Get started building solutions with the Batch client library for .NET

Learn the basics of Azure Batch and the Batch .NET library in this article as we discuss a C# sample application step by step. We look at how the sample application leverages the Batch service to process a parallel workload in the cloud, and how it interacts with Azure Storage for file staging and retrieval. You'll learn a common Batch application workflow and gain a base understanding of the major components of Batch such as jobs, tasks, pools, and compute nodes.

Batch solution workflow (basic)

Prerequisites

This article assumes that you have a working knowledge of C# and Visual Studio. It also assumes that you're able to satisfy the account creation requirements that are specified below for Azure and the Batch and Storage services.

Accounts

Important

Batch currently supports only the general-purpose storage account type, as described in step #5 Create a storage account in About Azure storage accounts.

Visual Studio

You must have Visual Studio 2015 or newer to build the sample project. You can find free and trial versions of Visual Studio in the overview of Visual Studio products.

DotNetTutorial code sample

The DotNetTutorial sample is one of the many Batch code samples found in the azure-batch-samples repository on GitHub. You can download all the samples by clicking Clone or download > Download ZIP on the repository home page, or by clicking the azure-batch-samples-master.zip direct download link. Once you've extracted the contents of the ZIP file, you can find the solution in the following folder:

\azure-batch-samples\CSharp\ArticleProjects\DotNetTutorial

Azure Batch Explorer (optional)

The Azure Batch Explorer is a free utility that is included in the azure-batch-samples repository on GitHub. While not required to complete this tutorial, it can be useful while developing and debugging your Batch solutions.

DotNetTutorial sample project overview

The DotNetTutorial code sample is a Visual Studio solution that consists of two projects: DotNetTutorial and TaskApplication.

  • DotNetTutorial is the client application that interacts with the Batch and Storage services to execute a parallel workload on compute nodes (virtual machines). DotNetTutorial runs on your local workstation.
  • TaskApplication is the program that runs on compute nodes in Azure to perform the actual work. In the sample, TaskApplication.exe parses the text in a file downloaded from Azure Storage (the input file). Then it produces a text file (the output file) that contains a list of the top three words that appear in the input file. After it creates the output file, TaskApplication uploads the file to Azure Storage. This makes it available to the client application for download. TaskApplication runs in parallel on multiple compute nodes in the Batch service.

The following diagram illustrates the primary operations that are performed by the client application, DotNetTutorial, and the application that is executed by the tasks, TaskApplication. This basic workflow is typical of many compute solutions that are created with Batch. While it does not demonstrate every feature available in the Batch service, nearly every Batch scenario includes portions of this workflow.

Batch example workflow

Step 1. Create containers in Azure Blob Storage.
Step 2. Upload task application files and input files to containers.
Step 3. Create a Batch pool.
    3a. The pool StartTask downloads the task binary files (TaskApplication) to nodes as they join the pool.
Step 4. Create a Batch job.
Step 5. Add tasks to the job.
    5a. The tasks are scheduled to execute on nodes.
    5b. Each task downloads its input data from Azure Storage, then begins execution.
Step 6. Monitor tasks.
    6a. As tasks are completed, they upload their output data to Azure Storage.
Step 7. Download task output from Storage.

As mentioned, not every Batch solution performs these exact steps, and may include many more, but the DotNetTutorial sample application demonstrates common processes found in a Batch solution.

Build the DotNetTutorial sample project

Before you can successfully run the sample, you must specify both Batch and Storage account credentials in the DotNetTutorial project's Program.cs file. If you have not done so already, open the solution in Visual Studio by double-clicking the DotNetTutorial.sln solution file. Or open it from within Visual Studio by using the File > Open > Project/Solution menu.

Open Program.cs within the DotNetTutorial project. Then add your credentials as specified near the top of the file:

// Update the Batch and Storage account credential strings below with the values
// unique to your accounts. These are used when constructing connection strings
// for the Batch and Storage client objects.

// Batch account credentials
private const string BatchAccountName = "";
private const string BatchAccountKey  = "";
private const string BatchAccountUrl  = "";

// Storage account credentials
private const string StorageAccountName = "";
private const string StorageAccountKey  = "";
Important

As mentioned above, you must currently specify the credentials for a general-purpose storage account in Azure Storage. Your Batch applications use blob storage within the general-purpose storage account. Do not specify the credentials for a Storage account that was created by selecting the Blob storage account type.

You can find your Batch and Storage account credentials within the account blade of each service in the Azure portal:

Batch credentials in the portal Storage credentials in the portal

Now that you've updated the project with your credentials, right-click the solution in Solution Explorer and click Build Solution. Confirm the restoration of any NuGet packages, if you're prompted.

Tip

If the NuGet packages are not automatically restored, or if you see errors about a failure to restore the packages, ensure that you have the NuGet Package Manager installed. Then enable the download of missing packages. See Enabling Package Restore During Build to enable package download.

In the following sections, we break down the sample application into the steps that it performs to process a workload in the Batch service, and discuss those steps in detail. We encourage you to refer to the open solution in Visual Studio while you work your way through the rest of this article, since not every line of code in the sample is discussed.

Navigate to the top of the MainAsync method in the DotNetTutorial project's Program.cs file to start with Step 1. Each step below then roughly follows the progression of method calls in MainAsync.

Step 1: Create Storage containers

Create containers in Azure Storage

Batch includes built-in support for interacting with Azure Storage. Containers in your Storage account will provide the files needed by the tasks that run in your Batch account. The containers also provide a place to store the output data that the tasks produce. The first thing the DotNetTutorial client application does is create three containers in Azure Blob Storage:

  • application: This container will store the application run by the tasks, as well as any of its dependencies, such as DLLs.
  • input: Tasks will download the data files to process from the input container.
  • output: When tasks complete input file processing, they will upload the results to the output container.

In order to interact with a Storage account and create containers, we use the Azure Storage Client Library for .NET. We create a reference to the account with CloudStorageAccount, and from that create a CloudBlobClient:

// Construct the Storage account connection string
string storageConnectionString = String.Format(
    "DefaultEndpointsProtocol=https;AccountName={0};AccountKey={1}",
    StorageAccountName,
    StorageAccountKey);

// Retrieve the storage account
CloudStorageAccount storageAccount =
    CloudStorageAccount.Parse(storageConnectionString);

// Create the blob client, for use in obtaining references to
// blob storage containers
CloudBlobClient blobClient = storageAccount.CreateCloudBlobClient();

We use the blobClient reference throughout the application and pass it as a parameter to several methods. An example of this is in the code block that immediately follows the above, where we call CreateContainerIfNotExistAsync to actually create the containers.

// Use the blob client to create the containers in Azure Storage if they don't
// yet exist
const string appContainerName    = "application";
const string inputContainerName  = "input";
const string outputContainerName = "output";
await CreateContainerIfNotExistAsync(blobClient, appContainerName);
await CreateContainerIfNotExistAsync(blobClient, inputContainerName);
await CreateContainerIfNotExistAsync(blobClient, outputContainerName);
private static async Task CreateContainerIfNotExistAsync(
    CloudBlobClient blobClient,
    string containerName)
{
        CloudBlobContainer container =
            blobClient.GetContainerReference(containerName);

        if (await container.CreateIfNotExistsAsync())
        {
                Console.WriteLine("Container [{0}] created.", containerName);
        }
        else
        {
                Console.WriteLine("Container [{0}] exists, skipping creation.",
                    containerName);
        }
}

Once the containers have been created, the application can now upload the files that will be used by the tasks.

Tip

How to use Blob Storage from .NET provides a good overview of working with Azure Storage containers and blobs. It should be near the top of your reading list as you start working with Batch.

Step 2: Upload task application and data files

Upload task application and input (data) files to containers

In the file upload operation, DotNetTutorial first defines collections of application and input file paths as they exist on the local machine. Then it uploads these files to the containers that you created in the previous step.

// Paths to the executable and its dependencies that will be executed by the tasks
List<string> applicationFilePaths = new List<string>
{
    // The DotNetTutorial project includes a project reference to TaskApplication,
    // allowing us to determine the path of the task application binary dynamically
    typeof(TaskApplication.Program).Assembly.Location,
    "Microsoft.WindowsAzure.Storage.dll"
};

// The collection of data files that are to be processed by the tasks
List<string> inputFilePaths = new List<string>
{
    @"..\..\taskdata1.txt",
    @"..\..\taskdata2.txt",
    @"..\..\taskdata3.txt"
};

// Upload the application and its dependencies to Azure Storage. This is the
// application that will process the data files, and will be executed by each
// of the tasks on the compute nodes.
List<ResourceFile> applicationFiles = await UploadFilesToContainerAsync(
    blobClient,
    appContainerName,
    applicationFilePaths);

// Upload the data files. This is the data that will be processed by each of
// the tasks that are executed on the compute nodes within the pool.
List<ResourceFile> inputFiles = await UploadFilesToContainerAsync(
    blobClient,
    inputContainerName,
    inputFilePaths);

There are two methods in Program.cs that are involved in the upload process:

  • UploadFilesToContainerAsync: This method returns a collection of ResourceFile objects (discussed below) and internally calls UploadFileToContainerAsync to upload each file that is passed in the filePaths parameter.
  • UploadFileToContainerAsync: This is the method that actually performs the file upload and creates the ResourceFile objects. After uploading the file, it obtains a shared access signature (SAS) for the file and returns a ResourceFile object that represents it. Shared access signatures are also discussed below.
private static async Task<ResourceFile> UploadFileToContainerAsync(
    CloudBlobClient blobClient,
    string containerName,
    string filePath)
{
        Console.WriteLine(
            "Uploading file {0} to container [{1}]...", filePath, containerName);

        string blobName = Path.GetFileName(filePath);

        CloudBlobContainer container = blobClient.GetContainerReference(containerName);
        CloudBlockBlob blobData = container.GetBlockBlobReference(blobName);
        await blobData.UploadFromFileAsync(filePath);

        // Set the expiry time and permissions for the blob shared access signature.
        // In this case, no start time is specified, so the shared access signature
        // becomes valid immediately
        SharedAccessBlobPolicy sasConstraints = new SharedAccessBlobPolicy
        {
                SharedAccessExpiryTime = DateTime.UtcNow.AddHours(2),
                Permissions = SharedAccessBlobPermissions.Read
        };

        // Construct the SAS URL for blob
        string sasBlobToken = blobData.GetSharedAccessSignature(sasConstraints);
        string blobSasUri = String.Format("{0}{1}", blobData.Uri, sasBlobToken);

        return new ResourceFile(blobSasUri, blobName);
}

ResourceFiles

A ResourceFile provides tasks in Batch with the URL to a file in Azure Storage that is downloaded to a compute node before that task is run. The ResourceFile.BlobSource property specifies the full URL of the file as it exists in Azure Storage. The URL may also include a shared access signature (SAS) that provides secure access to the file. Most tasks types within Batch .NET include a ResourceFiles property, including:

The DotNetTutorial sample application does not use the JobPreparationTask or JobReleaseTask task types, but you can read more about them in Run job preparation and completion tasks on Azure Batch compute nodes.

Shared access signature (SAS)

Shared access signatures are strings which—when included as part of a URL—provide secure access to containers and blobs in Azure Storage. The DotNetTutorial application uses both blob and container shared access signature URLs, and demonstrates how to obtain these shared access signature strings from the Storage service.

  • Blob shared access signatures: The pool's StartTask in DotNetTutorial uses blob shared access signatures when it downloads the application binaries and input data files from Storage (see Step #3 below). The UploadFileToContainerAsync method in DotNetTutorial's Program.cs contains the code that obtains each blob's shared access signature. It does so by calling CloudBlob.GetSharedAccessSignature.
  • Container shared access signatures: As each task finishes its work on the compute node, it uploads its output file to the output container in Azure Storage. To do so, TaskApplication uses a container shared access signature that provides write access to the container as part of the path when it uploads the file. Obtaining the container shared access signature is done in a similar fashion as when obtaining the blob shared access signature. In DotNetTutorial, you will find that the GetContainerSasUrl helper method calls CloudBlobContainer.GetSharedAccessSignature to do so. You'll read more about how TaskApplication uses the container shared access signature in "Step 6: Monitor Tasks."
Tip

Check out the two-part series on shared access signatures, Part 1: Understanding the shared access signature (SAS) model and Part 2: Create and use a shared access signature (SAS) with Blob storage, to learn more about providing secure access to data in your Storage account.

Step 3: Create Batch pool

Create a Batch pool

A Batch pool is a collection of compute nodes (virtual machines) on which Batch executes a job's tasks.

After uploading the application and data files to the Storage account with Azure Storage APIs, DotNetTutorial begins making calls to the Batch service with APIs provided by the Batch .NET library. The code first creates a BatchClient:

BatchSharedKeyCredentials cred = new BatchSharedKeyCredentials(
    BatchAccountUrl,
    BatchAccountName,
    BatchAccountKey);

using (BatchClient batchClient = BatchClient.Open(cred))
{
    ...

Next, the sample creates a pool of compute nodes in the Batch account with a call to CreatePoolIfNotExistsAsync. CreatePoolIfNotExistsAsync uses the BatchClient.PoolOperations.CreatePool method to create a new pool in the Batch service:

private static async Task CreatePoolIfNotExistAsync(BatchClient batchClient, string poolId, IList<ResourceFile> resourceFiles)
{
    CloudPool pool = null;
    try
    {
        Console.WriteLine("Creating pool [{0}]...", poolId);

        // Create the unbound pool. Until we call CloudPool.Commit() or CommitAsync(), no pool is actually created in the
        // Batch service. This CloudPool instance is therefore considered "unbound," and we can modify its properties.
        pool = batchClient.PoolOperations.CreatePool(
            poolId: poolId,
            targetDedicatedComputeNodes: 3,                                             // 3 compute nodes
            virtualMachineSize: "small",                                                // single-core, 1.75 GB memory, 225 GB disk
            cloudServiceConfiguration: new CloudServiceConfiguration(osFamily: "4"));   // Windows Server 2012 R2

        // Create and assign the StartTask that will be executed when compute nodes join the pool.
        // In this case, we copy the StartTask's resource files (that will be automatically downloaded
        // to the node by the StartTask) into the shared directory that all tasks will have access to.
        pool.StartTask = new StartTask
        {
            // Specify a command line for the StartTask that copies the task application files to the
            // node's shared directory. Every compute node in a Batch pool is configured with a number
            // of pre-defined environment variables that can be referenced by commands or applications
            // run by tasks.

            // Since a successful execution of robocopy can return a non-zero exit code (e.g. 1 when one or
            // more files were successfully copied) we need to manually exit with a 0 for Batch to recognize
            // StartTask execution success.
            CommandLine = "cmd /c (robocopy %AZ_BATCH_TASK_WORKING_DIR% %AZ_BATCH_NODE_SHARED_DIR%) ^& IF %ERRORLEVEL% LEQ 1 exit 0",
            ResourceFiles = resourceFiles,
            WaitForSuccess = true
        };

        await pool.CommitAsync();
    }
    catch (BatchException be)
    {
        // Swallow the specific error code PoolExists since that is expected if the pool already exists
        if (be.RequestInformation?.BatchError != null && be.RequestInformation.BatchError.Code == BatchErrorCodeStrings.PoolExists)
        {
            Console.WriteLine("The pool {0} already existed when we tried to create it", poolId);
        }
        else
        {
            throw; // Any other exception is unexpected
        }
    }
}

When you create a pool with CreatePool, you specify several parameters such as the number of compute nodes, the size of the nodes, and the nodes' operating system. In DotNetTutorial, we use CloudServiceConfiguration to specify Windows Server 2012 R2 from Cloud Services.

You can also create pools of compute nodes that are Azure Virtual Machines (VMs) by specifying the VirtualMachineConfiguration for your pool. You can create a pool of VM compute nodes from either Windows or Linux images. The source for your VM images can be either:

Important

You are charged for compute resources in Batch. To minimize costs, you can lower targetDedicatedComputeNodes to 1 before you run the sample.

Along with these physical node properties, you may also specify a StartTask for the pool. The StartTask executes on each node as that node joins the pool, and each time a node is restarted. The StartTask is especially useful for installing applications on compute nodes prior to the execution of tasks. For example, if your tasks process data by using Python scripts, you could use a StartTask to install Python on the compute nodes.

In this sample application, the StartTask copies the files that it downloads from Storage (which are specified by using the StartTask.ResourceFiles property) from the StartTask working directory to the shared directory that all tasks running on the node can access. Essentially, this copies TaskApplication.exe and its dependencies to the shared directory on each node as the node joins the pool, so that any tasks that run on the node can access it.

Tip

The application packages feature of Azure Batch provides another way to get your application onto the compute nodes in a pool. See Deploy applications to compute nodes with Batch application packages for details.

Also notable in the code snippet above is the use of two environment variables in the CommandLine property of the StartTask: %AZ_BATCH_TASK_WORKING_DIR% and %AZ_BATCH_NODE_SHARED_DIR%. Each compute node within a Batch pool is automatically configured with several environment variables that are specific to Batch. Any process that is executed by a task has access to these environment variables.

Tip

To find out more about the environment variables that are available on compute nodes in a Batch pool, and information on task working directories, see the Environment settings for tasks and Files and directories sections in the Batch feature overview for developers.

Step 4: Create Batch job

Create Batch job

A Batch job is a collection of tasks, and is associated with a pool of compute nodes. The tasks in a job execute on the associated pool's compute nodes.

You can use a job not only for organizing and tracking tasks in related workloads, but also for imposing certain constraints--such as the maximum runtime for the job (and by extension, its tasks) as well as job priority in relation to other jobs in the Batch account. In this example, however, the job is associated only with the pool that was created in step #3. No additional properties are configured.

All Batch jobs are associated with a specific pool. This association indicates which nodes the job's tasks will execute on. You specify this by using the CloudJob.PoolInformation property, as shown in the code snippet below.

private static async Task CreateJobAsync(
    BatchClient batchClient,
    string jobId,
    string poolId)
{
    Console.WriteLine("Creating job [{0}]...", jobId);

    CloudJob job = batchClient.JobOperations.CreateJob();
    job.Id = jobId;
    job.PoolInformation = new PoolInformation { PoolId = poolId };

    await job.CommitAsync();
}

Now that a job has been created, tasks are added to perform the work.

Step 5: Add tasks to job

Add tasks to job
(1) Tasks are added to the job, (2) the tasks are scheduled to run on nodes, and (3) the tasks download the data files to process

Batch tasks are the individual units of work that execute on the compute nodes. A task has a command line and runs the scripts or executables that you specify in that command line.

To actually perform work, tasks must be added to a job. Each CloudTask is configured by using a command-line property and ResourceFiles (as with the pool's StartTask) that the task downloads to the node before its command line is automatically executed. In the DotNetTutorial sample project, each task processes only one file. Thus, its ResourceFiles collection contains a single element.

private static async Task<List<CloudTask>> AddTasksAsync(
    BatchClient batchClient,
    string jobId,
    List<ResourceFile> inputFiles,
    string outputContainerSasUrl)
{
    Console.WriteLine("Adding {0} tasks to job [{1}]...", inputFiles.Count, jobId);

    // Create a collection to hold the tasks that we'll be adding to the job
    List<CloudTask> tasks = new List<CloudTask>();

    // Create each of the tasks. Because we copied the task application to the
    // node's shared directory with the pool's StartTask, we can access it via
    // the shared directory on the node that the task runs on.
    foreach (ResourceFile inputFile in inputFiles)
    {
        string taskId = "topNtask" + inputFiles.IndexOf(inputFile);
        string taskCommandLine = String.Format(
            "cmd /c %AZ_BATCH_NODE_SHARED_DIR%\\TaskApplication.exe {0} 3 \"{1}\"",
            inputFile.FilePath,
            outputContainerSasUrl);

        CloudTask task = new CloudTask(taskId, taskCommandLine);
        task.ResourceFiles = new List<ResourceFile> { inputFile };
        tasks.Add(task);
    }

    // Add the tasks as a collection, as opposed to issuing a separate AddTask call
    // for each. Bulk task submission helps to ensure efficient underlying API calls
    // to the Batch service.
    await batchClient.JobOperations.AddTaskAsync(jobId, tasks);

    return tasks;
}
Important

When they access environment variables such as %AZ_BATCH_NODE_SHARED_DIR% or execute an application not found in the node's PATH, task command lines must be prefixed with cmd /c. This will explicitly execute the command interpreter and instruct it to terminate after carrying out your command. This requirement is unnecessary if your tasks execute an application in the node's PATH (such as robocopy.exe or powershell.exe) and no environment variables are used.

Within the foreach loop in the code snippet above, you can see that the command line for the task is constructed such that three command-line arguments are passed to TaskApplication.exe:

  1. The first argument is the path of the file to process. This is the local path to the file as it exists on the node. When the ResourceFile object in UploadFileToContainerAsync was first created above, the file name was used for this property (as a parameter to the ResourceFile constructor). This indicates that the file can be found in the same directory as TaskApplication.exe.
  2. The second argument specifies that the top N words should be written to the output file. In the sample, this is hard-coded so that the top three words are written to the output file.
  3. The third argument is the shared access signature (SAS) that provides write access to the output container in Azure Storage. TaskApplication.exe uses this shared access signature URL when it uploads the output file to Azure Storage. You can find the code for this in the UploadFileToContainer method in the TaskApplication project's Program.cs file:
// NOTE: From project TaskApplication Program.cs

private static void UploadFileToContainer(string filePath, string containerSas)
{
        string blobName = Path.GetFileName(filePath);

        // Obtain a reference to the container using the SAS URI.
        CloudBlobContainer container = new CloudBlobContainer(new Uri(containerSas));

        // Upload the file (as a new blob) to the container
        try
        {
                CloudBlockBlob blob = container.GetBlockBlobReference(blobName);
                blob.UploadFromFile(filePath);

                Console.WriteLine("Write operation succeeded for SAS URL " + containerSas);
                Console.WriteLine();
        }
        catch (StorageException e)
        {

                Console.WriteLine("Write operation failed for SAS URL " + containerSas);
                Console.WriteLine("Additional error information: " + e.Message);
                Console.WriteLine();

                // Indicate that a failure has occurred so that when the Batch service
                // sets the CloudTask.ExecutionInformation.ExitCode for the task that
                // executed this application, it properly indicates that there was a
                // problem with the task.
                Environment.ExitCode = -1;
        }
}

Step 6: Monitor tasks

Monitor tasks
The client application (1) monitors the tasks for completion and success status, and (2) the tasks upload result data to Azure Storage

When tasks are added to a job, they are automatically queued and scheduled for execution on compute nodes within the pool associated with the job. Based on the settings you specify, Batch handles all task queuing, scheduling, retrying, and other task administration duties for you.

There are many approaches to monitoring task execution. DotNetTutorial shows a simple example that reports only on completion and task failure or success states. Within the MonitorTasks method in DotNetTutorial's Program.cs, there are three Batch .NET concepts that warrant discussion. They are listed below in their order of appearance:

  1. ODATADetailLevel: Specifying ODATADetailLevel in list operations (such as obtaining a list of a job's tasks) is essential in ensuring Batch application performance. Add Query the Azure Batch service efficiently to your reading list if you plan on doing any sort of status monitoring within your Batch applications.
  2. TaskStateMonitor: TaskStateMonitor provides Batch .NET applications with helper utilities for monitoring task states. In MonitorTasks, DotNetTutorial waits for all tasks to reach TaskState.Completed within a time limit. Then it terminates the job.
  3. TerminateJobAsync: Terminating a job with JobOperations.TerminateJobAsync (or the blocking JobOperations.TerminateJob) marks that job as completed. It is essential to do so if your Batch solution uses a JobReleaseTask. This is a special type of task, which is described in Job preparation and completion tasks.

The MonitorTasks method from DotNetTutorial's Program.cs appears below:

private static async Task<bool> MonitorTasks(
    BatchClient batchClient,
    string jobId,
    TimeSpan timeout)
{
    bool allTasksSuccessful = true;
    const string successMessage = "All tasks reached state Completed.";
    const string failureMessage = "One or more tasks failed to reach the Completed state within the timeout period.";

    // Obtain the collection of tasks currently managed by the job. Note that we use
    // a detail level to  specify that only the "id" property of each task should be
    // populated. Using a detail level for all list operations helps to lower
    // response time from the Batch service.
    ODATADetailLevel detail = new ODATADetailLevel(selectClause: "id");
    List<CloudTask> tasks =
        await batchClient.JobOperations.ListTasks(JobId, detail).ToListAsync();

    Console.WriteLine("Awaiting task completion, timeout in {0}...",
        timeout.ToString());

    // We use a TaskStateMonitor to monitor the state of our tasks. In this case, we
    // will wait for all tasks to reach the Completed state.
    TaskStateMonitor taskStateMonitor
        = batchClient.Utilities.CreateTaskStateMonitor();

    try
    {
        await taskStateMonitor.WhenAll(tasks, TaskState.Completed, timeout);
    }
    catch (TimeoutException)
    {
        await batchClient.JobOperations.TerminateJobAsync(jobId, failureMessage);
        Console.WriteLine(failureMessage);
        return false;
    }

    await batchClient.JobOperations.TerminateJobAsync(jobId, successMessage);

    // All tasks have reached the "Completed" state, however, this does not
    // guarantee all tasks completed successfully. Here we further check each task's
    // ExecutionInfo property to ensure that it did not encounter a failure
    // or return a non-zero exit code.

    // Update the detail level to populate only the task id and executionInfo
    // properties. We refresh the tasks below, and need only this information for
    // each task.
    detail.SelectClause = "id, executionInfo";

    foreach (CloudTask task in tasks)
    {
        // Populate the task's properties with the latest info from the Batch service
        await task.RefreshAsync(detail);

        if (task.ExecutionInformation.Result == TaskExecutionResult.Failure)
        {
            // A task with failure information set indicates there was a problem with the task. It is important to note that
            // the task's state can be "Completed," yet still have encountered a failure.

            allTasksSuccessful = false;

            Console.WriteLine("WARNING: Task [{0}] encountered a failure: {1}", task.Id, task.ExecutionInformation.FailureInformation.Message);
            if (task.ExecutionInformation.ExitCode != 0)
            {
                // A non-zero exit code may indicate that the application executed by the task encountered an error
                // during execution. As not every application returns non-zero on failure by default (e.g. robocopy),
                // your implementation of error checking may differ from this example.

                Console.WriteLine("WARNING: Task [{0}] returned a non-zero exit code - this may indicate task execution or completion failure.", task.Id);
            }
        }
    }

    if (allTasksSuccessful)
    {
        Console.WriteLine("Success! All tasks completed successfully within the specified timeout period.");
    }

    return allTasksSuccessful;
}

Step 7: Download task output

Download task output from Storage

Now that the job is completed, the output from the tasks can be downloaded from Azure Storage. This is done with a call to DownloadBlobsFromContainerAsync in DotNetTutorial's Program.cs:

private static async Task DownloadBlobsFromContainerAsync(
    CloudBlobClient blobClient,
    string containerName,
    string directoryPath)
{
        Console.WriteLine("Downloading all files from container [{0}]...", containerName);

        // Retrieve a reference to a previously created container
        CloudBlobContainer container = blobClient.GetContainerReference(containerName);

        // Get a flat listing of all the block blobs in the specified container
        foreach (IListBlobItem item in container.ListBlobs(
                    prefix: null,
                    useFlatBlobListing: true))
        {
                // Retrieve reference to the current blob
                CloudBlob blob = (CloudBlob)item;

                // Save blob contents to a file in the specified folder
                string localOutputFile = Path.Combine(directoryPath, blob.Name);
                await blob.DownloadToFileAsync(localOutputFile, FileMode.Create);
        }

        Console.WriteLine("All files downloaded to {0}", directoryPath);
}
Note

The call to DownloadBlobsFromContainerAsync in the DotNetTutorial application specifies that the files should be downloaded to your %TEMP% folder. Feel free to modify this output location.

Step 8: Delete containers

Because you are charged for data that resides in Azure Storage, it's always a good idea to remove blobs that are no longer needed for your Batch jobs. In DotNetTutorial's Program.cs, this is done with three calls to the helper method DeleteContainerAsync:

// Clean up Storage resources
await DeleteContainerAsync(blobClient, appContainerName);
await DeleteContainerAsync(blobClient, inputContainerName);
await DeleteContainerAsync(blobClient, outputContainerName);

The method itself merely obtains a reference to the container, and then calls CloudBlobContainer.DeleteIfExistsAsync:

private static async Task DeleteContainerAsync(
    CloudBlobClient blobClient,
    string containerName)
{
    CloudBlobContainer container = blobClient.GetContainerReference(containerName);

    if (await container.DeleteIfExistsAsync())
    {
        Console.WriteLine("Container [{0}] deleted.", containerName);
    }
    else
    {
        Console.WriteLine("Container [{0}] does not exist, skipping deletion.",
            containerName);
    }
}

Step 9: Delete the job and the pool

In the final step, you're prompted to delete the job and the pool that were created by the DotNetTutorial application. Although you're not charged for jobs and tasks themselves, you are charged for compute nodes. Thus, we recommend that you allocate nodes only as needed. Deleting unused pools can be part of your maintenance process.

The BatchClient's JobOperations and PoolOperations both have corresponding deletion methods, which are called if the user confirms deletion:

// Clean up the resources we've created in the Batch account if the user so chooses
Console.WriteLine();
Console.WriteLine("Delete job? [yes] no");
string response = Console.ReadLine().ToLower();
if (response != "n" && response != "no")
{
    await batchClient.JobOperations.DeleteJobAsync(JobId);
}

Console.WriteLine("Delete pool? [yes] no");
response = Console.ReadLine();
if (response != "n" && response != "no")
{
    await batchClient.PoolOperations.DeletePoolAsync(PoolId);
}
Important

Keep in mind that you are charged for compute resources—deleting unused pools will minimize cost. Also, be aware that deleting a pool deletes all compute nodes within that pool, and that any data on the nodes will be unrecoverable after the pool is deleted.

Run the DotNetTutorial sample

When you run the sample application, the console output will be similar to the following. During execution, you will experience a pause at Awaiting task completion, timeout in 00:30:00... while the pool's compute nodes are started. Use the Azure portal to monitor your pool, compute nodes, job, and tasks during and after execution. Use the Azure portal or the Azure Storage Explorer to view the Storage resources (containers and blobs) that are created by the application.

Typical execution time is approximately 5 minutes when you run the application in its default configuration.

Sample start: 1/8/2016 09:42:58 AM

Container [application] created.
Container [input] created.
Container [output] created.
Uploading file C:\repos\azure-batch-samples\CSharp\ArticleProjects\DotNetTutorial\bin\Debug\TaskApplication.exe to container [application]...
Uploading file Microsoft.WindowsAzure.Storage.dll to container [application]...
Uploading file ..\..\taskdata1.txt to container [input]...
Uploading file ..\..\taskdata2.txt to container [input]...
Uploading file ..\..\taskdata3.txt to container [input]...
Creating pool [DotNetTutorialPool]...
Creating job [DotNetTutorialJob]...
Adding 3 tasks to job [DotNetTutorialJob]...
Awaiting task completion, timeout in 00:30:00...
Success! All tasks completed successfully within the specified timeout period.
Downloading all files from container [output]...
All files downloaded to C:\Users\USERNAME\AppData\Local\Temp
Container [application] deleted.
Container [input] deleted.
Container [output] deleted.

Sample end: 1/8/2016 09:47:47 AM
Elapsed time: 00:04:48.5358142

Delete job? [yes] no: yes
Delete pool? [yes] no: yes

Sample complete, hit ENTER to exit...

Next steps

Feel free to make changes to DotNetTutorial and TaskApplication to experiment with different compute scenarios. For example, try adding an execution delay to TaskApplication, such as with Thread.Sleep, to simulate long-running tasks and monitor them in the portal. Try adding more tasks or adjusting the number of compute nodes. Add logic to check for and allow the use of an existing pool to speed execution time (hint: check out ArticleHelpers.cs in the Microsoft.Azure.Batch.Samples.Common project in azure-batch-samples).

Now that you're familiar with the basic workflow of a Batch solution, it's time to dig in to the additional features of the Batch service.

  • Review the Overview of Azure Batch features article, which we recommend if you're new to the service.
  • Start on the other Batch development articles under Development in-depth in the Batch learning path.
  • Check out a different implementation of processing the "top N words" workload by using Batch in the TopNWords sample.
