Kubernetes core concepts for Azure Kubernetes Service (AKS)

As application development moves towards a container-based approach, the need to orchestrate and manage resources is important. Kubernetes is the leading platform that provides the ability to provide reliable scheduling of fault-tolerant application workloads. Azure Kubernetes Service (AKS) is a managed Kubernetes offering that further simplifies container-based application deployment and management.

This article introduces the core Kubernetes infrastructure components such as the control plane, nodes, and node pools. Workload resources such as pods, deployments, and sets are also introduced, along with how to group resources into namespaces.

What is Kubernetes?

Kubernetes is a rapidly evolving platform that manages container-based applications and their associated networking and storage components. The focus is on the application workloads, not the underlying infrastructure components. Kubernetes provides a declarative approach to deployments, backed by a robust set of APIs for management operations.

You can build and run modern, portable, microservices-based applications that benefit from Kubernetes orchestrating and managing the availability of those application components. Kubernetes supports both stateless and stateful applications as teams progress through the adoption of microservices-based applications.

As an open platform, Kubernetes allows you to build your applications with your preferred programming language, OS, libraries, or messaging bus. Existing continuous integration and continuous delivery (CI/CD) tools can integrate with Kubernetes to schedule and deploy releases.

Azure Kubernetes Service (AKS) provides a managed Kubernetes service that reduces the complexity for deployment and core management tasks, including coordinating upgrades. The AKS control plane is managed by the Azure platform, and you only pay for the AKS nodes that run your applications. AKS is built on top of the open-source Azure Kubernetes Service Engine (aks-engine).

Kubernetes cluster architecture

A Kubernetes cluster is divided into two components:

  • Control plane nodes provide the core Kubernetes services and orchestration of application workloads.
  • Nodes run your application workloads.

Kubernetes control plane and node components

Control plane

When you create an AKS cluster, a control plane is automatically created and configured. This control plane is provided as a managed Azure resource abstracted from the user. There's no cost for the control plane, only the nodes that are part of the AKS cluster.

The control plane includes the following core Kubernetes components:

  • kube-apiserver - The API server is how the underlying Kubernetes APIs are exposed. This component provides the interaction for management tools, such as kubectl or the Kubernetes dashboard.
  • etcd - To maintain the state of your Kubernetes cluster and configuration, the highly available etcd is a key value store within Kubernetes.
  • kube-scheduler - When you create or scale applications, the Scheduler determines what nodes can run the workload and starts them.
  • kube-controller-manager - The Controller Manager oversees a number of smaller Controllers that perform actions such as replicating pods and handling node operations.

AKS provides a single-tenant control plane, with a dedicated API server, Scheduler, etc. You define the number and size of the nodes, and the Azure platform configures the secure communication between the control plane and nodes. Interaction with the control plane occurs through Kubernetes APIs, such as kubectl or the Kubernetes dashboard.

This managed control plane means that you don't need to configure components like a highly available etcd store, but it also means that you can't access the control plane directly. Upgrades to Kubernetes are orchestrated through the Azure CLI or Azure portal, which upgrades the control plane and then the nodes. To troubleshoot possible issues, you can review the control plane logs through Azure Monitor logs.

If you need to configure the control plane in a particular way or need direct access to it, you can deploy your own Kubernetes cluster using aks-engine.

For associated best practices, see Best practices for cluster security and upgrades in AKS.

Nodes and node pools

To run your applications and supporting services, you need a Kubernetes node. An AKS cluster has one or more nodes, which is an Azure virtual machine (VM) that runs the Kubernetes node components and container runtime:

  • The kubelet is the Kubernetes agent that processes the orchestration requests from the control plane and scheduling of running the requested containers.
  • Virtual networking is handled by the kube-proxy on each node. The proxy routes network traffic and manages IP addressing for services and pods.
  • The container runtime is the component that allows containerized applications to run and interact with additional resources such as the virtual network and storage. In AKS, Moby is used as the container runtime.

Azure virtual machine and supporting resources for a Kubernetes node

The Azure VM size for your nodes defines how many CPUs, how much memory, and the size and type of storage available (such as high-performance SSD or regular HDD). If you anticipate a need for applications that require large amounts of CPU and memory or high-performance storage, plan the node size accordingly. You can also scale up the number of nodes in your AKS cluster to meet demand.

In AKS, the VM image for the nodes in your cluster is currently based on Ubuntu Linux or Windows Server 2019. When you create an AKS cluster or scale up the number of nodes, the Azure platform creates the requested number of VMs and configures them. There's no manual configuration for you to perform. Agent nodes are billed as standard virtual machines, so any discounts you have on the VM size you're using (including Azure reservations) are automatically applied.

If you need to use a different host OS, container runtime, or include custom packages, you can deploy your own Kubernetes cluster using aks-engine. The upstream aks-engine releases features and provides configuration options before they are officially supported in AKS clusters. For example, if you wish to use a container runtime other than Moby, you can use aks-engine to configure and deploy a Kubernetes cluster that meets your current needs.

Resource reservations

Node resources are utilized by AKS to make the node function as part of your cluster. This can create a discrepancy between your node's total resources and the resources allocatable when used in AKS. This is important to note when setting requests and limits for user deployed pods.

To find a node's allocatable resources run:

kubectl describe node [NODE_NAME]

To maintain node performance and functionality, resources are reserved on each node by AKS. As a node grows larger in resources, the resource reservation grows due to a higher amount of user deployed pods needing management.

Note

Using AKS add-ons such as Container Insights (OMS) will consume additional node resources.

  • CPU - reserved CPU is dependent on node type and cluster configuration which may cause less allocatable CPU due to running additional features
CPU cores on host 1 2 4 8 16 32 64
Kube-reserved (millicores) 60 100 140 180 260 420 740
  • Memory - reserved memory includes the sum of two values
  1. The kubelet daemon is installed on all Kubernetes agent nodes to manage container creation and termination. By default on AKS, this daemon has the following eviction rule: memory.available<750Mi, which means a node must always have at least 750 Mi allocatable at all times. When a host is below that threshold of available memory, the kubelet will terminate one of the running pods to free memory on the host machine and protect it.

  2. The second value is a progressive rate of memory reserved for the kubelet daemon to properly function (kube-reserved).

    • 25% of the first 4 GB of memory
    • 20% of the next 4 GB of memory (up to 8 GB)
    • 10% of the next 8 GB of memory (up to 16 GB)
    • 6% of the next 112 GB of memory (up to 128 GB)
    • 2% of any memory above 128 GB

As a result of these two defined rules imposed to keep Kubernetes and agent nodes healthy, the amount of allocatable CPU and memory will appear less than the node itself could offer. The resource reservations defined above cannot be changed.

For example, if a node offers 7 GB, it will report 34% of memory not allocatable:

750Mi + (0.25*4) + (0.20*3) = 0.786GB + 1 GB + 0.6GB = 2.386GB / 7GB = 34% reserved

In addition to reservations for Kubernetes, the underlying node OS also reserves an amount of CPU and memory resources to maintain OS functions.

For associated best practices, see Best practices for basic scheduler features in AKS.

Node pools

Nodes of the same configuration are grouped together into node pools. A Kubernetes cluster contains one or more node pools. The initial number of nodes and size are defined when you create an AKS cluster, which creates a default node pool. This default node pool in AKS contains the underlying VMs that run your agent nodes.

Note

To ensure your cluster to operate reliably, you should run at least 2 (two) nodes in the default node pool.

When you scale or upgrade an AKS cluster, the action is performed against the default node pool. You can also choose to scale or upgrade a specific node pool. For upgrade operations, running containers are scheduled on other nodes in the node pool until all the nodes are successfully upgraded.

For more information about how to use multiple node pools in AKS, see Create and manage multiple node pools for a cluster in AKS.

Node selectors

In an AKS cluster that contains multiple node pools, you may need to tell the Kubernetes Scheduler which node pool to use for a given resource. For example, ingress controllers shouldn't run on Windows Server nodes (currently in preview in AKS). Node selectors let you define various parameters, such as the node OS, to control where a pod should be scheduled.

The following basic example schedules an NGINX instance on a Linux node using the node selector "beta.kubernetes.io/os": linux:

kind: Pod
apiVersion: v1
metadata:
  name: nginx
spec:
  containers:
    - name: myfrontend
      image: nginx:1.15.12
  nodeSelector:
    "beta.kubernetes.io/os": linux

For more information on how to control where pods are scheduled, see Best practices for advanced scheduler features in AKS.

Pods

Kubernetes uses pods to run an instance of your application. A pod represents a single instance of your application. Pods typically have a 1:1 mapping with a container, although there are advanced scenarios where a pod may contain multiple containers. These multi-container pods are scheduled together on the same node, and allow containers to share related resources.

When you create a pod, you can define resource requests to request a certain amount of CPU or memory resources. The Kubernetes Scheduler tries to schedule the pods to run on a node with available resources to meet the request. You can also specify maximum resource limits that prevent a given pod from consuming too much compute resource from the underlying node. A best practice is to include resource limits for all pods to help the Kubernetes Scheduler understand which resources are needed and permitted.

For more information, see Kubernetes pods and Kubernetes pod lifecycle.

A pod is a logical resource, but the container(s) are where the application workloads run. Pods are typically ephemeral, disposable resources, and individually scheduled pods miss some of the high availability and redundancy features Kubernetes provides. Instead, pods are usually deployed and managed by Kubernetes Controllers, such as the Deployment Controller.

Deployments and YAML manifests

A deployment represents one or more identical pods, managed by the Kubernetes Deployment Controller. A deployment defines the number of replicas (pods) to create, and the Kubernetes Scheduler ensures that if pods or nodes encounter problems, additional pods are scheduled on healthy nodes.

You can update deployments to change the configuration of pods, container image used, or attached storage. The Deployment Controller drains and terminates a given number of replicas, creates replicas from the new deployment definition, and continues the process until all replicas in the deployment are updated.

Most stateless applications in AKS should use the deployment model rather than scheduling individual pods. Kubernetes can monitor the health and status of deployments to ensure that the required number of replicas run within the cluster. When you only schedule individual pods, the pods aren't restarted if they encounter a problem, and aren't rescheduled on healthy nodes if their current node encounters a problem.

If an application requires a quorum of instances to always be available for management decisions to be made, you don't want an update process to disrupt that ability. Pod Disruption Budgets can be used to define how many replicas in a deployment can be taken down during an update or node upgrade. For example, if you have 5 replicas in your deployment, you can define a pod disruption of 4 to only permit one replica from being deleted/rescheduled at a time. As with pod resource limits, a best practice is to define pod disruption budgets on applications that require a minimum number of replicas to always be present.

Deployments are typically created and managed with kubectl create or kubectl apply. To create a deployment, you define a manifest file in the YAML (YAML Ain't Markup Language) format. The following example creates a basic deployment of the NGINX web server. The deployment specifies 3 replicas to be created, and that port 80 be open on the container. Resource requests and limits are also defined for CPU and memory.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx:1.15.2
        ports:
        - containerPort: 80
        resources:
          requests:
            cpu: 250m
            memory: 64Mi
          limits:
            cpu: 500m
            memory: 256Mi

More complex applications can be created by also including services such as load balancers within the YAML manifest.

For more information, see Kubernetes deployments.

Package management with Helm

A common approach to managing applications in Kubernetes is with Helm. You can build and use existing public Helm charts that contain a packaged version of application code and Kubernetes YAML manifests to deploy resources. These Helm charts can be stored locally, or often in a remote repository, such as an Azure Container Registry Helm chart repo.

To use Helm, a server component called Tiller is installed in your Kubernetes cluster. The Tiller manages the installation of charts within the cluster. The Helm client itself is installed locally on your computer, or can be used within the Azure Cloud Shell. You can search for or create Helm charts with the client, and then install them to your Kubernetes cluster.

Helm includes a client component and a server-side Tiller component that creates resources inside the Kubernetes cluster

For more information, see Install applications with Helm in Azure Kubernetes Service (AKS).

StatefulSets and DaemonSets

The Deployment Controller uses the Kubernetes Scheduler to run a given number of replicas on any available node with available resources. This approach of using deployments may be sufficient for stateless applications, but not for applications that require a persistent naming convention or storage. For applications that require a replica to exist on each node, or selected nodes, within a cluster, the Deployment Controller doesn't look at how replicas are distributed across the nodes.

There are two Kubernetes resources that let you manage these types of applications:

  • StatefulSets - Maintain the state of applications beyond an individual pod lifecycle, such as storage.
  • DaemonSets - Ensure a running instance on each node, early in the Kubernetes bootstrap process.

StatefulSets

Modern application development often aims for stateless applications, but StatefulSets can be used for stateful applications, such as applications that include database components. A StatefulSet is similar to a deployment in that one or more identical pods are created and managed. Replicas in a StatefulSet follow a graceful, sequential approach to deployment, scale, upgrades, and terminations. With a StatefulSet, the naming convention, network names, and storage persist as replicas are rescheduled.

You define the application in YAML format using kind: StatefulSet, and the StatefulSet Controller then handles the deployment and management of the required replicas. Data is written to persistent storage, provided by Azure Managed Disks or Azure Files. With StatefulSets, the underlying persistent storage remains even when the StatefulSet is deleted.

For more information, see Kubernetes StatefulSets.

Replicas in a StatefulSet are scheduled and run across any available node in an AKS cluster. If you need to ensure that at least one pod in your Set runs on a node, you can instead use a DaemonSet.

DaemonSets

For specific log collection or monitoring needs, you may need to run a given pod on all, or selected, nodes. A DaemonSet is again used to deploy one or more identical pods, but the DaemonSet Controller ensures that each node specified runs an instance of the pod.

The DaemonSet Controller can schedule pods on nodes early in the cluster boot process, before the default Kubernetes scheduler has started. This ability ensures that the pods in a DaemonSet are started before traditional pods in a Deployment or StatefulSet are scheduled.

Like StatefulSets, a DaemonSet is defined as part of a YAML definition using kind: DaemonSet.

For more information, see Kubernetes DaemonSets.

Note

If using the Virtual Nodes add-on, DaemonSets will not create pods on the virtual node.

Namespaces

Kubernetes resources, such as pods and Deployments, are logically grouped into a namespace. These groupings provide a way to logically divide an AKS cluster and restrict access to create, view, or manage resources. You can create namespaces to separate business groups, for example. Users can only interact with resources within their assigned namespaces.

Kubernetes namespaces to logically divide resources and applications

When you create an AKS cluster, the following namespaces are available:

  • default - This namespace is where pods and deployments are created by default when none is provided. In smaller environments, you can deploy applications directly into the default namespace without creating additional logical separations. When you interact with the Kubernetes API, such as with kubectl get pods, the default namespace is used when none is specified.
  • kube-system - This namespace is where core resources exist, such as network features like DNS and proxy, or the Kubernetes dashboard. You typically don't deploy your own applications into this namespace.
  • kube-public - This namespace is typically not used, but can be used for resources to be visible across the whole cluster, and can be viewed by any user.

For more information, see Kubernetes namespaces.

Next steps

This article covers some of the core Kubernetes components and how they apply to AKS clusters. For additional information on core Kubernetes and AKS concepts, see the following articles:
