SSL information.

Options to migrate data

You can move data from existing Cassandra workloads to Azure Cosmos DB by using the following options:

Migrate data using cqlsh COPY command

The CQL COPY command is used to copy local data to the Cassandra API account in Azure Cosmos DB. Use the following steps to copy data:

  1. Get your Cassandra API account’s connection string information:

    • Sign in to the Azure portal, and navigate to your Azure Cosmos account.

    • Open the Connection String pane that contains all the information that you need to connect to your Cassandra API account from cqlsh.

  2. Sign in to cqlsh using the connection information from the portal.

  3. Use the CQL COPY command to copy local data to the Cassandra API account.

    COPY exampleks.tablename FROM filefolderx/*.csv


Migrate data using Spark

Use the following steps to migrate data to the Cassandra API account with Spark:

Migrating data by using Spark jobs is a recommended option if you have data residing in an existing cluster in Azure virtual machines or any other cloud. This option requires Spark to be set up as an intermediary for one time or regular ingestion. You can accelerate this migration by using Azure ExpressRoute connectivity between on-premises and Azure.

Clean up resources

When they're no longer needed, you can delete the resource group, the Azure Cosmos account, and all the related resources. To do so, select the resource group for the virtual machine, select Delete, and then confirm the name of the resource group to delete.

Next steps

In this tutorial, you've learned how to migrate your data to Cassandra API account in Azure Cosmos DB. You can now proceed to the following article to learn about other Azure Cosmos DB concepts:
