Build a SCIM endpoint and configure user provisioning with Azure Active Directory (Azure AD)

As an application developer, you can use the System for Cross-Domain Identity Management (SCIM) user management API to enable automatic provisioning of users and groups between your application and Azure AD. This article describes how to build a SCIM endpoint and integrate with the Azure AD provisioning service. The SCIM specification provides a common user schema for provisioning. When used in conjunction with federation standards like SAML or OpenID Connect, SCIM gives administrators an end-to-end, standards-based solution for access management.

SCIM is a standardized definition of two endpoints: a /Users endpoint and a /Groups endpoint. It uses common REST verbs to create, update, and delete objects, and a pre-defined schema for common attributes like group name, username, first name, last name and email. Apps that offer a SCIM 2.0 REST API can reduce or eliminate the pain of working with a proprietary user management API. For example, any compliant SCIM client knows how to make an HTTP POST of a JSON object to the /Users endpoint to create a new user entry. Instead of needing a slightly different API for the same basic actions, apps that conform to the SCIM standard can instantly take advantage of pre-existing clients, tools, and code.

Provisioning from Azure AD to an app with SCIM

The standard user object schema and rest APIs for management defined in SCIM 2.0 (RFC 7642, 7643, 7644) allow identity providers and apps to more easily integrate with each other. Application developers that build a SCIM endpoint can integrate with any SCIM-compliant client without having to do custom work.

Automating provisioning to an application requires building and integrating a SCIM endpoint with the Azure AD SCIM compliant. Perform the following steps to start provisioning users and groups into your application.

Steps for integrating a SCIM endpoint with Azure AD

Step 1: Design your user and group schema

Every application requires different attributes to create a user or group. Start your integration by identifying the objects (users, groups) and attributes (name, manager, job title, etc.) that your application requires. The SCIM standard defines a schema for managing users and groups. The core user schema only requires three attributes: id (service provider defined identifier), externalId (client defined identifier), and meta (read-only metadata maintained by the service provider). All other attributes are optional. In addition to the core user schema, the SCIM standard defines an enterprise user extension and a model for extending the user schema to meet your application’s needs. If, for example, your application requires a user’s manager, you can use the enterprise user schema to collect the user’s manager and the core schema to collect the user’s email. To design your schema, follow the steps below:

  1. List the attributes your application requires. It can be helpful to break down your requirements into the attributes needed for authentication (e.g. loginName and email), attributes needed to manage the lifecycle of the user (e.g. status / active), and other attributes needed for your particular application to work (e.g. manager, tag).
  2. Check whether those attributes are already defined in the core user schema or enterprise user schema. If any attributes that you need and aren’t covered in the core or enterprise user schemas, you will need to define an extension to the user schema that covers the attributes you need. In the example below, we’ve added an extension to the user to allow provisioning a “tag” on a user. It is best to start with just the core and enterprise user schemas and expand out to additional custom schemas later.
  3. Map the SCIM attributes to the user attributes in Azure AD. If one of the attributes you have defined in your SCIM endpoint does not have a clear counterpart on the Azure AD user schema, there is a good chance the data isn’t stored on the user object at all on most tenants. Consider whether this attribute can be optional for creating a user. If the attribute is critical for your application to work, guide the tenant administrator to extend their schema or use an extension attribute as shown below for the “tags” property.

Table 1: Outline the attributes that you need

Step 1: Determine attributes your app requires Step 2: Map app requirements to SCIM standard Step 3: Map SCIM attributes to the Azure AD attributes
loginName userName userPrincipalName
firstName name.givenName givenName
lastName name.lastName lastName
workMail Emails[type eq “work”].value Mail
manager manager manager
tag urn:ietf:params:scim:schemas:extension:2.0:CustomExtension:tag extensionAttribute1
status active isSoftDeleted (computed value not stored on user)

The schema defined above would be represented using the Json payload below. Note that in addition to the attributes required for the application, the JSON representation includes the required “id,” “externalId,” and “meta” attributes.

{
     "schemas": ["urn:ietf:params:scim:schemas:core:2.0:User",
      "urn:ietf:params:scim:schemas:extension:enterprise:2.0:User",
      "urn:ietf:params:scim:schemas:extension:CustomExtensionName:2.0:User"],
     "userName":"bjensen",
     "externalId":"bjensen",
     "name":{
       "familyName":"Jensen",
       "givenName":"Barbara"
     },
     "urn:ietf:params:scim:schemas:extension:enterprise:2.0:User": {
     "Manager": "123456"
   },
     "urn:ietf:params:scim:schemas:extension:CustomExtensionName:2.0:CustomAttribute:User": {
     "tag": "701984",
   },
   "meta": {
     "resourceType": "User",
     "created": "2010-01-23T04:56:22Z",
     "lastModified": "2011-05-13T04:42:34Z",
     "version": "W\/\"3694e05e9dff591\"",
     "location":
 "https://example.com/v2/Users/2819c223-7f76-453a-919d-413861904646"
   }

Table 2: Default user attribute mapping

You can then use the table below to understand how the attributes your application requires could map to an attribute in Azure AD and the SCIM RFC. You can customize how attributes are mapped between Azure AD and your SCIM endpoint. Note that you don't need to support both users and groups or all the attributes shown below. They are a reference for how attributes in Azure AD are often mapped to properties in the SCIM protocol.

Azure Active Directory user "urn:ietf:params:scim:schemas:extension:enterprise:2.0:User"
IsSoftDeleted active
department urn:ietf:params:scim:schemas:extension:enterprise:2.0:User:department
displayName displayName
employeeId urn:ietf:params:scim:schemas:extension:enterprise:2.0:User:employeeNumber
Facsimile-TelephoneNumber phoneNumbers[type eq "fax"].value
givenName name.givenName
jobTitle title
mail emails[type eq "work"].value
mailNickname externalId
manager urn:ietf:params:scim:schemas:extension:enterprise:2.0:User:manager
mobile phoneNumbers[type eq "mobile"].value
postalCode addresses[type eq "work"].postalCode
proxy-Addresses emails[type eq "other"].Value
physical-Delivery-OfficeName addresses[type eq "other"].Formatted
streetAddress addresses[type eq "work"].streetAddress
surname name.familyName
telephone-Number phoneNumbers[type eq "work"].value
user-PrincipalName userName

Table 3: Default group attribute mapping

Azure Active Directory group urn:ietf:params:scim:schemas:core:2.0:Group
displayName displayName
mail emails[type eq "work"].value
mailNickname displayName
members members
objectId externalId
proxyAddresses emails[type eq "other"].Value

There are several endpoints defined in the SCIM RFC. You can get started with the /User endpoint and then expand from there. The /Schemas endpoint is helpful when using custom attributes or if your schema changes frequently. It enables a client to retrieve the most up-to-date schema automatically. The /Bulk endpoint is especially helpful when supporting groups. The table below describes the various endpoints defined in the SCIM standard. The /Schemas endpoint is helpful when using custom attributes or if your schema changes frequently. It enables a client to retrieve the most up to date schema automatically. The /Bulk endpoint is especially helpful when supporting groups. The table below describes the various endpoints defined in the SCIM standard.

Table 4: Determine the endpoints that you would like to develop

ENDPOINT DESCRIPTION
/User Perform CRUD operations on a user object.
/Group Perform CRUD operations on a group object.
/ServiceProviderConfig Provides details about the features of the SCIM standard that are supported, for example the resources that are supported and the authentication method.
/ResourceTypes Specifies metadata about each resource
/Schemas The set of attributes supported by each client and service provider can vary. While one service provider might include “name,” “title,” and “emails,” while another service provider uses “name,” “title,” and “phoneNumbers.” The schemas endpoint allows for discovery of the attributes supported.
/Bulk Bulk operations allow you to perform operations on a large collection of resource objects in a single operation (e.g. update memberships for a large group).

Step 2: Understand the Azure AD SCIM implementation

Important

The behavior of the Azure AD SCIM implementation was last updated on December 18, 2018. For information on what changed, see SCIM 2.0 protocol compliance of the Azure AD User Provisioning service.

