Triggers and actions for logic app workflows

All logic apps start with a trigger followed by actions. This article describes the kinds of triggers and actions that you can use for creating system integrations and automating business workflows or processes by building logic apps.

Triggers overview

All logic apps start with a trigger, which specifies the calls that can start a logic app run. Here are the types of triggers that you can use:

  • A polling trigger, which checks a service's HTTP endpoint at regular intervals
  • A push trigger, which calls the Workflow Service REST API

All triggers contain these top-level elements:

"<myTriggerName>": {
    "type": "<triggerType>",
    "inputs": { <callSettings> },
    "recurrence": {
        "frequency": "Second | Minute | Hour | Day | Week | Month | Year",
        "interval": "<recurrence-interval-based-on-frequency>"
    },
    "conditions": [ <array-with-required-conditions> ],
    "splitOn": "<property-used-for-creating-runs>",
    "operationOptions": "<options-for-operations-on-the-trigger>"
}

Trigger types and inputs

Each trigger type has a different interface and different inputs that defines its behavior.

Trigger type Description
Recurrence Fires based on a defined schedule. You can set a future date and time for firing this trigger. Based on the frequency, you can also specify times and days for running the workflow.
Request Makes your logic app into an endpoint that you can call, also known as a "manual" trigger.
HTTP Checks, or polls, an HTTP web endpoint. The HTTP endpoint must conform to a specific triggering contract either by using a "202" asynchronous pattern or by returning an array.
ApiConnection Polls like an HTTP trigger, but uses Microsoft-managed APIs.
HTTPWebhook Makes your logic app into a callable endpoint, like the Request trigger, but calls a specified URL for registering and unregistering.
ApiConnectionWebhook Works like the HTTPWebhook trigger, but uses Microsoft-managed APIs.

For more information, see Workflow Definition Language.

Recurrence trigger

This trigger runs based on the recurrence and schedule that you specify and provides an easy way for regularly running a workflow.

Here is a basic recurrence trigger example that runs daily:

"myRecurrenceTrigger": {
    "type": "Recurrence",
    "recurrence": {
        "frequency": "Day",
        "interval": 1
    }
}

You can also schedule a start date and time for firing the trigger. For example, to start a weekly report every Monday, you can schedule the logic app to start on a specific Monday like this example:

"myRecurrenceTrigger": {
    "type": "Recurrence",
    "recurrence": {
        "frequency": "Week",
        "interval": "1",
        "startTime": "2017-09-18T00:00:00Z"
    }
}

Here is the definition for this trigger:

"myRecurrenceTrigger": {
    "type": "Recurrence",
    "recurrence": {
        "frequency": "second|minute|hour|day|week|month",
        "interval": <recurrence-interval-based-on-frequency>,
        "schedule": {
            // Applies only when frequency is Day or Week. Separate values with commas.
            "hours": [ <one-or-more-hour-marks> ],
            // Applies only when frequency is Day or Week. Separate values with commas.
            "minutes": [ <one-or-more-minute-marks> ],
            // Applies only when frequency is Week. Separate values with commas.
            "weekDays": [ "Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, Sunday" ]
        },
        "startTime": "<start-date-time-with-format-YYYY-MM-DDThh:mm:ss>",
        "timeZone": "<specify-time-zone>"
    }
}
Element name Required Type Description
frequency Yes String The unit of time for how often the trigger fires. Use only one of these values: "second", "minute", "hour", "day", "week", or "month"
interval Yes Integer A positive integer that describes how often the workflow runs based on the frequency.

Here are the minimum and maximum intervals:

- Month: 1-16 months
- Day: 1-500 days
- Hour: 1-12,000 hours
- Minute: 1-72,000 minutes
- Second: 1-9,999,999 seconds

For example, if the interval is 6, and the frequency is "month", then the recurrence is every 6 months.

timeZone No String Applies only when you specify a start time because this trigger doesn't accept UTC offset. Specify the time zone that you want to apply.
startTime No String Specify the start date and time in this format:

YYYY-MM-DDThh:mm:ss if you specify a time zone

-or-

YYYY-MM-DDThh:mm:ssZ if you don't specify a time zone

So for example, if you want September 18, 2017 at 2:00 PM, then specify "2017-09-18T14:00:00" and specify a time zone such as "Pacific Standard Time". Or, specify "2017-09-18T14:00:00Z" without a time zone.

Note: This start time must follow the ISO 8601 date time specification in UTC date time format, but without a UTC offset. If you don't specify a time zone, you must add the letter "Z" at the end without any spaces. This "Z" refers to the equivalent nautical time.

For simple schedules, the start time is the first occurrence, while for complex schedules, the trigger doesn't fire any sooner than the start time. For more information about start dates and times, see Create and schedule regularly running tasks.

weekDays No String or string array If you specify "Week" for frequency, you can specify one or more days, separated by commas, when you want to run the workflow: "Monday", "Tuesday", "Wednesday", "Thursday", "Friday", "Saturday", and "Sunday"
hours No Integer or integer array If you specify "Day" or "Week" for frequency, you can specify one or more integers from 0 to 23, separated by commas, as the hours of the day when you want to run the workflow.

For example, if you specify "10", "12" and "14", you get 10 AM, 12 PM, and 2 PM as the hour marks.

minutes No Integer or integer array If you specify "Day" or "Week" for frequency, you can specify one or more integers from 0 to 59, separated by commas, as the minutes of the hour when you want to run the workflow.

For example, you can specify "30" as the minute mark and using the previous example for hours of the day, you get 10:30 AM, 12:30 PM, and 2:30 PM.

For example, this recurrence trigger specifies that your logic app runs weekly every Monday at 10:30 AM, 12:30 PM, and 2:30 PM Pacific Standard Time, starting no sooner than September 9, 2017 at 2:00 PM:

"myRecurrenceTrigger": {
    "type": "Recurrence",
    "recurrence": {
        "frequency": "Week",
        "interval": 1,
        "schedule": {
            "hours": [
                10,
                12,
                14
            ],
            "minutes": [
                30
            ],
            "weekDays": [
                "Monday"
            ]
        },
       "startTime": "2017-09-07T14:00:00",
       "timeZone": "Pacific Standard Time"
    }
}

For more information with recurrence and start time examples for this trigger, see Create and schedule regularly running tasks.

Request trigger

This trigger serves as an endpoint that you can use for calling your logic app through an HTTP request. A request trigger looks like this example:

"myRequestTrigger": {
    "type": "Request",
    "kind": "Http",
    "inputs": {
        "schema": {
            "type": "Object",
            "properties": {
                "myInputProperty1": { "type" : "string" },
                "myInputProperty2": { "type" : "number" }
            },
            "required": [ "myInputProperty1" ]
        }
    }
}

This trigger has an optional property called schema:

Element name Required Type Description
schema No Object A JSON schema that validates the incoming request. Useful for helping subsequent workflow steps know which properties to reference.

To invoke this trigger as an endpoint, you need to call the listCallbackUrl API. See Workflow Service REST API.

HTTP trigger

This trigger polls a specified endpoint and checks the response to determine whether the workflow should run or not. Here, the inputs object takes these parameters required for constructing an HTTP call:

Element name Required Type Description
method Yes String Uses one of these HTTP methods: "GET", "POST", "PUT", "DELETE", "PATCH", or "HEAD"
uri Yes String The HTTP or HTTPs endpoint that the trigger checks. Maximum string size: 2 KB
queries No Object Represents any query parameters that you want to include in the URL.

For example, "queries": { "api-version": "2015-02-01" } adds ?api-version=2015-02-01 to the URL.

headers No Object Represents each header that's sent in the request.

For example, to set the language and type on a request:

"headers": { "Accept-Language": "en-us", "Content-Type": "application/json" }

body No Object Represents the payload that's sent to the endpoint.
retryPolicy No Object Use this object for customizing the retry behavior for 4xx or 5xx errors. For more information, see Retry policies.
authentication No Object Represents the method that the request should use for authentication. For more information, see Scheduler Outbound Authentication.

Beyond Scheduler, there is one more supported property: authority. By default, this value is https://login.windows.net when not specified, but you can use a different value, such ashttps://login.windows\-ppe.net.

A retry policy applies to intermittent failures, characterized as HTTP status codes 408, 429, and 5xx, in addition to any connectivity exceptions. You can define this policy with the retryPolicy object as shown here:

"retryPolicy": {
    "type": "<retry-policy-type>",
    "interval": <retry-interval>,
    "count": <number-of-retry-attempts>
}

To work well with your logic app, the HTTP trigger requires the HTTP API to conform with a specific pattern. The trigger recognizes these properties:

Response Required Description
Status code Yes The status code 200 ("OK") causes a run. Any other status code doesn't cause a run.
Retry-after header No The number of seconds until the logic app polls the endpoint again.
Location header No The URL to call at the next polling interval. If not specified, the original URL is used.

Here are some example behaviors for different types of requests:

Response code Retry after Behavior
200 {none} Run the workflow, then check again for more data after the defined recurrence.
200 10 seconds Run the workflow, then check again for more data after 10 seconds.
202 60 seconds Don't trigger the workflow. The next attempt happens in one minute, subject to the defined recurrence. If the defined recurrence is less than one minute, the retry-after header takes precedence. Otherwise, the defined recurrence is used.
400 {none} Bad request, don't run the workflow. If no retryPolicy is defined, then the default policy is used. After the number of retries has been reached, the trigger checks again for data after the defined recurrence.
500 {none} Server error, don't run the workflow. If no retryPolicy is defined, then the default policy is used. After the number of retries has been reached, the trigger checks again for data after the defined recurrence.

Here are the HTTP trigger outputs:

Element name Type Description
headers Object The headers of the HTTP response
body Object The body of the HTTP response

APIConnection trigger

In basic functionality, this trigger works like the HTTP trigger. However, the parameters for identifying the action are different. Here is an example:

"myDailyReportTrigger": {
    "type": "ApiConnection",
    "inputs": {
        "host": {
            "api": {
                "runtimeUrl": "https://myarticles.example.com/"
            }
        },
        "connection": {
            "name": "@parameters('$connections')['myconnection'].name"
        }
    },
    "method": "POST",
    "body": {
        "category": "myCategory"
    }
}
Element name Required Type Description
host Yes Object The hosted gateway and ID for the API App
method Yes String Uses one of these HTTP methods: "GET", "POST", "PUT", "DELETE", "PATCH", or "HEAD"
queries No Object Represents any query parameters that you want to include in the URL.

For example, "queries": { "api-version": "2015-02-01" } adds ?api-version=2015-02-01 to the URL.

headers No Object Represents each header that's sent in the request.

For example, to set the language and type on a request:

"headers": { "Accept-Language": "en-us", "Content-Type": "application/json" }

body No Object Represents the payload that's sent to the endpoint.
retryPolicy No Object Use this object for customizing the retry behavior for 4xx or 5xx errors. For more information, see Retry policies.
authentication No Object Represents the method that the request should use for authentication. For more information, see Scheduler Outbound Authentication.

For the host object, here are the properties:

Element name Required Description
api runtimeUrl Yes The endpoint for the managed API
connection name The name of the managed API connection that the workflow uses. Must reference a parameter named $connection.

A retry policy applies to intermittent failures, characterized as HTTP status codes 408, 429, and 5xx, in addition to any connectivity exceptions. You can define this policy with the retryPolicy object as shown here:

"retryPolicy": {
    "type": "<retry-policy-type>",
    "interval": <retry-interval>,
    "count": <number-of-retry-attempts>
}

Here are the outputs for an API Connection trigger:

Element name Type Description
headers Object The headers of the HTTP response
body Object The body of the HTTP response

Learn more about how pricing works for API Connection triggers.

HTTPWebhook trigger

This trigger provides an endpoint, similar to the Request trigger, but the HTTPWebhook trigger also calls a specified URL for registering and unregistering. Here is an example of what an HTTPWebhook trigger might look like:

"myAppsSpotTrigger": {
    "type": "HttpWebhook",
    "inputs": {
        "subscribe": {
            "method": "POST",
            "uri": "https://pubsubhubbub.appspot.com/subscribe",
            "headers": {},
            "body": {
                "hub.callback": "@{listCallbackUrl()}",
                "hub.mode": "subscribe",
                "hub.topic": "https://pubsubhubbub.appspot.com/articleCategories/technology"
            },
            "authentication": {},
            "retryPolicy": {}
        },
        "unsubscribe": {
            "method": "POST",
            "url": "https://pubsubhubbub.appspot.com/subscribe",
            "body": {
                "hub.callback": "@{workflow().endpoint}@{listCallbackUrl()}",
                "hub.mode": "unsubscribe",
                "hub.topic": "https://pubsubhubbub.appspot.com/articleCategories/technology"
            },
            "authentication": {}
        }
    },
    "conditions": []
}

Many of these sections are optional, and the HTTPWebhook trigger behavior depends on the sections that you provide or omit. Here are the properties for the HTTPWebhook trigger:

Element name Required Description
subscribe No Specifies the outgoing request to call when the trigger is created and performs the initial registration.
unsubscribe No Specifies the outgoing request to call when the trigger is deleted.

You can specify limits on a webhook trigger in the same way as HTTP Asynchronous Limits. Here is more information about the subscribe and unsubscribe actions:

  • subscribe is called so that the trigger can start listening to events. This outgoing call starts with the same parameters as standard HTTP actions. This call happens when the workflow changes in any way, for example, when the credentials are rolled, or the trigger's input parameters change.

    To support this call, the @listCallbackUrl() function returns a unique URL for this specific trigger in the workflow. This URL represents the unique identifier for the endpoints that use the service's REST API.

  • unsubscribe is automatically called when an operation renders this trigger invalid, including these operations:

    • Deleting or disabling the trigger.
    • Deleting or disabling the workflow.
    • Deleting or disabling the subscription.

    The parameters for this function are the same as the HTTP trigger.

Here are the outputs from the HTTPWebhook trigger and are the contents of the incoming request:

Element name Type Description
headers Object The headers of the HTTP response
body Object The body of the HTTP response

Triggers: Conditions

For any trigger, you can use one or more conditions to determine whether the workflow should run or not. In this example, the report only triggers while the workflow's sendReports parameter is set to true.

"myDailyReportTrigger": {
    "type": "Recurrence",
    "conditions": [
        {
            "expression": "@parameters('sendReports')"
        }
    ],
    "recurrence": {
        "frequency": "Day",
        "interval": 1
    }
}

Finally, conditions can reference the status code of the trigger. For example, you can start a workflow only when your website returns a status code 500:

"conditions": [
    {
      "expression": "@equals(triggers().code, 'InternalServerError')"
    }
]

Note

By default, a trigger fires only on receiving a "200 OK" response. When an expression references a trigger's status code in any way, the trigger's default behavior is replaced. So, if you want the trigger to fire based on multiple status codes, for example, status code 200 and status code 201, you must include this statement as your condition:

@or(equals(triggers().code, 200),equals(triggers().code, 201))

Triggers: Process an array with multiple runs

If your trigger returns an array for your logic app to process, sometimes a "for each" loop might take too long to process each array item. Instead, you can use the SplitOn property in your trigger to debatch the array.

Debatching splits up the array items and starts a new logic app instance that runs for each array item. This approach is useful, for example, when you want to poll an endpoint that might return multiple new items between polling intervals. For the maximum number of array items that SplitOn can process in a single logic app run, see Limits and configuration.

Note

You can add SplitOn only to triggers by manually defining or overriding in code view for your logic app's JSON definition. You can't use SplitOn when you want to implement a synchronous response pattern. Any workflow that uses SplitOn and includes a response action runs asynchronously and immediately sends a 202 ACCEPTED response.

If your trigger's Swagger file describes a payload that is an array, the SplitOn property is automatically added to your trigger. Otherwise, add this property inside the response payload that has the array you want to debatch.

For example, suppose you have an API that returns this response:

{
    "Status": "Succeeded",
    "Rows": [
        {
            "id": 938109380,
            "name": "customer-name-one"
        },
        {
            "id": 938109381,
            "name": "customer-name-two"
        }
    ]
}

Your logic app only needs the content from Rows, so you can create a trigger like this example.

"myDebatchTrigger": {
    "type": "Http",
    "recurrence": {
        "frequency": "Second",
        "interval": "1"
    },
    "inputs": {
        "uri": "https://mydomain.com/myAPI",
        "method": "GET"
    },
    "splitOn": "@triggerBody()?.Rows"
}

Note

If you use the SplitOn command, you can't get the properties that are outside the array. So for this example, you can't get the status property in the response returned from the API.

To avoid a failure if the Rows property doesn't exist, this example uses the ? operator.

Your workflow definition can now use @triggerBody().name to get customer-name-one from the first run and customer-name-two from the second run. So, your trigger outputs look like these examples:

{
    "body": {
        "id": 938109380,
        "name": "customer-name-one"
    }
}
{
    "body": {
        "id": 938109381,
        "name": "customer-name-two"
    }
}

Triggers: Fire only after all active runs finish

You can configure recurrence triggers so that they fire only when all active runs have completed. To configure this setting, set the operationOptions property to singleInstance:

"myTrigger": {
    "type": "Http",
    "inputs": { },
    "recurrence": { },
    "operationOptions": "singleInstance"
}

If a scheduled recurrence happens while a workflow instance is running, the trigger skips and waits until the next scheduled recurrence interval to check again.

Actions overview

There are many types of actions, each with unique behavior. Each action type has different inputs that define an action's behavior. Collection actions can contain many other actions within themselves.

Standard actions

Action type Description
HTTP Calls an HTTP web endpoint.
ApiConnection Works like the HTTP action, but uses Microsoft-managed APIs.
ApiConnectionWebhook Works like HTTPWebhook, but uses Microsoft-managed APIs.
Response Defines the response for an incoming call.
Compose Constructs an arbitrary object from the action's inputs.
Function Represents an Azure function.
Wait Waits a fixed amount of time or until a specific time.
Workflow Represents a nested workflow.
Compose Constructs an arbitrary object from the action's inputs.
Query Filters an array based on a condition.
Select Projects each element of an array into a new value. For example, you can convert an array of numbers into an array of objects.
Table Converts an array of items into a CSV or HTML table.
Terminate Stops running a workflow.
Wait Waits a fixed amount of time or until a specific time.
Workflow Represents a nested workflow.

Collection actions

Action type Description
If Evaluate an expression and based on the result, runs the corresponding branch.
Switch Perform different actions based on specific values of an object.
ForEach This looping action iterates through an array and performs inner actions on each array item.
Until This looping action performs inner actions until a condition results to true.
Scope Use for logically grouping other actions.

HTTP action

An HTTP action calls a specified endpoint and checks the response to determine whether the workflow should run or not. For example:

"myLatestNewsAction": {
    "type": "Http",
    "inputs": {
        "method": "GET",
        "uri": "https://mynews.example.com/latest"
    }
}

Here, the inputs object takes these parameters required for constructing an HTTP call:

Element name Required Type Description
method Yes String Uses one of these HTTP methods: "GET", "POST", "PUT", "DELETE", "PATCH", or "HEAD"
uri Yes String The HTTP or HTTPs endpoint that the trigger checks. Maximum string size: 2 KB
queries No Object Represents any query parameters that you want to include in the URL.

For example, "queries": { "api-version": "2015-02-01" } adds ?api-version=2015-02-01 to the URL.

headers No Object Represents each header that's sent in the request.

For example, to set the language and type on a request:

"headers": { "Accept-Language": "en-us", "Content-Type": "application/json" }

body No Object Represents the payload that's sent to the endpoint.
retryPolicy No Object Use this object for customizing the retry behavior for 4xx or 5xx errors. For more information, see Retry policies.
operationsOptions No String Defines the set of special behaviors to override.
authentication No Object Represents the method that the request should use for authentication. For more information, see Scheduler Outbound Authentication.

Beyond Scheduler, there is one more supported property: authority. By default, this value is https://login.windows.net when not specified, but you can use a different value, such ashttps://login.windows\-ppe.net.

HTTP actions and APIConnection actions support retry policies. A retry policy applies to intermittent failures, characterized as HTTP status codes 408, 429, and 5xx, in addition to any connectivity exceptions. You can define this policy with the retryPolicy object as shown here:

"retryPolicy": {
    "type": "<retry-policy-type>",
    "interval": <retry-interval>,
    "count": <number-of-retry-attempts>
}

This example HTTP action retries fetching the latest news two times if there are intermittent failures for a total of three executions and a 30-second delay between each attempt:

"myLatestNewsAction": {
    "type": "Http",
    "inputs": {
        "method": "GET",
        "uri": "https://mynews.example.com/latest",
        "retryPolicy": {
            "type": "fixed",
            "interval": "PT30S",
            "count": 2
        }
    }
}

The retry interval is specified in ISO 8601 format. This interval has a default and minimum value of 20 seconds, while the maximum value is one hour. The default and maximum retry count is four hours. If you don't specify a retry policy definition, a fixed strategy is used with default retry count and interval values. To disable the retry policy, set its type to None.

Asynchronous patterns

By default, all HTTP-based actions support the standard asynchronous operation pattern. So if the remote server indicates that the request is accepted for processing with a "202 ACCEPTED" response, the Logic Apps engine keeps polling the URL specified in the response's location header until reaching a terminal state, which is a non-202 response.

To disable the asynchronous behavior previously described, set operationOptions to DisableAsyncPattern in the action inputs. In this case, the action's output is based on the initial 202 response from the server. For example:

"invokeLongRunningOperationAction": {
    "type": "Http",
    "inputs": {
        "method": "POST",
        "uri": "https://host.example.com/resources"
    },
    "operationOptions": "DisableAsyncPattern"
}

Asynchronous limits

You can limit the duration for an asynchronous pattern to a specific time interval. If the time interval elapses without reaching a terminal state, the action's status is marked Cancelled with an ActionTimedOut code. The limit timeout is specified in ISO 8601 format. This example shows how you can specify limits:

"<action-name>": {
    "type": "Workflow|Webhook|Http|ApiConnectionWebhook|ApiConnection",
    "inputs": { },
    "limit": {
        "timeout": "PT10S"
    }
}

APIConnection action

This action references a Microsoft-managed connector, requiring a reference to a valid connection and information about the API and parameters. Here is an example APIConnection action:

"Send_Email": {
    "type": "ApiConnection",
    "inputs": {
        "host": {
            "api": {
                "runtimeUrl": "https://logic-apis-df.azure-apim.net/apim/office365"
            },
            "connection": {
                "name": "@parameters('$connections')['office365']['connectionId']"
            }
        },
        "method": "POST",
        "body": {
            "Subject": "New tweet from @{triggerBody()['TweetedBy']}",
            "Body": "@{triggerBody()['TweetText']}",
            "To": "me@example.com"
        },
        "path": "/Mail"
    },
    "runAfter": {}
}
Element name Required Type Description
host Yes Object Represents the connector information such as the runtimeUrl and reference to the connection object.
method Yes String Uses one of these HTTP methods: "GET", "POST", "PUT", "DELETE", "PATCH", or "HEAD"
path Yes String The path for the API operation
queries No Object Represents any query parameters that you want to include in the URL.

For example, "queries": { "api-version": "2015-02-01" } adds ?api-version=2015-02-01 to the URL.

headers No Object Represents each header that's sent in the request.

For example, to set the language and type on a request:

"headers": { "Accept-Language": "en-us", "Content-Type": "application/json" }

body No Object Represents the payload that's sent to the endpoint.
retryPolicy No Object Use this object for customizing the retry behavior for 4xx or 5xx errors. For more information, see Retry policies.
operationsOptions No String Defines the set of special behaviors to override.
authentication No Object Represents the method that the request should use for authentication. For more information, see Scheduler Outbound Authentication.

A retry policy applies to intermittent failures, characterized as HTTP status codes 408, 429, and 5xx, in addition to any connectivity exceptions. You can define this policy with the retryPolicy object as shown here:

"retryPolicy": {
    "type": "<retry-policy-type>",
    "interval": <retry-interval>,
    "count": <number-of-retry-attempts>
}

APIConnection webhook action

The APIConnectionWebhook action references a Microsoft-managed connector. This action requires a reference to a valid connection and information about the API and parameters. You can specify limits on a webhook action in the same way as HTTP Asynchronous Limits.

"Send_approval_email": {
    "type": "ApiConnectionWebhook",
    "inputs": {
        "host": {
            "api": {
                "runtimeUrl": "https://logic-apis-df.azure-apim.net/apim/office365"
            },
            "connection": {
                "name": "@parameters('$connections')['office365']['connectionId']"
            }
        },
        "body": {
            "Message": {
                "Subject": "Approval Request",
                "Options": "Approve, Reject",
                "Importance": "Normal",
                "To": "me@email.com"
            }
        },
        "path": "/approvalmail",
        "authentication": "@parameters('$authentication')"
    },
    "runAfter": {}
}
Element name Required Type Description
host Yes Object Represents the connector information such as the runtimeUrl and reference to the connection object.
path Yes String The path for the API operation
queries No Object Represents any query parameters that you want to include in the URL.

For example, "queries": { "api-version": "2015-02-01" } adds ?api-version=2015-02-01 to the URL.

headers No Object Represents each header that's sent in the request.

For example, to set the language and type on a request:

"headers": { "Accept-Language": "en-us", "Content-Type": "application/json" }

body No Object Represents the payload that's sent to the endpoint.
retryPolicy No Object Use this object for customizing the retry behavior for 4xx or 5xx errors. For more information, see Retry policies.
operationsOptions No String Defines the set of special behaviors to override.
authentication No Object Represents the method that the request should use for authentication. For more information, see Scheduler Outbound Authentication.

Response action

This action contains the entire response payload from an HTTP request and includes a statusCode, body, and headers:

"myResponseAction": {
    "type": "Response",
    "inputs": {
        "statusCode": 200,
        "body": {
            "contentFieldOne": "value100",
            "anotherField": 10.001
        },
        "headers": {
            "x-ms-date": "@utcnow()",
            "Content-type": "application/json"
        }
    },
    "runAfter": {}
}

The response action has special restrictions that don't apply to other actions, specifically:

  • You can't have response actions in parallel branches within a logic app definition because the incoming request requires a deterministic response.

  • If the workflow reaches a response action after the incoming request already received a response, the response action is considered failed or in conflict. As a result, the logic app run is marked Failed.

  • A workflow with response actions can't use the splitOn command in the trigger definition because the call creates multiple runs. As a result, check for this case when the workflow operation is PUT, and return a "bad request" response.

Compose action

This action lets you construct an arbitrary object, and the output is the result from evaluating the action's inputs.

Note

You can use the Compose action for constructing any output, including objects, arrays, and any other type natively supported by logic apps like XML and binary.

For example, you can use the Compose action for merging outputs from multiple actions:

"composeUserRecordAction": {
    "type": "Compose",
    "inputs": {
        "firstName": "@actions('getUser').firstName",
        "alias": "@actions('getUser').alias",
        "thumbnailLink": "@actions('lookupThumbnail').url"
    }
}

Function action

This action lets you represent and call an Azure function, for example:

"<my-Azure-Function-name>": {
   "type": "Function",
    "inputs": {
        "function": {
            "id": "/subscriptions/<Azure-subscription-ID>/resourceGroups/<Azure-resource-group-name>/providers/Microsoft.Web/sites/<your-Azure-function-app-name>/functions/<your-Azure-function-name>"
        },
        "queries": {
            "extrafield": "specialValue"
        },
        "headers": {
            "x-ms-date": "@utcnow()"
        },
        "method": "POST",
        "body": {
            "contentFieldOne": "value100",
            "anotherField": 10.001
        }
    },
    "runAfter": {}
}
Element name Required Type Description
function id Yes String The resource ID for the Azure function that you want to call.
method No String The HTTP method used to call the function. If not specified, "POST" is the default method.
queries No Object Represents any query parameters that you want to include in the URL.

For example, "queries": { "api-version": "2015-02-01" } adds ?api-version=2015-02-01 to the URL.

headers No Object Represents each header that's sent in the request.

For example, to set the language and type on a request:

"headers": { "Accept-Language": "en-us", "Content-Type": "application/json" }

body No Object Represents the payload that's sent to the endpoint.

When you save your logic app, the Logic Apps engine performs some checks on the referenced function:

  • You must have access to the function.
  • You can use only a standard HTTP trigger or generic JSON Webhook trigger.
  • The function shouldn't have any route defined.
  • Only "function" and "anonymous" authorization levels are allowed.

Note

The Logic Apps engine retrieves and caches the trigger URL, which is used at runtime. So if any operation invalidates the cached URL, the action fails at runtime. To work around this issue, save the logic app again, which causes the logic app to retrieve and cache the trigger URL again.

Select action

This action lets you project each element of an array into a new value. This example converts an array of numbers into an array of objects:

"selectNumbersAction": {
    "type": "Select",
    "inputs": {
        "from": [ 1, 3, 0, 5, 4, 2 ],
        "select": { "number": "@item()" }
    }
}
Name Required Type Description
from Yes Array The source array
select Yes Any The projection applied to each element in the source array

The output from the select action is an array that has the same cardinality as the input array. Each element is transformed as defined by the select property. If the input is an empty array, the output is also an empty array.

Terminate action

This action stops a workflow run, canceling any actions in progress, and skipping any remaining actions. The terminate action doesn't affect already completed actions.

For example, to stop a run that has Failed status:

"HandleUnexpectedResponse": {
    "type": "Terminate",
    "inputs": {
        "runStatus": "Failed",
        "runError": {
            "code": "UnexpectedResponse",
            "message": "Received an unexpected response",
        }
    }
}
Name Required Type Description
runStatus Yes String The target run's status, which is either Failed or Cancelled
runError No Object The error details. Supported only when runStatus is set to Failed.
runError code No String The run's error code
runError message No String The run's error message

Query action

This action lets you filter an array based on a condition.

Note

You can't use the Compose action to construct any output, including objects, arrays, and any other type natively supported by logic apps like XML and binary.

For example, to select numbers greater than two:

"filterNumbersAction": {
    "type": "Query",
    "inputs": {
        "from": [ 1, 3, 0, 5, 4, 2 ],
        "where": "@greater(item(), 2)"
    }
}
Name Required Type Description
from Yes Array The source array
where Yes String The condition that's applied to each element from the source array. If no values satisfy the where condition, the result is an empty array.

The output from the query action is an array that has elements from the input array that satisfy the condition.

Table action

This action lets you convert an array into a CSV or HTML table.

"ConvertToTable": {
    "type": "Table",
    "inputs": {
        "from": "<source-array>",
        "format": "CSV | HTML"
    }
}
Name Required Type Description
from Yes Array The source array. If the from property value is an empty array, the output is an empty table.
format Yes String The table format that you want, either "CSV" or "HTML"
columns No Array The table columns that you want. Use to override the default table shape.
column header No String The column header
column value Yes String The column value

Suppose you define a table action like this example:

"convertToTableAction": {
    "type": "Table",
    "inputs": {
        "from": "@triggerBody()",
        "format": "HTML"
    }
}

And use this array for @triggerBody():

[ {"ID": 0, "Name": "apples"},{"ID": 1, "Name": "oranges"} ]

Here is the output from this example:

IDName
0apples
1oranges

To customize this table, you can specify the columns explicitly, for example:

"ConvertToTableAction": {
    "type": "Table",
    "inputs": {
        "from": "@triggerBody()",
        "format": "html",
        "columns": [
            {
                "header": "Produce ID",
                "value": "@item().id"
            },
            {
              "header": "Description",
              "value": "@concat('fresh ', item().name)"
            }
        ]
    }
}

Here is the output from this example:

Produce IDDescription
0fresh apples
1fresh oranges

Wait action

This action suspends workflow execution for the specified interval. This example causes the workflow to wait 15 minutes:

"waitForFifteenMinutesAction": {
    "type": "Wait",
    "inputs": {
        "interval": {
            "unit": "minute",
            "count": 15
        }
    }
}

Alternatively, to wait until a specific moment in time, you can use this example:

"waitUntilOctoberAction": {
    "type": "Wait",
    "inputs": {
        "until": {
            "timestamp": "2017-10-01T00:00:00Z"
        }
    }
}

Note

You can specify the wait duration with either the interval object or the until object, but not both.

Element name Required Type Description
until No Object The wait duration based on a point in time
until timestamp Yes String The point in time in UTC date time format when the wait expires
interval No Object The wait duration based on the interval unit and count
interval unit Yes String The unit of time. Use only one of these values: "second", "minute", "hour", "day", "week", or "month"
interval count Yes Integer A positive integer representing the number of interval units used for the wait duration

Workflow action

This action lets you nest a workflow. The Logic Apps engine performs an access check on the child workflow, more specifically, the trigger, so you must have access to the child workflow. For example:

"<my-nested-workflow-action-name>": {
    "type": "Workflow",
    "inputs": {
        "host": {
            "id": "/subscriptions/<my-subscription-ID>/resourceGroups/<my-resource-group-name>/providers/Microsoft.Logic/<my-nested-workflow-action-name>",
            "triggerName": "mytrigger001"
        },
        "queries": {
            "extrafield": "specialValue"
        },
        "headers": {
            "x-ms-date": "@utcnow()",
            "Content-type": "application/json"
        },
        "body": {
            "contentFieldOne": "value100",
            "anotherField": 10.001
        }
    },
    "runAfter": {}
}
Element name Required Type Description
host id Yes String The resource ID for the workflow that you want to call
host triggerName Yes String The name of the trigger that you want to invoke
queries No Object Represents any query parameters that you want to include in the URL.

For example, "queries": { "api-version": "2015-02-01" } adds ?api-version=2015-02-01 to the URL.

headers No Object Represents each header that's sent in the request.

For example, to set the language and type on a request:

"headers": { "Accept-Language": "en-us", "Content-Type": "application/json" }

body No Object Represents the payload that is sent to the endpoint.

This action's outputs are based on what you define in the Response action for the child workflow. If the child workflow doesn't define a Response action, the outputs are empty.

Collection actions overview

To help you control workflow execution, collection actions can include other actions. You can directly refer to referencing actions in a collection outside of the collection. For example, if you define an Http action in a scope, then @body('http') is still valid anywhere in a workflow. Also, actions in a collection can only "run after" other actions in the same collection.

If action

This action, which is a conditional statement, lets you evaluate a condition and execute a branch based on whether the expression evaluates as true. If the condition evaluates successfully as true, the condition is marked "Succeeded". Actions that are in the actions or else objects evaluate to these values:

  • "Succeeded" when they run and succeed
  • "Failed" when they run and fail
  • "Skipped" when the respective branch doesn't run

Learn more about conditional statements in logic apps.

"<my-condition-name>": {
  "type": "If",
  "expression": "<condition>",
  "actions": {
    "if-true-run-this-action": {
      "type": <action-type>,
      "inputs": {},
      "runAfter": {}
    }
  },
  "else": {
    "actions": {
        "if-false-run-this-action": {
            "type": <action-type>,
            "inputs": {},
            "runAfter": {}
        }
    }
  },
  "runAfter": {}
}
Name Required Type Description
actions Yes Object The inner actions to run when expression evaluates to true
expression Yes String The expression to evaluate
else No Object The inner actions to run when expression evaluates to false

For example:

"myCondition": {
    "type": "If",
    "actions": {
        "if-true-check-this-website": {
            "type": "Http",
            "inputs": {
                "method": "GET",
                "uri": "http://this-url"
            },
            "runAfter": {}
        }
    },
    "else": {
        "actions": {
            "if-false-check-this-other-website": {
                "type": "Http",
                "inputs": {
                    "method": "GET",
                    "uri": "http://this-other-url"
                },
                "runAfter": {}
            }
        }
    }
}

How conditions can use expressions in actions

Here are some examples that show how you can use expressions in conditions:

JSON expression Result
"expression": "@parameters('hasSpecialAction')" Any value that evaluates as true causes this condition to pass. Supports only Boolean expressions. To convert other types to Boolean, use these functions: empty or equals
"expression": "@greater(actions('action1').output.value, parameters('threshold'))" Supports comparison functions. For this example, the action runs only when the output of action1 is greater than the threshold value.
"expression": "@or(greater(actions('action1').output.value, parameters('threshold')), less(actions('action1').output.value, 100))" Supports logic functions for creating nested Boolean expressions. In this example, the action runs when the output of action1 is more than the threshold or under 100.
"expression": "@equals(length(actions('action1').outputs.errors), 0))" To check whether an array has any items, you can use array functions. In this example, the action runs when the errors array is empty.
"expression": "parameters('hasSpecialAction')" This expression causes an error and isn't a valid condition. Conditions must use the "@" symbol.

Switch action

This action, which is a switch statement, performs different actions based on specific values of an object, expression, or token. This action evaluates the object, expression, or token, chooses the case that matches the result, and runs actions for only that case. When no case matches the result, the default action runs. When the switch statement runs, only one case should match the result. Learn more about switch statements in logic apps.

"<my-switch-statement-name>": {
   "type": "Switch",
   "expression": "<evaluate-this-object-expression-token>",
   "cases": {
      "myCase1" : {
         "actions" : {
           "myAction1": {}
         },
         "case": "<result1>"
      },
      "myCase2": {
         "actions" : {
           "myAction2": {}
         },
         "case": "<result2>"
      }
   },
   "default": {
      "actions": {
          "myDefaultAction": {}
      }
   },
   "runAfter": {}
}
Name Required Type Description
expression Yes String The object, expression, or token to evaluate
cases Yes Object Contains the sets of inner actions that run based on the expression result.
case Yes String The value to match with the result
actions Yes Object The inner actions that run for the case matching the expression result
default No Object The inner actions that run when no cases match the result

For example:

"myApprovalEmailAction": {
   "type": "Switch",
   "expression": "@body('Send_approval_email')?['SelectedOption']",
   "cases": {
      "Case": {
         "actions" : {
           "Send_an_email": {...}
         },
         "case": "Approve"
      },
      "Case_2": {
         "actions" : {
           "Send_an_email_2": {...}
         },
         "case": "Reject"
      }
   },
   "default": {
      "actions": {}
   },
   "runAfter": {
      "Send_approval_email": [
         "Succeeded"
      ]
   }
}

Foreach action

This looping action iterates through an array and performs inner actions on each array item. By default, the Foreach loop runs in parallel. For the maximum number of parallel cycles that "for each" loops can run, see Limits and config. To run each cycle sequentially, set the operationOptions parameter to Sequential. Learn more about Foreach loops in logic apps.

"<my-forEach-loop-name>": {
    "type": "Foreach",
    "actions": {
        "myInnerAction1": {
            "type": "<action-type>",
            "inputs": {}
        },
        "myInnerAction2": {
            "type": "<action-type>",
            "inputs": {}
        }
    },
    "foreach": "<array>",
    "runAfter": {}
}
Name Required Type Description
actions Yes Object The inner actions to run inside the loop
foreach Yes String The array to iterate through
operationOptions No String Specifies any operation options for customizing behavior. Currently supports only Sequential for sequentially running iterations where the default behavior is parallel.

For example:

"forEach_EmailAction": {
    "type": "Foreach",
    "foreach": "@body('email_filter')",
    "actions": {
        "Send_email": {
            "type": "ApiConnection",
            "inputs": {
                "body": {
                    "to": "@item()",
                    "from": "me@contoso.com",
                    "message": "Hello, thank you for ordering"
                },
                "host": {
                    "connection": {
                        "id": "@parameters('$connections')['office365']['connection']['id']"
                    }
                }
            }
        }
    },
    "foreach": "@body('email_filter')",
    "runAfter": {
        "email_filter": [ "Succeeded" ]
    }
}

Until action

This looping action runs inner actions until a condition evaluates as true. Learn more about "until" loops in logic apps.

 "<my-Until-loop-name>": {
    "type": "Until",
    "actions": {
        "myActionName": {
            "type": "<action-type>",
            "inputs": {},
            "runAfter": {}
        }
    },
    "expression": "<myCondition>",
    "limit": {
        "count": 1000,
        "timeout": "PT1H"
    },
    "runAfter": {}
}
Name Required Type Description
actions Yes Object The inner actions to run inside the loop
expression Yes String The expression to evaluate after each iteration
limit Yes Object The limits for the loop. Must define at least one limit.
count No Integer The limit on the number of iterations to perform
timeout No String The timeout limit in ISO 8601 format that specifies how long the loop should run

For example:

 "runUntilSucceededAction": {
    "type": "Until",
    "actions": {
        "Http": {
            "type": "Http",
            "inputs": {
                "method": "GET",
                "uri": "http://myurl"
            },
            "runAfter": {}
        }
    },
    "expression": "@equals(outputs('Http')['statusCode', 200)",
    "limit": {
        "count": 100,
        "timeout": "PT1H"
    },
    "runAfter": {}
}

Scope action

This action lets you logically group actions in a workflow. The scope also gets its own status after all the actions in that scope finish running. Learn more about scopes.

"<my-scope-action-name>": {
    "type": "Scope",
    "actions": {
        "myInnerAction1": {
            "type": "<action-type>",
            "inputs": {}
        },
        "myInnerAction2": {
            "type": "<action-type>",
            "inputs": {}
        }
    }
}
Name Required Type Description
actions Yes Object The inner actions to run inside the scope

Next steps
