Create an internal load balancer by using the Azure PowerShell module

Important

Azure Load Balancer supports two different types: Basic and Standard. This article discusses Basic Load Balancer. Basic Load Balancer is generally available, whereas Standard Load Balancer is currently in Public Preview. For more information about Standard Load Balancer, see Standard Load Balancer Overview.

Azure Internal Load Balancer (ILB) provides network load balancing between virtual machines that reside inside a cloud service or a virtual network with a regional scope.

For information about the use and configuration of virtual networks with a regional scope, see Regional virtual networks. Existing virtual networks that have been configured for an affinity group cannot use ILB.

Note

Azure offers two deployment models for creating and working with resources: Resource Manager and classic. This article describes how to create a load balancer by using the Resource Manager deployment model. Microsoft recommends that Azure Resource Manager be used for most new deployments.

Configuration scenario

In this scenario, we're creating an internal load balancer in a virtual network as shown in the following figure:

Internal load balancer scenario

The configuration for our scenario is as follows:

  • Two virtual machines named DB1 and DB2
  • Endpoints for the internal load balancer
  • An internal load balancer

Prerequisite: Install the Azure PowerShell module

To perform the steps in this article, you need to install and configure the Azure PowerShell module. Be sure to complete all of the instructions. After the installation is finished, sign in to Azure and select your subscription.

Note

You need an Azure account to complete these steps. If you don't have an Azure account, you can sign up for a free trial.

Get started with the configuration

This article explains how to create an internal load balancer by using Azure Resource Manager with the Azure PowerShell module. In the Resource Manager deployment model, the objects that are needed to create an internal load balancer are configured individually. After the objects are created and configured, they are combined to create a load balancer.

To deploy a load balancer, the following objects must be created:

  • Front-end IP pool: The private IP address for all incoming network traffic.
  • Back-end address pool: The network interfaces to receive the load-balanced traffic from the front-end IP address.
  • Load balancing rules: The port (source and local) configuration for the load balancer.
  • Probe configuration: The health status probes for virtual machines.
  • Inbound NAT rules: The port rules for direct access to virtual machines.

For more information about load balancer components, see Azure Resource Manager support for load balancer.

The following steps explain how to configure a load balancer between two virtual machines.

Set up PowerShell to use Resource Manager

Make sure you have the latest production version of the Azure PowerShell module. PowerShell must be correctly configured to access your Azure subscription.

Step 1: Start PowerShell

Start the PowerShell module for Azure Resource Manager.

Login-AzureRmAccount

Step 2: View your subscriptions

Check your available Azure subscriptions.

Get-AzureRmSubscription

Enter your credentials when you're prompted for authentication.

Step 3: Select the subscription to use

Choose which of your Azure subscriptions to use for deploying the load balancer.

Select-AzureRmSubscription -Subscriptionid "GUID of subscription"

Step 4: Choose the resource group for the load balancer

Create a new resource group for the load balancer. Skip this step if you're using an existing resource group.

New-AzureRmResourceGroup -Name NRP-RG -location "West US"

Azure Resource Manager requires that all resource groups specify a location. The location is used as the default for all resources in the resource group. Always use the same resource group for all commands related to creating the load balancer.

In the example, we created a resource group named NRP-RG with the location West US.

Create the virtual network and IP address for the front-end IP pool

Create a subnet for the virtual network and assign it to the variable $backendSubnet.

$backendSubnet = New-AzureRmVirtualNetworkSubnetConfig -Name LB-Subnet-BE -AddressPrefix 10.0.2.0/24

Create a virtual network.

$vnet= New-AzureRmVirtualNetwork -Name NRPVNet -ResourceGroupName NRP-RG -Location "West US" -AddressPrefix 10.0.0.0/16 -Subnet $backendSubnet

The virtual network is created. The LB-Subnet-BE subnet is added to the NRPVNet virtual network. These values are assigned to the $vnet variable.

Create the front-end IP pool and back-end address pool

Create a front-end IP pool for the incoming traffic and a back-end address pool to receive the load-balanced traffic.

Step 1: Create a front-end IP pool

Create a front-end IP pool with the private IP address 10.0.2.5 for the subnet 10.0.2.0/24. This address is the incoming network traffic endpoint.

$frontendIP = New-AzureRmLoadBalancerFrontendIpConfig -Name LB-Frontend -PrivateIpAddress 10.0.2.5 -SubnetId $vnet.subnets[0].Id

Step 2: Create a back-end address pool

Create a back-end address pool to receive incoming traffic from the front-end IP pool:

$beaddresspool= New-AzureRmLoadBalancerBackendAddressPoolConfig -Name "LB-backend"

Create the configuration rules, probe, and load balancer

After the front-end IP pool and the back-end address pool are created, specify the rules for the load balancer resource.

Step 1: Create the configuration rules

The example creates the following four rule objects:

  • An inbound NAT rule for the Remote Desktop Protocol (RDP): Redirects all incoming traffic on port 3441 to port 3389.
  • A second inbound NAT rule for RDP: Redirects all incoming traffic on port 3442 to port 3389.
  • A health probe rule: Checks the health status of the HealthProbe.aspx path.
  • A load balancer rule: Load-balances all incoming traffic on public port 80 to local port 80 in the back-end address pool.
$inboundNATRule1= New-AzureRmLoadBalancerInboundNatRuleConfig -Name "RDP1" -FrontendIpConfiguration $frontendIP -Protocol TCP -FrontendPort 3441 -BackendPort 3389

$inboundNATRule2= New-AzureRmLoadBalancerInboundNatRuleConfig -Name "RDP2" -FrontendIpConfiguration $frontendIP -Protocol TCP -FrontendPort 3442 -BackendPort 3389

$healthProbe = New-AzureRmLoadBalancerProbeConfig -Name "HealthProbe" -RequestPath "HealthProbe.aspx" -Protocol http -Port 80 -IntervalInSeconds 15 -ProbeCount 2

$lbrule = New-AzureRmLoadBalancerRuleConfig -Name "HTTP" -FrontendIpConfiguration $frontendIP -BackendAddressPool $beAddressPool -Probe $healthProbe -Protocol Tcp -FrontendPort 80 -BackendPort 80

Step 2: Create the load balancer

Create the load balancer and combine the rule objects (inbound NAT for RDP, load balancer, and health probe):

$NRPLB = New-AzureRmLoadBalancer -ResourceGroupName "NRP-RG" -Name "NRP-LB" -Location "West US" -FrontendIpConfiguration $frontendIP -InboundNatRule $inboundNATRule1,$inboundNatRule2 -LoadBalancingRule $lbrule -BackendAddressPool $beAddressPool -Probe $healthProbe

Create the network interfaces

After creating the internal load balancer, define the network interfaces (NICs) that will receive the incoming load-balanced network traffic, NAT rules, and probe. Each network interface is configured individually and is assigned later to a virtual machine.

Step 1: Create the first network interface

Get the resource virtual network and subnet. These values are used to create the network interfaces:

$vnet = Get-AzureRmVirtualNetwork -Name NRPVNet -ResourceGroupName NRP-RG

$backendSubnet = Get-AzureRmVirtualNetworkSubnetConfig -Name LB-Subnet-BE -VirtualNetwork $vnet

Create the first network interface with the name lb-nic1-be. Assign the interface to the load balancer back-end pool. Associate the first NAT rule for RDP with this NIC:

$backendnic1= New-AzureRmNetworkInterface -ResourceGroupName "NRP-RG" -Name lb-nic1-be -Location "West US" -PrivateIpAddress 10.0.2.6 -Subnet $backendSubnet -LoadBalancerBackendAddressPool $nrplb.BackendAddressPools[0] -LoadBalancerInboundNatRule $nrplb.InboundNatRules[0]

Step 2: Create the second network interface

Create the second network interface with the name lb-nic2-be. Assign the second interface to the same load balancer back-end pool as the first interface. Associate the second NIC with the second NAT rule for RDP:

$backendnic2= New-AzureRmNetworkInterface -ResourceGroupName "NRP-RG" -Name lb-nic2-be -Location "West US" -PrivateIpAddress 10.0.2.7 -Subnet $backendSubnet -LoadBalancerBackendAddressPool $nrplb.BackendAddressPools[0] -LoadBalancerInboundNatRule $nrplb.InboundNatRules[1]

Review the configuration:

$backendnic1

The settings should be as follows:

Name                 : lb-nic1-be
ResourceGroupName    : NRP-RG
Location             : westus
Id                   : /subscriptions/f50504a2-1865-4541-823a-b32842e3e0ee/resourceGroups/NRP-RG/providers/Microsoft.Network/networkInterfaces/lb-nic1-be
Etag                 : W/"d448256a-e1df-413a-9103-a137e07276d1"
ProvisioningState    : Succeeded
Tags                 :
VirtualMachine       : null
IpConfigurations     : [
                     {
                       "PrivateIpAddress": "10.0.2.6",
                       "PrivateIpAllocationMethod": "Static",
                       "Subnet": {
                         "Id": "/subscriptions/f50504a2-1865-4541-823a-b32842e3e0ee/resourceGroups/NRP-RG/providers/Microsoft.Network/virtualNetworks/NRPVNet/subnets/LB-Subnet-BE"
                       },
                       "PublicIpAddress": {
                         "Id": null
                       },
                       "LoadBalancerBackendAddressPools": [
                         {
                           "Id": "/subscriptions/f50504a2-1865-4541-823a-b32842e3e0ee/resourceGroups/NRP-RG/providers/Microsoft.Network/loadBalancers/NRPlb/backendAddressPools/LB-backend"
                         }
                       ],
                       "LoadBalancerInboundNatRules": [
                         {
                           "Id": "/subscriptions/f50504a2-1865-4541-823a-b32842e3e0ee/resourceGroups/NRP-RG/providers/Microsoft.Network/loadBalancers/NRPlb/inboundNatRules/RDP1"
                         }
                       ],
                       "ProvisioningState": "Succeeded",
                       "Name": "ipconfig1",
                       "Etag": "W/\"d448256a-e1df-413a-9103-a137e07276d1\"",
                       "Id": "/subscriptions/f50504a2-1865-4541-823a-b32842e3e0ee/resourceGroups/NRP-RG/providers/Microsoft.Network/networkInterfaces/lb-nic1-be/ipConfigurations/ipconfig1"
                     }
                   ]
DnsSettings          : {
                     "DnsServers": [],
                     "AppliedDnsServers": []
                   }
AppliedDnsSettings   :
NetworkSecurityGroup : null
Primary              : False

Step 3: Assign the NIC to a VM

Assign the NIC to a virtual machine by using the Add-AzureRmVMNetworkInterface command.

For step-by-step instructions to create a virtual machine and assign the NIC, see Create an Azure VM by using PowerShell.

Add the network interface

After the virtual machine has been created, add the network interface.

Step 1: Store the load balancer resource

Store the load balancer resource in a variable (if you haven't done that yet). We're using the variable name $lb. For the attribute values in the script, use the names for the load balancer resources that were created in the previous steps.

$lb = Get-AzureRmLoadBalancer –name NRP-LB -resourcegroupname NRP-RG

Step 2: Store the back-end configuration

Store the back-end configuration into the $backend variable.

$backend = Get-AzureRmLoadBalancerBackendAddressPoolConfig -name LB-backend -LoadBalancer $lb

Step 3: Store the network interface

Store the network interface in another variable. This interface was created in "Create the network interfaces, Step 1." We're using the variable name $nic1. Use the same network interface name from the previous example.

$nic = Get-AzureRmNetworkInterface –name lb-nic1-be -resourcegroupname NRP-RG

Step 4: Change the back-end configuration

Change the back-end configuration on the network interface.

$nic.IpConfigurations[0].LoadBalancerBackendAddressPools=$backend

Step 5: Save the network interface object

Save the network interface object.

Set-AzureRmNetworkInterface -NetworkInterface $nic

After the interface is added to the back-end pool, network traffic is load-balanced according to the rules. These rules were configured in "Create the configuration rules, probe, and load balancer."

Update an existing load balancer

Step 1: Assign the load balancer object to a variable

Assign the load balancer object (from the previous example) to the $slb variable by using the Get-AzureRmLoadBalancer command:

$slb = Get-AzureRmLoadBalancer -Name NRPLB -ResourceGroupName NRP-RG

Step 2: Add a NAT rule

Add a new inbound NAT rule to an existing load balancer. Use port 81 for the front-end pool and port 8181 for the back-end pool:

$slb | Add-AzureRmLoadBalancerInboundNatRuleConfig -Name NewRule -FrontendIpConfiguration $slb.FrontendIpConfigurations[0] -FrontendPort 81  -BackendPort 8181 -Protocol Tcp

Step 3: Save the configuration

Save the new configuration by using the Set-AzureLoadBalancer command:

$slb | Set-AzureRmLoadBalancer

Remove an existing load balancer

Delete the NRP-LB load balancer in the NRP-RG resource group by using the Remove-AzureRmLoadBalancer command:

Remove-AzureRmLoadBalancer -Name NRPLB -ResourceGroupName NRP-RG

Note

Use the optional -Force switch to prevent the confirmation prompt for the deletion.
