Machine Learning Anomaly Detection API

Overview

Anomaly Detection API is an example built with Azure Machine Learning that detects anomalies in time series data with numerical values that are uniformly spaced in time.

This API can detect the following types of anomalous patterns in time series data:

  • Positive and negative trends: For example, when monitoring memory usage in computing an upward trend may be of interest as it may be indicative of a memory leak,
  • Changes in the dynamic range of values: For example, when monitoring the exceptions thrown by a cloud service, any changes in the dynamic range of values could indicate instability in the health of the service, and
  • Spikes and Dips: For example, when monitoring the number of login failures in a service or number of checkouts in an e-commerce site, spikes or dips could indicate abnormal behavior.

These machine learning detectors track such changes in values over time and report ongoing changes in their values as anomaly scores. They do not require adhoc threshold tuning and their scores can be used to control false positive rate. The anomaly detection API is useful in several scenarios like service monitoring by tracking KPIs over time, usage monitoring through metrics such as number of searches, numbers of clicks, performance monitoring through counters like memory, CPU, file reads, etc. over time.

The Anomaly Detection offering comes with useful tools to get you started.

  • The web application helps you evaluate and visualize the results of anomaly detection APIs on your data.
Note

Try IT Anomaly Insights solution powered by this API

To get this end to end solution deployed to your Azure subscription Start here >

API Deployment

In order to use the API, you must deploy it to your Azure subscription where it will be hosted as an Azure Machine Learning web service. You can do this from the Cortana Intelligence Gallery. This will deploy two AzureML Web Services (and their related resources) to your Azure subscription - one for anomaly detection with seasonality detection, and one without seasonality detection. Once the deployment has completed, you will be able to manage your APIs from the AzureML web services page. From this page, you will be able to find your endpoint locations, API keys, as well as sample code for calling the API. More detailed instructions are available here.

Scaling the API

By default, your deployment will have a free Dev/Test billing plan which includes 1,000 transactions/month and 2 compute hours/month. You can upgrade to another plan as per your needs. Details on the pricing of different plans are available here under "Production Web API pricing".

Managing AML Plans

You can manage your billing plan here. The plan name will be based on the resource group name you chose when deploying the API, plus a string that is unique to your subscription. Instructions on how to upgrade your plan are available here under the "Managing billing plans" section.

API Definition

The web service provides a REST-based API over HTTPS that can be consumed in different ways including a web or mobile application, R, Python, Excel, etc. You send your time series data to this service via a REST API call, and it runs a combination of the three anomaly types described below.

Calling the API

In order to call the API, you will need to know the endpoint location and API key. Both of these, along with sample code for calling the API, are available from the AzureML web services page. Navigate to the desired API, and then click the "Consume" tab to find them. Note that you can call the API as a Swagger API (i.e. with the URL parameter format=swagger) or as a non-Swagger API (i.e. without the format URL parameter). The sample code uses the Swagger format. Below is an example request and response in non-Swagger format. These examples are to the seasonality endpoint. The non-seasonality endpoint is similar.

Sample Request Body

The request contains two objects: Inputs and GlobalParameters. In the example request below, some parameters are sent explicitly while others are not (scroll down for a full list of parameters for each endpoint). Parameters that are not sent explicitly in the request will use the default values given below.

{
            "Inputs": {
                    "input1": {
                            "ColumnNames": ["Time", "Data"],
                            "Values": [
                                    ["5/30/2010 18:07:00", "1"],
                                    ["5/30/2010 18:08:00", "1.4"],
                                    ["5/30/2010 18:09:00", "1.1"]
                            ]
                    }
            },
    "GlobalParameters": {
        "tspikedetector.sensitivity": "3",
        "zspikedetector.sensitivity": "3",
        "bileveldetector.sensitivity": "3.25",
        "detectors.spikesdips": "Both"
    }
}

Sample Response

Note that, in order to see the ColumnNames field, you must include details=true as a URL parameter in your request. See the tables below for the meaning behind each of these fields.

