Azure SQL Database and Azure SQL Data Warehouse IP firewall rules

Note

This article applies to Azure SQL servers, and to both Azure SQL Database and Azure SQL Data Warehouse databases on an Azure SQL server. For simplicity, SQL Database is used to refer to both SQL Database and SQL Data Warehouse.

Important

This article does not apply to Azure SQL Database Managed Instance. For information about network configuration, see Connect your application to Azure SQL Database Managed Instance.

When you create a new Azure SQL server named mysqlserver, for example, the SQL Database firewall blocks all access to the public endpoint for the server (which is accessible at mysqlserver.database.windows.net).

Important

SQL Data Warehouse only supports server-level IP firewall rules. It doesn't support database-level IP firewall rules.

How the firewall works

Connection attempts from the internet and Azure must pass through the firewall before they reach your SQL server or SQL database, as the following diagram shows.

Firewall configuration diagram

Server-level IP firewall rules

These rules enable clients to access your entire Azure SQL server, that is, all the databases within the same SQL Database server. The rules are stored in the master database. You can have a maximum of 128 server-level IP firewall rules for an Azure SQL Server.

You can configure server-level IP firewall rules by using the Azure portal, PowerShell, or Transact-SQL statements.

  • To use the portal or PowerShell, you must be the subscription owner or a subscription contributor.
  • To use Transact-SQL, you must connect to the SQL Database instance as the server-level principal login or as the Azure Active Directory administrator. (A server-level IP firewall rule must first be created by a user who has Azure-level permissions.)

Database-level IP firewall rules

These rules enable clients to access certain (secure) databases within the same SQL Database server. You create the rules for each database (including the master database), and they're stored in the individual database.

You can only create and manage database-level IP firewall rules for master and user databases by using Transact-SQL statements and only after you configure the first server-level firewall.

If you specify an IP address range in the database-level IP firewall rule that's outside the range in the server-level IP firewall rule, only those clients that have IP addresses in the database-level range can access the database.

You can have a maximum of 128 database-level IP firewall rules for a database. For more information about configuring database-level IP firewall rules, see the example later in this article and see sp_set_database_firewall_rule (Azure SQL Database).

Recommendations for how to set firewall rules

We recommend that you use database-level IP firewall rules whenever possible. This practice enhances security and makes your database more portable. Use server-level IP firewall rules for administrators. Also use them when you have many databases that have the same access requirements, and you don't want to configure each database individually.

Note

For information about portable databases in the context of business continuity, see Authentication requirements for disaster recovery.

Server-level versus database-level IP firewall rules

Should users of one database be fully isolated from another database?

If yes, use database-level IP firewall rules to grant access. This method avoids using server-level IP firewall rules, which permit access through the firewall to all databases. That would reduce the depth of your defenses.

Do users at the IP addresses need access to all databases?

If yes, use server-level IP firewall rules to reduce the number of times that you have to configure IP firewall rules.

Does the person or team who configures the IP firewall rules only have access through the Azure portal, PowerShell, or the REST API?

If so, you must use server-level IP firewall rules. Database-level IP firewall rules can only be configured through Transact-SQL.

Is the person or team who configures the IP firewall rules prohibited from having high-level permission at the database level?

If so, use server-level IP firewall rules. You need at least CONTROL DATABASE permission at the database level to configure database-level IP firewall rules through Transact-SQL.

Does the person or team who configures or audits the IP firewall rules centrally manage IP firewall rules for many (perhaps hundreds) of databases?

In this scenario, best practices are determined by your needs and environment. Server-level IP firewall rules might be easier to configure, but scripting can configure rules at the database-level. And even if you use server-level IP firewall rules, you might need to audit database-level IP firewall rules to see if users with CONTROL permission on the database create database-level IP firewall rules.

Can I use a mix of server-level and database-level IP firewall rules?

Yes. Some users, such as administrators, might need server-level IP firewall rules. Other users, such as users of a database application, might need database-level IP firewall rules.

Connections from the internet

When a computer tries to connect to your database server from the internet, the firewall first checks the originating IP address of the request against the database-level IP firewall rules for the database that the connection requests.

  • If the address is within a range that's specified in the database-level IP firewall rules, the connection is granted to the SQL database that contains the rule.
  • If the address isn't within a range in the database-level IP firewall rules, the firewall checks the server-level IP firewall rules. If the address is within a range that's in the server-level IP firewall rules, the connection is granted. Server-level IP firewall rules apply to all SQL databases on the Azure SQL server.
  • If the address isn't within a range that's in any of the database-level or server-level IP firewall rules, the connection request fails.

Note

To access SQL Database from your local computer, ensure that the firewall on your network and local computer allow outgoing communication on TCP port 1433.

Connections from inside Azure

To allow applications hosted inside Azure to connect to your SQL server, Azure connections must be enabled. When an application from Azure tries to connect to your database server, the firewall verifies that Azure connections are allowed. A firewall setting that has starting and ending IP addresses equal to 0.0.0.0 indicates that Azure connections are allowed. If the connection isn't allowed, the request doesn't reach the SQL Database server.

Important

This option configures the firewall to allow all connections from Azure, including connections from the subscriptions of other customers. If you select this option, make sure that your login and user permissions limit access to authorized users only.

Create and manage IP firewall rules

You create the first server-level firewall setting by using the Azure portal or programmatically by using Azure PowerShell, Azure CLI, or an Azure REST API. You create and manage additional server-level IP firewall rules by using these methods or Transact-SQL.

Important

Database-level IP firewall rules can only be created and managed by using Transact-SQL.

To improve performance, server-level IP firewall rules are temporarily cached at the database level. To refresh the cache, see DBCC FLUSHAUTHCACHE.

Tip

You can use SQL Database Auditing to audit server-level and database-level firewall changes.

Use the Azure portal to manage server-level IP firewall rules

To set a server-level IP firewall rule in the Azure portal, go to the overview page for your Azure SQL database or your SQL Database server.

Tip

For a tutorial, see Create a DB using the Azure portal.

From the database overview page

  1. To set a server-level IP firewall rule from the database overview page, select Set server firewall on the toolbar, as the following image shows. The Firewall settings page for the SQL Database server opens.

    Server IP firewall rule

  2. Select Add client IP on the toolbar to add the IP address of the computer that you're using, and then select Save. A server-level IP firewall rule is created for your current IP address.

    Set server-level IP firewall rule

From the server overview page

The overview page for your server opens. It shows the fully qualified server name (such as mynewserver20170403.database.windows.net) and provides options for further configuration.

  1. To set a server-level rule from this page, select Firewall from the Settings menu on the left side.

  2. Select Add client IP on the toolbar to add the IP address of the computer that you're using, and then select Save. A server-level IP firewall rule is created for your current IP address.

Use Transact-SQL to manage IP firewall rules

Catalog view or stored procedure Level Description
sys.firewall_rules Server Displays the current server-level IP firewall rules
sp_set_firewall_rule Server Creates or updates server-level IP firewall rules
sp_delete_firewall_rule Server Removes server-level IP firewall rules
sys.database_firewall_rules Database Displays the current database-level IP firewall rules
sp_set_database_firewall_rule Database Creates or updates the database-level IP firewall rules
sp_delete_database_firewall_rule Databases Removes database-level IP firewall rules

The following example reviews the existing rules, enables a range of IP addresses on the server Contoso, and deletes an IP firewall rule:

SELECT * FROM sys.firewall_rules ORDER BY name;

Next, add a server-level IP firewall rule.

EXECUTE sp_set_firewall_rule @name = N'ContosoFirewallRule',
   @start_ip_address = '192.168.1.1', @end_ip_address = '192.168.1.10'

To delete a server-level IP firewall rule, execute the sp_delete_firewall_rule stored procedure. The following example deletes the rule ContosoFirewallRule:

EXECUTE sp_delete_firewall_rule @name = N'ContosoFirewallRule'

Use PowerShell to manage server-level IP firewall rules

Note

This article has been updated to use the new Azure PowerShell Az module. You can still use the AzureRM module, which will continue to receive bug fixes until at least December 2020. To learn more about the new Az module and AzureRM compatibility, see Introducing the new Azure PowerShell Az module. For Az module installation instructions, see Install Azure PowerShell.

Important

The PowerShell Azure Resource Manager module is still supported by Azure SQL Database, but all development is now for the Az.Sql module. For these cmdlets, see AzureRM.Sql. The arguments for the commands in the Az and AzureRm modules are substantially identical.

Cmdlet Level Description
Get-AzSqlServerFirewallRule Server Returns the current server-level firewall rules
New-AzSqlServerFirewallRule Server Creates a new server-level firewall rule
Set-AzSqlServerFirewallRule Server Updates the properties of an existing server-level firewall rule
Remove-AzSqlServerFirewallRule Server Removes server-level firewall rules

The following example uses PowerShell to set a server-level IP firewall rule:

New-AzSqlServerFirewallRule -ResourceGroupName "myResourceGroup" `
    -ServerName $servername `
    -FirewallRuleName "AllowSome" -StartIpAddress "0.0.0.0" -EndIpAddress "0.0.0.0"

Use CLI to manage server-level IP firewall rules

Cmdlet Level Description
az sql server firewall-rule create Server Creates a server IP firewall rule
az sql server firewall-rule list Server Lists the IP firewall rules on a server
az sql server firewall-rule show Server Shows the detail of an IP firewall rule
az sql server firewall-rule update Server Updates an IP firewall rule
az sql server firewall-rule delete Server Deletes an IP firewall rule

The following example uses CLI to set a server-level IP firewall rule:

az sql server firewall-rule create --resource-group myResourceGroup --server $servername \
-n AllowYourIp --start-ip-address 0.0.0.0 --end-ip-address 0.0.0.0

Use a REST API to manage server-level IP firewall rules

API Level Description
List firewall rules Server Displays the current server-level IP firewall rules
Create or update firewall rules Server Creates or updates server-level IP firewall rules
Delete firewall rules Server Removes server-level IP firewall rules
Get firewall rules Server Gets server-level IP firewall rules

Troubleshoot the database firewall

Consider the following points when access to the SQL Database service doesn't behave as you expect.

  • Local firewall configuration:

    Before your computer can access SQL Database, you may need to create a firewall exception on your computer for TCP port 1433. To make connections inside the Azure cloud boundary, you may have to open additional ports. For more information, see the "SQL Database: Outside vs inside" section of Ports beyond 1433 for ADO.NET 4.5 and SQL Database.

  • Network address translation:

    Because of network address translation (NAT), the IP address that's used by your computer to connect to SQL Database may be different than the IP address in your computer's IP configuration settings. To view the IP address that your computer is using to connect to Azure:

    1. Sign in to the portal.
    2. Go to the Configure tab on the server that hosts your database.
    3. The Current Client IP Address is displayed in the Allowed IP Addresses section. Select Add for Allowed IP Addresses to allow this computer to access the server.
  • Changes to the allow list haven't taken effect yet:

    There may be up to a five-minute delay for changes to the SQL Database firewall configuration to take effect.

  • The login isn't authorized, or an incorrect password was used:

    If a login doesn't have permissions on the SQL Database server or the password is incorrect, the connection to the server is denied. Creating a firewall setting only gives clients an opportunity to try to connect to your server. The client must still provide the necessary security credentials. For more information about preparing logins, see Controlling and granting database access to SQL Database and SQL Data Warehouse.

  • Dynamic IP address:

    If you have an internet connection that uses dynamic IP addressing and you have trouble getting through the firewall, try one of the following solutions:

    • Ask your internet service provider for the IP address range that's assigned to your client computers that access the SQL Database server. Add that IP address range as an IP firewall rule.
    • Get static IP addressing instead for your client computers. Add the IP addresses as IP firewall rules.
