Configuring Azure Multi-Factor Authentication

This article helps you manage Azure Multi-Factor Authentication now that you are up and running. It covers a variety of topics that help you to get the most out of Azure Multi-Factor Authentication. Not all of these features are available in every version of Azure Multi-Factor Authentication.

The configuration for some of the features below is found in the Azure Multi-Factor Authentication Management Portal. There are two different ways that you can access the MFA management portal, which are both done via the Azure portal. The first is by managing a Multi-Factor Auth Provider if using consumption-based MFA. The second is via the MFA service settings. The second option requires either a Multi-Factor Auth Provider or an Azure MFA, Azure AD Premium or Enterprise Mobility Suite license.

To access the MFA Management Portal via an Azure Multi-Factor Auth Provider, sign into the Azure portal as an administrator and select the Active Directory option. Click the Multi-Factor Auth Providers tab, then select your directory and click the Manage button at the bottom.

To access the MFA Management Portal via the MFA Service Settings page, sign into the Azure portal as an administrator and select the Active Directory option. Click on your directory and then click the Configure tab. Under the multi-factor authentication section, select Manage service settings. At the bottom of the MFA Service Settings page, click the Go to the portal link.

Feature Description What is covered
Fraud alert Fraud alert can be configured and set up so that your users can report fraudulent attempts to access their resources. How to set up, configure and report fraud
One-time bypass A one-time bypass allows a user to authenticate a single time by "bypassing" multi-factor authentication. How to set up and configure a one-time bypass
Custom Voice Messages Custom voice messages allow you to use your own recordings or greetings with multi-factor authentication. How to set up and configure custom greetings and messages
Caching Caching allows you to set a specific time period so that subsequent authentication attempts succeed automatically. How to set up and configure authentication caching.
Trusted IPs Trusted IPs is a feature of multi-factor authentication that allows administrators of a managed or federated tenant the ability to bypass multi-factor authentication for users that are signing in from the company’s local intranet. Configure and set up IP addresses that are exempt for multi-factor authentication
App Passwords An app password allows an application that is not MFA-aware to bypass multi-factor authentication and continue working. Information about app passwords.
Remember Multi-Factor Authentication for remembered devices and browsers Allows you to remember devices for a set number of days after a user has successfully signed in using MFA. Information about enabling this feature and setting up the number of days.
Selectable Verification Methods Allows you to choose the authentication methods that are available for users to use. Information about enabling or disabling specific authentication methods such as call or text messages.

Fraud Alert

Fraud alert can be configured and set up so that your users can report fraudulent attempts to access their resources. Users can report fraud either with the mobile app or through their phone.

To set up and configure fraud alert

  1. Log on to http://azure.microsoft.com
  2. Navigate to the MFA Management Portal per the instructions at the top of this page.
  3. In the Azure Multi-Factor Authentication Management Portal, click Settings under the Configure section.
  4. Under the Fraud Alert section of the Settings page, check the Allow users to submit Fraud Alerts checkbox.
  5. If you want users to be blocked when fraud is reported, place a check in Block user when fraud is reported.
  6. In the Code To Report Fraud During Initial Greeting textbox, enter a number code that can be used during call verification. If a user enters this code plus # instead of just the # sign, then a fraud alert will be reported.
  7. At the bottom, click Save.
Note

Microsoft’s default voice greetings instruct users to press 0# to submit a fraud alert. If you want to use a code other than 0, you should record and upload your own custom voice greetings with appropriate instructions.

Cloud

To report fraud alert

Fraud alert can be reported two ways. Either through the mobile app or through the phone.

To report fraud alert with the mobile app

  1. When a verification is sent to your phone, select it to start the Microsoft Authenticator app.
  2. To report fraud, click the Cancel and Report Fraud. This brings up a box that says your organization's IT Support staff will be notified.
  3. Click report fraud.
  4. On the app, click Close.

Cloud

Cloud

To report fraud alert with the phone

  1. When a verification call comes in to your phone, answer it.
  2. To report fraud, enter the code that has been configured to correspond with reporting fraud via the phone and then the # sign. You will be notified that a fraud alert has been submitted.
  3. End the call.

To view the fraud report

  1. Log on to http://azure.microsoft.com
  2. On the left, select Active Directory.
  3. At the top select Multi-Factor Auth Providers. This brings up a list of your Multi-Factor Auth Providers.
  4. If you have more than one Multi-Factor Auth Provider, select the one you wish to view the fraud alert report and click Manage at the bottom of the page. If you have only one, click Manage. This opens the Azure Multi-Factor Authentication Management Portal.
  5. On the Azure Multi-Factor Authentication Management Portal, on the left, under View A Report, click Fraud Alert.
  6. Specify the date range that you wish to view in the report. Also you can specify any specific usernames, phone numbers, and the user's status.
  7. Click Run. This brings up a report similar to the one below. You can also click Export to CSV if you wish to export the report.

One-time bypass

A one-time bypass allows a user to authenticate a single time by "bypassing" multi-factor authentication. The bypass is temporary and expires after the specified number of seconds. So in situations where the mobile app or phone is not receiving a notification or phone-call, you can enable a one-time bypass so the user can access the desired resource.

To create a one-time bypass

  1. Log on to http://azure.microsoft.com
  2. Navigate to the MFA Management Portal per the instructions at the top of this page.
  3. In the Azure Multi-Factor Authentication Management Portal, if you see the name of your tenant or Azure MFA Provider on the left with a + next to it, click the + see different MFA Server replication groups and the Azure Default group. Click on the appropriate group.
  4. Under User Administration, click One-Time Bypass. Cloud
  5. On the One-Time Bypass page, click New One-Time Bypass.
  6. Enter the user’s username, the number of seconds that the bypass will exist, the reason for the bypass and click Bypass. Cloud
  7. At this point, the user must sign in before the one-time bypass expires.

To view the one-time bypass report

  1. Log on to http://azure.microsoft.com
  2. On the left, select Active Directory.
  3. At the top select Multi-Factor Auth Providers. This brings up a list of your Multi-Factor Auth Providers.
  4. If you have more than one Multi-Factor Auth Provider, select the one you wish to view the fraud alert report and click Manage at the bottom of the page. If you have only one, click Manage. This opens the Azure Multi-Factor Authentication Management Portal.
  5. On the Azure Multi-Factor Authentication Management Portal, on the left, under View A Report, click One-Time Bypass.
  6. Specify the date range that you wish to view in the report. Also you can specify any specific usernames, phone numbers, and the user's status.
  7. Click Run. This brings up a report similar to the one below. You can also click Export to CSV if you wish to export the report.
Cloud

Custom voice messages

Custom voice messages allow you to use your own recordings or greetings with multi-factor authentication. These can be used in addition to or to replace the Microsoft records.

Before you begin be aware of the following:

  • The current supported file formats are .wav and .mp3.
  • The file size limit is 5 MB.
  • It is recommended that for Authentication messages that it be no longer than 20 seconds. Anything greater than this could cause the verification to fail because the user may not respond before the message finishes and the verification times out.

To set up custom voice messages in Azure Multi-Factor Authentication

  1. Create a custom voice message using one of the supported file formats.
  2. Log on to http://azure.microsoft.com
  3. Navigate to the MFA Management Portal per the instructions at the top of this page.
  4. In the Azure Multi-Factor Authentication Management Portal, click Voice Messages under the Configure section.
  5. Under the Voice Messages section, click New Voice Message. Cloud
  6. On the Configure: New Voice Messages page, click Manage Sound Files. Cloud
  7. On the Configure: Sound Files page, click Upload Sound File. Cloud
  8. On the Configure: Upload Sound File, click Browse and navigate to your voice message, click Open. Cloud
  9. Add a Description and click Upload.
  10. Once this completes, a message confirms that you have successfully uploaded the file.
  11. On the left, click Voice Messages.
  12. Under the Voice Messages section, click New Voice Message.
  13. From the Language drop-down, select a language.
  14. If this message is for a specific application, specify it in the Application box.
  15. From the Message Type, select the message type to be overridden with our new custom message.
  16. From the Sound File drop-down, select your sound file.
  17. Click Create. A message confirms that you have successfully created a voice message. Cloud

Caching in Azure Multi-Factor Authentication

Caching allows you to set a specific time period so that subsequent authentication attempts succeed automatically. This is primarily used when on-premises systems such as VPN send multiple verification requests while the first request is still in progress. This allows the subsequent requests to succeed automatically after the user succeeds the verification in progress. Note that caching is not intended to be used for sign-ins to Azure AD.

To set up caching in Azure Multi-Factor Authentication

  1. Log on to http://azure.microsoft.com
  2. Navigate to the MFA Management Portal per the instructions at the top of this page.
  3. In the Azure Multi-Factor Authentication Management Portal, click Caching under the Configure section.
  4. On the Configure caching page click New Cache
  5. Select the Cache type and the cache seconds. Click create.
Cloud

Trusted IPs

Trusted IPs is a feature of multi-factor authentication that allows administrators of a managed or federated tenant the ability to bypass multi-factor authentication for users that are signing in from the company’s local intranet. This feature is available with the full version of Azure Multi-Factor Authentication. (For details on how to get the full version of Azure Multi-Factor Authentication, see How to get Azure Multi-Factor Authentication.)

Type of Azure AD Tenant Available Trusted IP options
Managed Specific IP address ranges – Administrators can specify a range of IP addresses that can bypass multi-factor authentication for users that are signing in from the company’s intranet.
Federated
  • All Federated Users - All federated users who are signing-in from inside the organization will bypass multi-factor authentication using a claim issued by AD FS.
  • Specific IP address ranges – Administrators can specify a range of IP addresses that can bypass multi-factor authentication for users that are signing in from the company’s intranet.
  • This bypass only works from inside a company’s intranet. So for example, if you only selected all federated users, and a user signs in from outside the company’s intranet, that user has to authenticate using multi-factor authentication even if the user presents an AD FS claim. The following table describes when multi-factor authentication and app passwords are required inside your corpnet and outside your corpnet when Trusted IPs is enabled.

    Trusted IPs enabled Trusted IPs disabled
    Inside corpnet For browser flows, multi-factor authentication NOT required.
    For rich client apps, regular passwords work if the user has not created any app passwords. Once an app password has been created, app passwords are required. For rich client apps, app passwords required
    Outside corpnet For browser flows, multi-factor authentication required.
    For rich client apps, app passwords required. For rich client apps, app passwords required.

    To enable Trusted IPs

    1. Sign-in to the Azure classic portal.
    2. On the left, click Active Directory.
    3. Under, Directory click on the directory you wish to set up Trusted IPsing on.
    4. On the Directory you have selected, click Configure.
    5. In the multi-factor authentication section, click Manage service settings.
    6. On the Service Settings page, under Trusted IPs, select either:

      • For requests from federated users originating from my intranet – All federated users who are signing in from the corporate network will bypass multi-factor authentication using a claim issued by AD FS.
      • For requests from a specific range of public IPs – enter the IP addresses in the boxes provided using CIDR notation. For example: xxx.xxx.xxx.0/24 for IP addresses in the range xxx.xxx.xxx.1 – xxx.xxx.xxx.254, or xxx.xxx.xxx.xxx/32 for a single IP address. You can enter up to 50 IP address ranges.
    7. Click save.
    8. Once the updates have been applied, click close.

    Trusted IPs

    App Passwords

    In some apps, like Office 2010 or older and Apple Mail you can't use multi-factor authentication. To use these apps, you'll need to use "app passwords" in place of your traditional password. The app password allows the application to bypass multi-factor authentication and continue working.

    Note

    Modern Authentication for the Office 2013 Clients

    Office 2013 clients (including Outlook) now support new Authentication Protocols and can be enabled to support Multi-Factor Authentication. This means that once enabled, app passwords are not required for use with Office 2013 clients. For more information, see Office 2013 modern authentication public preview announced.

    Important things to know about app passwords

    The following is an important list of things that you should know about app passwords.

