Resilient File System (ReFS) overview

Applies to: Windows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012

The Resilient File System (ReFS) is Microsoft's newest file system, designed to maximize data availability, scale efficiently to large data sets across diverse workloads, and provide data integrity with resiliency to corruption. It seeks to address an expanding set of storage scenarios and establish a foundation for future innovations.

Key benefits

Resiliency

ReFS introduces new features that can precisely detect corruptions and also fix those corruptions while remaining online, helping provide increased integrity and availability for your data:

  • Integrity-streams - ReFS uses checksums for metadata and optionally for file data, giving ReFS the ability to reliably detect corruptions.
  • Storage Spaces integration - when used with a mirror or parity space, ReFS can automatically repair detected corruptions using the alternate copy of the data provided by Storage Spaces. Repair processes are both localized to the area of corruption and performed online, requiring no volume downtime.
  • Salvaging data - if a volume becomes corrupted and an alternate copy of the corrupted data doesn't exist, ReFS removes the corrupt data from the namespace. ReFS keeps the volume online while it handles most non-correctable corruptions, but there are rare cases that require ReFS to take the volume offline.
  • Proactive error correction - in addition to validating data before reads and writes, ReFS introduces a data integrity scanner, known as a scrubber. This scrubber periodically scans the volume, identifying latent corruptions and proactively triggering a repair of corrupt data.

Performance

In addition to providing resiliency improvements, ReFS introduces new features for performance-sensitive and virtualized workloads. Real-time tier optimization, block cloning, and sparse valid data length (VDL) are good examples of the evolving capabilities of ReFS, which are designed to support dynamic and diverse workloads:

  • Mirror-accelerated parity - Mirror-accelerated parity delivers both high performance and also capacity efficient storage for your data.

    To deliver both high performance and capacity efficient storage, ReFS divides a volume into two logical storage groups, known as tiers. These tiers can have their own drive and resiliency types, allowing each tier to optimize for either performance or capacity. Some example configurations include:

    Performance tier Capacity tier
    Mirrored SSD Mirrored HDD
    Mirrored SSD Parity SSD
    Mirrored SSD Parity HDD

    Once these tiers are configured, ReFS uses them to deliver fast storage for hot data and capacity-efficient storage for cold data:

    • All writes will occur in the performance tier, and large chunks of data that remain in the performance tier will be efficiently moved to the capacity tier in real time.
    • If using a hybrid deployment (mixing flash and HDD drives), the cache in Storage Spaces Direct helps accelerate reads, reducing the effect of data fragmentation characteristic of virtualized workloads. Otherwise, if using an all-flash deployment, reads also occur in the performance tier.

    Note

    For Windows Server deployments, mirror-accelerated parity is only supported on Storage Spaces Direct. We recommend using mirror-accelerated parity with archival and backup workloads only. For virtualized and other high performance random workloads, we recommend using three-way mirrors for better performance.

  • Accelerated VM operations - ReFS introduces new functionality specifically targeted to improve the performance of virtualized workloads:

    • Block cloning - block cloning accelerates copy operations, enabling quick, low-impact VM checkpoint merge operations.
    • Sparse VDL - sparse VDL allows ReFS to zero files rapidly, reducing the time needed to create fixed VHDs from 10s of minutes to mere seconds.
  • Variable cluster sizes - ReFS supports both 4K and 64K cluster sizes. 4K is the recommended cluster size for most deployments, but 64K clusters are appropriate for large, sequential IO workloads.

Scalability

ReFS is designed to support extremely large data sets - millions of terabytes - without negatively impacting performance, achieving greater scale than prior file systems.

Supported deployments

Microsoft has developed NTFS specifically for general-purpose use with a wide range of configurations and workloads. For customers specially requiring the availability, resiliency, and/or scale that ReFS provides, Microsoft supports ReFS for use with the following configurations and scenarios:

Note

All ReFS supported configurations must use Windows Server Catalog certified hardware and meet application requirements.

Important

If you plan to use ReFS for Cluster Shared Volumes (CSVs), please see Use Cluster Shared Volumes in a failover cluster for important information.

Storage Spaces Direct

Deploying ReFS on Storage Spaces Direct is recommended for virtualized workloads or network-attached storage:

  • Mirror-accelerated parity and the cache in Storage Spaces Direct deliver high performance and capacity-efficient storage.
  • The introduction of block clone and sparse VDL dramatically accelerates .vhdx file operations, such as creation, merge, and expansion.
  • Integrity-streams, online repair, and alternate data copies enable ReFS and Storage Spaces Direct to jointly detect and correct storage controller and storage media corruptions within both metadata and data.
  • ReFS provides the functionality to scale and support large data sets.

Storage Spaces

Deploying ReFS on Storage Spaces with shared SAS enclosures is suitable for hosting archival data and storing user documents:

  • Integrity-streams, online repair, and alternate data copies enable ReFS and Storage Spaces to jointly detect and correct storage controller and storage media corruptions within both metadata and data.
  • Storage Spaces deployments can also utilize block-cloning and the scalability offered in ReFS.

Note

Storage Spaces supports local non-removable direct-attached via BusTypes SATA, SAS, NVME, or attached via HBA (also known as RAID controller in pass-through mode).

Basic disks

Deploying ReFS on basic disks is best suited for applications that implement their own software resiliency and availability solutions:

  • Applications that introduce their own resiliency and availability software solutions can use integrity-streams, block-cloning, and the ability to scale and support large data sets.

Note

Basic disks include local non-removable direct-attached via BusTypes SATA, SAS, NVME, or RAID. Basic disks do not include Storage Spaces.

Backup target

Deploying ReFS as a backup target is best suited for applications and hardware that implements its own resiliency and availability solutions:

  • Applications that introduce their own resiliency and availability software solutions can use integrity-streams, block-cloning, and the ability to scale and support large data sets.

Note

Backup targets include the above supported configurations. Please contact application and storage array vendors for support details on Fiber Channel and iSCSI SANs. For SANs, if features such as thin provisioning, TRIM/UNMAP, or Offloaded Data Transfer (ODX) are required, NTFS must be used.

Feature comparison

Limits

Feature ReFS NTFS
Maximum file name length 255 Unicode characters 255 Unicode characters
Maximum path name length 32K Unicode characters 32K Unicode characters
Maximum file size 35 PB (petabytes) 256 TB
Maximum volume size 35 PB 256 TB

Functionality

The following features are available with ReFS and NTFS:

Feature ReFS NTFS
BitLocker encryption Yes Yes
Data Deduplication Yes1 Yes
Cluster Shared Volume (CSV) support Yes2 3 Yes
Junctions/Soft links Yes Yes
Hard links Yes4 Yes
Failover cluster support Yes Yes
Access-control lists Yes Yes
USN journal Yes Yes
Changes notifications Yes Yes
Junction points Yes Yes
Mount points Yes Yes
Reparse points Yes Yes
Volume snapshots Yes Yes
File IDs Yes Yes
Oplocks Yes Yes
Sparse files Yes Yes
Named streams Yes Yes
Thin Provisioning Yes5 Yes
Trim/Unmap Yes5 Yes
Page file support Yes6 Yes
  1. Available on Windows Server, version 1709 and later, Windows Server 2019 (1809) LTSC or later.
  2. Available on Windows Server 2012 R2 and later.
  3. CSV will not use Direct I/O with Storage Spaces, Storage Spaces Direct (S2D) or SAN.
  4. Version ReFS 3.5 formatted by Windows 10 Enterprise Insider Preview build 19536 and later. Hard links support is added for newly formatted volumes only. Hard links can't be used on volumes that have been upgraded from previous versions
  5. Storage Spaces only.
  6. Available on ReFS 3.7 and later.

The following features are only available with ReFS:

Functionality ReFS NTFS
Block clone Yes No
Sparse VDL Yes No
Mirror-accelerated parity Yes (on Storage Spaces Direct) No
File-level snapshots Yes1 No
  1. Available on Windows Server 2022 and later.

The following features are unavailable on ReFS at this time:

Functionality ReFS NTFS
File system compression No Yes
File system encryption No Yes
Transactions No Yes
Object IDs No Yes
Offloaded Data Transfer (ODX) No Yes
Short names No Yes
Extended attributes No Yes
Disk quotas No Yes
Bootable No Yes
Supported on removable media No Yes
