Feature Tour of the Visual Studio Debugger

This topic introduces the features of the Visual Studio debugger. If you want to follow along by opening your own app in Visual Studio, you can do that, or you can follow along with a sample app using the Beginner's Guide.

The features described here are applicable to C#, C++, Visual Basic, JavaScript, and other languages supported by Visual Studio (except where noted).

Set a breakpoint and start the debugger

To debug, you need to start your app with the debugger attached to the app process. F5 (Debug > Start Debugging) is the most common way to do that. However, right now you may not have set any breakpoints to examine your app code, so we will do that first and then start debugging.

If you have a file open in the code editor, you can set a breakpoint by clicking in the margin to the left of a line of code.

Set a Breakpoint

Press F5 (Debug > Start Debugging) and the debugger runs to the first breakpoint that it encounters. If the app is not yet running, F5 starts the debugger and stops at the first breakpoint.

Breakpoints are a useful feature when you know the line of code or the section of code that you want to examine in detail.

We provide the keyboard shortcuts for most commands because they make navigation of your app code quicker. (Equivalent commands such as menu commands are shown in parentheses.)

To start your app with the debugger attached, press F11 (Debug > Step Into). F11 is the Step Into command and advances the app execution one statement at a time. When you start the app with F11, the debugger breaks on the first statement that gets executed.

F11 Step Into

The yellow arrow represents the statement on which the debugger paused, which also suspends app execution at the same point (this statement has not yet executed).

F11 is a good way to examine the execution flow in the most detail. (To move faster through code, we show you some other options as well.) By default, the debugger skips over non-user code (if you want more details, see Just My Code).

Note

In managed code, you will see a dialog box asking if you want to be notified when you automatically step over properties and operators (default behavior). If you want to change the setting later, disable Step over properties and operators setting in the Tools > Options menu under Debugging.

Step over code to skip functions

When you are on a line of code that is a function or method call, you can press F10 (Debug > Step Over) instead of F11.

F10 advances the debugger without stepping into functions or methods in your app code (the code still executes). By pressing F10, you can skip over code that you're not interested in. This way, you can quickly get to code that you are more interested in.

Step into a property

As mentioned earlier, by default the debugger skips over managed properties and fields, but the Step Into Specific command allows you to override this behavior.

Right-click on a property or field and choose Step Into Specific, then choose one of the available options.

Step into Specific

In this example, Step Into Specific gets us to the code for Path.set.

Step into Specific

Run to a point in your code quickly using the mouse

While in the debugger, hover over a line of code until the Run to Click (Run execution to here) button Run to Click appears on the left.

Run to Click

Note

The Run to Click (Run execution to here) button is new in Visual Studio 2017.

Click the Run to Click (Run execution to here) button. The debugger advances to the line of code where you clicked.

Using this button is similar to setting a temporary breakpoint. This command is also handy for getting around quickly within a visible region of app code. You can use Run to Click in any open file.

Advance the debugger out of the current function

Sometimes, you might want to continue your debugging session but advance the debugger all the way through the current function.

Press Shift + F11 (or Debug > Step Out).

This command resumes app execution (and advances the debugger) until the current function returns.

Run to cursor

Stop the debugger by pressing the Stop Debugging red button Stop Debugging or Shift + F5.

Right-click a line of code in your app and choose Run to Cursor. This command starts debugging and sets a temporary breakpoint on the current line of code.

Run to Cursor

If you have set breakpoints, the debugger pauses on the first breakpoint that it hits.

Press F5 until you reach the line of code where you selected Run to Cursor.

This command is useful when you are editing code and want to quickly set a temporary breakpoint and start the debugger.

Note

You can use Run to Cursor in the Call Stack window while you are debugging.

Restart your app quickly

Click the Restart Restart App button in the Debug Toolbar (Ctrl + Shift +F5).

When you press Restart, it saves time versus stopping the app and restarting the debugger. The debugger pauses at the first breakpoint that is hit by executing code.

If you do want to stop the debugger and get back into the code editor, you can press the red stop Stop Debugging button instead of Restart.

Inspect variables with data tips

Now that you know your way around a little, you have a good opportunity to start inspecting your app state (variables) with the debugger. Features that allow you to inspect variables are some of the most useful features of the debugger, and there are different ways to do it. Often, when you try to debug an issue, you are attempting to find out whether variables are storing the values that you expect them to have in a particular app state.

While paused in the debugger, hover over an object with the mouse and you see its default property value (in this example, the file name market 031.jpg is the default property value).

View a Data Tip

Expand the object to see all its properties (such as the FullPath property in this example).

Often, when debugging, you want a quick way to check property values on objects, and the data tips are a good way to do it.

Tip

In most supported languages, you can edit code in the middle of a debugging session. For more info, see Edit and Continue.

Inspect variables with the Autos and Locals windows

While debugging, look at the Autos window at the bottom of the code editor.

Autos Window

In the Autos window, you see variables along with their current value and their type. The Autos window shows all variables used on the current line or the preceding line (In C++, the window shows variables in the preceding three lines of code. Check documentation for language-specific behavior).

Note

In JavaScript, the Locals window is supported but not the Autos window.

Next, look at the Locals window. The Locals window shows you the variables that are currently in scope.

Locals Window

In this example, the this object and the object f are in scope. For more info, see Inspect Variables in the Autos and Locals Windows.

Set a watch

You can use a Watch window to specify a variable (or an expression) that you want to keep an eye on.

While debugging, right-click an object and choose Add Watch.

Watch Window

In this example, you have a watch set on the File object, and you can see its value change as you move through the debugger. Unlike the other variable windows, the Watch windows always show the variables that you are watching (they're grayed out when out of scope).

For more info, see Set a Watch using the Watch and QuickWatch Windows

Examine the call stack

Click the Call Stack window while you are debugging, which is by default open in the lower right pane.

Examine the Call Stack

The Call Stack window shows the order in which methods and functions are getting called. The top line shows the current function (the Update method in this example). The second line shows that Update was called from the Path.set property, and so on. The call stack is a good way to examine and understand the execution flow of an app.

Note

The Call Stack window is similar to the Debug perspective in some IDEs like Eclipse.

You can double-click a line of code to go look at that source code and that also changes the current scope being inspected by the debugger. This does not advance the debugger.

You can also use right-click menus from the Call Stack window to do other things. For example, you can insert breakpoints into specific functions, restart your app using Run to Cursor, and to go examine source code. See How to: Examine the Call Stack.

Examine an exception

When your app throws an exception, the debugger takes you to the line of code that threw the exception.

Exception Helper

In this example, the Exception Helper shows you a System.Argument exception and an error message that says that the path is not a legal form. So, we know the error occurred on a method or function argument.

In this example, the DirectoryInfo call gave the error on the empty string stored in the value variable.

The Exception Helper is a great feature that can help you debug errors. You can also do things like view error details and add a watch from the Exception Helper. Or, if needed, you can change conditions for throwing the particular exception.

Note

The Exception Helper replaces the Exception Assistant in Visual Studio 2017.

Expand the Exception Settings node to see more options on how to handle this exception type, but you don't need to change anything for this tour!

More features to look at

  • Debugger Tips and Tricks Learn how to increase your productivity with the debugger.

  • Edit and Continue For a subset of languages (C#, C++, Visual Basic), the Edit and Continue feature allows you to edit code in the middle of a debugging session.

  • Debug Multithreaded Applications Describes how to debug multithreaded applications.

  • Remote Debugging Describes how to debug apps running on other machines or devices.

  • IntelliTrace Describes the IntelliTrace feature in Visual Studio Enterprise. You can use it to record and trace your code's execution history.

  • Network Usage Describes a profiling tool that you can use to debug web services and other network resources in Universal Windows Apps (UWP). Use the tool to examine payloads.

  • Debug Interface Access SDK Describes the Microsoft Debug Interface Access Software Development Kit (DIA SDK). The DIA SDK provides access to debug information stored in program database (.pdb) files generated by Microsoft postcompiler tools.