If you're building an application that supports a SCIM 2.0 user management API, this section describes in detail how the Azure AD SCIM client is implemented. It also shows how to model your SCIM protocol request handling and responses. Once you've implemented your SCIM endpoint, you can test it by following the procedure described in the previous section.

Within the SCIM 2.0 protocol specification, your application must meet these requirements:

  • Supports creating users, and optionally also groups, as per section 3.3 of the SCIM protocol.
  • Supports modifying users or groups with PATCH requests, as per section 3.5.2 of the SCIM protocol.
  • Supports retrieving a known resource for a user or group created earlier, as per section 3.4.1 of the SCIM protocol.
  • Supports querying users or groups, as per section 3.4.2 of the SCIM protocol. By default, users are retrieved by their id and queried by their username and externalid, and groups are queried by displayName.
  • Supports querying user by ID and by manager, as per section 3.4.2 of the SCIM protocol.
  • Supports querying groups by ID and by member, as per section 3.4.2 of the SCIM protocol.
  • Accepts a single bearer token for authentication and authorization of Azure AD to your application.

Follow these general guidelines when implementing a SCIM endpoint to ensure compatibility with Azure AD:

  • id is a required property for all the resources. Every response that returns a resource should ensure each resource has this property, except for ListResponse with zero members.
  • Response to a query/filter request should always be a ListResponse.
  • Groups are optional, but only supported if the SCIM implementation supports PATCH requests.
  • It isn't necessary to include the entire resource in the PATCH response.
  • Microsoft Azure AD only uses the following operators:
    • eq
    • and
  • Don't require a case-sensitive match on structural elements in SCIM, in particular PATCH op operation values, as defined in https://tools.ietf.org/html/rfc7644#section-3.5.2. Azure AD emits the values of 'op' as Add, Replace, and Remove.
  • Microsoft Azure AD makes requests to fetch a random user and group to ensure that the endpoint and the credentials are valid. It's also done as a part of Test Connection flow in the Azure portal.
  • The attribute that the resources can be queried on should be set as a matching attribute on the application in the Azure portal. For more information, see Customizing User Provisioning Attribute Mappings

User provisioning and deprovisioning

The following illustration shows the messages that Azure Active Directory sends to a SCIM service to manage the lifecycle of a user in your application's identity store.

Shows the user provisioning and deprovisioning sequence
User provisioning and deprovisioning sequence

Group provisioning and deprovisioning

Group provisioning and deprovisioning are optional. When implemented and enabled, the following illustration shows the messages that Azure AD sends to a SCIM service to manage the lifecycle of a group in your application's identity store. Those messages differ from the messages about users in two ways:

  • Requests to retrieve groups specify that the members attribute is to be excluded from any resource provided in response to the request.
  • Requests to determine whether a reference attribute has a certain value are requests about the members attribute.

Shows the group provisioning and deprovisioning sequence
Group provisioning and deprovisioning sequence

SCIM protocol requests and responses

This section provides example SCIM requests emitted by the Azure AD SCIM client and example expected responses. For best results, you should code your app to handle these requests in this format and emit the expected responses.

Important

To understand how and when the Azure AD user provisioning service emits the operations described below, see the section Provisioning cycles: Initial and incremental in How provisioning works.

User Operations

Group Operations

User Operations

  • Users can be queried by userName or email[type eq "work"] attributes.

Create User

Request

POST /Users

{
	"schemas": [
	    "urn:ietf:params:scim:schemas:core:2.0:User",
	    "urn:ietf:params:scim:schemas:extension:enterprise:2.0:User"],
	"externalId": "0a21f0f2-8d2a-4f8e-bf98-7363c4aed4ef",
	"userName": "Test_User_ab6490ee-1e48-479e-a20b-2d77186b5dd1",
	"active": true,
	"emails": [{
		"primary": true,
		"type": "work",
		"value": "Test_User_fd0ea19b-0777-472c-9f96-4f70d2226f2e@testuser.com"
	}],
	"meta": {
		"resourceType": "User"
	},
	"name": {
		"formatted": "givenName familyName",
		"familyName": "familyName",
		"givenName": "givenName"
	},
	"roles": []
}
Response

HTTP/1.1 201 Created

{
	"schemas": ["urn:ietf:params:scim:schemas:core:2.0:User"],
	"id": "48af03ac28ad4fb88478",
	"externalId": "0a21f0f2-8d2a-4f8e-bf98-7363c4aed4ef",
	"meta": {
		"resourceType": "User",
		"created": "2018-03-27T19:59:26.000Z",
		"lastModified": "2018-03-27T19:59:26.000Z"
	},
	"userName": "Test_User_ab6490ee-1e48-479e-a20b-2d77186b5dd1",
	"name": {
		"formatted": "givenName familyName",
		"familyName": "familyName",
		"givenName": "givenName",
	},
	"active": true,
	"emails": [{
		"value": "Test_User_fd0ea19b-0777-472c-9f96-4f70d2226f2e@testuser.com",
		"type": "work",
		"primary": true
	}]
}

Get User

Request

GET /Users/5d48a0a8e9f04aa38008

Response (User found)

HTTP/1.1 200 OK

{
	"schemas": ["urn:ietf:params:scim:schemas:core:2.0:User"],
	"id": "5d48a0a8e9f04aa38008",
	"externalId": "58342554-38d6-4ec8-948c-50044d0a33fd",
	"meta": {
		"resourceType": "User",
		"created": "2018-03-27T19:59:26.000Z",
		"lastModified": "2018-03-27T19:59:26.000Z"
	},
	"userName": "Test_User_feed3ace-693c-4e5a-82e2-694be1b39934",
	"name": {
		"formatted": "givenName familyName",
		"familyName": "familyName",
		"givenName": "givenName",
	},
	"active": true,
	"emails": [{
		"value": "Test_User_22370c1a-9012-42b2-bf64-86099c2a1c22@testuser.com",
		"type": "work",
		"primary": true
	}]
}
Request

GET /Users/5171a35d82074e068ce2

Response (User not found. Note that the detail is not required, only status.)
{
    "schemas": [
        "urn:ietf:params:scim:api:messages:2.0:Error"
    ],
    "status": "404",
    "detail": "Resource 23B51B0E5D7AE9110A49411D@7cca31655d49f3640a494224 not found"
}

Get User by query

Request

GET /Users?filter=userName eq "Test_User_dfeef4c5-5681-4387-b016-bdf221e82081"

Response

HTTP/1.1 200 OK

{
	"schemas": ["urn:ietf:params:scim:api:messages:2.0:ListResponse"],
	"totalResults": 1,
	"Resources": [{
		"schemas": ["urn:ietf:params:scim:schemas:core:2.0:User"],
		"id": "2441309d85324e7793ae",
		"externalId": "7fce0092-d52e-4f76-b727-3955bd72c939",
		"meta": {
			"resourceType": "User",
			"created": "2018-03-27T19:59:26.000Z",
			"lastModified": "2018-03-27T19:59:26.000Z"

		},
		"userName": "Test_User_dfeef4c5-5681-4387-b016-bdf221e82081",
		"name": {
			"familyName": "familyName",
			"givenName": "givenName"
		},
		"active": true,
		"emails": [{
			"value": "Test_User_91b67701-697b-46de-b864-bd0bbe4f99c1@testuser.com",
			"type": "work",
			"primary": true
		}]
	}],
	"startIndex": 1,
	"itemsPerPage": 20
}

Get User by query - Zero results

Request

GET /Users?filter=userName eq "non-existent user"

Response

HTTP/1.1 200 OK

{
	"schemas": ["urn:ietf:params:scim:api:messages:2.0:ListResponse"],
	"totalResults": 0,
	"Resources": [],
	"startIndex": 1,
	"itemsPerPage": 20
}

Update User [Multi-valued properties]

