Mount SMB Azure file share on Linux

Caution

This article references CentOS, a Linux distribution that is nearing End Of Life (EOL) status. Please consider your use and planning accordingly. Azure Files is Microsoft's easy to use cloud file system. Azure file shares can be mounted in Linux distributions using the SMB kernel client.

The recommended way to mount an Azure file share on Linux is using SMB 3.1.1. By default, Azure Files requires encryption in transit, which is supported by SMB 3.0+. Azure Files also supports SMB 2.1, which doesn't support encryption in transit, but you can't mount Azure file shares with SMB 2.1 from another Azure region or on-premises for security reasons. Unless your application specifically requires SMB 2.1, use SMB 3.1.1.

Distribution SMB 3.1.1 (Recommended) SMB 3.0
Linux kernel version
  • Basic 3.1.1 support: 4.17
  • Default mount: 5.0
  • AES-128-GCM encryption: 5.3
  • AES-256-GCM encryption: 5.10
  • Basic 3.0 support: 3.12
  • AES-128-CCM encryption: 4.11
Ubuntu AES-128-GCM encryption: 18.04.5 LTS+ AES-128-CCM encryption: 16.04.4 LTS+
Red Hat Enterprise Linux (RHEL)
  • Basic: 8.0+
  • Default mount: 8.2+
  • AES-128-GCM encryption: 8.2+
7.5+
Debian Basic: 10+ AES-128-CCM encryption: 10+
SUSE Linux Enterprise Server AES-128-GCM encryption: 15 SP2+ AES-128-CCM encryption: 12 SP2+

If your Linux distribution isn't listed in the above table, you can check the Linux kernel version with the uname command:

uname -r

Note

SMB 2.1 support was added to Linux kernel version 3.7. If you're using a version of the Linux kernel after 3.7, it should support SMB 2.1.

Applies to

File share type SMB NFS
Standard file shares (GPv2), LRS/ZRS Yes No
Standard file shares (GPv2), GRS/GZRS Yes No
Premium file shares (FileStorage), LRS/ZRS Yes No

Prerequisites

  • Ensure the cifs-utils package is installed. The cifs-utils package can be installed using the package manager on the Linux distribution of your choice.

On Ubuntu and Debian, use the apt package manager:

sudo apt update
sudo apt install cifs-utils

On other distributions, use the appropriate package manager or compile from source.

  • The most recent version of the Azure Command Line Interface (CLI). For more information on how to install the Azure CLI, see Install the Azure CLI and select your operating system. If you prefer to use the Azure PowerShell module in PowerShell 6+, you may; however, the instructions in this article are for the Azure CLI.

  • Ensure port 445 is open: SMB communicates over TCP port 445 - make sure your firewall or ISP isn't blocking TCP port 445 from the client machine. Replace <your-resource-group> and <your-storage-account> and then run the following script:

    RESOURCE_GROUP_NAME="<your-resource-group>"
    STORAGE_ACCOUNT_NAME="<your-storage-account>"

    # This command assumes you have logged in with az login
    HTTP_ENDPOINT=$(az storage account show \
        --resource-group $RESOURCE_GROUP_NAME \
        --name $STORAGE_ACCOUNT_NAME \
        --query "primaryEndpoints.file" --output tsv | tr -d '"')
    SMBPATH=$(echo $HTTP_ENDPOINT | cut -c7-${#HTTP_ENDPOINT})
    FILE_HOST=$(echo $SMBPATH | tr -d "/")

    nc -zvw3 $FILE_HOST 445


    If the connection was successful, you should see something similar to the following output:

    Connection to <your-storage-account> 445 port [tcp/microsoft-ds] succeeded!


    If you're unable to open up port 445 on your corporate network or are blocked from doing so by an ISP, you may use a VPN connection or ExpressRoute to work around port 445. For more information, see Networking considerations for direct Azure file share access.

Mount the Azure file share on-demand with mount

When you mount a file share on a Linux OS, your remote file share is represented as a folder in your local file system. You can mount file shares to anywhere on your system. The following example mounts under the /media path. You can change this to your preferred path you want by modifying the $MNT_ROOT variable.

Replace <resource-group-name>, <storage-account-name>, and <file-share-name> with the appropriate information for your environment:

RESOURCE_GROUP_NAME="<resource-group-name>"
STORAGE_ACCOUNT_NAME="<storage-account-name>"
FILE_SHARE_NAME="<file-share-name>"

MNT_ROOT="/media"
MNT_PATH="$MNT_ROOT/$STORAGE_ACCOUNT_NAME/$FILE_SHARE_NAME"

sudo mkdir -p $MNT_PATH

Next, mount the file share using the mount command. In the following example, the $SMB_PATH command is populated using the fully qualified domain name for the storage account's file endpoint and $STORAGE_ACCOUNT_KEY is populated with the storage account key.

Note

Starting in Linux kernel version 5.0, SMB 3.1.1 is the default negotiated protocol. If you're using a version of the Linux kernel older than 5.0, specify vers=3.1.1 in the mount options list.

# This command assumes you have logged in with az login
HTTP_ENDPOINT=$(az storage account show \
    --resource-group $RESOURCE_GROUP_NAME \
    --name $STORAGE_ACCOUNT_NAME \
    --query "primaryEndpoints.file" --output tsv | tr -d '"')
SMB_PATH=$(echo $HTTP_ENDPOINT | cut -c7-${#HTTP_ENDPOINT})$FILE_SHARE_NAME

STORAGE_ACCOUNT_KEY=$(az storage account keys list \
    --resource-group $RESOURCE_GROUP_NAME \
    --account-name $STORAGE_ACCOUNT_NAME \
    --query "[0].value" --output tsv | tr -d '"')

sudo mount -t cifs $SMB_PATH $MNT_PATH -o username=$STORAGE_ACCOUNT_NAME,password=$STORAGE_ACCOUNT_KEY,serverino,nosharesock,actimeo=30,mfsymlinks

You can use uid/gid or dir_mode and file_mode in the mount options for the mount command to set permissions. For more information on how to set permissions, see UNIX numeric notation.

You can also mount the same Azure file share to multiple mount points if desired. When you're done using the Azure file share, use sudo umount $mntPath to unmount the share.

Automatically mount file shares

When you mount a file share on a Linux OS, your remote file share is represented as a folder in your local file system. You can mount file shares to anywhere on your system. The following example mounts under the /media path. You can change this to your preferred path you want by modifying the $MNT_ROOT variable.

MNT_ROOT="/media"
sudo mkdir -p $MNT_ROOT

To mount an Azure file share on Linux, use the storage account name as the username of the file share, and the storage account key as the password. Because the storage account credentials may change over time, you should store the credentials for the storage account separately from the mount configuration.

The following example shows how to create a file to store the credentials. Remember to replace <resource-group-name> and <storage-account-name> with the appropriate information for your environment.

RESOURCE_GROUP_NAME="<resource-group-name>"
STORAGE_ACCOUNT_NAME="<storage-account-name>"

# Create a folder to store the credentials for this storage account and
# any other that you might set up.
CREDENTIAL_ROOT="/etc/smbcredentials"
sudo mkdir -p "/etc/smbcredentials"

# Get the storage account key for the indicated storage account.
# You must be logged in with az login and your user identity must have
# permissions to list the storage account keys for this command to work.
STORAGE_ACCOUNT_KEY=$(az storage account keys list \
    --resource-group $RESOURCE_GROUP_NAME \
    --account-name $STORAGE_ACCOUNT_NAME \
    --query "[0].value" --output tsv | tr -d '"')

# Create the credential file for this individual storage account
SMB_CREDENTIAL_FILE="$CREDENTIAL_ROOT/$STORAGE_ACCOUNT_NAME.cred"
if [ ! -f $SMB_CREDENTIAL_FILE ]; then
    echo "username=$STORAGE_ACCOUNT_NAME" | sudo tee $SMB_CREDENTIAL_FILE > /dev/null
    echo "password=$STORAGE_ACCOUNT_KEY" | sudo tee -a $SMB_CREDENTIAL_FILE > /dev/null
else
    echo "The credential file $SMB_CREDENTIAL_FILE already exists, and was not modified."
fi

# Change permissions on the credential file so only root can read or modify the password file.
sudo chmod 600 $SMB_CREDENTIAL_FILE

To automatically mount a file share, you have a choice between using a static mount via the /etc/fstab utility or using a dynamic mount via the autofs utility.

Static mount with /etc/fstab

Using the earlier environment, create a folder for your storage account/file share under your mount folder. Replace <file-share-name> with the appropriate name of your Azure file share.

FILE_SHARE_NAME="<file-share-name>"

MNT_PATH="$MNT_ROOT/$STORAGE_ACCOUNT_NAME/$FILE_SHARE_NAME"
sudo mkdir -p $MNT_PATH

Finally, create a record in the /etc/fstab file for your Azure file share. In the command below, the default 0755 Linux file and folder permissions are used, which means read, write, and execute for the owner (based on the file/directory Linux owner), read and execute for users in owner group, and read and execute for others on the system. You may wish to set alternate uid and gid or dir_mode and file_mode permissions on mount as desired. For more information on how to set permissions, see UNIX numeric notation on Wikipedia.

Tip

If you want Docker containers running .NET Core applications to be able to write to the Azure file share, include nobrl in the SMB mount options to avoid sending byte range lock requests to the server.

HTTP_ENDPOINT=$(az storage account show \
    --resource-group $RESOURCE_GROUP_NAME \
    --name $STORAGE_ACCOUNT_NAME \
    --query "primaryEndpoints.file" --output tsv | tr -d '"')
SMB_PATH=$(echo $HTTP_ENDPOINT | cut -c7-${#HTTP_ENDPOINT})$FILE_SHARE_NAME

if [ -z "$(grep $SMB_PATH\ $MNT_PATH /etc/fstab)" ]; then
    echo "$SMB_PATH $MNT_PATH cifs _netdev,nofail,credentials=$SMB_CREDENTIAL_FILE,serverino,nosharesock,actimeo=30" | sudo tee -a /etc/fstab > /dev/null
else
    echo "/etc/fstab was not modified to avoid conflicting entries as this Azure file share was already present. You may want to double check /etc/fstab to ensure the configuration is as desired."
fi

sudo mount -a

Note

Starting in Linux kernel version 5.0, SMB 3.1.1 is the default negotiated protocol. You can specify alternate protocol versions using the vers mount option (protocol versions are 3.1.1, 3.0, and 2.1).

Dynamically mount with autofs

To dynamically mount a file share with the autofs utility, install it using the package manager on the Linux distribution of your choice.

On Ubuntu and Debian distributions, use the apt package manager:

sudo apt update
sudo apt install autofs

Next, update the autofs configuration files.

FILE_SHARE_NAME="<file-share-name>"

HTTP_ENDPOINT=$(az storage account show \
    --resource-group $RESOURCE_GROUP_NAME \
    --name $STORAGE_ACCOUNT_NAME \
    --query "primaryEndpoints.file" --output tsv | tr -d '"')
SMB_PATH=$(echo $HTTP_ENDPOINT | cut -c7-$(expr length $HTTP_ENDPOINT))$FILE_SHARE_NAME

echo "$FILE_SHARE_NAME -fstype=cifs,credentials=$SMB_CREDENTIAL_FILE :$SMB_PATH" > /etc/auto.fileshares

echo "/fileshares /etc/auto.fileshares --timeout=60" > /etc/auto.master

The final step is to restart the autofs service.

sudo systemctl restart autofs

Mount a file share snapshot

If you want to mount a specific snapshot of an SMB Azure file share, you must supply the snapshot option as part of the mount command, where snapshot is the time that the particular snapshot was created in a format such as @GMT-2023.01.05-00.08.20. The snapshot option has been supported in the Linux kernel since version 4.19.

After you've created the file share snapshot, follow these instructions to mount it.

  1. In the Azure portal, navigate to the storage account that contains the file share that you want to mount a snapshot of.

  2. Select Data storage > File shares and select the file share.

  3. Select Operations > Snapshots and take note of the name of the snapshot you want to mount. The snapshot name will be a GMT timestamp, such as in the screenshot below.

    Screenshot showing how to locate a file share snapshot name and timestamp in the Azure portal.

  4. Convert the timestamp to the format expected by the mount command, which is @GMT-year.month.day-hour.minutes.seconds. In this example, you'd convert 2023-01-05T00:08:20.0000000Z to @GMT-2023.01.05-00.08.20.

  5. Run the mount command using the GMT time to specify the snapshot value. Be sure to replace <storage-account-name>, <file-share-name>, and the GMT timestamp with your values. The .cred file contains the credentials to be used to mount the share (see Automatically mount file shares).

    sudo mount -t cifs //<storage-account-name>.file.core.windows.net/<file-share-name> /media/<file-share-name>/snapshot1 -o credentials=/etc/smbcredentials/snapshottestlinux.cred,snapshot=@GMT-2023.01.05-00.08.20

  6. If you're able to browse the snapshot under the path /media/<file-share-name>/snapshot1, then the mount succeeded.

If the mount fails, see Troubleshoot Azure Files connectivity and access issues (SMB).
