Add a VM to a lab in Azure DevTest Labs

If you have already created your first VM, you likely did so from a pre-loaded marketplace image. Now, if you want to add subsequent VMs to your lab, you can also choose a base that is either a custom image or a formula. This tutorial walks you through using the Azure portal to add a VM to a lab in DevTest Labs.

This article also shows you how to manage the artifacts for a VM in your lab.

Steps to add a VM to a lab in Azure DevTest Labs

  1. Sign in to the Azure portal.

  2. Select All Services, and then select DevTest Labs in the DEVOPS section. If you select * (star) next to DevTest Labs in the DEVOPS section. This action adds DevTest Labs to the left navigational menu so that you can access it easily the next time. Then, you can select DevTest Labs on the left navigational menu.

    All services - select DevTest Labs

  3. From the list of labs, select the lab in which you want to create the VM.

  4. On the lab's Overview page, select + Add.

    Add VM button

  5. On the Choose a base page, select a marketplace image for the VM.

  6. On the Basic Settings tab of the Virtual machine page, do the following actions:

    1. Enter a name for the VM in the Virtual machine name text box. The text box is pre-filled for you with a unique auto-generated name. The name corresponds to the user name within your email address followed by a unique 3-digit number. This feature saves you the time to think of a machine name and type it every time you create a machine. You can override this auto-filled field with a name of your choice if you wish to. To override the auto-filled name for the VM, enter a name in the Virtual machine name text box.

    2. Enter a User Name that is granted administrator privileges on the virtual machine. The user name for the machine is pre-filled with a unique auto-generated name. The name corresponds to the user name within your email address. This feature saves you the time to decide on a username every time you create a new machine. Again, you can override this auto-filled field with a username of your choice if you wish to. To override the auto-filled value for user name, enter a value in the User Name text box. This user is granted administrator privileges on the virtual machine.

    3. If you are creating first VM in the lab, enter a password for the user. To save this password as a default password in the Azure key vault associated with the lab, select Save as default password. The default password is saved in the key vault with the name: VmPassword. When you try to create subsequent VMs in the lab, VmPassword is automatically selected for the password. To override the value, clear the Use a saved secret check box, and enter a password.

      Choose a base

      You can also save secrets in the key vault first and then use it while creating a VM in the lab. For more information, see Store secrets in a key vault. To use the password stored in the key vault, select Use a saved secret, and specify a key value that corresponds to your secret (password).

    4. In the More options section, select Change size. Select one of the predefined items that specify the processor cores, RAM size, and the hard drive size of the VM to create.

    5. Select Add or Remove Artifacts. Select and configure the artifacts that you want to add to the base image. Note: If you're new to DevTest Labs or configuring artifacts, refer to the Add an existing artifact to a VM section, and then return here when finished.

  7. Switch to the Advanced Settings tab at the top, and do the following actions:

    1. To change the virtual network that the VM is in, select Change VNet.

    2. To change the subnet, select Change subnet.

    3. Specify whether the IP address of the VM is public, private, or shared.

    4. To automatically delete the VM, specify the expiration date and time.

    5. To make the VM claimable by a lab user, select Yes for Make this machine claimable option.

    6. Specify the number of the instances of VM that you want to make it available to your lab users.

      Choose a base

  8. Select Create to add the specified VM to the lab.

    The lab page displays the status of the VM's creation - first as Creating, then as Running after the VM has been started.

    VM creation status

Add an existing artifact to a VM

While creating a VM, you can add existing artifacts. Each lab includes artifacts from the Public DevTest Labs Artifact Repository as well as artifacts that you've created and added to your own Artifact Repository.

  • Azure DevTest Labs artifacts let you specify actions that are performed when the VM is provisioned, such as running Windows PowerShell scripts, running Bash commands, and installing software.
  • Artifact parameters let you customize the artifact for your particular scenario

To discover how to create artifacts, see the article, Learn how to author your own artifacts for use with DevTest Labs.

  1. Sign in to the Azure portal.
  2. Select All Services, and then select DevTest Labs from the list.
  3. From the list of labs, select the lab containing the VM with which you want to work.
  4. Select My virtual machines.
  5. Select the desired VM.
  6. Select Manage artifacts.
  7. Select Apply artifacts.
  8. On the Apply artifacts pane, select the artifact you wish to add to the VM.
  9. On the Add artifact pane, enter the required parameter values and any optional parameters that you need.
  10. Select Add to add the artifact and return to the Apply artifacts pane.
  11. Continue adding artifacts as needed for your VM.
  12. Once you've added your artifacts, you can change the order in which the artifacts are run. You can also go back to view or modify an artifact.
  13. When you're done adding artifacts, select Apply

Change the order in which artifacts are run

By default, the actions of the artifacts are executed in the order in which they are added to the VM. The following steps illustrate how to change the order in which the artifacts are run.

  1. At the top of the Apply artifacts pane, select the link indicating the number of artifacts that have been added to the VM.

    Number of artifacts added to VM

  2. On the Selected artifacts pane, drag and drop the artifacts into the desired order. Note: If you have trouble dragging the artifact, make sure that you are dragging from the left side of the artifact.

  3. Select OK when done.

View or modify an artifact

The following steps illustrate how to view or modify the parameters of an artifact:

  1. At the top of the Apply artifacts pane, select the link indicating the number of artifacts that have been added to the VM.

    Number of artifacts added to VM

  2. On the Selected artifacts pane, select the artifact that you want to view or edit.

  3. On the Add artifact pane, make any needed changes, and select OK to close the Add artifact pane.

  4. Select OK to close the Selected artifacts pane.

Save Azure Resource Manager template

An Azure Resource Manager template provides a declarative way to define a repeatable deployment. The following steps explain how to save the Azure Resource Manager template for the VM being created. Once saved, you can use the Azure Resource Manager template to deploy new VMs with Azure PowerShell.

  1. On the Virtual machine pane, select View Azure Resource Manager Template.
  2. On the View Azure Resource Manager template pane, select the template text.
  3. Copy the selected text to the clipboard.
  4. Select OK to close the View Azure Resource Manager Template pane.
  5. Open a text editor.
  6. Paste in the template text from the clipboard.
  7. Save the file for later use.
