Single sign-on to applications in Azure Active Directory

Learn how to choose the most appropriate single sign-on method when configuring applications in Azure Active Directory (Azure AD).

  • With single sign-on, users sign in once with one account to access domain-joined devices, company resources, software as a service (SaaS) applications, and web applications. After signing in, the user can launch applications from the Office 365 portal or the Azure AD MyApps access panel. Administrators can centralize user account management, and automatically add or remove user access to applications based on group membership.

  • Without single sign-on, users must remember application-specific passwords and sign in to each application. IT staff needs to create and update user accounts for each application such as Office 365, Box, and Salesforce. Users need to remember their passwords, plus spend the time to sign in to each application.

This article describes the single sign-on methods, and helps you choose the best method for your applications.

Choosing a single sign-on method

There are several ways to configure an application for single sign-on. Choosing a single sign method for an application depends on how the application is configured for authentication. All of the single sign-on methods, except disabled, automatically sign users in to applications without requiring a second sign-on.

  • Cloud applications can use SAML, password-based, linked, or disabled methods for single sign-on. SAML is the most secure single sign-on method.
  • On-premises applications can use password-based, Integrated Windows Authentication, header-based, linked, or disabled methods for single sign-on. The on-premises choices work when applications are configured for Application Proxy.

This flowchart helps you decide which single sign-on method is best for your situation.

Choose single sign-on method

The following table summarizes the single sign-on methods, and links to more details.

Single sign-on method Application types When to use
SAML Cloud only Use SAML whenever possible. SAML works when apps are configured to use one of the SAML protocols.
Password-based cloud and on-premises Use when the application authenticates with username and password. Password-based single sign-on enables secure application password storage and replay using a web browser extension or mobile app. This method uses the existing sign-in process provided by the application, but enables an administrator to manage the passwords.
Linked cloud and on-premises Use linked single sign-on when the application is configured for single sign-on in another identity provider service. This option doesn't add single sign-on to the application. However, the application might already have single sign-on implemented using another service such as Active Directory Federation Services.
Disabled cloud and on-premises Use disabled single sign-on when the app isn't ready to be configured for single sign-on. Users need to enter their username and password every time they launch this application.
Integrated Windows Authentication (IWA) on-premises only Use this single sign-on method for applications that use Integrated Windows Authentication (IWA), or claims-aware applications. The Application Proxy connectors use Kerberos Constrained Delegation (KCD) to authenticate users to the application.
Header-based on-premises only Use header-based single sign-on when the application uses headers for authentication. Header-based single sign-on requires PingAccess for Azure Active Directory. Application Proxy uses Azure AD to authenticate the user and then passes traffic through the connector service.

SAML SSO

With SAML single sign-on, Azure AD authenticates to the application by using the user's Azure AD account. Azure AD communicates the sign-on information to the application through a connection protocol. With SAML-based single sign-on, you can map users to specific application roles based on rules you define in your SAML claims

SAML-based single sign-on is:

  • More secure than password-based single sign-on and all other sign-on methods.
  • Our recommended method for single sign-on.

SAML-based single sign-on is supported for applications that use any of these protocols:

  • SAML 2.0
  • WS-Federation

To configure an application for SAML-based single sign-on, see Configure SAML-based single sign-on. Also, many applications have application-specific tutorials that step you through configuring SAML-based single sign-on for specific applications.

For more information about how the SAML protocol works, see Single sign-on SAML protocol.

Password-based SSO

With password-based sign-on, the application authenticates to the application with a username and password. End-users sign in to the application the first time they access it. After the first sign-on, Azure Active Directory supplies the username and password to the application.

Password-based single sign-on uses the existing authentication process provided by the application. When you enable password single sign-on for an application, Azure AD collects and securely stores user names and passwords for the application. User credentials are stored in an encrypted state in the directory.

Use password-based single sign-on when:

  • An application can't support SAML single sign-on protocol.
  • An application authenticates with a username and password instead of access tokens and headers.

Password-based single sign-on is supported for any cloud-based application that has an HTML-based sign-in page. The user can use any of the following browsers:

  • Internet Explorer 11 on Windows 7 or later
  • Edge on Windows 10 Anniversary Edition or later
  • Chrome on Windows 7 or later, and on MacOS X or later
  • Firefox 26.0 or later on Windows XP SP2 or later, and on Mac OS X 10.6 or later

To configure a cloud application for password-based single sign-on, see Configure the application for password single sign-on.

To configure an on-premises application for single sign-on through Application Proxy, see Password vaulting for single sign-on with Application Proxy

Managing credentials for password-based SSO

To authenticate a user to an application, Azure AD retrieves the user's credentials from the directory and enters them into the application's sign-in page. Azure AD securely passes the user credentials via a web browser extension or mobile app. This process enables an administrator to manage user credentials, and doesn't require users to remember their password.

Important

The credentials are obfuscated from the end user during the automated sign-in process. However, the credentials are discoverable by using web-debugging tools. Users and administrators need to follow the same security policies as if credentials were entered directly by the user.

Passwords for each application can either be managed by the Azure AD administrator or by the users.

When the Azure AD administrator manages the credentials:

  • The user doesn't need to reset or remember the user name and password. The user can access the application by clicking on it in their access panel or via a provided link.
  • The administrator can do management tasks on the credentials. For example, the administrator can update application access according to user group memberships and employee status.
  • The administrator can use administrative credentials to provide access to applications shared among many users. For example, the administrator can allow everyone who can access an application to have access to a social media or document sharing application.

When the end user manages the credentials:

  • Users can manage their passwords by updating or deleting them as needed.
  • Administrators are still able to set new credentials for the application.

Linked SSO

Linked sign-on enables Azure AD to provide single sign-on to an application that is already configured for single sign-on in another service. The linked application can appear to end users in the Office 365 portal or Azure AD MyApps portal. For example, a user can launch an application that is configured for single sign-on in Active Directory Federation Services 2.0 (AD FS) from the Office 365 portal. Additional reporting is also available for linked applications that are launched from the Office 365 portal or the Azure AD MyApps portal.

Use linked single sign-on to:

  • Provide a consistent user experience while you migrate applications over a period of time. If you're migrating applications to Azure Active Directory, you can use linked single sign-on to quickly publish links to all the applications you intend to migrate. Users can find all the links in the MyApps portal or the Office 365 application launcher. Users won't know they're accessing a linked application or a migrated application.

Once a user has authenticated with a linked application, an account record needs to be created before the end user is provided single sign-on access. Provisioning this account record can either occur automatically, or it can occur manually by an administrator.

Disabled SSO

Disabled mode means single sign-on isn't used for the application. When single sign-on is disabled, users might need to authenticate twice. First, users authenticate to Azure AD, and then they sign in to the application.

Use disabled single sign-on mode:

  • If you're not ready to integrate this application with Azure AD single sign-on, or
  • If you're testing other aspects of the application, or
  • As a layer of security to an on-premises application that doesn't require users to authenticate. With disabled, the user needs to authenticate.

Integrated Windows Authentication (IWA) SSO

Azure AD Application Proxy provides single sign-on (SSO) to applications that use Integrated Windows Authentication (IWA), or claims-aware applications. If your application uses IWA, Application Proxy authenticates to the application by using Kerberos Constrained Delegation (KCD). For a claims-aware application that trusts Azure Active Directory, single sign-on works because the user was already authenticated by using Azure AD.

Use Integrated Windows Authentication single sign-on mode:

  • To provide single sign-on to an on-premises app that authenticates with IWA.

To configure an on-premises app for IWA, see Kerberos Constrained Delegation for single sign-on to your applications with Application Proxy.

How single sign-on with KCD works

This diagram explains the flow when a user accesses an on-premises application that uses IWA.

Microsoft AAD authentication flow diagram

  1. The user enters the URL to access the on-prem application through Application Proxy.
  2. Application Proxy redirects the request to Azure AD authentication services to preauthenticate. At this point, Azure AD applies any applicable authentication and authorization policies, such as multifactor authentication. If the user is validated, Azure AD creates a token and sends it to the user.
  3. The user passes the token to Application Proxy.
  4. Application Proxy validates the token and retrieves the User Principal Name (UPN) from the token. It then sends the request, the UPN, and the Service Principal Name (SPN) to the Connector through a dually authenticated secure channel.
  5. The connector uses Kerberos Constrained Delegation (KCD) negotiation with the on-prem AD, impersonating the user to get a Kerberos token to the application.
  6. Active Directory sends the Kerberos token for the application to the connector.
  7. The connector sends the original request to the application server, using the Kerberos token it received from AD.
  8. The application sends the response to the connector, which is then returned to the Application Proxy service and finally to the user.

Header-based SSO

Header-based single sign-on works for applications that use HTTP headers for authentication. This sign-on method uses a third-party authentication service called PingAccess. A user only needs to authenticate to Azure AD.

Use header-based single sign-on when:

  • Application Proxy and PingAccess are configured for the application

To configure header-based authentication, see Header-based authentication for single sign-on with Application Proxy.

What is PingAccess for Azure AD?

Using PingAccess for Azure AD, users can access and single sign-on to applications that use headers for authentication. Application Proxy treats these applications like any other, using Azure AD to authenticate access and then passing traffic through the connector service. After authentication occurs, the PingAccess service translates the Azure AD access token into a header format that is sent to the application.

Your users won’t notice anything different when they sign in to use your corporate applications. They can still work from anywhere on any device. The Application Proxy connectors direct remote traffic to all applications, and they’ll continue to load balance automatically.

How do I get a license for PingAccess?

Since this scenario is offered through a partnership between Azure Active Directory and PingAccess, you need licenses for both services. However, Azure Active Directory Premium subscriptions include a basic PingAccess license that covers up to 20 applications. If you need to publish more than 20 header-based applications, you can acquire an additional license from PingAccess.

For more information, see Azure Active Directory editions.
