Query examples using "full" Lucene search syntax (advanced queries in Azure Search)

When constructing queries for Azure Search, you can replace the default simple query parser with the more expansive Lucene Query Parser in Azure Search to formulate specialized and advanced query definitions.

The Lucene parser supports complex query constructs, such as field-scoped queries, fuzzy and prefix wildcard search, proximity search, term boosting, and regular expression search. The additional power comes with additional processing requirements so you should expect a slightly longer execution time. In this article, you can step through examples demonstrating query operations available when using the full syntax.

Note

Many of the specialized query constructions enabled through the full Lucene query syntax are not text-analyzed, which can be surprising if you expect stemming or lemmatization. Lexical analysis is only performed on complete terms (a term query or phrase query). Query types with incomplete terms (prefix query, wildcard query, regex query, fuzzy query) are added directly to the query tree, bypassing the analysis stage. The only transformation performed on incomplete query terms is lowercasing.

Formulate requests in Postman

The following examples leverage a NYC Jobs search index consisting of jobs available based on a dataset provided by the City of New York OpenData initiative. This data should not be considered current or complete. The index is on a sandbox service provided by Microsoft, which means you do not need an Azure subscription or Azure Search to try these queries.

What you do need is Postman or an equivalent tool for issuing HTTP request on GET. For more information, see Explore with REST clients.

Set the request header

  1. In the request header, set Content-Type to application/json.

  2. Add an api-key, and set it to this string: 252044BE3886FE4A8E3BAA4F595114BB. This is a query key for the sandbox search service hosting the NYC Jobs index.

After you specify the request header, you can reuse it for all of the queries in this article, swapping out only the search= string.

Postman request header

Set the request URL

Request is a GET command paired with a URL containing the Azure Search endpoint and search string.

Postman request header

URL composition has the following elements:

  • https://azs-playground.search.windows.net/ is a sandbox search service maintained by the Azure Search development team.
  • indexes/nycjobs/ is the NYC Jobs index in the indexes collection of that service. Both the service name and index are required on the request.
  • docs is the documents collection containing all searchable content. The query api-key provided in the request header only works on read operations targeting the documents collection.
  • api-version=2019-05-06 sets the api-version, which is a required parameter on every request.
  • search=* is the query string, which in the initial query is null, returning the first 50 results (by default).

Send your first query

As a verification step, paste the following request into GET and click Send. Results are returned as verbose JSON documents. Entire documents are returned, which allows you to see all fields and all values.

Paste this URL into a REST client as a validation step and to view document structure.

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&$count=true&search=*

The query string, search=*, is an unspecified search equivalent to null or empty search. It's the simplest search you can do.

Optionally, you can add $count=true to the URL to return a count of the documents matching the search criteria. On an empty search string, this is all the documents in the index (about 2800 in the case of NYC Jobs).

How to invoke full Lucene parsing

Add queryType=full to invoke the full query syntax, overriding the default simple query syntax.

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&search=*

All of the examples in this article specify the queryType=full search parameter, indicating that the full syntax is handled by the Lucene Query Parser.

Example 1: Query scoped to a list of fields

This first example is not Lucene-specific, but we lead with it to introduce the first fundamental query concept: field scope. This example scopes the entire query and the response to just a few specific fields. Knowing how to structure a readable JSON response is important when your tool is Postman or Search explorer.

For brevity, the query targets only the business_title field and specifies only business titles are returned. The searchFields parameter restricts query execution to just the business_title field, and select specifies which fields are included in the response.

Partial query string

&search=*&searchFields=business_title&$select=business_title

Here is the same query with multiple fields in a comma-delimited list.

search=*&searchFields=business_title, posting_type&$select=business_title, posting_type

The spaces after the commas are optional.

Tip

When using the REST API from your application code, don't forget to URL-encode parameters like $select and searchFields.

Full URL

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&search=*&searchFields=business_title&$select=business_title

Response for this query should look similar to the following screenshot.

Postman sample response

You might have noticed the search score in the response. Uniform scores of 1 occur when there is no rank, either because the search was not full text search, or because no criteria was applied. For null search with no criteria, rows come back in arbitrary order. When you include actual search criteria, you will see search scores evolve into meaningful values.

Full Lucene syntax supports scoping individual search expressions to a specific field. This example searches for business titles with the term senior in them, but not junior.

Partial query string

$select=business_title&search=business_title:(senior NOT junior)

Here is the same query with multiple fields.

$select=business_title, posting_type&search=business_title:(senior NOT junior) AND posting_type:external

Full URL

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&$select=business_title&search=business_title:(senior NOT junior)

Postman sample response

You can define a fielded search operation with the fieldName:searchExpression syntax, where the search expression can be a single word or a phrase, or a more complex expression in parentheses, optionally with Boolean operators. Some examples include the following:

  • business_title:(senior NOT junior)
  • state:("New York" OR "New Jersey")
  • business_title:(senior NOT junior) AND posting_type:external

Be sure to put multiple strings within quotation marks if you want both strings to be evaluated as a single entity, as in this case searching for two distinct locations in the state field. Also, ensure the operator is capitalized as you see with NOT and AND.

The field specified in fieldName:searchExpression must be a searchable field. See Create Index (Azure Search Service REST API) for details on how index attributes are used in field definitions.

Note

In the example above, we did not need to use the searchFields parameter because each part of the query has a field name explicitly specified. However, you can still use the searchFields parameter if you want to run a query where some parts are scoped to a specific field, and the rest could apply to several fields. For example, the query search=business_title:(senior NOT junior) AND external&searchFields=posting_type would match senior NOT junior only to the business_title field, while it would match "external" with the posting_type field. The field name provided in fieldName:searchExpression always takes precedence over the searchFields parameter, which is why in this example, we do not need to include business_title in the searchFields parameter.

Full Lucene syntax also supports fuzzy search, matching on terms that have a similar construction. To do a fuzzy search, append the tilde ~ symbol at the end of a single word with an optional parameter, a value between 0 and 2, that specifies the edit distance. For example, blue~ or blue~1 would return blue, blues, and glue.

Partial query string

searchFields=business_title&$select=business_title&search=business_title:asosiate~

Phrases aren't supported directly but you can specify a fuzzy match on component parts of a phrase.

searchFields=business_title&$select=business_title&search=business_title:asosiate~ AND comm~

Full URL

This query searches for jobs with the term "associate" (deliberately misspelled):

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&searchFields=business_title&$select=business_title&search=business_title:asosiate~

Fuzzy search response

Note

Fuzzy queries are not analyzed. Query types with incomplete terms (prefix query, wildcard query, regex query, fuzzy query) are added directly to the query tree, bypassing the analysis stage. The only transformation performed on incomplete query terms is lowercasing.

Proximity searches are used to find terms that are near each other in a document. Insert a tilde "~" symbol at the end of a phrase followed by the number of words that create the proximity boundary. For example, "hotel airport"~5 will find the terms hotel and airport within 5 words of each other in a document.

Partial query string

searchFields=business_title&$select=business_title&search=business_title:%22senior%20analyst%22~1

Full URL

In this query, for jobs with the term "senior analyst" where it is separated by no more than one word:

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&searchFields=business_title&$select=business_title&search=business_title:%22senior%20analyst%22~1

Proximity query

Try it again removing the words between the term "senior analyst". Notice that 8 documents are returned for this query as opposed to 10 for the previous query.

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&searchFields=business_title&$select=business_title&search=business_title:%22senior%20analyst%22~0

Example 5: Term boosting

Term boosting refers to ranking a document higher if it contains the boosted term, relative to documents that do not contain the term. To boost a term, use the caret, "^", symbol with a boost factor (a number) at the end of the term you are searching.

Full URLs

In this "before" query, search for jobs with the term computer analyst and notice there are no results with both words computer and analyst, yet computer jobs are at the top of the results.

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&searchFields=business_title&$select=business_title&search=business_title:computer%20analyst

Term boosting before

In the "after" query, repeat the search, this time boosting results with the term analyst over the term computer if both words do not exist.

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&searchFields=business_title&$select=business_title&search=business_title:computer%20analyst%5e2

A more human readable version of the above query is search=business_title:computer analyst^2. For a workable query, ^2 is encoded as %5E2, which is harder to see.

Term boosting after

Term boosting differs from scoring profiles in that scoring profiles boost certain fields, rather than specific terms. The following example helps illustrate the differences.

Consider a scoring profile that boosts matches in a certain field, such as genre in the musicstoreindex example. Term boosting could be used to further boost certain search terms higher than others. For example, "rock^2 electronic" will boost documents that contain the search terms in the genre field higher than other searchable fields in the index. Furthermore, documents that contain the search term "rock" will be ranked higher than the other search term "electronic" as a result of the term boost value (2).

When setting the factor level, the higher the boost factor, the more relevant the term will be relative to other search terms. By default, the boost factor is 1. Although the boost factor must be positive, it can be less than 1 (for example, 0.2).

Example 6: Regex

A regular expression search finds a match based on the contents between forward slashes "/", as documented in the RegExp class.

Partial query string

searchFields=business_title&$select=business_title&search=business_title:/(Sen|Jun)ior/

Full URL

In this query, search for jobs with either the term Senior or Junior: search=business_title:/(Sen|Jun)ior/.

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&searchFields=business_title&$select=business_title&search=business_title:/(Sen|Jun)ior/

Regex query

Note

Regex queries are not analyzed. The only transformation performed on incomplete query terms is lowercasing.

You can use generally recognized syntax for multiple (*) or single (?) character wildcard searches. Note the Lucene query parser supports the use of these symbols with a single term, and not a phrase.

Partial query string

searchFields=business_title&$select=business_title&search=business_title:prog*

Full URL

In this query, search for jobs that contain the prefix 'prog' which would include business titles with the terms programming and programmer in it. You cannot use a * or ? symbol as the first character of a search.

https://azs-playground.search.windows.net/indexes/nycjobs/docs?api-version=2019-05-06&queryType=full&$count=true&searchFields=business_title&$select=business_title&search=business_title:prog*

Wildcard query

Note

Wildcard queries are not analyzed. The only transformation performed on incomplete query terms is lowercasing.

Next steps

Try specifying the Lucene Query Parser in your code. The following links explain how to set up search queries for both .NET and the REST API. The links use the default simple syntax so you will need to apply what you learned from this article to specify the queryType.

Additional syntax reference, query architecture, and examples can be found in the following links:
