Understand AKS cluster performance with Azure Monitor for containers

With Azure Monitor for containers, you can use the performance charts and health status to monitor the workload of your Azure Kubernetes Service (AKS) clusters from two perspectives, directly from an AKS cluster or all AKS clusters in a subscription from Azure Monitor. Viewing Azure Container Instances (ACI) is also possible when you monitor a specific AKS cluster.

This article will help you understand the experience between the two perspectives, and how it helps you quickly assess, investigate, and resolve issues detected.

For information about enabling Azure Monitor for containers, see Onboard Azure Monitor for containers.

Azure Monitor provides a multi-cluster view showing the health status of all monitored AKS clusters deployed across resource groups in your subscriptions. It shows AKS clusters discovered that are not monitored by the solution. Immediately you can understand cluster health, and from here you can drill down to the node and controller performance page, or navigate to see performance charts for the cluster. For AKS clusters discovered and identified as unmonitored, you can enable monitoring for that cluster at any time. ​ ​

Sign in to the Azure portal

Sign in to the Azure portal.

Multi-cluster view from Azure Monitor

To view the health status of all AKS clusters deployed, select Monitor from the left-hand pane in the Azure portal. Under the Insights section, select Containers.

Azure Monitor multi-cluster dashboard example

On the Monitored clusters tab, you are able to learn the following:

  1. How many clusters are in a critical or unhealthy state, versus how many are healthy or not reporting (referred to as an unknown state)?
  2. Are all of my Azure Kubernetes Engine (AKS-engine) deployments healthy?
  3. How many nodes, user and system pods are deployed per cluster.

The health statuses included are:

  • Healthy – no issues detected for the VM and it is functioning as required.
  • Critical – one or more critical issues are detected, which need to be addressed in order to restore normal operational state as expected.
  • Warning - one or more issues are detected, which need to be addressed or the health condition could become critical.
  • Unknown – if the service was not able to make a connection with the node or pod, the status changes to an unknown state.
  • Not found - Either the workspace, the resource group, or subscription containing the workspace for this solution has been deleted.
  • Unauthorized - User doesn’t have required permissions to read the data in the workspace.
  • Error - Error occurred while attempting to read data from the workspace.
  • Mis configured - Azure Monitor for containers was not configured correctly in the specified workspace.
  • No data - Data has not reported to the workspace in the last 30 minutes.

Health state calculates overall cluster status as worst of” the three states with one exception – if any of the three states is unknown, overall cluster state will show Unknown.

The following table provides a breakdown of the calculation controlling the health states for a monitored cluster on the multi-cluster view.

Status Availability
User Pod
Healthy 100%
Warning 90 - 99%
Critical <90%
Unknown If not reported in last 30 minutes
System Pod
Healthy 100%
Warning N/A
Critical <100%
Unknown If not reported in last 30 minutes
Node
Healthy >85%
Warning 60 - 84%
Critical <60%
Unknown If not reported in last 30 minutes

From the list of clusters, you can drill down to the Cluster page by clicking on the name of the cluster, to the Nodes performance page by clicking on the rollup of nodes in the Nodes column for that specific cluster, or drill down to the Controllers performance page by clicking on the rollup of User pods or System pods column. ​

View performance directly from an AKS cluster

Access to Azure Monitor for containers is available directly from an AKS cluster by selecting Insights from the left-hand pane. Viewing information about your AKS cluster is organized into four perspectives:

  • Cluster
  • Nodes
  • Controllers
  • Containers

The default page opened when you click on Insights is Cluster, and it includes four line performance charts displaying key performance metrics of your cluster.

Example performance charts on the Cluster tab

The performance chart displays four performance metrics:

  • Node CPU Utilization %: An aggregated perspective of CPU utilization for the entire cluster. You can filter the results for the time range by selecting Avg, Min, Max, 50th, 90th, and 95th in the percentiles selector above the chart, either individually or combined.
  • Node memory utilization %: An aggregated perspective of memory utilization for the entire cluster. You can filter the results for the time range by selecting Avg, Min, Max, 50th, 90th, and 95th in the percentiles selector above the chart, either individually or combined.
  • Node count: A node count and status from Kubernetes. Statuses of the cluster nodes represented are All, Ready, and Not Ready and can be filtered individually or combined in the selector above the chart.
  • Activity pod count: A pod count and status from Kubernetes. Statuses of the pods represented are All, Pending, Running, and Unknown and can be filtered individually or combined in the selector above the chart.

You can use the left/right arrow keys to cycle through each data point on the chart and the up/down arrow keys to cycle through the percentile lines.

When you switch to Nodes, Controllers, and Containers tab, automatically displayed on the right-side of the page is the property pane. It shows the properties of the item selected, including labels you define to organize Kubernetes objects. Click on the >> link in the pane to view\hide the pane.

Example Kubernetes perspectives properties pane

As you expand the objects in the hierarchy, the properties pane updates based on the object selected. From the pane, you can also view Kubernetes events with pre-defined log searches by clicking on the View Kubernetes event logs link at the top of the pane. For more information about viewing Kubernetes log data, see Search logs to analyze data. While you are reviewing your containers in the Containers view, you can see container logs in real time. For more information about this feature and the configuration required to grant and control access, see How to view container logs real time with Azure Monitor for containers.

Use the + Add Filter option from the top of the page to filter the results for the view by Service, Node, or Namespace and after selecting the filter scope, you then select from one of the values shown in the Select value(s) field. After the filter is configured, it is applied globally while viewing any perspective of the AKS cluster. The formula only supports the equal sign. You can add additional filters on top of the first one to further narrow your results. For example, if you specified a filter by Node, your second filter would only allow you to select Service or Namespace.

Example using the filter to narrow down results

Specifying a filter in one tab continues to be applied when you select another and it is deleted after you click the x symbol next to the specified filter.

Switch to the Nodes tab and the row hierarchy follows the Kubernetes object model, starting with a node in your cluster. Expand the node and you can view one or more pods running on the node. If more than one container is grouped to a pod, they are displayed as the last row in the hierarchy. You can also view how many non-pod related workloads are running on the host if the host has processor or memory pressure.

Example Kubernetes Node hierarchy in the performance view

Azure Container Instances Virtual Nodes running the Linux OS are shown after the last AKS cluster node in the list. When you expand an ACI Virtual Node, you can view one or more ACI pods and containers running on the node. Metrics are not collected and reported for nodes, only pods.

Example Node hierarchy with Container Instances listed

From an expanded node, you can drill down from the pod or container running on the node to the controller to view performance data filtered for that controller. Click on the value under the Controller column for the specific node.
Example drill-down from node to controller in the performance view

You can select controllers or containers at the top of the page and review the status and resource utilization for those objects. If instead you want to review memory utilization, in the Metric drop-down list, select Memory RSS or Memory working set. Memory RSS is supported only for Kubernetes version 1.8 and later. Otherwise, you view values for Min % as NaN %, which is a numeric data type value that represents an undefined or unrepresentable value.

Container nodes performance view

By default, Performance data is based on the last six hours, but you can change the window by using the TimeRange option at the upper left. You can also filter the results within the time range by selecting Avg, Min, Max, 50th, 90th, and 95th in the percentile selector.

Percentile selection for data filtering

When you mouse over the bar graph under the Trend column, each bar shows either CPU or memory usage, depending on which metric is selected, within a sample period of 15 minutes. After you select the trend chart through a keyboard, you can use the Alt+PageUp or Alt+PageDown keys to cycle through each bar individually and get the same details as you would on mouseover.

Trend bar chart hover example

In the next example, note for the first in the list - node aks-nodepool1-, the value for Containers is 9, which is a rollup of the total number of containers deployed.

Rollup of containers per node example

It can help you quickly identify whether you have a proper balance of containers between nodes in your cluster.

The information that's presented when you view Nodes is described in the following table:

Column Description
Name The name of the host.
Status Kubernetes view of the node status.
Avg %, Min %, Max %, 50th %, 90th % Average node percentage based on percentile during the selected duration.
Avg, Min, Max, 50th, 90th Average nodes actual value based on percentile during that time duration selected. The average value is measured from the CPU/Memory limit set for a node; for pods and containers it is the avg value reported by the host.
Containers Number of containers.
Uptime Represents the time since a node started or was rebooted.
Controllers Only for containers and pods. It shows which controller it is residing in. Not all pods are in a controller, so some might display N/A.
Trend Avg %, Min %, Max %, 50th %, 90th % Bar graph trend represents the average percentile metric percentage of the controller.

In the selector, select Controllers.

Select controllers view

Here you can view the performance health of your controllers and ACI Virtual Node controllers or Virtual Node pods not connected to a controller.

 controllers performance view

The row hierarchy starts with a controller and when you expand a controller, you view one or more pods. Expand pod, and the last row displays the container grouped to the pod. From an expanded controller, you can drill down to the node it is running on to view performance data filtered for that node. ACI pods not connected to a controller are listed last in the list.

Example Controllers hierarchy with Container Instances pods listed

Click on the value under the Node column for the specific controller.

Example drill down from node to controller in the performance view

The information that's displayed when you view controllers is described in the following table:

Column Description
Name The name of the controller.
Status The rollup status of the containers when it has completed running with status, such as OK, Terminated, Failed Stopped, or Paused. If the container is running, but the status was either not properly displayed or was not picked up by the agent and has not responded more than 30 minutes, the status is Unknown. Additional details of the status icon are provided in the table below.
Avg %, Min %, Max %, 50th %, 90th % Rollup average of the average percentage of each entity for the selected metric and percentile.
Avg, Min, Max, 50th, 90th Rollup of the average CPU millicore or memory performance of the container for the selected percentile. The average value is measured from the CPU/Memory limit set for a pod.
Containers Total number of containers for the controller or pod.
Restarts Rollup of the restart count from containers.
Uptime Represents the time since a container started.
Node Only for containers and pods. It shows which controller it is residing.
Trend Avg %, Min %, Max %, 50th %, 90th % Bar graph trend represents the average percentile metric of the controller.

The icons in the status field indicate the online status of the containers:

Icon Status
Ready running status icon Running (Ready)
Waiting or paused status icon Waiting or Paused
Last reported running status icon Last reported running but hasn't responded more than 30 minutes
Successful status icon Successfully stopped or failed to stop

The status icon displays a count based on what the pod provides. It shows the worst two states, and when you hover over the status, it displays a rollup status from all pods in the container. If there isn't a ready state, the status value displays (0).

In the selector, select Containers.

Select containers view

Here you can view the performance health of your Azure Kubernetes and Azure Container Instances containers.

 controllers performance view

From a container, you can drill down to a pod or node to view performance data filtered for that object. Click on the value under the Pod or Node column for the specific container.

Example drill down from node to controller in the performance view

The information that's displayed when you view containers is described in the following table:

Column Description
Name The name of the controller.
Status Status of the containers, if any. Additional details of the status icon are provided in the next table.
Avg %, Min %, Max %, 50th %, 90th % The rollup of the average percentage of each entity for the selected metric and percentile.
Avg, Min, Max, 50th, 90th The rollup of the average CPU millicore or memory performance of the container for the selected percentile. The average value is measured from the CPU/Memory limit set for a pod.
Pod Container where the pod resides.
Node  Node where the container resides.
Restarts Represents the time since a container started.
Uptime Represents the time since a container was started or rebooted.
Trend Avg %, Min %, Max %, 50th %, 90th % Bar graph trend represents the average percentile metric percentage of the container.

The icons in the status field indicate the online statuses of pods, as described in the following table:

Icon Status
Ready running status icon Running (Ready)
Waiting or paused status icon Waiting or Paused
Last reported running status icon Last reported running but hasn't responded in more than 30 minutes
Terminated status icon Successfully stopped or failed to stop
Failed status icon Failed state

Container data-collection details

Container Insights collects various performance metrics and log data from container hosts and containers. Data is collected every three minutes.

Container records

Examples of records that are collected by Azure Monitor for containers and the data types that appear in log search results are displayed in the following table:

Data type Data type in Log Search Fields
Performance for hosts and containers Perf Computer, ObjectName, CounterName (%Processor Time, Disk Reads MB, Disk Writes MB, Memory Usage MB, Network Receive Bytes, Network Send Bytes, Processor Usage sec, Network), CounterValue, TimeGenerated, CounterPath, SourceSystem
Container inventory ContainerInventory TimeGenerated, Computer, container name, ContainerHostname, Image, ImageTag, ContainerState, ExitCode, EnvironmentVar, Command, CreatedTime, StartedTime, FinishedTime, SourceSystem, ContainerID, ImageID
Container image inventory ContainerImageInventory TimeGenerated, Computer, Image, ImageTag, ImageSize, VirtualSize, Running, Paused, Stopped, Failed, SourceSystem, ImageID, TotalContainer
Container log ContainerLog TimeGenerated, Computer, image ID, container name, LogEntrySource, LogEntry, SourceSystem, ContainerID
Container service log ContainerServiceLog TimeGenerated, Computer, TimeOfCommand, Image, Command, SourceSystem, ContainerID
Container node inventory ContainerNodeInventory_CL TimeGenerated, Computer, ClassName_s, DockerVersion_s, OperatingSystem_s, Volume_s, Network_s, NodeRole_s, OrchestratorType_s, InstanceID_g, SourceSystem
Container process ContainerProcess_CL TimeGenerated, Computer, Pod_s, Namespace_s, ClassName_s, InstanceID_s, Uid_s, PID_s, PPID_s, C_s, STIME_s, Tty_s, TIME_s, Cmd_s, Id_s, Name_s, SourceSystem
Inventory of pods in a Kubernetes cluster KubePodInventory TimeGenerated, Computer, ClusterId, ContainerCreationTimeStamp, PodUid, PodCreationTimeStamp, ContainerRestartCount, PodRestartCount, PodStartTime, ContainerStartTime, ServiceName, ControllerKind, ControllerName, ContainerStatus, ContainerID, ContainerName, Name, PodLabel, Namespace, PodStatus, ClusterName, PodIp, SourceSystem
Inventory of nodes part of a Kubernetes cluster KubeNodeInventory TimeGenerated, Computer, ClusterName, ClusterId, LastTransitionTimeReady, Labels, Status, KubeletVersion, KubeProxyVersion, CreationTimeStamp, SourceSystem
Kubernetes Events KubeEvents_CL TimeGenerated, Computer, ClusterId_s, FirstSeen_t, LastSeen_t, Count_d, ObjectKind_s, Namespace_s, Name_s, Reason_s, Type_s, TimeGenerated_s, SourceComponent_s, ClusterName_s, Message, SourceSystem
Services in the Kubernetes cluster KubeServices_CL TimeGenerated, ServiceName_s, Namespace_s, SelectorLabels_s, ClusterId_s, ClusterName_s, ClusterIP_s, ServiceType_s, SourceSystem
Performance metrics for nodes part of the Kubernetes cluster Perf | where ObjectName == “K8SNode” Computer, ObjectName, CounterName (cpuUsageNanoCores, , memoryWorkingSetBytes, memoryRssBytes, networkRxBytes, networkTxBytes, restartTimeEpoch, networkRxBytesPerSec, networkTxBytesPerSec, cpuAllocatableNanoCores, memoryAllocatableBytes, cpuCapacityNanoCores, memoryCapacityBytes),CounterValue, TimeGenerated, CounterPath, SourceSystem
Performance metrics for containers part of the Kubernetes cluster Perf | where ObjectName == “K8SContainer” CounterName (cpuUsageNanoCores, memoryWorkingSetBytes, memoryRssBytes, restartTimeEpoch, cpuRequestNanoCores, memoryRequestBytes, cpuLimitNanoCores, memoryLimitBytes),CounterValue, TimeGenerated, CounterPath, SourceSystem

Search logs to analyze data

Log Analytics can help you look for trends, diagnose bottlenecks, forecast, or correlate data that can help you determine whether the current cluster configuration is performing optimally. Pre-defined log searches are provided for you to immediately start using or to customize to return the information the way you want.

You can perform interactive analysis of data in the workspace by selecting the View Kubernetes event logs or View container logs option in the preview pane. The Log Search page appears to the right of the Azure portal page that you were on.

Analyze data in Log Analytics

The container logs output that's forwarded to Log Analytics are STDOUT and STDERR. Because Azure Monitor is monitoring Azure-managed Kubernetes (AKS), Kube-system is not collected today because of the large volume of generated data.

Example log search queries

It's often useful to build queries that start with an example or two and then modify them to fit your requirements. To help build more advanced queries, you can experiment with the following sample queries:

Query Description
ContainerInventory
| project Computer, Name, Image, ImageTag, ContainerState, CreatedTime, StartedTime, FinishedTime
| render table
List all of a container's lifecycle information
KubeEvents_CL
| where not(isempty(Namespace_s))
| sort by TimeGenerated desc
| render table
Kubernetes events
ContainerImageInventory
| summarize AggregatedValue = count() by Image, ImageTag, Running
Image inventory
Select the Line chart display option:
Perf
| where ObjectName == "K8SContainer" and CounterName == "cpuUsageNanoCores" | summarize AvgCPUUsageNanoCores = avg(CounterValue) by bin(TimeGenerated, 30m), InstanceName
Container CPU
Select the Line chart display option:
Perf
| where ObjectName == "K8SContainer" and CounterName == "memoryRssBytes" | summarize AvgUsedRssMemoryBytes = avg(CounterValue) by bin(TimeGenerated, 30m), InstanceName
Container memory

Next steps

Azure Monitor for containers does not include a predefined set of alerts to copy and modify according to your supporting processes and procedures. Review the Create performance alerts with Azure Monitor for containers to learn how to create recommended alerts for high CPU and memory utilization.