{
    "Results": {
        "output1": {
            "type": "table",
            "value": {
                "Values": [
                    ["5/30/2010 6:07:00 PM", "1", "1", "0", "0", "-0.687952590518378", "0", "-0.687952590518378", "0", "-0.687952590518378", "0"],
                    ["5/30/2010 6:08:00 PM", "1.4", "1.4", "0", "0", "-1.07030497733224", "0", "-0.884548154298423", "0", "-1.07030497733224", "0"],
                    ["5/30/2010 6:09:00 PM", "1.1", "1.1", "0", "0", "-1.30229513613974", "0", "-1.173800281031", "0", "-1.30229513613974", "0"]
                ],
                "ColumnNames": ["Time", "OriginalData", "ProcessedData", "TSpike", "ZSpike", "BiLevelChangeScore", "BiLevelChangeAlert", "PosTrendScore", "PosTrendAlert", "NegTrendScore", "NegTrendAlert"],
                "ColumnTypes": ["DateTime", "Double", "Double", "Double", "Double", "Double", "Int32", "Double", "Int32", "Double", "Int32"]
            }
        }
    }
}

Score API

The Score API is used for running anomaly detection on non-seasonal time series data. The API runs a number of anomaly detectors on the data and returns their anomaly scores. The figure below shows an example of anomalies that the Score API can detect. This time series has 2 distinct level changes, and 3 spikes. The red dots show the time at which the level change is detected, while the black dots show the detected spikes. Score API

Detectors

The anomaly detection API supports detectors in 3 broad categories. Details on specific input parameters and outputs for each detector can be found in the following table.

Detector Category Detector Description Input Parameters Outputs
Spike Detectors TSpike Detector Detect spikes and dips based on far the values are from first and third quartiles tspikedetector.sensitivity: takes integer value in the range 1-10, default: 3; Higher values will catch more extreme values thus making it less sensitive TSpike: binary values – ‘1’ if a spike/dip is detected, ‘0’ otherwise
Spike Detectors ZSpike Detector Detect spikes and dips based on how far the datapoints are from their mean zspikedetector.sensitivity: take integer value in the range 1-10, default: 3; Higher values will catch more extreme values making it less sensitive ZSpike: binary values – ‘1’ if a spike/dip is detected, ‘0’ otherwise
Slow Trend Detector Slow Trend Detector Detect slow positive trend as per the set sensitivity trenddetector.sensitivity: threshold on detector score (default: 3.25, 3.25 – 5 is a reasonable range to select this from; The higher the less sensitive) tscore: floating number representing anomaly score on trend
Level Change Detectors Bidirectional Level Change Detector Detect both upward and downward level change as per the set sensitivity bileveldetector.sensitivity: threshold on detector score (default: 3.25, 3.25 – 5 is a reasonable range to select this from; The higher the less sensitive) rpscore: floating number representing anomaly score on upward and downward level change

Parameters

More detailed information on these input parameters is listed in the table below:

Input Parameters Description Default Setting Type Valid Range Suggested Range
detectors.historyWindow History (in # of data points) used for anomaly score computation 500 integer 10-2000 Time-series dependent
detectors.spikesdips Whether to detect only spikes, only dips, or both Both enumerated Both, Spikes, Dips Both
bileveldetector.sensitivity Sensitivity for bidirectional level change detector. 3.25 double None 3.25-5 (Lesser values mean more sensitive)
trenddetector.sensitivity Sensitivity for positive trend detector. 3.25 double None 3.25-5 (Lesser values mean more sensitive)
tspikedetector.sensitivity Sensitivity for TSpike Detector 3 integer 1-10 3-5 (Lesser values mean more sensitive)
zspikedetector.sensitivity Sensitivity for ZSpike Detector 3 integer 1-10 3-5 (Lesser values mean more sensitive)
postprocess.tailRows Number of the latest data points to be kept in the output results 0 integer 0 (keep all data points), or specify number of points to keep in results N/A

Output

The API runs all detectors on your time series data and returns anomaly scores and binary spike indicators for each point in time. The table below lists outputs from the API.

Outputs Description
Time Timestamps from raw data, or aggregated (and/or) imputed data if aggregation (and/or) missing data imputation is applied
Data Values from raw data, or aggregated (and/or) imputed data if aggregation (and/or) missing data imputation is applied
TSpike Binary indicator to indicate whether a spike is detected by TSpike Detector
ZSpike Binary indicator to indicate whether a spike is detected by ZSpike Detector
rpscore A floating number representing anomaly score on bidirectional level change
rpalert 1/0 value indicating there is a bidirectional level change anomaly based on the input sensitivity
tscore A floating number representing anomaly score on positive trend
talert 1/0 value indicating there is a positive trend anomaly based on the input sensitivity

ScoreWithSeasonality API

The ScoreWithSeasonality API is used for running anomaly detection on time series that have seasonal patterns. This API is useful to detect deviations in seasonal patterns.
The following figure shows an example of anomalies detected in a seasonal time series. The time series has one spike (the 1st black dot), two dips (the 2nd black dot and one at the end), and one level change (red dot). Note that both the dip in the middle of the time series and the level change are only discernable after seasonal components are removed from the series. Seasonality API

Detectors

The detectors in the seasonality endpoint are similar to the ones in the non-seasonality endpoint, but with slightly different parameter names (listed below).

Parameters

More detailed information on these input parameters is listed in the table below:

Input Parameters Description Default Setting Type Valid Range Suggested Range
preprocess.aggregationInterval Aggregation interval in seconds for aggregating input time series 0 (no aggregation is performed) integer 0: skip aggregation, > 0 otherwise 5 minutes to 1 day, time-series dependent
preprocess.aggregationFunc Function used for aggregating data into the specified AggregationInterval mean enumerated mean, sum, length N/A
preprocess.replaceMissing Values used to impute missing data lkv (last known value) enumerated zero, lkv, mean N/A
detectors.historyWindow History (in # of data points) used for anomaly score computation 500 integer 10-2000 Time-series dependent
detectors.spikesdips Whether to detect only spikes, only dips, or both Both enumerated Both, Spikes, Dips Both
bileveldetector.sensitivity Sensitivity for bidirectional level change detector. 3.25 double None 3.25-5 (Lesser values mean more sensitive)
postrenddetector.sensitivity Sensitivity for positive trend detector. 3.25 double None 3.25-5 (Lesser values mean more sensitive)
negtrenddetector.sensitivity Sensitivity for negative trend detector. 3.25 double None 3.25-5 (Lesser values mean more sensitive)
tspikedetector.sensitivity Sensitivity for TSpike Detector 3 integer 1-10 3-5 (Lesser values mean more sensitive)
zspikedetector.sensitivity Sensitivity for ZSpike Detector 3 integer 1-10 3-5 (Lesser values mean more sensitive)
seasonality.enable Whether seasonality analysis is to be performed true boolean true, false Time-series dependent
seasonality.numSeasonality Maximum number of periodic cycles to be detected 1 integer 1, 2 1-2
seasonality.transform Whether seasonal (and) trend components shall be removed before applying anomaly detection deseason enumerated none, deseason, deseasontrend N/A
postprocess.tailRows Number of the latest data points to be kept in the output results 0 integer 0 (keep all data points), or specify number of points to keep in results N/A

Output

The API runs all detectors on your time series data and returns anomaly scores and binary spike indicators for each point in time. The table below lists outputs from the API.

Outputs Description
Time Timestamps from raw data, or aggregated (and/or) imputed data if aggregation (and/or) missing data imputation is applied
OriginalData Values from raw data, or aggregated (and/or) imputed data if aggregation (and/or) missing data imputation is applied
ProcessedData Either of the following:
  • Seasonally adjusted time series if significant seasonality has been detected and deseason option selected;
  • seasonally adjusted and detrended time series if significant seasonality has been detected and deseasontrend option selected
  • otherwise, this is the same as OriginalData
TSpike Binary indicator to indicate whether a spike is detected by TSpike Detector
ZSpike Binary indicator to indicate whether a spike is detected by ZSpike Detector
BiLevelChangeScore A floating number representing anomaly score on level change
BiLevelChangeAlert 1/0 value indicating there is a level change anomaly based on the input sensitivity
PosTrendScore A floating number representing anomaly score on positive trend
PosTrendAlert 1/0 value indicating there is a positive trend anomaly based on the input sensitivity
NegTrendScore A floating number representing anomaly score on negative trend
NegTrendAlert 1/0 value indicating there is a negative trend anomaly based on the input sensitivity
