Control access to IoT Hub

Overview

This article describes the options for securing your IoT hub. IoT Hub uses permissions to grant access to each IoT hub endpoint. Permissions limit the access to an IoT hub based on functionality.

This article describes:

  • The different permissions that you can grant to a device or back-end app to access your IoT hub.
  • The authentication process and the tokens it uses to verify permissions.
  • How to scope credentials to limit access to specific resources.
  • IoT Hub support for X.509 certificates.
  • Custom device authentication mechanisms that use existing device identity registries or authentication schemes.

When to use

You must have appropriate permissions to access any of the IoT Hub endpoints. For example, a device must include a token containing security credentials along with every message it sends to IoT Hub.

Access control and permissions

You can grant permissions in the following ways:

  • IoT hub-level shared access policies. Shared access policies can grant any combination of permissions. You can define policies in the Azure portal, or programmatically by using the IoT Hub resource provider REST APIs. A newly created IoT hub has the following default policies:

    • iothubowner: Policy with all permissions.
    • service: Policy with ServiceConnect permission.
    • device: Policy with DeviceConnect permission.
    • registryRead: Policy with RegistryRead permission.
    • registryReadWrite: Policy with RegistryRead and RegistryWrite permissions.
    • Per-device security credentials. Each IoT Hub contains an identity registry. For each device in this identity registry, you can configure security credentials that grant DeviceConnect permissions scoped to the corresponding device endpoints.

For example, in a typical IoT solution:

  • The device management component uses the registryReadWrite policy.
  • The event processor component uses the service policy.
  • The run-time device business logic component uses the service policy.
  • Individual devices connect using credentials stored in the IoT hub's identity registry.
Note

See permissions for detailed information.

Authentication

Azure IoT Hub grants access to endpoints by verifying a token against the shared access policies and identity registry security credentials.

Security credentials, such as symmetric keys, are never sent over the wire.

Note

The Azure IoT Hub resource provider is secured through your Azure subscription, as are all providers in the Azure Resource Manager.

For more information about how to construct and use security tokens, see IoT Hub security tokens.

Protocol specifics

Each supported protocol, such as MQTT, AMQP, and HTTP, transports tokens in different ways.

When using MQTT, the CONNECT packet has the deviceId as the ClientId, {iothubhostname}/{deviceId} in the Username field, and a SAS token in the Password field. {iothubhostname} should be the full CName of the IoT hub (for example, contoso.azure-devices.net).

When using AMQP, IoT Hub supports SASL PLAIN and AMQP Claims-Based-Security.

If you use AMQP claims-based-security, the standard specifies how to transmit these tokens.

For SASL PLAIN, the username can be:

  • {policyName}@sas.root.{iothubName} if using IoT hub-level tokens.
  • {deviceId}@sas.{iothubname} if using device-scoped tokens.

In both cases, the password field contains the token, as described in IoT Hub security tokens.

HTTP implements authentication by including a valid token in the Authorization request header.

Example

Username (DeviceId is case-sensitive): iothubname.azure-devices.net/DeviceId

Password (Generate SAS token with the device explorer tool): SharedAccessSignature sr=iothubname.azure-devices.net%2fdevices%2fDeviceId&sig=kPszxZZZZZZZZZZZZZZZZZAhLT%2bV7o%3d&se=1487709501

Note

The Azure IoT SDKs automatically generate tokens when connecting to the service. In some cases, the Azure IoT SDKs do not support all the protocols or all the authentication methods.

Special considerations for SASL PLAIN

When using SASL PLAIN with AMQP, a client connecting to an IoT hub can use a single token for each TCP connection. When the token expires, the TCP connection disconnects from the service and triggers a reconnect. This behavior, while not problematic for a back-end app, is damaging for a device app for the following reasons:

  • Gateways usually connect on behalf of many devices. When using SASL PLAIN, they have to create a distinct TCP connection for each device connecting to an IoT hub. This scenario considerably increases the consumption of power and networking resources, and increases the latency of each device connection.
  • Resource-constrained devices are adversely affected by the increased use of resources to reconnect after each token expiration.

Scope IoT hub-level credentials

You can scope IoT hub-level security policies by creating tokens with a restricted resource URI. For example, the endpoint to send device-to-cloud messages from a device is /devices/{deviceId}/messages/events. You can also use an IoT hub-level shared access policy with DeviceConnect permissions to sign a token whose resourceURI is /devices/{deviceId}. This approach creates a token that is only usable to send messages on behalf of device deviceId.

This mechanism is similar to the Event Hubs publisher policy, and enables you to implement custom authentication methods.

Security tokens

IoT Hub uses security tokens to authenticate devices and services to avoid sending keys on the wire. Additionally, security tokens are limited in time validity and scope. Azure IoT SDKs automatically generate tokens without requiring any special configuration. Some scenarios, however, require you to generate and use security tokens directly. These scenarios include the direct use of the MQTT, AMQP, or HTTP surfaces, or the implementation of the token service pattern, as explained in Custom device authentication.

IoT Hub also allows devices to authenticate with IoT Hub using X.509 certificates.

Security token structure

You use security tokens to grant time-bounded access to devices and services to specific functionality in IoT Hub. To ensure that only authorized devices and services can connect, security tokens must be signed with either a shared access key or a symmetric key. These keys are stored with a device identity in the identity registry.

A token signed with a shared access key grants access to all the functionality associated with the shared access policy permissions. On the other hand, a token signed with a device identity's symmetric key only grants the DeviceConnect permission for the associated device identity.

The security token has the following format:

SharedAccessSignature sig={signature-string}&se={expiry}&skn={policyName}&sr={URL-encoded-resourceURI}

Here are the expected values:

Value Description
{signature} An HMAC-SHA256 signature string of the form: {URL-encoded-resourceURI} + "\n" + expiry. Important: The key is decoded from base64 and used as key to perform the HMAC-SHA256 computation.
{resourceURI} URI prefix (by segment) of the endpoints that can be accessed with this token, starting with host name of the IoT hub (no protocol). For example, myHub.azure-devices.net/devices/device1
{expiry} UTF8 strings for number of seconds since the epoch 00:00:00 UTC on 1 January 1970.
{URL-encoded-resourceURI} Lower case URL-encoding of the lower case resource URI
{policyName} The name of the shared access policy to which this token refers. Absent if the token refers to device-registry credentials.

Note on prefix: The URI prefix is computed by segment and not by character. For example /a/b is a prefix for /a/b/c but not for /a/bc.

The following Node.js snippet shows a function called generateSasToken that computes the token from the inputs resourceUri, signingKey, policyName, expiresInMins. The next sections detail how to initialize the different inputs for the different token use cases.

var generateSasToken = function(resourceUri, signingKey, policyName, expiresInMins) {
    resourceUri = encodeURIComponent(resourceUri);

    // Set expiration in seconds
    var expires = (Date.now() / 1000) + expiresInMins * 60;
    expires = Math.ceil(expires);
    var toSign = resourceUri + '\n' + expires;

    // Use crypto
    var hmac = crypto.createHmac('sha256', new Buffer(signingKey, 'base64'));
    hmac.update(toSign);
    var base64UriEncoded = encodeURIComponent(hmac.digest('base64'));

    // Construct autorization string
    var token = "SharedAccessSignature sr=" + resourceUri + "&sig="
    + base64UriEncoded + "&se=" + expires;
    if (policyName) token += "&skn="+policyName;
    return token;
};

As a comparison, the equivalent Python code to generate a security token is:

from base64 import b64encode, b64decode
from hashlib import sha256
from time import time
from urllib import quote_plus, urlencode
from hmac import HMAC

def generate_sas_token(uri, key, policy_name, expiry=3600):
    ttl = time() + expiry
    sign_key = "%s\n%d" % ((quote_plus(uri)), int(ttl))
    print sign_key
    signature = b64encode(HMAC(b64decode(key), sign_key, sha256).digest())

    rawtoken = {
        'sr' :  uri,
        'sig': signature,
        'se' : str(int(ttl))
    }

    if policy_name is not None:
        rawtoken['skn'] = policy_name

    return 'SharedAccessSignature ' + urlencode(rawtoken)
Note

Since the time validity of the token is validated on IoT Hub machines, the drift on the clock of the machine that generates the token must be minimal.

Use SAS tokens in a device app

There are two ways to obtain DeviceConnect permissions with IoT Hub with security tokens: use a symmetric device key from the identity registry, or use a shared access key.

Remember that all functionality accessible from devices is exposed by design on endpoints with prefix /devices/{deviceId}.

Important

The only way that IoT Hub authenticates a specific device is using the device identity symmetric key. In cases when a shared access policy is used to access device functionality, the solution must consider the component issuing the security token as a trusted subcomponent.

The device-facing endpoints are (irrespective of the protocol):

Endpoint Functionality
{iot hub host name}/devices/{deviceId}/messages/events Send device-to-cloud messages.
{iot hub host name}/devices/{deviceId}/devicebound Receive cloud-to-device messages.

Use a symmetric key in the identity registry

When using a device identity's symmetric key to generate a token, the policyName (skn) element of the token is omitted.

For example, a token created to access all device functionality should have the following parameters:

  • resource URI: {IoT hub name}.azure-devices.net/devices/{device id},
  • signing key: any symmetric key for the {device id} identity,
  • no policy name,
  • any expiration time.

An example using the preceding Node.js function would be:

var endpoint ="myhub.azure-devices.net/devices/device1";
var deviceKey ="...";

var token = generateSasToken(endpoint, deviceKey, null, 60);

The result, which grants access to all functionality for device1, would be:

SharedAccessSignature sr=myhub.azure-devices.net%2fdevices%2fdevice1&sig=13y8ejUk2z7PLmvtwR5RqlGBOVwiq7rQR3WZ5xZX3N4%3D&se=1456971697

Note

It is possible to generate a SAS token using the .NET device explorer tool or the cross-platform, node-based iothub-explorer command-line utility.

Use a shared access policy

When creating a token from a shared access policy, the policy name field skn must be set to the name of the policy used. It is also required that the policy grants the DeviceConnect permission.

The two main scenarios for using shared access policies to access device functionality are:

Since the shared access policy can potentially grant access to connect as any device, it is important to use the correct resource URI when creating security tokens. This is especially important for token services, which have to scope the token to a specific device using the resource URI. This point is less relevant for protocol gateways as they are already mediating traffic for all devices.

As an example, a token service using the pre-created shared access policy called device would create a token with the following parameters:

  • resource URI: {IoT hub name}.azure-devices.net/devices/{device id},
  • signing key: one of the keys of the device policy,
  • policy name: device,
  • any expiration time.

An example using the preceding Node.js function would be:

var endpoint ="myhub.azure-devices.net/devices/device1";
var policyName = 'device';
var policyKey = '...';

var token = generateSasToken(endpoint, policyKey, policyName, 60);

The result, which grants access to all functionality for device1, would be:

SharedAccessSignature sr=myhub.azure-devices.net%2fdevices%2fdevice1&sig=13y8ejUk2z7PLmvtwR5RqlGBOVwiq7rQR3WZ5xZX3N4%3D&se=1456971697&skn=device

A protocol gateway could use the same token for all devices simply setting the resource URI to myhub.azure-devices.net/devices.

Use security tokens from service components

Service components can only generate security tokens using shared access policies granting the appropriate permissions as explained previously.

Here are the service functions exposed on the endpoints:

Endpoint Functionality
{iot hub host name}/devices Create, update, retrieve, and delete device identities.
{iot hub host name}/messages/events Receive device-to-cloud messages.
{iot hub host name}/servicebound/feedback Receive feedback for cloud-to-device messages.
{iot hub host name}/devicebound Send cloud-to-device messages.

As an example, a service generating using the pre-created shared access policy called registryRead would create a token with the following parameters:

  • resource URI: {IoT hub name}.azure-devices.net/devices,
  • signing key: one of the keys of the registryRead policy,
  • policy name: registryRead,
  • any expiration time.
var endpoint ="myhub.azure-devices.net/devices";
var policyName = 'device';
var policyKey = '...';

var token = generateSasToken(endpoint, policyKey, policyName, 60);

The result, which would grant access to read all device identities, would be:

SharedAccessSignature sr=myhub.azure-devices.net%2fdevices&sig=JdyscqTpXdEJs49elIUCcohw2DlFDR3zfH5KqGJo4r4%3D&se=1456973447&skn=registryRead

Supported X.509 certificates

You can use any X.509 certificate to authenticate a device with IoT Hub. Certificates include:

  • An existing X.509 certificate. A device may already have an X.509 certificate associated with it. The device can use this certificate to authenticate with IoT Hub.
  • A self-generated and self-signed X-509 certificate. A device manufacturer or in-house deployer can generate these certificates and store the corresponding private key (and certificate) on the device. You can use tools such as OpenSSL and Windows SelfSignedCertificate utility for this purpose.
  • CA-signed X.509 certificate. You can also use an X.509 certificate generated and signed by a Certification Authority (CA) to identify a device and authenticate a device with IoT Hub. IoTHub only verifies that the thumbprint presented matches the configured thumbprint. IotHub does not validate the certificate chain.

A device may either use an X.509 certificate or a security token for authentication, but not both.

Register an X.509 certificate for a device

The Azure IoT Service SDK for C# (version 1.0.8+) supports registering a device that uses an X.509 certificate for authentication. Other APIs such as import/export of devices also support X.509 certificates.

C# Support

The RegistryManager class provides a programmatic way to register a device. In particular, the AddDeviceAsync and UpdateDeviceAsync methods enable you to register and update a device in the IoT Hub identity registry. These two methods take a Device instance as input. The Device class includes an Authentication property that allows you to specify primary and secondary X.509 certificate thumbprints. The thumbprint represents a SHA-1 hash of the X.509 certificate (stored using binary DER encoding). You have the option of specifying a primary thumbprint or a secondary thumbprint or both. Primary and secondary thumbprints are supported to handle certificate rollover scenarios.

Note

IoT Hub does not require or store the entire X.509 certificate, only the thumbprint.

Here is a sample C# code snippet to register a device using an X.509 certificate:

var device = new Device(deviceId)
{
  Authentication = new AuthenticationMechanism()
  {
    X509Thumbprint = new X509Thumbprint()
    {
      PrimaryThumbprint = "921BC9694ADEB8929D4F7FE4B9A3A6DE58B0790B"
    }
  }
};
RegistryManager registryManager = RegistryManager.CreateFromConnectionString(deviceGatewayConnectionString);
await registryManager.AddDeviceAsync(device);

Use an X.509 certificate during run-time operations

The Azure IoT device SDK for .NET (version 1.0.11+) supports the use of X.509 certificates.

C# Support

The class DeviceAuthenticationWithX509Certificate supports the creation of DeviceClient instances using an X.509 certificate. The X.509 certificate must be in the PFX (also called PKCS #12) format that includes the private key.

Here is a sample code snippet:

var authMethod = new DeviceAuthenticationWithX509Certificate("<device id>", x509Certificate);

var deviceClient = DeviceClient.Create("<IotHub DNS HostName>", authMethod);

Custom device authentication

You can use the IoT Hub identity registry to configure per-device security credentials and access control using tokens. However, if an IoT solution already has a significant investment in a custom identity registry and/or authentication scheme, you can integrate this existing infrastructure with IoT Hub by creating a token service. In this way, you can use other IoT features in your solution.

A token service is a custom cloud service. It uses an IoT Hub shared access policy with DeviceConnect permissions to create device-scoped tokens. These tokens enable a device to connect to your IoT hub.

Steps of the token service pattern

Here are the main steps of the token service pattern:

  1. Create an IoT Hub shared access policy with DeviceConnect permissions for your IoT hub. You can create this policy in the Azure portal or programmatically. The token service uses this policy to sign the tokens it creates.
  2. When a device needs to access your IoT hub, it requests a signed token from your token service. The device can authenticate with your custom identity registry/authentication scheme to determine the device identity that the token service uses to create the token.
  3. The token service returns a token. The token is created by using /devices/{deviceId} as resourceURI, with deviceId as the device being authenticated. The token service uses the shared access policy to construct the token.
  4. The device uses the token directly with the IoT hub.
Note

You can use the .NET class SharedAccessSignatureBuilder or the Java class IotHubServiceSasToken to create a token in your token service.

The token service can set the token expiration as desired. When the token expires, the IoT hub severs the device connection. Then, the device must request a new token from the token service. A short expiry time increases the load on both the device and the token service.

For a device to connect to your hub, you must still add it to the IoT Hub identity registry — even though the device is using a token and not a device key to connect. Therefore, you can continue to use per-device access control by enabling or disabling device identities in the IoT Hub identity registry when the device authenticates with a token. This approach mitigates the risks of using tokens with long expiry times.

Comparison with a custom gateway

The token service pattern is the recommended way to implement a custom identity registry/authentication scheme with IoT Hub. It is recommended because IoT Hub continues to handle most of the solution traffic. However, there are cases where the custom authentication scheme is so intertwined with the protocol that a service processing all the traffic (custom gateway) is required. An example of such a scenario is usingTransport Layer Security (TLS) and pre-shared keys (PSKs). For more information, see the protocol gateway topic.

Reference topics:

The following reference topics provide you with more information about controlling access to your IoT hub.

IoT Hub permissions

The following table lists the permissions you can use to control access to your IoT hub.

Permission Notes
RegistryRead Grants read access to the identity registry. For more information, see Identity registry.
This permission is used by back-end cloud services.
RegistryReadWrite Grants read and write access to the identity registry. For more information, see Identity registry.
This permission is used by back-end cloud services.
ServiceConnect Grants access to cloud service-facing communication and monitoring endpoints.
Grants permission to receive device-to-cloud messages, send cloud-to-device messages, and retrieve the corresponding delivery acknowledgments.
Grants permission to retrieve delivery acknowledgements for file uploads.
Grants permission to access device twins to update tags and desired properties, retrieve reported properties, and run queries.
This permission is used by back-end cloud services.
DeviceConnect Grants access to device-facing endpoints.
Grants permission to send device-to-cloud messages and receive cloud-to-device messages.
Grants permission to perform file upload from a device.
Grants permission to receive device twin desired property notifications and update device twin reported properties.
Grants permission to perform file uploads.
This permission is used by devices.

Additional reference material

Other reference topics in the IoT Hub developer guide include:

Next steps

Now you have learned how to control access IoT Hub, you may be interested in the following IoT Hub developer guide topics:

If you would like to try out some of the concepts described in this article, you may be interested in the following IoT Hub tutorials:
