.NET Cryptography Model

.NET provides implementations of many standard cryptographic algorithms, and the .NET cryptography model is extensible.

Object Inheritance

The .NET cryptography system implements an extensible pattern of derived class inheritance. The hierarchy is as follows:

This pattern of derived classes lets you add a new algorithm or a new implementation of an existing algorithm. For example, to create a new public-key algorithm, you would inherit from the AsymmetricAlgorithm class. To create a new implementation of a specific algorithm, you would create a non-abstract derived class of that algorithm.

How Algorithms Are Implemented in .NET

As an example of the different implementations available for an algorithm, consider symmetric algorithms. The base for all symmetric algorithms is SymmetricAlgorithm, which is inherited by Aes, TripleDES, and others that are no longer recommended.

Aes is inherited by AesCryptoServiceProvider, AesCng, and AesManaged.

In .NET Framework on Windows:

  • *CryptoServiceProvider algorithm classes, such as AesCryptoServiceProvider, are wrappers around the Windows Cryptography API (CAPI) implementation of an algorithm.
  • *Cng algorithm classes, such as ECDiffieHellmanCng, are wrappers around the Windows Cryptography Next Generation (CNG) implementation.
  • *Managed classes, such as AesManaged, are written entirely in managed code. *Managed implementations are not certified by the Federal Information Processing Standards (FIPS), and may be slower than the *CryptoServiceProvider and *Cng wrapper classes.

In .NET Core and .NET 5 and later versions, all implementation classes (*CryptoServiceProvider, *Managed, and *Cng) are wrappers for the operating system (OS) algorithms. If the OS algorithms are FIPS-certified, then .NET uses FIPS-certified algorithms. For more information, see Cross-Platform Cryptography.

In most cases, you don't need to directly reference an algorithm implementation class, such as AesCryptoServiceProvider. The methods and properties you typically need are on the base algorithm class, such as Aes. Create an instance of a default implementation class by using a factory method on the base algorithm class, and refer to the base algorithm class. For example, see the highlighted line of code in the following example:

using System;
using System.IO;
using System.Security.Cryptography;

public class EncryptExample
{
    public static void Main(string[] args)
    {
        //Encryption key used to encrypt the stream.
        //The same value must be used to encrypt and decrypt the stream.
        byte[] key = { 0x01, 0x02, 0x03, 0x04, 0x05, 0x06, 0x07, 0x08, 0x09, 0x10, 0x11, 0x12, 0x13, 0x14, 0x15, 0x16 };

        try
        {
            //Create a file stream
            using FileStream myStream = new FileStream("TestData.txt", FileMode.OpenOrCreate);

            //Create a new instance of the default Aes implementation class
            // and configure encryption key.
            using Aes aes = Aes.Create();
            aes.Key = key;

            //Stores IV at the beginning of the file.
            //This information will be used for decryption.
            byte[] iv = aes.IV;
            myStream.Write(iv, 0, iv.Length);

            //Create a CryptoStream, pass it the FileStream, and encrypt
            //it with the Aes class.
            using CryptoStream cryptStream = new CryptoStream(
                myStream,
                aes.CreateEncryptor(),
                CryptoStreamMode.Write);

            //Create a StreamWriter for easy writing to the
            //file stream.
            using StreamWriter sWriter = new StreamWriter(cryptStream);

            //Write to the stream.
            sWriter.WriteLine("Hello World!");

            //Inform the user that the message was written
            //to the stream.
            Console.WriteLine("The file was encrypted.");
        }
        catch
        {
            //Inform the user that an exception was raised.
            Console.WriteLine("The encryption failed.");
            throw;
        }
    }
}
Imports System
Imports System.IO
Imports System.Security.Cryptography

Module Module1
    Sub Main()
        'Encryption key used to encrypt the stream.
        'The same value must be used to encrypt and decrypt the stream.
        Dim key As Byte() = {&H1, &H2, &H3, &H4, &H5, &H6, &H7, &H8, &H9, &H10, &H11, &H12, &H13, &H14, &H15, &H16}

        Try
            'Create a file stream
            Using myStream As FileStream = New FileStream("TestData.txt", FileMode.OpenOrCreate)

                'Create a new instance of the default Aes implementation class
                ' and configure encryption key.
                Using aes As Aes = Aes.Create()
                    aes.Key = key

                    'Stores IV at the beginning of the file.
                    'This information will be used for decryption.
                    Dim iv As Byte() = aes.IV
                    myStream.Write(iv, 0, iv.Length)

                    'Create a CryptoStream, pass it the FileStream, and encrypt
                    'it with the Aes class.
                    Using cryptStream As New CryptoStream(myStream, aes.CreateEncryptor(), CryptoStreamMode.Write)

                        'Create a StreamWriter for easy writing to the
                        'file stream.
                        Using sWriter As New StreamWriter(cryptStream)

                            'Write to the stream.
                            sWriter.WriteLine("Hello World!")
                        End Using
                    End Using
                End Using
            End Using

            'Inform the user that the message was written
            'to the stream.
            Console.WriteLine("The text was encrypted.")
        Catch
            'Inform the user that an exception was raised.
            Console.WriteLine("The encryption failed.")
            Throw
        End Try
    End Sub
End Module

Cryptographic Configuration

Cryptographic configuration lets you resolve a specific implementation of an algorithm to an algorithm name, allowing extensibility of the .NET cryptography classes. You can add your own hardware or software implementation of an algorithm and map the implementation to the algorithm name of your choice. If an algorithm is not specified in the configuration file, the default settings are used.

Choosing an Algorithm

You can select an algorithm for different reasons: for example, for data integrity, for data privacy, or to generate a key. Symmetric and hash algorithms are intended for protecting data for either integrity reasons (protect from change) or privacy reasons (protect from viewing). Hash algorithms are used primarily for data integrity.

Here is a list of recommended algorithms by application:
