Post-configuration steps to optimize your environment

Post-configuration steps to help improve performance, maintain your BizTalk environment, and install the EDI schemas.

Disable Shared Memory protocol in SQL Server

  1. Open SQL Server Configuration Manager > expand SQL Server Network Configuration > Protocols for MSSQLSERVER.
  2. Right-click Shared Memory > Disable.
  3. Select SQL Server Services, right-click SQL Server (MSSQLServer) > Restart.
  4. Close SQL Server Configuration Manager.

Configure the SQL Agent jobs

  1. Open SQL Server Management Studio, and connect to Database Engine.

  2. Expand SQL Server Agent, and expand Jobs. Configure the following jobs:

    • Backup BizTalk Server: Backs up the BizTalk Server databases and the log files. When configuring the job, you determine parameters like frequency and file location.

      The following links describe the SQL Agent job and its parameters:

      This SQL Agent job also truncates the transaction logs, which helps improve performance.

      This job doesn't remove or delete backup files, including older files. To delete backup files, refer to The "Backup BizTalk Server" job fails when backup files accumulate over time in the Microsoft BizTalk Server database server.

    • DTA Purge and Archive: Truncates and archives the BizTalk Server Tracking database (BizTalkDTADb). When configuring the job, you determine parameters like how many days to keep completed instances and how many to days to keep all data.

      The following links describe the SQL Agent job and its parameters:

      This SQL Agent job directly impacts performance by maintaining the tracking host and purging tracking events.

Maintain your backup files

BizTalk Server does not include any job to delete backup files. As a result, how you maintain your backup files is up to you. Many users create the sp_DeleteBackupHistoryAndFiles stored procedure, and then call this stored procedure directly in the Backup BizTalk Server job. Some users create a maintenance plan. The choice is yours. This topic lists both options.

Option 1: Create the sp_DeleteBackupHistoryAndFiles stored procedure

  1. In SQL Server Management Studio, select the BizTalk Management database (BizTalkMgmtDb).

  2. Select New Query, and run the following T-SQL script to create the sp_DeleteBackupHistoryAndFiles (BizTalk Server 2016) or sp_DeleteBackupHistoryAndFiles2013 (BizTalk Server 2013 R2 and older) stored procedure:

    sp_DeleteBackupHistoryAndFiles (BizTalk Server 2016 and newer)

    CREATE PROCEDURE [dbo].[sp_DeleteBackupHistoryAndFiles] @DaysToKeep smallint = null
    AS

    BEGIN
    set nocount on
    IF @DaysToKeep IS NULL OR @DaysToKeep <= 1
    RETURN
    /*
    Only delete full sets
    If a set spans a day in such a way that some items fall into the deleted group and the other does not, do not delete the set
    */

    /*
    First delete MarkName from all other databases
    */
    declare @BackupServer sysname ,@BackupDB sysname, @tsql nvarchar(1024), @MarkToBeDeleted nvarchar(128)
    DECLARE BackupDB_Cursor insensitive cursor for
    SELECT	ServerName, DatabaseName
    FROM	admv_BackupDatabases
    ORDER BY ServerName
    open BackupDB_Cursor

    SELECT @MarkToBeDeleted = MAX([MarkName])
    FROM [dbo].[adm_BackupHistory] [h1]
    WHERE [BackupType] = 'lg' AND datediff( dd, [BackupDateTime], getdate() ) >= @DaysToKeep
    AND	[BackupSetId] NOT IN ( SELECT [BackupSetId] FROM [dbo].[adm_BackupHistory] [h2] WHERE [h2].[BackupSetId] = [h1].[BackupSetId] AND datediff( dd, [h2].[BackupDateTime], getdate() ) < @DaysToKeep AND [h2].[BackupType] = 'lg')
    AND EXISTS( SELECT TOP 1 1 FROM [dbo].[adm_BackupHistory] [h2] WHERE [h2].[BackupSetId] > [h1].[BackupSetId] AND [h2].[BackupType] = 'lg')
    fetch next from BackupDB_Cursor into @BackupServer, @BackupDB

    while @@fetch_status = 0
    	begin
    	set @tsql = '[' + @BackupServer + '].[' + @BackupDB + '].[dbo].[sp_CleanUpMarkLog]'
    	exec @tsql @MarkName=@MarkToBeDeleted
    	fetch next from BackupDB_Cursor into @BackupServer, @BackupDB
    	end

    close BackupDB_Cursor
    deallocate BackupDB_Cursor

    DECLARE DeleteBackupFiles CURSOR
    -- xp_delete_file variant
    FOR SELECT [BackupFileLocation] + '\' + [BackupFileName] FROM [adm_BackupHistory]
    -- xp_cmdshell variant
    -- FOR SELECT 'del "' + [BackupFileLocation] + '\' + [BackupFileName] + '"' FROM [adm_BackupHistory]
    WHERE  datediff( dd, [BackupDateTime], getdate() ) >= @DaysToKeep
    AND [BackupSetId] NOT IN ( SELECT [BackupSetId] FROM [dbo].[adm_BackupHistory] [h2] WHERE [h2].[BackupSetId] = [BackupSetId] AND datediff( dd, [h2].[BackupDateTime], getdate() ) < @DaysToKeep )

    DECLARE @cmd varchar(400)
    OPEN DeleteBackupFiles
    FETCH NEXT FROM DeleteBackupFiles INTO @cmd
    WHILE (@@fetch_status <> -1)
    BEGIN
        IF (@@fetch_status <> -2)
        BEGIN
    -- xp_delete_file variant
            EXECUTE master.dbo.xp_delete_file 0, @cmd
    -- xp_cmdshell variant
    --        EXEC master.dbo.xp_cmdshell @cmd, NO_OUTPUT
            delete from [adm_BackupHistory] WHERE CURRENT OF DeleteBackupFiles
            print @cmd
        END
        FETCH NEXT FROM DeleteBackupFiles INTO @cmd
    END

    CLOSE DeleteBackupFiles
    DEALLOCATE DeleteBackupFiles
    END
    GO


    sp_DeleteBackupHistoryAndFiles2013 (BizTalk 2013 R2 and older)

    CREATE PROCEDURE [dbo].[sp_DeleteBackupHistoryAndFiles2013] @DaysToKeep smallint = null
    AS

    BEGIN
    set nocount on
    IF @DaysToKeep IS NULL OR @DaysToKeep <= 1
    RETURN
    /*
    Only delete full sets
    If a set spans a day in such a way that some items fall into the deleted group and the other does not, do not delete the set
    */

    DECLARE DeleteBackupFiles CURSOR
    FOR SELECT 'del "' + [BackupFileLocation] + '\' + [BackupFileName] + '"' FROM [adm_BackupHistory]
    WHERE  datediff( dd, [BackupDateTime], getdate() ) >= @DaysToKeep
    AND [BackupSetId] NOT IN ( SELECT [BackupSetId] FROM [dbo].[adm_BackupHistory] [h2] WHERE [h2].[BackupSetId] = [BackupSetId] AND  datediff( dd, [h2].[BackupDateTime], getdate() ) < @DaysToKeep )

    DECLARE @cmd varchar(400)
    OPEN DeleteBackupFiles
    FETCH NEXT FROM DeleteBackupFiles INTO @cmd
    WHILE (@@fetch_status <> -1)
    BEGIN
        IF (@@fetch_status <> -2)
        BEGIN
            EXEC master.dbo.xp_cmdshell @cmd, NO_OUTPUT
            delete from [adm_BackupHistory] WHERE CURRENT OF DeleteBackupFiles
            print @cmd
        END
        FETCH NEXT FROM DeleteBackupFiles INTO @cmd
    END

    CLOSE DeleteBackupFiles
    DEALLOCATE DeleteBackupFiles
    END
    GO

  3. Open the Backup BizTalk Server job > select Steps.

  4. Edit the Clear Backup History step so that it calls the new sp_DeleteBackupHistoryAndFiles or sp_DeleteBackupHistoryAndFiles2013 stored procedure instead of the previous sp_DeleteBackupHistory stored procedure.

  5. Select OK to save your changes.

Option 2: Create a maintenance plan

  1. In SQL Server Management Studio, expand Management, right-click Maintenance Plans, and select Maintenance Plan Wizard.
  2. Name the plan (for example, name it Purge Backup Files), and then select the Change button next to Schedule.
  3. Choose how frequently you want to purge the backup files. These settings are completely up to you. Select OK, and then select Next.
  4. Select Maintenance Cleanup Task > Next.
  5. In the Cleanup Task window, go to Search folder and delete files..., select your backup Folder (maybe f:\BizTalkBackUps), and enter .bak for the File extension. You can also choose to delete files based on their age. For example, enter 3 if you want to delete files that are older than 3 weeks. Select Next.
  6. Finish going through the wizard and enter any additional information you want. Select Finish.

Install EDI schemas and more EDI AS2 configuration

The EANCOM, EDIFACT, HIPAA, and X12 schema files are included in a self-extracting executable file named MicrosoftEdiXSDTemplates.exe. To create EDI solutions, extract these files, and deploy with your projects. To install and extract these files:

  1. Run the BizTalk Server installation, and install the Developer Tools and SDK component. This component downloads the MicrosoftEdiXSDTemplates.exe EDI schema file to the \XSD_Schema\EDI folder.

    Note

    If you upgrade BizTalk Server, the MicrosoftEdiXSDTemplates.exe file in your installation is replaced with the new MicrosoftEdiXSDTemplates.exe file associated with the upgrade. If you need the previous the schemas, then back up the previous MicrosoftEdiXSDTemplates.exe file.

    Note

    If you upgrade message schemas when you upgrade BizTalk Server to a later build, you may encounter issues using the updated schemas, or you may have to perform additional updating steps. See the "Considerations for updating schemas" section in Important Considerations for Updating Applications

  2. Go to \Program Files\Microsoft BizTalk Server\XSD_Schema\EDI, and double-click MicrosoftEdiXSDTemplates.exe.

  3. Extract the schemas to \Program Files\Microsoft BizTalk Server\XSD_Schema\EDI. When you extract the schemas, they are stored in EANCOM, EDIFACT, HIPAA, and X12 folders.

Add a reference to the BizTalk Server EDI application

EDI schemas, pipelines, and orchestrations are deployed in the BizTalk EDI Application. To use any other application as an EDI application, add a reference to the BizTalk EDI Application. Steps:

  1. In the BizTalk Server Administration Console, expand Applications. Right-click the application that you want to use for EDI (such as BizTalk Application 1), select Add, and then select References.

  2. Select BizTalk EDI Application, and select OK to save your changes.

Tip

To see references to other applications, right-click any application, and select Properties. Select References. You can also add new references, and remove existing references.

Note

Do not add custom artifacts to the BizTalk EDI Application. It's best to leave this application as-is.

Start batch orchestrations

If you enable a party to receive and/or send EDI batches, then start the batching orchestrations. These orchestrations are not started by the installation wizard or the configuration wizard. Steps:

  1. In BizTalk Server Administration Console, expand BizTalk EDI Application, and selectOrchestrations.

  2. Right-click each of the following orchestrations, and select Start:

    • Microsoft.BizTalk.Edi.BatchSuspendOrchestration.BatchElementSuspendService (assembly: Microsoft.BizTalk.Edi.BatchingOrchestration.dll)

    • Microsoft.BizTalk.Edi.BatchingOrchestration.BatchingService (assembly: Microsoft.BizTalk.Edi.BatchingOrchestration.dll)

    • Microsoft.BizTalk.Edi.RoutingOrchestration.BatchRoutingService (assembly: Microsoft.BizTalk.Edi.RoutingOrchestration.dll)

Note

The EDI batching orchestrations should only be started if you receive and/or send EDI batches. Starting them when the system is not receiving or sending EDI batches could affect system performance.

Migrate EDI artifacts from a previous BizTalk version

The way trading partners are managed in BizTalk Server was updated in BizTalk Server 2010 and newer versions. In the previous BizTalk Server versions, a party was created only for the trading partner, and not for the partner hosting BizTalk Server. In BizTalk Server 2010 and newer, a party must be created for all the trading partners, including the partner hosting BizTalk Server. In previous BizTalk Server versions, the encoding (X12 and EDIFACT) and transport (AS2) protocol properties are defined at the party level. In BizTalk Server 2010 and newer versions, these properties are defined through agreements.

To migrate party data from previous versions, BizTalk Server includes a Party Migration Tool. Consider the following migration paths:

BizTalk Server Version Migration Path
BizTalk Server 2006 R2 Upgrade to BizTalk Server 2009. Then, use the Party Migration Tool included with BizTalk Server 2013/2013 R2 to migrate to BizTalk Server 2013/2013 R2.

Or, use the Party Migration Tool included with BizTalk Server 2013/2013 R2 to migrate to BizTalk Server 2010. Then, upgrade to BizTalk Server 2013/2013 R2.
BizTalk Server 2009 Use the Party Migration Tool included with BizTalk Server 2013/2013 R2 to migrate directly to BizTalk Server 2013/2013 R2.
BizTalk Server 2010 Upgrade to BizTalk Server 2013/2013 R2.

The Party Migration Tool is available on the BizTalk Server media under the \PartyMigrationTool folder.

Install BizTalk Health Monitor (BHM)

BizTalk Health Monitor provides a dashboard to create and view MessageBox Viewer reports, create custom queries, run Terminator tasks, monitor multiple BizTalk environments, and more. If you are responsible for a BizTalk envrionment, we suggest you install and use this tool to check the health of your BizTalk environment, and also maintain it.

Key links:

Download BHM Install BHM BHM Official Blog

Create your hosts and host instances

It is recommended to separate some key tasks into separate hosts. For example, always create a separate host that is dedicated to only tracking. Create another host/host instance that focuses on receiving messages, another host/host instance for sending messages, and another host/host instance for orchestration.

There are many recommendations in this area. Here are a few to get you started:

Managing BizTalk Hosts and Host Instances Providing High Availability for BizTalk Hosts Best Practices: Create and Configure BizTalk Server Host and Host Running Orchestrations in Multiple Hosts on the Same Computer PowerShell to Create and Configure BizTalk Server Host, Host Instances and Handlers BizTalk Server Resources on the TechNet Wiki
