Azure Functions triggers and bindings concepts

This article is a conceptual overview of triggers and bindings in Azure Functions. Features that are common to all bindings and all supported languages are described here.

Overview

A trigger defines how a function is invoked. A function must have exactly one trigger. Triggers have associated data, which is usually the payload that triggered the function.

Input and output bindings provide a declarative way to connect to data from within your code. Bindings are optional and a function can have multiple input and output bindings.

Triggers and bindings let you avoid hardcoding the details of the services that you're working with. Your function receives data (for example, the content of a queue message) in function parameters. You send data (for example, to create a queue message) by using the return value of the function. In C# and C# script, alternative ways to send data are out parameters and collector objects.

When you develop functions by using the Azure portal, triggers and bindings are configured in a function.json file. The portal provides a UI for this configuration but you can edit the file directly by changing to the Advanced editor.

When you develop functions by using Visual Studio to create a class library, you configure triggers and bindings by decorating methods and parameters with attributes.

Example trigger and binding

Suppose you want to write a new row to Azure Table storage whenever a new message appears in Azure Queue storage. This scenario can be implemented using an Azure Queue storage trigger and an Azure Table storage output binding.

Here's a function.json file for this scenario.

{
  "bindings": [
    {
      "name": "order",
      "type": "queueTrigger",
      "direction": "in",
      "queueName": "myqueue-items",
      "connection": "MY_STORAGE_ACCT_APP_SETTING"
    },
    {
      "name": "$return",
      "type": "table",
      "direction": "out",
      "tableName": "outTable",
      "connection": "MY_TABLE_STORAGE_ACCT_APP_SETTING"
    }
  ]
}

The first element in the bindings array is the Queue storage trigger. The type and direction properties identify the trigger. The name property identifies the function parameter that receives the queue message content. The name of the queue to monitor is in queueName, and the connection string is in the app setting identified by connection.

The second element in the bindings array is the Azure Table Storage output binding. The type and direction properties identify the binding. The name property specifies how the function provides the new table row, in this case by using the function return value. The name of the table is in tableName, and the connection string is in the app setting identified by connection.

To view and edit the contents of function.json in the Azure portal, click the Advanced editor option on the Integrate tab of your function.

Note

The value of connection is the name of an app setting that contains the connection string, not the connection string itself. Bindings use connection strings stored in app settings to enforce the best practice that function.json does not contain service secrets.

Here's C# script code that works with this trigger and binding. Notice that the name of the parameter that provides the queue message content is order; this name is required because the name property value in function.json is order

#r "Newtonsoft.Json"

using Newtonsoft.Json.Linq;

// From an incoming queue message that is a JSON object, add fields and write to Table storage
// The method return value creates a new row in Table Storage
public static Person Run(JObject order, TraceWriter log)
{
    return new Person() {
            PartitionKey = "Orders",
            RowKey = Guid.NewGuid().ToString(),
            Name = order["Name"].ToString(),
            MobileNumber = order["MobileNumber"].ToString() };
}

public class Person
{
    public string PartitionKey { get; set; }
    public string RowKey { get; set; }
    public string Name { get; set; }
    public string MobileNumber { get; set; }
}

The same function.json file can be used with a JavaScript function:

// From an incoming queue message that is a JSON object, add fields and write to Table Storage
// The second parameter to context.done is used as the value for the new row
module.exports = function (context, order) {
    order.PartitionKey = "Orders";
    order.RowKey = generateRandomId();

    context.done(null, order);
};

function generateRandomId() {
    return Math.random().toString(36).substring(2, 15) +
        Math.random().toString(36).substring(2, 15);
}

In a class library, the same trigger and binding information — queue and table names, storage accounts, function parameters for input and output — is provided by attributes instead of a function.json file. Here's an example:

 public static class QueueTriggerTableOutput
 {
     [FunctionName("QueueTriggerTableOutput")]
     [return: Table("outTable", Connection = "MY_TABLE_STORAGE_ACCT_APP_SETTING")]
     public static Person Run(
         [QueueTrigger("myqueue-items", Connection = "MY_STORAGE_ACCT_APP_SETTING")]JObject order,
         TraceWriter log)
     {
         return new Person() {
                 PartitionKey = "Orders",
                 RowKey = Guid.NewGuid().ToString(),
                 Name = order["Name"].ToString(),
                 MobileNumber = order["MobileNumber"].ToString() };
     }
 }

 public class Person
 {
     public string PartitionKey { get; set; }
     public string RowKey { get; set; }
     public string Name { get; set; }
     public string MobileNumber { get; set; }
 }

Supported bindings

The following table shows the bindings that are supported in the two major versions of the Azure Functions runtime.

Type 1.x 2.x Trigger Input Output
Blob Storage
Cosmos DB
Event Grid
Event Hubs
External File2
External Table2
HTTP 1
Microsoft Graph
Excel tables
Microsoft Graph
OneDrive files
Microsoft Graph
Outlook email
Microsoft Graph
Events
Microsoft Graph
Auth tokens
Mobile Apps
Notification Hubs
Queue storage
SendGrid
Service Bus
Table storage
Timer 1
Twilio
Webhooks

1 In 2.x, all bindings except HTTP and Timer must be registered. See Register binding extensions.

2 Experimental — not supported and might be abandoned in the future.

For information about which bindings are in preview or are approved for production use, see Supported languages.

Register binding extensions

In some development environments, you have to explicitly register a binding that you want to use. Binding extensions are provided in NuGet packages, and to register an extension you install a package. The following table indicates when and how you register binding extensions.

Development environment Registration
in Functions 1.x
Registration
in Functions 2.x
Azure portal Automatic Automatic with prompt
Local using Azure Functions Core Tools Automatic Use Core Tools CLI commands
C# class library using Visual Studio 2017 Use NuGet tools Use NuGet tools
C# class library using Visual Studio Code N/A Use .NET Core CLI

The following binding types are exceptions that don't require explicit registration because they are automatically registered in all versions and environments: HTTP and timer.

Azure portal development

This section applies only to Functions 2.x. Binding extensions don't have to be explicitly registered in Functions 1.x.

When you create a function or add a binding, you are prompted when the extension for the trigger or binding requires registration. Respond to the prompt by clicking Install to register the extension. Installation can take up to 10 minutes on a consumption plan.

You need only install each extension one time for a given function app. For supported bindings that are not available in the portal or to update the an installed extension, you can also manually install or update Azure Functions binding extensions from the portal.

Local development Azure Functions Core Tools

This section applies only to Functions 2.x. Binding extensions don't have to be explicitly registered in Functions 1.x.

When you develop functions locally, you can install the extensions you need by using the Azure Functions Core Tools from the Terminal or from a command prompt.

After you have updated your function.json file to include all the bindings that your function needs, run the following command in the project folder.

func extensions install

The command reads the function.json file to see which packages you need, installs them, and rebuilds the extensions project. It adds any new bindings at the current version but does not update existing bindings. Use the --force option to update existing bindings to the latest version when installing new ones.

If you want to install a particular version of a package or you want to install packages before editing the function.json file, use the func extensions install command with the name of the package, as shown in the following example:

func extensions install --package Microsoft.Azure.WebJobs.ServiceBus --version <target_version>

Replace <target_version> with a specific version of the package, such as 3.0.0-beta5. Valid versions are listed on the individual package pages at NuGet.org.

C# class library with Visual Studio 2017

In Visual Studio 2017, you can install packages from the Package Manager Console using the Install-Package command, as shown in the following example:

Install-Package Microsoft.Azure.WebJobs.ServiceBus --Version <target_version>

The name of the package to use for a given binding is provided in the reference article for that binding. For an example, see the Packages section of the Service Bus binding reference article.

Replace <target_version> in the example with a specific version of the package, such as 3.0.0-beta5. Valid versions are listed on the individual package pages at NuGet.org. The major versions that correspond to Functions runtime 1.x or 2.x are specified in the reference article for the binding.

C# class library with Visual Studio Code

In Visual Studio Code, you can install packages from the command prompt using the dotnet add package command in the .NET Core CLI, as shown in the following example:

dotnet add package Microsoft.Azure.WebJobs.ServiceBus --version <target_version>

The .NET Core CLI can only be used for Azure Functions 2.x development.

The name of the package to use for a given binding is provided in the reference article for that binding. For an example, see the Packages section of the Service Bus binding reference article.