Request

PATCH /Users/6764549bef60420686bc HTTP/1.1

{
	"schemas": ["urn:ietf:params:scim:api:messages:2.0:PatchOp"],
	"Operations": [
            {
    		"op": "Replace",
    		"path": "emails[type eq \"work\"].value",
    		"value": "updatedEmail@microsoft.com"
    	    },
    	    {
    		"op": "Replace",
    		"path": "name.familyName",
    		"value": "updatedFamilyName"
    	    }
	]
}
Response

HTTP/1.1 200 OK

{
	"schemas": ["urn:ietf:params:scim:schemas:core:2.0:User"],
	"id": "6764549bef60420686bc",
	"externalId": "6c75de36-30fa-4d2d-a196-6bdcdb6b6539",
	"meta": {
		"resourceType": "User",
		"created": "2018-03-27T19:59:26.000Z",
		"lastModified": "2018-03-27T19:59:26.000Z"
	},
	"userName": "Test_User_fbb9dda4-fcde-4f98-a68b-6c5599e17c27",
	"name": {
		"formatted": "givenName updatedFamilyName",
		"familyName": "updatedFamilyName",
		"givenName": "givenName"
	},
	"active": true,
	"emails": [{
		"value": "updatedEmail@microsoft.com",
		"type": "work",
		"primary": true
	}]
}

Update User [Single-valued properties]

Request

PATCH /Users/5171a35d82074e068ce2 HTTP/1.1

{
	"schemas": ["urn:ietf:params:scim:api:messages:2.0:PatchOp"],
	"Operations": [{
		"op": "Replace",
		"path": "userName",
		"value": "5b50642d-79fc-4410-9e90-4c077cdd1a59@testuser.com"
	}]
}
Response

HTTP/1.1 200 OK

{
	"schemas": ["urn:ietf:params:scim:schemas:core:2.0:User"],
	"id": "5171a35d82074e068ce2",
	"externalId": "aa1eca08-7179-4eeb-a0be-a519f7e5cd1a",
	"meta": {
		"resourceType": "User",
		"created": "2018-03-27T19:59:26.000Z",
		"lastModified": "2018-03-27T19:59:26.000Z"

	},
	"userName": "5b50642d-79fc-4410-9e90-4c077cdd1a59@testuser.com",
	"name": {
		"formatted": "givenName familyName",
		"familyName": "familyName",
		"givenName": "givenName",
	},
	"active": true,
	"emails": [{
		"value": "Test_User_49dc1090-aada-4657-8434-4995c25a00f7@testuser.com",
		"type": "work",
		"primary": true
	}]
}

Disable User

Request

PATCH /Users/5171a35d82074e068ce2 HTTP/1.1

{
    "Operations": [
        {
            "op": "Replace",
            "path": "active",
            "value": false
        }
    ],
    "schemas": [
        "urn:ietf:params:scim:api:messages:2.0:PatchOp"
    ]
}
Response
{
    "schemas": [
        "urn:ietf:params:scim:schemas:core:2.0:User"
    ],
    "id": "CEC50F275D83C4530A495FCF@834d0e1e5d8235f90a495fda",
    "userName": "deanruiz@testuser.com",
    "name": {
        "familyName": "Harris",
        "givenName": "Larry"
    },
    "active": false,
    "emails": [
        {
            "value": "gloversuzanne@testuser.com",
            "type": "work",
            "primary": true
        }
    ],
    "addresses": [
        {
            "country": "ML",
            "type": "work",
            "primary": true
        }
    ],
    "meta": {
        "resourceType": "Users",
        "location": "/scim/5171a35d82074e068ce2/Users/CEC50F265D83B4530B495FCF@5171a35d82074e068ce2"
    }
}

Delete User

Request

DELETE /Users/5171a35d82074e068ce2 HTTP/1.1

Response

HTTP/1.1 204 No Content

Group Operations

  • Groups shall always be created with an empty members list.
  • Groups can be queried by the displayName attribute.
  • Update to the group PATCH request should yield an HTTP 204 No Content in the response. Returning a body with a list of all the members isn't advisable.
  • It isn't necessary to support returning all the members of the group.

Create Group

Request

POST /Groups HTTP/1.1

{
	"schemas": ["urn:ietf:params:scim:schemas:core:2.0:Group", "http://schemas.microsoft.com/2006/11/ResourceManagement/ADSCIM/2.0/Group"],
	"externalId": "8aa1a0c0-c4c3-4bc0-b4a5-2ef676900159",
	"displayName": "displayName",
	"meta": {
		"resourceType": "Group"
	}
}
Response

HTTP/1.1 201 Created

{
	"schemas": ["urn:ietf:params:scim:schemas:core:2.0:Group"],
	"id": "927fa2c08dcb4a7fae9e",
	"externalId": "8aa1a0c0-c4c3-4bc0-b4a5-2ef676900159",
	"meta": {
		"resourceType": "Group",
		"created": "2018-03-27T19:59:26.000Z",
		"lastModified": "2018-03-27T19:59:26.000Z"

	},
	"displayName": "displayName",
	"members": []
}

Get Group

Request

GET /Groups/40734ae655284ad3abcc?excludedAttributes=members HTTP/1.1

Response

HTTP/1.1 200 OK

{
	"schemas": ["urn:ietf:params:scim:schemas:core:2.0:Group"],
	"id": "40734ae655284ad3abcc",
	"externalId": "60f1bb27-2e1e-402d-bcc4-ec999564a194",
	"meta": {
		"resourceType": "Group",
		"created": "2018-03-27T19:59:26.000Z",
		"lastModified": "2018-03-27T19:59:26.000Z"
	},
	"displayName": "displayName",
}

Get Group by displayName

Request

GET /Groups?excludedAttributes=members&filter=displayName eq "displayName" HTTP/1.1

Response

HTTP/1.1 200 OK

{
	"schemas": ["urn:ietf:params:scim:api:messages:2.0:ListResponse"],
	"totalResults": 1,
	"Resources": [{
		"schemas": ["urn:ietf:params:scim:schemas:core:2.0:Group"],
		"id": "8c601452cc934a9ebef9",
		"externalId": "0db508eb-91e2-46e4-809c-30dcbda0c685",
		"meta": {
			"resourceType": "Group",
			"created": "2018-03-27T22:02:32.000Z",
			"lastModified": "2018-03-27T22:02:32.000Z",

		},
		"displayName": "displayName",
	}],
	"startIndex": 1,
	"itemsPerPage": 20
}

Update Group [Non-member attributes]

Request

PATCH /Groups/fa2ce26709934589afc5 HTTP/1.1

{
	"schemas": ["urn:ietf:params:scim:api:messages:2.0:PatchOp"],
	"Operations": [{
		"op": "Replace",
		"path": "displayName",
		"value": "1879db59-3bdf-4490-ad68-ab880a269474updatedDisplayName"
	}]
}
Response

HTTP/1.1 204 No Content

Update Group [Add Members]

Request

PATCH /Groups/a99962b9f99d4c4fac67 HTTP/1.1

{
	"schemas": ["urn:ietf:params:scim:api:messages:2.0:PatchOp"],
	"Operations": [{
		"op": "Add",
		"path": "members",
		"value": [{
			"$ref": null,
			"value": "f648f8d5ea4e4cd38e9c"
		}]
	}]
}
Response

HTTP/1.1 204 No Content

Update Group [Remove Members]

Request

PATCH /Groups/a99962b9f99d4c4fac67 HTTP/1.1

{
	"schemas": ["urn:ietf:params:scim:api:messages:2.0:PatchOp"],
	"Operations": [{
		"op": "Remove",
		"path": "members",
		"value": [{
			"$ref": null,
			"value": "f648f8d5ea4e4cd38e9c"
		}]
	}]
}
Response

HTTP/1.1 204 No Content

Delete Group

Request

DELETE /Groups/cdb1ce18f65944079d37 HTTP/1.1

Response

HTTP/1.1 204 No Content

Security requirements

TLS Protocol Versions

The only acceptable TLS protocol versions are TLS 1.2 and TLS 1.3. No other versions of TLS are permitted. No version of SSL is permitted.

  • RSA keys must be at least 2,048 bits.
  • ECC keys must be at least 256 bits, generated using an approved elliptic curve

Key Lengths

All services must use X.509 certificates generated using cryptographic keys of sufficient length, meaning:

Cipher Suites

All services must be configured to use the following cipher suites, in the exact order specified below. Note that if you only have an RSA certificate, installed the ECDSA cipher suites do not have any effect.

TLS 1.2 Cipher Suites minimum bar:

  • TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256
  • TLS_ECDHE_ECDSA_WITH_AES_256_GCM_SHA384
  • TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256
  • TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384
  • TLS_ECDHE_ECDSA_WITH_AES_128_CBC_SHA256
  • TLS_ECDHE_ECDSA_WITH_AES_256_CBC_SHA384
  • TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256
  • TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384

Step 3: Build a SCIM endpoint

By creating a SCIM web service that interfaces with Azure Active Directory, you can enable automatic user provisioning for virtually any application or identity store.

Here’s how it works:

  1. Azure AD provides a common language infrastructure (CLI) library named Microsoft.SystemForCrossDomainIdentityManagement, included with the code samples describe below. System integrators and developers can use this library to create and deploy a SCIM-based web service endpoint that can connect Azure AD to any application’s identity store.
  2. Mappings are implemented in the web service to map the standardized user schema to the user schema and protocol required by the application.
  3. The endpoint URL is registered in Azure AD as part of a custom application in the application gallery.
  4. Users and groups are assigned to this application in Azure AD. Upon assignment, they're put into a queue to be synchronized to the target application. The synchronization process handling the queue runs every 40 minutes.

Code samples

To make this process easier, code samples are provided, which create a SCIM web service endpoint and demonstrate automatic provisioning. The sample is of a provider that maintains a file with rows of comma-separated values representing users and groups.

Prerequisites

Getting started

The easiest way to implement a SCIM endpoint that can accept provisioning requests from Azure AD is to build and deploy the code sample that outputs the provisioned users to a comma-separated value (CSV) file.

To create a sample SCIM endpoint

  1. Download the code sample package at https://github.com/Azure/AzureAD-BYOA-Provisioning-Samples/tree/master

  2. Unzip the package and place it on your Windows machine at a location such as C:\AzureAD-BYOA-Provisioning-Samples.

  3. In this folder, launch the FileProvisioning\Host\FileProvisioningService.csproj project in Visual Studio.

  4. Select Tools > NuGet Package Manager > Package Manager Console, and execute the following commands for the FileProvisioningService project to resolve the solution references:

     Update-Package -Reinstall

  5. Build the FileProvisioningService project.

  6. Launch the Command Prompt application in Windows (as an Administrator), and use the cd command to change the directory to your \AzureAD-BYOA-Provisioning-Samples\FileProvisioning\Host\bin\Debug folder.

  7. Run the following command, replacing <ip-address> with the IP address or domain name of the Windows machine:

     FileSvc.exe http://<ip-address>:9000 TargetFile.csv

  8. In Windows under Windows Settings > Network & Internet Settings, select the Windows Firewall > Advanced Settings, and create an Inbound Rule that allows inbound access to port 9000.

  9. If the Windows machine is behind a router, the router needs to be configured to run Network Access Translation between its port 9000 that is exposed to the internet, and port 9000 on the Windows machine. This configuration is required for Azure AD to access this endpoint in the cloud.

To register the sample SCIM endpoint in Azure AD

  1. Sign in to the Azure Active Directory portal.

  2. Select Enterprise applications from the left pane. A list of all configured apps is shown, including apps that were added from the gallery.

  3. Select + New application > All > Non-gallery application.

  4. Enter a name for your application, and select Add to create an app object. The application object created is intended to represent the target app you would be provisioning to and implementing single sign-on for, and not just the SCIM endpoint.

  5. In the app management screen, select Provisioning in the left panel.

  6. In the Provisioning Mode menu, select Automatic.

  7. In the Tenant URL field, enter the URL of the application's SCIM endpoint. Example: https://api.contoso.com/scim/

  8. If the SCIM endpoint requires an OAuth bearer token from an issuer other than Azure AD, then copy the required OAuth bearer token into the optional Secret Token field. If this field is left blank, Azure AD includes an OAuth bearer token issued from Azure AD with each request. Apps that use Azure AD as an identity provider can validate this Azure AD-issued token.

  9. Select Test Connection to have Azure Active Directory attempt to connect to the SCIM endpoint. If the attempt fails, error information is displayed.

    Note

    Test Connection queries the SCIM endpoint for a user that doesn't exist, using a random GUID as the matching property selected in the Azure AD configuration. The expected correct response is HTTP 200 OK with an empty SCIM ListResponse message

  10. If the attempts to connect to the application succeed, then select Save to save the admin credentials.

  11. In the Mappings section, there are two selectable sets of attribute mappings: one for user objects and one for group objects. Select each one to review the attributes that are synchronized from Azure Active Directory to your app. The attributes selected as Matching properties are used to match the users and groups in your app for update operations. Select Save to commit any changes.

  12. Under Settings, the Scope field defines which users and or groups are synchronized. Select "Sync only assigned users and groups (recommended) to only sync users and groups assigned in the Users and groups tab.

  13. Once your configuration is complete, set the Provisioning Status to On.

  14. Select Save to start the Azure AD provisioning service.

  15. If syncing only assigned users and groups (recommended), be sure to select the Users and groups tab and assign the users or groups you want to sync.

Once the initial cycle has started, you can select Audit logs in the left panel to monitor progress, which shows all actions done by the provisioning service on your app. For more information on how to read the Azure AD provisioning logs, see Reporting on automatic user account provisioning.

The final step in verifying the sample is to open the TargetFile.csv file in the \AzureAD-BYOA-Provisioning-Samples\ProvisioningAgent\bin\Debug folder on your Windows machine. Once the provisioning process is run, this file shows the details of all assigned and provisioned users and groups.

Development libraries

To develop your own web service that conforms to the SCIM specification, first familiarize yourself with the following libraries provided by Microsoft to help accelerate the development process:

  • Common Language Infrastructure (CLI) libraries are offered for use with languages based on that infrastructure, such as C#. One of those libraries, Microsoft.SystemForCrossDomainIdentityManagement.Service, declares an interface, Microsoft.SystemForCrossDomainIdentityManagement.IProvider, shown in the following illustration. A developer using the libraries would implement that interface with a class that may be referred to, generically, as a provider. The libraries let the developer deploy a web service that conforms to the SCIM specification. The web service can be either hosted within Internet Information Services, or any executable CLI assembly. Request is translated into calls to the provider’s methods, which would be programmed by the developer to operate on some identity store.

    Breakdown: A request translated into calls to the provider's methods

  • Express route handlers are available for parsing node.js request objects representing calls (as defined by the SCIM specification), made to a node.js web service.

Building a custom SCIM endpoint

Developers using the CLI libraries can host their services within any executable CLI assembly, or within Internet Information Services. Here is sample code for hosting a service within an executable assembly, at the address http://localhost:9000:

 private static void Main(string[] arguments)
 {
 // Microsoft.SystemForCrossDomainIdentityManagement.IMonitor,
 // Microsoft.SystemForCrossDomainIdentityManagement.IProvider and
 // Microsoft.SystemForCrossDomainIdentityManagement.Service are all defined in
 // Microsoft.SystemForCrossDomainIdentityManagement.Service.dll.

 Microsoft.SystemForCrossDomainIdentityManagement.IMonitor monitor =
   new DevelopersMonitor();
 Microsoft.SystemForCrossDomainIdentityManagement.IProvider provider =
   new DevelopersProvider(arguments[1]);
 Microsoft.SystemForCrossDomainIdentityManagement.Service webService = null;
 try
 {
     webService = new WebService(monitor, provider);
     webService.Start("http://localhost:9000");

     Console.ReadKey(true);
 }
 finally
 {
     if (webService != null)
     {
         webService.Dispose();
         webService = null;
     }
 }
 }

 public class WebService : Microsoft.SystemForCrossDomainIdentityManagement.Service
 {
 private Microsoft.SystemForCrossDomainIdentityManagement.IMonitor monitor;
 private Microsoft.SystemForCrossDomainIdentityManagement.IProvider provider;

 public WebService(
   Microsoft.SystemForCrossDomainIdentityManagement.IMonitor monitoringBehavior,
   Microsoft.SystemForCrossDomainIdentityManagement.IProvider providerBehavior)
 {
     this.monitor = monitoringBehavior;
     this.provider = providerBehavior;
 }

 public override IMonitor MonitoringBehavior
 {
     get
     {
         return this.monitor;
     }

     set
     {
         this.monitor = value;
     }
 }

 public override IProvider ProviderBehavior
 {
     get
     {
         return this.provider;
     }

     set
     {
         this.provider = value;
     }
 }
 }

This service must have an HTTP address and server authentication certificate of which the root certification authority is one of the following names:

  • CNNIC
  • Comodo
  • CyberTrust
  • DigiCert
  • GeoTrust
  • GlobalSign
  • Go Daddy
  • VeriSign
  • WoSign

A server authentication certificate can be bound to a port on a Windows host using the network shell utility:

netsh http add sslcert ipport=0.0.0.0:443 certhash=0000000000003ed9cd0c315bbb6dc1c08da5e6 appid={00112233-4455-6677-8899-AABBCCDDEEFF}

Here, the value provided for the certhash argument is the thumbprint of the certificate, while the value provided for the appid argument is an arbitrary globally unique identifier.

To host the service within Internet Information Services, a developer would build a CLI code library assembly with a class named Startup in the default namespace of the assembly. Here is a sample of such a class:

 public class Startup
 {
 // Microsoft.SystemForCrossDomainIdentityManagement.IWebApplicationStarter,
 // Microsoft.SystemForCrossDomainIdentityManagement.IMonitor and
 // Microsoft.SystemForCrossDomainIdentityManagement.Service are all defined in
 // Microsoft.SystemForCrossDomainIdentityManagement.Service.dll.

 Microsoft.SystemForCrossDomainIdentityManagement.IWebApplicationStarter starter;

 public Startup()
 {
     Microsoft.SystemForCrossDomainIdentityManagement.IMonitor monitor =
       new DevelopersMonitor();
     Microsoft.SystemForCrossDomainIdentityManagement.IProvider provider =
       new DevelopersProvider();
     this.starter =
       new Microsoft.SystemForCrossDomainIdentityManagement.WebApplicationStarter(
         provider,
         monitor);
 }

 public void Configuration(
   Owin.IAppBuilder builder) // Defined in Owin.dll.
 {
     this.starter.ConfigureApplication(builder);
 }
 }

Handling endpoint authentication

Requests from Azure Active Directory include an OAuth 2.0 bearer token. Any service receiving the request should authenticate the issuer as being Azure Active Directory for the expected Azure Active Directory tenant, for access to the Microsoft Graph API service. In the token, the issuer is identified by an iss claim, like "iss":"https://sts.windows.net/cbb1a5ac-f33b-45fa-9bf5-f37db0fed422/". In this example, the base address of the claim value, https://sts.windows.net, identifies Azure Active Directory as the issuer, while the relative address segment, cbb1a5ac-f33b-45fa-9bf5-f37db0fed422, is a unique identifier of the Azure Active Directory tenant for which the token was issued. The audience for the token will be the application template ID for the app in the gallery. The application template ID for all custom apps is 8adf8e6e-67b2-4cf2-a259-e3dc5476c621. The application template ID for each app in the gallery varies. Please contact ProvisioningFeedback@microsoft.com for questions on the application template ID for a gallery application. Each of the applications registered in a single tenant may receive the same iss claim with SCIM requests.

Developers using the CLI libraries provided by Microsoft for building a SCIM service can authenticate requests from Azure Active Directory using the Microsoft.Owin.Security.ActiveDirectory package by following these steps:

First, in a provider, implement the Microsoft.SystemForCrossDomainIdentityManagement.IProvider.StartupBehavior property by having it return a method to be called whenever the service is started:

  public override Action<Owin.IAppBuilder, System.Web.Http.HttpConfiguration.HttpConfiguration> StartupBehavior
  {
    get
    {
      return this.OnServiceStartup;
    }
  }

  private void OnServiceStartup(
    Owin.IAppBuilder applicationBuilder,  // Defined in Owin.dll.
    System.Web.Http.HttpConfiguration configuration)  // Defined in System.Web.Http.dll.
  {
  }

Next, add the following code to that method to have any request to any of the service’s endpoints authenticated as bearing a token issued by Azure Active Directory for a specified tenant, for access to the Microsoft Graph API service:

  private void OnServiceStartup(
    Owin.IAppBuilder applicationBuilder IAppBuilder applicationBuilder,
    System.Web.Http.HttpConfiguration HttpConfiguration configuration)
  {
    // IFilter is defined in System.Web.Http.dll.
    System.Web.Http.Filters.IFilter authorizationFilter =
      new System.Web.Http.AuthorizeAttribute(); // Defined in System.Web.Http.dll.configuration.Filters.Add(authorizationFilter);

    // SystemIdentityModel.Tokens.TokenValidationParameters is defined in
    // System.IdentityModel.Token.Jwt.dll.
    SystemIdentityModel.Tokens.TokenValidationParameters tokenValidationParameters =
      new TokenValidationParameters()
      {
        ValidAudience = "8adf8e6e-67b2-4cf2-a259-e3dc5476c621"
      };

    // WindowsAzureActiveDirectoryBearerAuthenticationOptions is defined in
    // Microsoft.Owin.Security.ActiveDirectory.dll
    Microsoft.Owin.Security.ActiveDirectory.
    WindowsAzureActiveDirectoryBearerAuthenticationOptions authenticationOptions =
      new WindowsAzureActiveDirectoryBearerAuthenticationOptions()    {
      TokenValidationParameters = tokenValidationParameters,
      Tenant = "03F9FCBC-EA7B-46C2-8466-F81917F3C15E" // Substitute the appropriate tenant’s
                                                    // identifier for this one.
    };

    applicationBuilder.UseWindowsAzureActiveDirectoryBearerAuthentication(authenticationOptions);
  }

Handling provisioning and deprovisioning of users

Example 1. Query the service for a matching user

Azure Active Directory queries the service for a user with an externalId attribute value matching the mailNickname attribute value of a user in Azure AD. The query is expressed as a Hypertext Transfer Protocol (HTTP) request such as this example, wherein jyoung is a sample of a mailNickname of a user in Azure Active Directory.

Note

This is an example only. Not all users will have a mailNickname attribute, and the value a user has may not be unique in the directory. Also, the attribute used for matching (which in this case is externalId) is configurable in the Azure AD attribute mappings.

GET https://.../scim/Users?filter=externalId eq jyoung HTTP/1.1
 Authorization: Bearer ...

If the service was built using the CLI libraries provided by Microsoft for implementing SCIM services, then the request is translated into a call to the Query method of the service’s provider. Here is the signature of that method:

 // System.Threading.Tasks.Tasks is defined in mscorlib.dll.
 // Microsoft.SystemForCrossDomainIdentityManagement.Resource is defined in
 // Microsoft.SystemForCrossDomainIdentityManagement.Schemas.
 // Microsoft.SystemForCrossDomainIdentityManagement.IQueryParameters is defined in
 // Microsoft.SystemForCrossDomainIdentityManagement.Protocol.

 System.Threading.Tasks.Task<Microsoft.SystemForCrossDomainIdentityManagement.Resource[]> Query(
   Microsoft.SystemForCrossDomainIdentityManagement.IQueryParameters parameters,
   string correlationIdentifier);

Here is the definition of the Microsoft.SystemForCrossDomainIdentityManagement.IQueryParameters interface:

 public interface IQueryParameters:
   Microsoft.SystemForCrossDomainIdentityManagement.IRetrievalParameters
 {
     System.Collections.Generic.IReadOnlyCollection <Microsoft.SystemForCrossDomainIdentityManagement.IFilter> AlternateFilters
     { get; }
 }

 public interface Microsoft.SystemForCrossDomainIdentityManagement.IRetrievalParameters
 {
   system.Collections.Generic.IReadOnlyCollection<string> ExcludedAttributePaths
   { get; }
   System.Collections.Generic.IReadOnlyCollection<string> RequestedAttributePaths
   { get; }
   string SchemaIdentifier
   { get; }
 }
    GET https://.../scim/Users?filter=externalId eq jyoung HTTP/1.1
    Authorization: Bearer ...

If the service was built using the Common Language Infrastructure libraries provided by Microsoft for implementing SCIM services, then the request is translated into a call to the Query method of the service’s provider. Here is the signature of that method:

  // System.Threading.Tasks.Tasks is defined in mscorlib.dll.
  // Microsoft.SystemForCrossDomainIdentityManagement.Resource is defined in
  // Microsoft.SystemForCrossDomainIdentityManagement.Schemas.
  // Microsoft.SystemForCrossDomainIdentityManagement.IQueryParameters is defined in
  // Microsoft.SystemForCrossDomainIdentityManagement.Protocol.

  System.Threading.Tasks.Task<Microsoft.SystemForCrossDomainIdentityManagement.Resource[]>  Query(
    Microsoft.SystemForCrossDomainIdentityManagement.IQueryParameters parameters,
    string correlationIdentifier);

Here is the definition of the Microsoft.SystemForCrossDomainIdentityManagement.IQueryParameters interface:

  public interface IQueryParameters:
    Microsoft.SystemForCrossDomainIdentityManagement.IRetrievalParameters
  {
      System.Collections.Generic.IReadOnlyCollection  <Microsoft.SystemForCrossDomainIdentityManagement.IFilter> AlternateFilters
      { get; }
  }

  public interface Microsoft.SystemForCrossDomainIdentityManagement.IRetrievalParameters
  {
    system.Collections.Generic.IReadOnlyCollection<string> ExcludedAttributePaths
    { get; }
    System.Collections.Generic.IReadOnlyCollection<string> RequestedAttributePaths
    { get; }
    string SchemaIdentifier
    { get; }
  }

  public interface Microsoft.SystemForCrossDomainIdentityManagement.IFilter
  {
      Microsoft.SystemForCrossDomainIdentityManagement.IFilter AdditionalFilter
        { get; set; }
      string AttributePath
        { get; }
      Microsoft.SystemForCrossDomainIdentityManagement.ComparisonOperator FilterOperator
        { get; }
      string ComparisonValue
        { get; }
  }

  public enum Microsoft.SystemForCrossDomainIdentityManagement.ComparisonOperator
  {
      Equals
  }

In the following sample of a query for a user with a given value for the externalId attribute, values of the arguments passed to the Query method are:

  • parameters.AlternateFilters.Count: 1
  • parameters.AlternateFilters.ElementAt(0).AttributePath: "externalId"
  • parameters.AlternateFilters.ElementAt(0).ComparisonOperator: ComparisonOperator.Equals
  • parameters.AlternateFilter.ElementAt(0).ComparisonValue: "jyoung"
  • correlationIdentifier: System.Net.Http.HttpRequestMessage.GetOwinEnvironment["owin.RequestId"]

Example 2. Provision a user

If the response to a query to the web service for a user with an externalId attribute value that matches the mailNickname attribute value of a user doesn't return any users, then Azure Active Directory requests that the service provision a user corresponding to the one in Azure Active Directory. Here is an example of such a request:

 POST https://.../scim/Users HTTP/1.1
 Authorization: Bearer ...
 Content-type: application/scim+json
 {
   "schemas":
   [
     "urn:ietf:params:scim:schemas:core:2.0:User",
     "urn:ietf:params:scim:schemas:extension:enterprise:2.0User"],
   "externalId":"jyoung",
   "userName":"jyoung",
   "active":true,
   "addresses":null,
   "displayName":"Joy Young",
   "emails": [
     {
       "type":"work",
       "value":"jyoung@Contoso.com",
       "primary":true}],
   "meta": {
     "resourceType":"User"},
    "name":{
     "familyName":"Young",
     "givenName":"Joy"},
   "phoneNumbers":null,
   "preferredLanguage":null,
   "title":null,
   "department":null,
   "manager":null}

The CLI libraries provided by Microsoft for implementing SCIM services would translate that request into a call to the Create method of the service’s provider. The Create method has this signature:

 // System.Threading.Tasks.Tasks is defined in mscorlib.dll.
 // Microsoft.SystemForCrossDomainIdentityManagement.Resource is defined in
 // Microsoft.SystemForCrossDomainIdentityManagement.Schemas.

 System.Threading.Tasks.Task<Microsoft.SystemForCrossDomainIdentityManagement.Resource> Create(
   Microsoft.SystemForCrossDomainIdentityManagement.Resource resource,
   string correlationIdentifier);

In a request to provision a user, the value of the resource argument is an instance of the Microsoft.SystemForCrossDomainIdentityManagement. Core2EnterpriseUser class, defined in the Microsoft.SystemForCrossDomainIdentityManagement.Schemas library. If the request to provision the user succeeds, then the implementation of the method is expected to return an instance of the Microsoft.SystemForCrossDomainIdentityManagement. Core2EnterpriseUser class, with the value of the Identifier property set to the unique identifier of the newly provisioned user.

Example 3. Query the current state of a user

To update a user known to exist in an identity store fronted by an SCIM, Azure Active Directory proceeds by requesting the current state of that user from the service with a request such as:

 GET ~/scim/Users/54D382A4-2050-4C03-94D1-E769F1D15682 HTTP/1.1
 Authorization: Bearer ...

In a service built using the CLI libraries provided by Microsoft for implementing SCIM services, the request is translated into a call to the Retrieve method of the service’s provider. Here is the signature of the Retrieve method:

 // System.Threading.Tasks.Tasks is defined in mscorlib.dll.
 // Microsoft.SystemForCrossDomainIdentityManagement.Resource and
 // Microsoft.SystemForCrossDomainIdentityManagement.IResourceRetrievalParameters
 // are defined in Microsoft.SystemForCrossDomainIdentityManagement.Schemas.
 System.Threading.Tasks.Task<Microsoft.SystemForCrossDomainIdentityManagement.Resource>
    Retrieve(
      Microsoft.SystemForCrossDomainIdentityManagement.IResourceRetrievalParameters
        parameters,
        string correlationIdentifier);

 public interface
   Microsoft.SystemForCrossDomainIdentityManagement.IResourceRetrievalParameters:
     IRetrievalParameters
     {
       Microsoft.SystemForCrossDomainIdentityManagement.IResourceIdentifier
         ResourceIdentifier
           { get; }
 }
 public interface Microsoft.SystemForCrossDomainIdentityManagement.IResourceIdentifier
 {
     string Identifier
       { get; set; }
     string Microsoft.SystemForCrossDomainIdentityManagement.SchemaIdentifier
       { get; set; }
 }

In the example of a request to retrieve the current state of a user, the values of the properties of the object provided as the value of the parameters argument are as follows:

  • Identifier: "54D382A4-2050-4C03-94D1-E769F1D15682"
  • SchemaIdentifier: "urn:ietf:params:scim:schemas:extension:enterprise:2.0:User"

Example 4. Query the value of a reference attribute to be updated

If a reference attribute is to be updated, then Azure Active Directory queries the service to determine whether the current value of the reference attribute in the identity store fronted by the service already matches the value of that attribute in Azure Active Directory. For users, the only attribute of which the current value is queried in this way is the manager attribute. Here is an example of a request to determine whether the manager attribute of a particular user object currently has a certain value:

If the service was built using the CLI libraries provided by Microsoft for implementing SCIM services, then the request is translated into a call to the Query method of the service’s provider. The value of the properties of the object provided as the value of the parameters argument are as follows:

  • parameters.AlternateFilters.Count: 2
  • parameters.AlternateFilters.ElementAt(x).AttributePath: "ID"
  • parameters.AlternateFilters.ElementAt(x).ComparisonOperator: ComparisonOperator.Equals
  • parameters.AlternateFilter.ElementAt(x).ComparisonValue: "54D382A4-2050-4C03-94D1-E769F1D15682"
  • parameters.AlternateFilters.ElementAt(y).AttributePath: "manager"
  • parameters.AlternateFilters.ElementAt(y).ComparisonOperator: ComparisonOperator.Equals
  • parameters.AlternateFilter.ElementAt(y).ComparisonValue: "2819c223-7f76-453a-919d-413861904646"
  • parameters.RequestedAttributePaths.ElementAt(0): "ID"
  • parameters.SchemaIdentifier: "urn:ietf:params:scim:schemas:extension:enterprise:2.0:User"

Here, the value of the index x can be 0 and the value of the index y can be 1, or the value of x can be 1 and the value of y can be 0, depending on the order of the expressions of the filter query parameter.

Example 5. Request from Azure AD to an SCIM service to update a user

Here is an example of a request from Azure Active Directory to an SCIM service to update a user:

  PATCH ~/scim/Users/54D382A4-2050-4C03-94D1-E769F1D15682 HTTP/1.1
  Authorization: Bearer ...
  Content-type: application/scim+json
  {
    "schemas":
    [
      "urn:ietf:params:scim:api:messages:2.0:PatchOp"],
    "Operations":
    [
      {
        "op":"Add",
        "path":"manager",
        "value":
          [
            {
              "$ref":"http://.../scim/Users/2819c223-7f76-453a-919d-413861904646",
              "value":"2819c223-7f76-453a-919d-413861904646"}]}]}

The Microsoft Common Language Infrastructure libraries for implementing SCIM services would translate the request into a call to the Update method of the service’s provider. Here is the signature of the Update method:

  // System.Threading.Tasks.Tasks and
  // System.Collections.Generic.IReadOnlyCollection<T>
  // are defined in mscorlib.dll.
  // Microsoft.SystemForCrossDomainIdentityManagement.IPatch,
  // Microsoft.SystemForCrossDomainIdentityManagement.PatchRequestBase,
  // Microsoft.SystemForCrossDomainIdentityManagement.IResourceIdentifier,
  // Microsoft.SystemForCrossDomainIdentityManagement.PatchOperation,
  // Microsoft.SystemForCrossDomainIdentityManagement.OperationName,
  // Microsoft.SystemForCrossDomainIdentityManagement.IPath and
  // Microsoft.SystemForCrossDomainIdentityManagement.OperationValue
  // are all defined in Microsoft.SystemForCrossDomainIdentityManagement.Protocol.

  System.Threading.Tasks.Task Update(
    Microsoft.SystemForCrossDomainIdentityManagement.IPatch patch,
    string correlationIdentifier);

  public interface Microsoft.SystemForCrossDomainIdentityManagement.IPatch
  {
  Microsoft.SystemForCrossDomainIdentityManagement.PatchRequestBase
    PatchRequest
      { get; set; }
  Microsoft.SystemForCrossDomainIdentityManagement.IResourceIdentifier
    ResourceIdentifier
      { get; set; }
  }

  public class PatchRequest2:
    Microsoft.SystemForCrossDomainIdentityManagement.PatchRequestBase
  {
  public System.Collections.Generic.IReadOnlyCollection
    <Microsoft.SystemForCrossDomainIdentityManagement.PatchOperation>
      Operations
      { get;}

  public void AddOperation(
    Microsoft.SystemForCrossDomainIdentityManagement.PatchOperation operation);
  }

  public class PatchOperation
  {
  public Microsoft.SystemForCrossDomainIdentityManagement.OperationName
    Name
    { get; set; }

  public Microsoft.SystemForCrossDomainIdentityManagement.IPath
    Path
    { get; set; }

  public System.Collections.Generic.IReadOnlyCollection
    <Microsoft.SystemForCrossDomainIdentityManagement.OperationValue> Value
    { get; }

  public void AddValue(
    Microsoft.SystemForCrossDomainIdentityManagement.OperationValue value);
  }

  public enum OperationName
  {
    Add,
    Remove,
    Replace
  }

  public interface IPath
  {
    string AttributePath { get; }
    System.Collections.Generic.IReadOnlyCollection<IFilter> SubAttributes { get; }
    Microsoft.SystemForCrossDomainIdentityManagement.IPath ValuePath { get; }
  }

  public class OperationValue
  {
    public string Reference
    { get; set; }

    public string Value
    { get; set; }
  }

In the example of a request to update a user, the object provided as the value of the patch argument has these property values:

  • ResourceIdentifier.Identifier: "54D382A4-2050-4C03-94D1-E769F1D15682"
  • ResourceIdentifier.SchemaIdentifier: "urn:ietf:params:scim:schemas:extension:enterprise:2.0:User"
  • (PatchRequest as PatchRequest2).Operations.Count: 1
  • (PatchRequest as PatchRequest2).Operations.ElementAt(0).OperationName: OperationName.Add
  • (PatchRequest as PatchRequest2).Operations.ElementAt(0).Path.AttributePath: "manager"
  • (PatchRequest as PatchRequest2).Operations.ElementAt(0).Value.Count: 1
  • (PatchRequest as PatchRequest2).Operations.ElementAt(0).Value.ElementAt(0).Reference: http://.../scim/Users/2819c223-7f76-453a-919d-413861904646
  • (PatchRequest as PatchRequest2).Operations.ElementAt(0).Value.ElementAt(0).Value: 2819c223-7f76-453a-919d-413861904646

Example 6. Deprovision a user

To deprovision a user from an identity store fronted by an SCIM service, Azure AD sends a request such as:

  DELETE ~/scim/Users/54D382A4-2050-4C03-94D1-E769F1D15682 HTTP/1.1
  Authorization: Bearer ...

If the service was built using the Common Language Infrastructure libraries provided by Microsoft for implementing SCIM services, then the request is translated into a call to the Delete method of the service’s provider. That method has this signature:

  // System.Threading.Tasks.Tasks is defined in mscorlib.dll.
  // Microsoft.SystemForCrossDomainIdentityManagement.IResourceIdentifier,
  // is defined in Microsoft.SystemForCrossDomainIdentityManagement.Protocol.
  System.Threading.Tasks.Task Delete(
    Microsoft.SystemForCrossDomainIdentityManagement.IResourceIdentifier
      resourceIdentifier,
    string correlationIdentifier);

The object provided as the value of the resourceIdentifier argument has these property values in the example of a request to deprovision a user:

  • ResourceIdentifier.Identifier: "54D382A4-2050-4C03-94D1-E769F1D15682"
  • ResourceIdentifier.SchemaIdentifier: "urn:ietf:params:scim:schemas:extension:enterprise:2.0:User"

Step 4: Integrate your SCIM endpoint with the Azure AD SCIM client

Azure AD can be configured to automatically provision assigned users and groups to applications that implement a specific profile of the SCIM 2.0 protocol. The specifics of the profile are documented in Step 2: Understand the Azure AD SCIM implementation.

Check with your application provider, or your application provider's documentation for statements of compatibility with these requirements.

Important

The Azure AD SCIM implementation is built on top of the Azure AD user provisioning service, which is designed to constantly keep users in sync between Azure AD and the target application, and implements a very specific set of standard operations. It's important to understand these behaviors to understand the behavior of the Azure AD SCIM client. For more information, see the section Provisioning cycles: Initial and incremental in How provisioning works.

Getting started

Applications that support the SCIM profile described in this article can be connected to Azure Active Directory using the "non-gallery application" feature in the Azure AD application gallery. Once connected, Azure AD runs a synchronization process every 40 minutes where it queries the application's SCIM endpoint for assigned users and groups, and creates or modifies them according to the assignment details.

To connect an application that supports SCIM:

  1. Sign in to the Azure Active Directory portal. Note that you can get access a free trial for Azure Active Directory with P2 licenses by signing up for the developer program

  2. Select Enterprise applications from the left pane. A list of all configured apps is shown, including apps that were added from the gallery.

  3. Select + New application > All > Non-gallery application.

  4. Enter a name for your application, and select Add to create an app object. The new app is added to the list of enterprise applications and opens to its app management screen.

    Screenshot shows the Azure AD application gallery
    Azure AD application gallery

  5. In the app management screen, select Provisioning in the left panel.

  6. In the Provisioning Mode menu, select Automatic.

    Example: An app's Provisioning page in the Azure portal
    Configuring provisioning in the Azure portal

  7. In the Tenant URL field, enter the URL of the application's SCIM endpoint. Example: https://api.contoso.com/scim/

  8. If the SCIM endpoint requires an OAuth bearer token from an issuer other than Azure AD, then copy the required OAuth bearer token into the optional Secret Token field. If this field is left blank, Azure AD includes an OAuth bearer token issued from Azure AD with each request. Apps that use Azure AD as an identity provider can validate this Azure AD-issued token.

    Note

    It's not recommended to leave this field blank and rely on a token generated by Azure AD. This option is primarily available for testing purposes.

  9. Select Test Connection to have Azure Active Directory attempt to connect to the SCIM endpoint. If the attempt fails, error information is displayed.

    Note

    Test Connection queries the SCIM endpoint for a user that doesn't exist, using a random GUID as the matching property selected in the Azure AD configuration. The expected correct response is HTTP 200 OK with an empty SCIM ListResponse message.

  10. If the attempts to connect to the application succeed, then select Save to save the admin credentials.

  11. In the Mappings section, there are two selectable sets of attribute mappings: one for user objects and one for group objects. Select each one to review the attributes that are synchronized from Azure Active Directory to your app. The attributes selected as Matching properties are used to match the users and groups in your app for update operations. Select Save to commit any changes.

    Note

    You can optionally disable syncing of group objects by disabling the "groups" mapping.

  12. Under Settings, the Scope field defines which users and groups are synchronized. Select Sync only assigned users and groups (recommended) to only sync users and groups assigned in the Users and groups tab.

  13. Once your configuration is complete, set the Provisioning Status to On.

  14. Select Save to start the Azure AD provisioning service.

  15. If syncing only assigned users and groups (recommended), be sure to select the Users and groups tab and assign the users or groups you want to sync.

Once the initial cycle has started, you can select Provisioning logs in the left panel to monitor progress, which shows all actions done by the provisioning service on your app. For more information on how to read the Azure AD provisioning logs, see Reporting on automatic user account provisioning.

Note

The initial cycle takes longer to perform than later syncs, which occur approximately every 40 minutes as long as the service is running.

If you're building an application that will be used by more than one tenant, you can make it available in the Azure AD application gallery. This will make it easy for organizations to discover the application and configure provisioning. Publishing your app in the Azure AD gallery and making provisioning available to others is easy. Check out the steps here. Microsoft will work with you to integrate your application into our gallery, test your endpoint, and release onboarding documentation for customers to use.

Follow the checklist below to ensure that your application is onboarded quicky and customers have a smooth deployment experience. The information will be gathered from you when onboarding to the gallery.

  • Support a SCIM 2.0 user and group endpoint (Only one is required but both are recommended)
  • Support at least 25 requests per second per tenant (Required)
  • Support the OAuth authorization code grant or a long lived token as described below (Required)
  • Establish an engineering and support point of contact to support customers post gallery onboarding (Required)
  • Support updating multiple group memberships with a single PATCH (Recommended)
  • Document your SCIM endpoint publicly (Recommended)
  • Support schema discovery (Recommended)

The SCIM spec does not define a SCIM-specific scheme for authentication and authorization. It relies on the use of existing industry standards. The Azure AD provisioning client supports two authorization methods for applications in the gallery.

Authorization method Pros Cons Support
Username and password (not recommended or supported by Azure AD) Easy to implement Insecure - Your Pa$$word doesn't matter Supported on a case-by-case basis for gallery apps. Not supported for non-gallery apps.
Long-lived bearer token (supported by Azure AD currently) Long-lived tokens do not require a user to be present. They are easy for admins to use when setting up provisioning. Long-lived tokens can be hard to share with an admin without using insecure methods such as email. Supported for gallery and non-gallery apps.
OAuth authorization code grant (supported by Azure AD currently) Access tokens are much shorter-lived than passwords, and have an automated refresh mechanism that long-lived bearer tokens do not have. A real user must be present during initial authorization, adding a level of accountability. Requires a user to be present. If the user leaves the organization, the token is invalid and authorization will need to be completed again. Supported for gallery apps. Support for non-gallery apps is underway.
OAuth client credentials grant (not supported, on our roadmap) Access tokens are much shorter-lived than passwords, and have an automated refresh mechanism that long-lived bearer tokens do not have. Both the authorization code grant and the client credentials grant create the same type of access token, so moving between these methods is transparent to the API. Provisioning can be completely automated, and new tokens can be silently requested without user interaction. Not supported for gallery and non-gallery apps. Support is in our backlog.

OAuth authorization code grant flow: The provisioning service supports the authorization code grant. After submitting your request for publishing your app in the gallery, our team will work with you to collect the following information:

  • Authorization URL: A URL by the client to obtain authorization from the resource owner via user-agent redirection. The user is redirected to this URL to authorize access.
  • Token exchange URL: A URL by the client to exchange an authorization grant for an access token, typically with client authentication.
  • Client ID: The authorization server issues the registered client a client identifier, which is a unique string representing the registration information provided by the client. The client identifier is not a secret; it is exposed to the resource owner and must not be used alone for client authentication.
  • Client secret: The client secret is a secret generated by the authorization server. It should be a unique value known only to the authorization server.

Note that OAuth v1 is not supported due to exposure of the client secret. OAuth v2 is supported.

Best practices (recommended but not required):

  • Support multiple redirect URLs. Administrators can configure provisioning from both "portal.azure.com" and "aad.portal.azure.com". Supporting multiple redirect URLs will ensure that users can authorize access from either portal.
  • Support multiple secrets to ensure smooth secret renewal, without downtime.

Long lived OAuth bearer tokens: If your application does not support the OAuth authorization code grant flow, you can also generate a long lived OAuth bearer token than that an administrator can use to setup the provisioning integration. The token should be perpetual, or else the provisioning job will be quarantined when the token expires. This token must be below 1KB in size.

For additional authentication and authorization methods, let us know on UserVoice.

To help drive awareness and demand of our joint integration, we recommend you update your existing documentation and amplify the integration in your marketing channels. The below is a set of checklist activities we recommend you complete to support the launch

  • Sales and customer support readiness. Ensure your sales and support teams are aware and can speak to the integration capabilities. Brief your sales and support team, provide them with FAQs and include the integration into your sales materials.
  • Blog post and/or press release. Craft a blog post or press release that describes the joint integration, the benefits and how to get started. Example: Imprivata and Azure Active Directory Press Release
  • Social media. Leverage your social media like Twitter, Facebook or LinkedIn to promote the integration to your customers. Be sure to include @AzureAD so we can retweet your post. Example: Imprivata Twitter Post
  • Marketing website. Create or update your marketing pages (e.g. integration page, partner page, pricing page, etc.) to include the availability of the joint integration. Example: Pingboard integration Page, Smartsheet integration page, Monday.com pricing page
  • Technical documentation. Create a help center article or technical documentation on how customers can get started. Example: Envoy + Microsoft Azure Active Directory integration.
  • Customer communication. Alert customers of the new integration through your customer communication (monthly newsletters, email campaigns, product release notes).

Allow IP addresses used by the Azure AD provisioning service to make SCIM requests

Certain apps allow inbound traffic to their app. In order for the Azure AD provisioning service to function as expected, the IP addresses used must be allowed. For a list of IP addresses for each service tag/region, see the JSON file - Azure IP Ranges and Service Tags – Public Cloud. You can download and program these IPs into your firewall as needed. The reserved IP ranges for Azure AD provisioning can be found under "AzureActiveDirectoryDomainServices."