    • Users can have multiple app passwords, which increases the surface area for theft. Since app passwords are hard to remember, it might encourage people to write this down. This is not recommended and should be discouraged because only one factor is required to login with app password.
    • Apps which cache passwords and use it in on-premises scenarios might start failing since the app password isn't known outside of the organizational id. An example is Exchange emails that are on-premises but the archived mail is in the cloud. The same password doesn't work.
    • The actual password is automatically generated and is not supplied by the user. This is because the automatically generated password, is harder for an attacker to guess and is more secure.
    • Currently there is a limit of 40 passwords per user. You will be prompted to delete one of your existing app passwords in order to create a new one.
    • Once multi-factor authentication is enabled on a user's account, app passwords can be used with most non-browser clients such as Outlook and Lync, but administrative actions cannot be performed using app passwords through non-browser applications such as Windows PowerShell even if that user has an administrative account. Ensure you create a service account with a strong password to run PowerShell scripts and do not enable that account for multi-factor authentication.
    Warning

    App passwords don't work in hybrid environments where clients communicate with both on-premises and cloud autodiscover endpoints. This is because domain passwords are required to authenticate on-premises and app passwords are required to authenticate with the cloud.

    Naming Guidance for App Passwords

    It is recommended that app password names should reflect the device on which they are used. For instance, if you have a laptop that has non-browser apps such as Outlook, Word, and Excel, you only need to create one app password named Laptop and use that app password in all of these applications. Although you can create separate passwords for all of these applications, it is not recommended. The recommend way is to use one app password per device.

    Cloud

    Federated (SSO) App Passwords

    Azure AD supports federation with on-premises Windows Server Active Directory Domain Services (AD DS). If your organization is federated(SSO) with Azure AD and you are going to be using Azure Multi-Factor Authentication, then the following is important information that you should be aware when using app passwords. This applies only to federated(SSO) customers.

    • The App Password is verified by Azure AD and hence bypasses federation. Federation is only actively used when setting up App Password.
    • For federated(SSO) users, we never go to the Identity Provider (IdP) unlike the passive flow. The passwords are stored in the organizational id. If the user leaves the company, that info has to flow to organizational id using DirSync in real time. Account disable/deletion may take up to three hours to sync, delaying disable/deletion of App Password in Azure AD.
    • On-premises Client Access Control settings are not honored by App Password
    • No on-premises authentication logging / auditing capability is available for App Password
    • More end-user education is required for the Microsoft Lync 2013 client. For the required steps, see How to change the password in your email to the app password.
    • Certain advanced architectural designs may require using a combination of organizational username and passwords and app passwords when using multi-factor authentication with clients, depending on where they authenticate. For clients that authenticate against an on-premise infrastructure, you would use an organizational username and password. For clients that authenticate against Azure AD, you would use the app password.

    For example, suppose you have an architecture that consists of the following:

    • You are federating your on-premise instance of Active Directory with Azure AD
    • You are using Exchange online
    • You are using Lync that is specifically on-premise
    • You are using Azure Multi-Factor Authentication

    Proofup

    In these instances, you must do the following:

    • When signing-in to Lync, use your organizations’ username and password.
    • When attempting to access the address book via an Outlook client that connects to Exchange online, use an app password.

    Allowing app password creation

    By default, users cannot create app passwords. This feature must be enabled. To allow users the ability to create app passwords, use the following procedure.

    To enable users to create app passwords

    1. Sign in to the Azure classic portal.
    2. On the left, click Active Directory.
    3. Under, Directory click on the directory for the user you wish to enable.
    4. At the top, click Users.
    5. At the bottom of the page, click Manage Multi-Factor Auth.
    6. At the top of the multi-factor authentication page, click Service Settings.
    7. Ensure that the radio button next to Allow users to create app passwords to sign into non-browser applications is selected.

    Create App Passwords

    Creating app passwords

    Users can create app passwords during their initial registration. They are given an option at the end of the registration process that allows them to create them.

    Additionally users can also create app passwords later on by changing their settings in the Azure portal, the Office 365 portal or by

    To create app passwords in the Office 365 portal


    1. Sign in to the Office 365 portal
    2. In the top right corner, select the settings widget
    3. On the left, select Additional Security Verification
    4. On the right, select Update my phone numbers used for account security
    5. On the proofup page, at the top, select app passwords
    6. Click Create
    7. Enter a name for the app password and click Next
    8. Copy the app password to the clipboard and paste it into your app.
    Cloud

    To create app passwords in the Azure portal


    1. Sign in to the Azure classic portal.
    2. At the top, right-click on your user name and select Additional Security Verification.
    3. On the proofup page, at the top, select app passwords
    4. Click Create
    5. Enter a name for the app password and click Next
    6. Copy the app password to the clipboard and paste it into your app.

    App passwords

    To create app passwords if you do not have an Office 365 or Azure subscription


    1. Sign in to https://myapps.microsoft.com
    2. At the top, select profile.
    3. Click on your user name and select Additional Security Verification.
    4. On the proofup page, at the top, select app passwords
    5. Click Create
    6. Enter a name for the app password and click Next
    7. Copy the app password to the clipboard and paste it into your app.

    App passwords

    Remember Multi-Factor Authentication for devices users trust

    Remembering Multi-Factor Authentication for devices and browsers that users trust is a free feature for all MFA users. It allows you to give users the option to by-pass MFA for a set number of days after performing a successful sign-in using MFA. This can enhance the usability for your users.

    However, since the users are allowed to remember MFA for trusted devices, this feature may reduce account security. To ensure account security, you should restore Multi-Factor Authentication for their devices for either of the following scenarios:

    • If their corporate account has become compromised
    • If a remembered device is lost or stolen
    Note

    This feature is implemented as a browser cookie cache. It doesn't work if your browser cookies are not enabled.

    How to enable/disable Remember multi-factor authentication

    1. Sign in to the Azure classic portal.
    2. On the left, click Active Directory.
    3. Under Active Directory, click on the directory you wish to set up Remember Multi-Factor Authentication for devices.
    4. On the Directory you have selected, click Configure.
    5. In the multi-factor authentication section, click Manage service settings.
    6. On the Service Settings page, under manage user device settings, select/unselect the Allow users to remember multi-factor authentication on devices they trust. Remember devices
    7. Set the number of days that you want to allow the suspension. The default is 14 days.
    8. Click save.
    9. Click close.

    Selectable Verification Methods

    On both the cloud and on-premises versions, you can choose which verification methods are available for your users. The table below provides a brief overview of each method.

    When your users enroll their accounts for MFA, they choose their preferred verification method out of the options that you enabled. The guidance for their enrollment process is covered in Set up my account for two-step verification

    Method Description
    Call to phone Places an automated voice call to the Authentication phone. The user answers the call and presses # in the phone keypad to authenticate. This phone number is not synchronized to on-premises Active Directory.
    Text message to phone Sends a text message containing a verification code to the user. The user is prompted to either reply to the text message with the verification code or to enter the verification code into the sign-in interface.
    Notification through mobile app In this mode, the Microsoft Authenticator app prevents unauthorized access to accounts and stops fraudulent transactions. This is done using a push notification to your phone or registered device. Simply view the notification and if it is legitimate you tap Verify. Otherwise you may choose Deny or choose to deny and report the fraudulent notification. For information on reporting fraudulent notifications see How to use the Deny and Report Fraud Feature for Multi-Factor Authentication.
    The Microsoft Authenticator app is available for Windows Phone, Android, and IOS.
    Verification code from mobile app In this mode, the Microsoft Authenticator app can be used as a software token to generate an OATH verification code. This verification code can then be entered along with the username and password to provide the second form of authentication.

    The Microsoft Authenticator app is available for Windows Phone, Android, and IOS.

    How to enable/disable authentication methods

    1. Sign in to the Azure classic portal.
    2. On the left, click Active Directory.
    3. Under Active Directory, click on the directory you wish to enable or disable authentication methods.
    4. On the Directory you have selected, click Configure.
    5. In the multi-factor authentication section, click Manage service settings.
    6. On the Service Settings page, under verification options, select/unselect the options you wish to use.
      Verification options
    7. Click save.
    8. Click close.
