Build advanced schedules and recurrences for jobs in Azure Scheduler

Important

Azure Logic Apps is replacing Azure Scheduler, which is being retired. To schedule jobs, try Azure Logic Apps instead.

Within an Azure Scheduler job, the schedule is the core that determines when and how the Scheduler service runs the job. You can set up multiple one-time and recurring schedules for a job with Scheduler. One-time schedules run only once at a specified time and are basically recurring schedules that run only once. Recurring schedules run on a specified frequency. With this flexibility, you can use Scheduler for various business scenarios, for example:

  • Clean up data regularly: Create a daily job that deletes all tweets older than three months.

  • Archive data: Create a monthly job that pushes invoice history to a backup service.

  • Request external data: Create a job that runs every 15 minutes and pulls a new weather report from NOAA.

  • Process images: Create a weekday job that runs during off-peak hours and uses cloud computing for compressing images uploaded during the day.

This article describes example jobs you can create by using Scheduler and and the Azure Scheduler REST API, and includes the JavaScript Object Notation (JSON) definition for each schedule.

Supported scenarios

These examples show the range of scenarios that Azure Scheduler supports and how to create schedules for various behavior patterns, for example:

  • Run once at a specific date and time.
  • Run and recur a specific number of times.
  • Run immediately and recur.
  • Run and recur every n minutes, hours, days, weeks, or months, starting at a specific time.
  • Run and recur weekly or monthly, but only on specific days of the week or on specific days of the month.
  • Run and recur multiple times for a specific period. For example, every month on the last Friday and Monday, or daily at 5:15 AM and at 5:15 PM.

This article later describes these scenarios in more detail.

Create schedule with REST API

To create a basic schedule with the Azure Scheduler REST API, follow these steps:

  1. Register your Azure subscription with a resource provider by using the Register operation - Resource Manager REST API. The provider name for the Azure Scheduler service is Microsoft.Scheduler.

  2. Create a job collection by using the Create or Update operation for job collections in the Scheduler REST API.

  3. Create a job by using the Create or Update operation for jobs.

Job schema elements

This table provides a high-level overview for the major JSON elements you can use when setting up recurrences and schedules for jobs.

Element Required Description
startTime No A DateTime string value in ISO 8601 format that specifies when the job first starts in a basic schedule.

For complex schedules, the job starts no sooner than startTime.

recurrence No The recurrence rules for when the job runs. The recurrence object supports these elements: frequency, interval, schedule, count, and endTime.

If you use the recurrence element, you must also use the frequency element, while other recurrence elements are optional.

frequency Yes, when you use recurrence The time unit between occurrences and supports these values: "Minute", "Hour", "Day", "Week", "Month", and "Year"
interval No A positive integer that determines the number of time units between occurrences based on frequency.

For example, if interval is 10 and frequency is "Week", the job recurs every 10 weeks.

Here are the maximum number of intervals for each frequency:

- 18 months
- 78 weeks
- 548 days
- For hours and minutes, the range is 1 <= <interval> <= 1000.

schedule No Defines changes to the recurrence based on the specified minute-marks, hour-marks, days of the week, and days of the month
count No A positive integer that specifies the number of times that the job runs before finishing.

For example, when a daily job has count set to 7, and the start date is Monday, the job finishes running on Sunday. If the start date has already passed, the first run is calculated from the creation time.

Without endTime or count, the job runs infinitely. You can't use both count and endTime in the same job, but the rule that finishes first is honored.

endTime No A Date or DateTime string value in ISO 8601 format that specifies when the job stops running. You can set a value for endTime that's in the past.

Without endTime or count, the job runs infinitely. You can't use both count and endTime in the same job, but the rule that finishes first is honored.

For example, this JSON schema describes a basic schedule and recurrence for a job:

"properties": {
   "startTime": "2012-08-04T00:00Z",
   "recurrence": {
      "frequency": "Week",
      "interval": 1,
      "schedule": {
         "weekDays": ["Monday", "Wednesday", "Friday"],
         "hours": [10, 22]
      },
      "count": 10,
      "endTime": "2012-11-04"
   },
},

Dates and DateTime values

  • Dates in Scheduler jobs include only the date and follow the ISO 8601 specification.

  • Date-times in Scheduler jobs include both date and time, follow the ISO 8601 specification, and is assumed to be UTC when no UTC offset is specified.

For more information, see Concepts, terminology, and entities.

Details: startTime

This table describes how startTime controls the way a job runs:

startTime No recurrence Recurrence, no schedule Recurrence with schedule
No start time Run once immediately. Run once immediately. Run subsequent executions calculated from the last execution time. Run once immediately. Run subsequent executions based on a recurrence schedule.
Start time in the past Run once immediately. Calculate the first future run time after start time, and run at that time.

Run subsequent executions calculated from the last execution time.

See the example after this table.

Start job no sooner than the specified start time. The first occurrence is based on the schedule calculated from the start time.

Run subsequent executions based on a recurrence schedule.

Start time in the future or the current time Run once at the specified start time. Run once at the specified start time.

Run subsequent executions calculated from the last execution time.

Start job no sooner than the specified start time. The first occurrence is based on the schedule, calculated from the start time.

Run subsequent executions based on a recurrence schedule.

Suppose you this example with these conditions: a start time in the past with a recurrence, but no schedule.

"properties": {
   "startTime": "2015-04-07T14:00Z",
   "recurrence": {
      "frequency": "Day",
      "interval": 2
   }
}
  • The current date and time is "2015-04-08 13:00".

  • The start date and time is "2015-04-07 14:00", which is before the current date and time.

  • The recurrence is every two days.

  1. Under these conditions, the first execution is on 2015-04-09 at 14:00.

    Scheduler calculates the execution occurrences based on the start time, discards any instances in the past, and uses the next instance in the future. In this case, startTime is on 2015-04-07 at 2:00 PM, so the next instance is two days from that time, which is 2015-04-09 at 2:00 PM.

    The first execution is the same whether startTime is 2015-04-05 14:00 or 2015-04-01 14:00. After the first execution, subsequent executions are calculated based on the schedule.

  2. The executions then follow in this order:

    1. 2015-04-11 at 2:00 PM
    2. 2015-04-13 at 2:00 PM
    3. 2015-04-15 at 2:00 PM
    4. And so on...
  3. Finally, when a job has a schedule but no specified hours and minutes, these values default to the hours and minutes in the first execution, respectively.

Details: schedule

You can use schedule to limit the number of job executions. For example, if a job with a frequency of "month" has a schedule that runs only on day 31, the job runs only in months that have a thirty-first day.

You can also use schedule to expand the number of job executions. For example, if a job with a frequency of "month" has a schedule that runs on month days 1 and 2, the job runs on the first and second days of the month instead of only once a month.

If you specify multiple schedule elements, the order of evaluation is from the largest to smallest: week number, month day, weekday, hour, and minute.

The following table describes schedule elements in detail:

JSON name Description Valid values
minutes Minutes of the hour at which the job runs. An array of integers.
hours Hours of the day at which the job runs. An array of integers.
weekDays Days of the week the job runs. Can be specified only with a weekly frequency. An array of any of the following values (maximum array size is 7):
- "Monday"
- "Tuesday"
- "Wednesday"
- "Thursday"
- "Friday"
- "Saturday"
- "Sunday"

Not case-sensitive.
monthlyOccurrences Determines which days of the month the job runs. Can be specified only with a monthly frequency. An array of monthlyOccurrences objects:
{ "day": day, "occurrence": occurrence}

day is the day of the week the job runs. For example, {Sunday} is every Sunday of the month. Required.

occurrence is the occurrence of the day during the month. For example, {Sunday, -1} is the last Sunday of the month. Optional.
monthDays Day of the month the job runs. Can be specified only with a monthly frequency. An array of the following values:
- Any value <= -1 and >= -31
- Any value >= 1 and <= 31

Examples: Recurrence schedules

The following examples show various recurrence schedules. The examples focus on the schedule object and its subelements.

These schedules assume that interval is set to 1. The examples also assume the correct frequency values for the values in schedule. For example, you can't use a frequency of "day" and have a monthDays modification in schedule. We describe these restrictions earlier in the article.

Example Description
{"hours":[5]} Run at 5 AM every day.

Scheduler matches up each value in "hours" with each value in "minutes", one by one, to create a list of all the times at which the job runs.
{"minutes":[15], "hours":[5]} Run at 5:15 AM every day.
{"minutes":[15], "hours":[5,17]} Run at 5:15 AM and 5:15 PM every day.
{"minutes":[15,45], "hours":[5,17]} Run at 5:15 AM, 5:45 AM, 5:15 PM, and 5:45 PM every day.
{"minutes":[0,15,30,45]} Run every 15 minutes.
{hours":[0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23]} Run every hour.

This job runs every hour. The minute is controlled by the value for startTime, if it is specified. If no startTime value is specified, the minute is controlled by the creation time. For example, if the start time or creation time (whichever applies) is 12:25 PM, the job runs at 00:25, 01:25, 02:25, …, 23:25.

The schedule is equivalent to a job with a frequency of "hour", an interval of 1, and no schedule value. The difference is that you can use this schedule with different frequency and interval values to create other jobs. For example, if frequency is "month", the schedule runs only once a month instead of every day (if frequency is "day").
{minutes:[0]} Run every hour on the hour.

This job also runs every hour, but on the hour (12 AM, 1 AM, 2 AM, and so on). This is equivalent to a job with a frequency of "hour", a startTime value of zero minutes, and no schedule, if the frequency is "day". However, if the frequency is "week" or "month", the schedule executes only one day a week or one day a month, respectively.
{"minutes":[15]} Run at 15 minutes past the hour every hour.

Runs every hour, starting at 00:15 AM, 1:15 AM, 2:15 AM, and so on. It ends at 11:15 PM.
{"hours":[17], "weekDays":["saturday"]} Run at 5 PM on Saturday every week.
{hours":[17], "weekDays":["monday", "wednesday", "friday"]} Run at 5 PM on Monday, Wednesday, and Friday every week.
{"minutes":[15,45], "hours":[17], "weekDays":["monday", "wednesday", "friday"]} Run at 5:15 PM and 5:45 PM on Monday, Wednesday, and Friday every week.
{"hours":[5,17], "weekDays":["monday", "wednesday", "friday"]} Run at 5 AM and 5 PM on Monday, Wednesday, and Friday every week.
{"minutes":[15,45], "hours":[5,17], "weekDays":["monday", "wednesday", "friday"]} Run at 5:15 AM, 5:45 AM, 5:15 PM, and 5:45 PM on Monday, Wednesday, and Friday every week.
{"minutes":[0,15,30,45], "weekDays":["monday", "tuesday", "wednesday", "thursday", "friday"]} Run every 15 minutes on weekdays.
{"minutes":[0,15,30,45], "hours": [9, 10, 11, 12, 13, 14, 15, 16] "weekDays":["monday", "tuesday", "wednesday", "thursday", "friday"]} Run every 15 minutes on weekdays, between 9 AM and 4:45 PM.
{"weekDays":["sunday"]} Run on Sundays at start time.
{"weekDays":["tuesday", "thursday"]} Run on Tuesdays and Thursdays at start time.
{"minutes":[0], "hours":[6], "monthDays":[28]} Run at 6 AM on the twenty-eighth day of every month (assuming a frequency of "month").
{"minutes":[0], "hours":[6], "monthDays":[-1]} Run at 6 AM on the last day of the month.

If you want to run a job on the last day of a month, use -1 instead of day 28, 29, 30, or 31.
{"minutes":[0], "hours":[6], "monthDays":[1,-1]} Run at 6 AM on the first and last day of every month.
{monthDays":[1,-1]} Run on the first and last day of every month at start time.
{monthDays":[1,14]} Run on the first and fourteenth day of every month at start time.
{monthDays":[2]} Run on the second day of the month at start time.
{"minutes":[0], "hours":[5], "monthlyOccurrences":[{"day":"friday", "occurrence":1}]} Run on the first Friday of every month at 5 AM.
{"monthlyOccurrences":[{"day":"friday", "occurrence":1}]} Run on the first Friday of every month at start time.
{"monthlyOccurrences":[{"day":"friday", "occurrence":-3}]} Run on the third Friday from the end of the month, every month, at start time.
{"minutes":[15], "hours":[5], "monthlyOccurrences":[{"day":"friday", "occurrence":1},{"day":"friday", "occurrence":-1}]} Run on the first and last Friday of every month at 5:15 AM.
{"monthlyOccurrences":[{"day":"friday", "occurrence":1},{"day":"friday", "occurrence":-1}]} Run on the first and last Friday of every month at start time.
{"monthlyOccurrences":[{"day":"friday", "occurrence":5}]} Run on the fifth Friday of every month at start time.

If there is no fifth Friday in a month, the job doesn't run. You might consider using -1 instead of 5 for the occurrence if you want to run the job on the last occurring Friday of the month.
{"minutes":[0,15,30,45], "monthlyOccurrences":[{"day":"friday", "occurrence":-1}]} Run every 15 minutes on the last Friday of the month.
{"minutes":[15,45], "hours":[5,17], "monthlyOccurrences":[{"day":"wednesday", "occurrence":3}]} Run at 5:15 AM, 5:45 AM, 5:15 PM, and 5:45 PM on the third Wednesday of every month.