Replace <target_version> in the example with a specific version of the package, such as 3.0.0-beta5. Valid versions are listed on the individual package pages at NuGet.org. The major versions that correspond to Functions runtime 1.x or 2.x are specified in the reference article for the binding.

Binding direction

All triggers and bindings have a direction property in the function.json file:

  • For triggers, the direction is always in
  • Input and output bindings use in and out
  • Some bindings support a special direction inout. If you use inout, only the Advanced editor is available in the Integrate tab.

When you use attributes in a class library to configure triggers and bindings, the direction is provided in an attribute constructor or inferred from the parameter type.

Using the function return value

In languages that have a return value, you can bind an output binding to the return value:

  • In a C# class library, apply the output binding attribute to the method return value.
  • In other languages, set the name property in function.json to $return.

If there are multiple output bindings, use the return value for only one of them.

In C# and C# script, alternative ways to send data to an output binding are out parameters and collector objects.

See the language-specific example showing use of the return value:

C# example

Here's C# code that uses the return value for an output binding, followed by an async example:

[FunctionName("QueueTrigger")]
[return: Blob("output-container/{id}")]
public static string Run([QueueTrigger("inputqueue")]WorkItem input, TraceWriter log)
{
    string json = string.Format("{{ \"id\": \"{0}\" }}", input.Id);
    log.Info($"C# script processed queue message. Item={json}");
    return json;
}
[FunctionName("QueueTrigger")]
[return: Blob("output-container/{id}")]
public static Task<string> Run([QueueTrigger("inputqueue")]WorkItem input, TraceWriter log)
{
    string json = string.Format("{{ \"id\": \"{0}\" }}", input.Id);
    log.Info($"C# script processed queue message. Item={json}");
    return Task.FromResult(json);
}

C# script example

Here's the output binding in the function.json file:

{
    "name": "$return",
    "type": "blob",
    "direction": "out",
    "path": "output-container/{id}"
}

Here's the C# script code, followed by an async example:

public static string Run(WorkItem input, TraceWriter log)
{
    string json = string.Format("{{ \"id\": \"{0}\" }}", input.Id);
    log.Info($"C# script processed queue message. Item={json}");
    return json;
}
public static Task<string> Run(WorkItem input, TraceWriter log)
{
    string json = string.Format("{{ \"id\": \"{0}\" }}", input.Id);
    log.Info($"C# script processed queue message. Item={json}");
    return Task.FromResult(json);
}

F# example

Here's the output binding in the function.json file:

{
    "name": "$return",
    "type": "blob",
    "direction": "out",
    "path": "output-container/{id}"
}

Here's the F# code:

let Run(input: WorkItem, log: TraceWriter) =
    let json = String.Format("{{ \"id\": \"{0}\" }}", input.Id)
    log.Info(sprintf "F# script processed queue message '%s'" json)
    json

JavaScript example

Here's the output binding in the function.json file:

{
    "name": "$return",
    "type": "blob",
    "direction": "out",
    "path": "output-container/{id}"
}

In JavaScript, the return value goes in the second parameter for context.done:

module.exports = function (context, input) {
    var json = JSON.stringify(input);
    context.log('Node.js script processed queue message', json);
    context.done(null, json);
}

Binding dataType property

In .NET, use the parameter type to define the data type for input data. For instance, use string to bind to the text of a queue trigger, a byte array to read as binary and a custom type to deserialize to a POCO object.

For languages that are dynamically typed such as JavaScript, use the dataType property in the function.json file. For example, to read the content of an HTTP request in binary format, set dataType to binary:

{
    "type": "httpTrigger",
    "name": "req",
    "direction": "in",
    "dataType": "binary"
}

Other options for dataType are stream and string.

Binding expressions and patterns

One of the most powerful features of triggers and bindings is binding expressions. In the function.json file and in function parameters and code, you can use expressions that resolve to values from various sources.

Most expressions are identified by wrapping them in curly braces. For example, in a queue trigger function, {queueTrigger} resolves to the queue message text. If the path property for a blob output binding is container/{queueTrigger} and the function is triggered by a queue message HelloWorld, a blob named HelloWorld is created.

Types of binding expressions

Binding expressions - app settings

As a best practice, secrets and connection strings should be managed using app settings, rather than configuration files. This limits access to these secrets and makes it safe to store files such as function.json in public source control repositories.

App settings are also useful whenever you want to change configuration based on the environment. For example, in a test environment, you may want to monitor a different queue or blob storage container.

App setting binding expressions are identified differently from other binding expressions: they are wrapped in percent signs rather than curly braces. For example if the blob output binding path is %Environment%/newblob.txt and the Environment app setting value is Development, a blob will be created in the Development container.

When a function is running locally, app setting values come from the local.settings.json file.

Note that the connection property of triggers and bindings is a special case and automatically resolves values as app settings, without percent signs.

The following example is an Azure Queue Storage trigger that uses an app setting %input-queue-name% to define the queue to trigger on.

{
  "bindings": [
    {
      "name": "order",
      "type": "queueTrigger",
      "direction": "in",
      "queueName": "%input-queue-name%",
      "connection": "MY_STORAGE_ACCT_APP_SETTING"
    }
  ]
}

You can use the same approach in class libraries:

[FunctionName("QueueTrigger")]
public static void Run(
    [QueueTrigger("%input-queue-name%")]string myQueueItem,
    TraceWriter log)
{
    log.Info($"C# Queue trigger function processed: {myQueueItem}");
}

Binding expressions - trigger file name

The path for a Blob trigger can be a pattern that lets you refer to the name of the triggering blob in other bindings and function code. The pattern can also include filtering criteria that specify which blobs can trigger a function invocation.

For example, in the following Blob trigger binding, the path pattern is sample-images/{filename}, which creates a binding expression named filename:

{
  "bindings": [
    {
      "name": "image",
      "type": "blobTrigger",
      "path": "sample-images/{filename}",
      "direction": "in",
      "connection": "MyStorageConnection"
    },
    ...

The expression filename can then be used in an output binding to specify the name of the blob being created:

    ...
    {
      "name": "imageSmall",
      "type": "blob",
      "path": "sample-images-sm/{filename}",
      "direction": "out",
      "connection": "MyStorageConnection"
    }
  ],
}

Function code has access to this same value by using filename as a parameter name:

// C# example of binding to {filename}
public static void Run(Stream image, string filename, Stream imageSmall, TraceWriter log)
{
    log.Info($"Blob trigger processing: {filename}");
    // ...
}

The same ability to use binding expressions and patterns applies to attributes in class libraries. In the following example, the attribute constructor parameters are the same path values as the preceding function.json examples:

[FunctionName("ResizeImage")]
public static void Run(
    [BlobTrigger("sample-images/{filename}")] Stream image,
    [Blob("sample-images-sm/{filename}", FileAccess.Write)] Stream imageSmall,
    string filename,
    TraceWriter log)
{
    log.Info($"Blob trigger processing: {filename}");
    // ...
}

You can also create expressions for parts of the file name such as the extension. For more information on how to use expressions and patterns in the Blob path string, see the Storage blob binding reference.

Binding expressions - trigger metadata

In addition to the data payload provided by a trigger (such as the content of the queue message that triggered a function), many triggers provide additional metadata values. These values can be used as input parameters in C# and F# or properties on the context.bindings object in JavaScript.

For example, an Azure Queue storage trigger supports the following properties:

  • QueueTrigger - triggering message content if a valid string
  • DequeueCount
  • ExpirationTime
  • Id
  • InsertionTime
  • NextVisibleTime
  • PopReceipt

These metadata values are accessible in function.json file properties. For example, suppose you use a queue trigger and the queue message contains the name of a blob you want to read. In the function.json file, you can use queueTrigger metadata property in the blob path property, as shown in the following example:

  "bindings": [
    {
      "name": "myQueueItem",
      "type": "queueTrigger",
      "queueName": "myqueue-items",
      "connection": "MyStorageConnection",
    },
    {
      "name": "myInputBlob",
      "type": "blob",
      "path": "samples-workitems/{queueTrigger}",
      "direction": "in",
      "connection": "MyStorageConnection"
    }
  ]

Details of metadata properties for each trigger are described in the corresponding reference article. For an example, see queue trigger metadata. Documentation is also available in the Integrate tab of the portal, in the Documentation section below the binding configuration area.

Binding expressions - JSON payloads

When a trigger payload is JSON, you can refer to its properties in configuration for other bindings in the same function and in function code.

The following example shows the function.json file for a webhook function that receives a blob name in JSON: {"BlobName":"HelloWorld.txt"}. A Blob input binding reads the blob, and the HTTP output binding returns the blob contents in the HTTP response. Notice that the Blob input binding gets the blob name by referring directly to the BlobName property ("path": "strings/{BlobName}")

{
  "bindings": [
    {
      "name": "info",
      "type": "httpTrigger",
      "direction": "in",
      "webHookType": "genericJson"
    },
    {
      "name": "blobContents",
      "type": "blob",
      "direction": "in",
      "path": "strings/{BlobName}",
      "connection": "AzureWebJobsStorage"
    },
    {
      "name": "res",
      "type": "http",
      "direction": "out"
    }
  ]
}

For this to work in C# and F#, you need a class that defines the fields to be deserialized, as in the following example:

using System.Net;

public class BlobInfo
{
    public string BlobName { get; set; }
}

public static HttpResponseMessage Run(HttpRequestMessage req, BlobInfo info, string blobContents, TraceWriter log)
{
    if (blobContents == null) {
        return req.CreateResponse(HttpStatusCode.NotFound);
    }

    log.Info($"Processing: {info.BlobName}");

    return req.CreateResponse(HttpStatusCode.OK, new {
        data = $"{blobContents}"
    });
}

In JavaScript, JSON deserialization is automatically performed.

module.exports = function (context, info) {
    if ('BlobName' in info) {
        context.res = {
            body: { 'data': context.bindings.blobContents }
        }
    }
    else {
        context.res = {
            status: 404
        };
    }
    context.done();
}

Dot notation

If some of the properties in your JSON payload are objects with properties, you can refer to those directly by using dot notation. For example, suppose your JSON looks like this:

{"BlobName": {
  "FileName":"HelloWorld",
  "Extension":"txt"
  }
}

You can refer directly to FileName as BlobName.FileName. With this JSON format, here's what the path property in the preceding example would look like:

"path": "strings/{BlobName.FileName}.{BlobName.Extension}",

In C#, you would need two classes:

public class BlobInfo
{
    public BlobName BlobName { get; set; }
}
public class BlobName
{
    public string FileName { get; set; }
    public string Extension { get; set; }
}

Binding expressions - create GUIDs

The {rand-guid} binding expression creates a GUID. The following blob path in a function.json file creates a blob with a name like 50710cb5-84b9-4d87-9d83-a03d6976a682.txt.

{
  "type": "blob",
  "name": "blobOutput",
  "direction": "out",
  "path": "my-output-container/{rand-guid}"
}

Binding expressions - current time

The binding expression DateTime resolves to DateTime.UtcNow. The following blob path in a function.json file creates a blob with a name like 2018-02-16T17-59-55Z.txt.

{
  "type": "blob",
  "name": "blobOutput",
  "direction": "out",
  "path": "my-output-container/{DateTime}"
}

Binding at runtime

In C# and other .NET languages, you can use an imperative binding pattern, as opposed to the declarative bindings in function.json and attributes. Imperative binding is useful when binding parameters need to be computed at runtime rather than design time. To learn more, see the C# developer reference or the C# script developer reference.

function.json file schema

The function.json file schema is available at http://json.schemastore.org/function.

Handling binding errors

Azure Functions triggers and bindings communicate with various Azure services. When integrating with these services, you may have errors raised that originate from the APIs of the underlying Azure services. Errors can also occur when you try to communicate with other services from your function code by using REST or client libraries. To avoid loss of data and ensure good behavior of your functions, it is important to handle errors from either source.

The following triggers have built-in retry support:

By default, these triggers are retried up to five times. After the fifth retry, these triggers write a message to a special poison queue.

For the other Functions triggers, there is no built-in retry when errors occur during function execution. To prevent loss of trigger information should an error occur in your function, we recommend that you use try-catch blocks in your function code to catch any errors. When an error occurs, write the information passed into the function by the trigger to a special "poison" message queue. This approach is the same one used by the Blob storage trigger.

In this way, you can capture trigger events that could be lost due to errors and retry them at a later time using another function to process messages from the poison queue using the stored information.

For links to all relevant error topics for the various services supported by Functions, see the Binding error codes section of the Azure Functions error handling overview topic.

Next steps

For more information on a specific binding, see the following articles:
