Kernel Extended Attributes

Article
08/09/2023

Starting in Windows 8, NTFS supports Kernel Extended Attributes (Kernel EAs). Verifying an image's signature is an expensive operation. Storing information about whether a previously validated binary has been changed reduces the number of instances where an image has to undergo a full signature check. Using Kernel EAs for this reason boosts the performance of image file signature validation.

EAs with the name prefix $Kernel can only be modified from kernel mode. Any EA that begins with this string is considered a Kernel EA. Before retrieving the necessary update sequence number (USN), it's recommended to first issue FSCTL_WRITE_USN_CLOSE_RECORD to commit any pending USN Journal updates on the file that may have occurred earlier. Otherwise, the FileUSN value may change shortly after setting the Kernel EA.

It's recommended that a Kernel EA contains at least the following information:

USN UsnJournalID
- The UsnJournalID field is a GUID that identifies the current incarnation of USN Journal File. The USN Journal can be deleted and created from user mode per volume. Each time the USN Journal is created a new UsnJournalID GUID is generated. With this field, you can tell if there was a period of time where the USN Journal was disabled and can revalidate.
  - This value can be retrieved using FSCTL_QUERY_USN_JOURNAL.
USN FileUSN
- The FileUSN value contains the USN ID of the last change that was made to the file and is tracked inside the Master File Table (MFT) record for the given file.
  - When the USN Journal is deleted, FileUSN is reset to zero.

This information, along with any other a given usage might need, is then set on the file as a Kernel EA.

Setting a Kernel Extended Attribute

In order to set a Kernel EA, it must begin with the prefix "$Kernel." followed by a valid EA name string. An attempt to set a Kernel EA from user mode is silently ignored. The request returns STATUS_SUCCESS but no actual EA modification is made. Calling an API like ZwSetEaFile or FltSetEaFile to set a Kernel EA from kernel mode isn't sufficient because SMB supports the setting of EAs across the network and those requests are issued from kernel mode on the server.

To set a Kernel EA, the caller must also set the IRP_MN_KERNEL_CALL value in the MinorFunction field of the IRP (I/O request packet). Since the only way to set this field is by generating a custom IRP, the routine FsRtlSetKernelEaFile has been exported from the FsRtl package as a support function to set up a Kernel EA.

Starting in Windows 10 version 1803, user EAs and kernel EAs can be intermixed. Setting a kernel EA doesn't generate a USN_REASON_EA_CHANGE record to the USN Journal. The system does generate USN_REASON_EA_CHANGE when any user EAs are set.

Querying an Extended Attribute

Querying the EAs on a file from user mode returns both normal and Kernel EAs. They're returned to user mode to minimize any application compatibility issues. The normal ZwQueryEaFile and FltQueryEaFile operations return both normal and kernel EAs from both user and kernel modes.

When only a FileObject is available, using FsRtlQueryKernelEaFile may be more convenient for use to query for Kernel EAs from kernel mode.

Querying Update Sequence Number Journal Information

The FSCTL_QUERY_USN_JOURNAL operation requires SE_MANAGE_VOLUME_PRIVILEGE even when issued from kernel mode unless the IRP_MN_KERNEL_CALL value was set in the MinorFunction field of the IRP. The routine FsRtlKernelFsControlFile has been exported from the FsRtl package in the Kernel to easily allow kernel mode components to issue this USN request.

NOTE Starting with Windows 10, version 1703 and later this operation no longer requires SE_MANAGE_VOLUME_PRIVILEGE.

Auto-Deletion of Kernel Extended Attributes

Simply rescanning a file because the USN ID of the file changed can be expensive as there are many benign reasons a USN update may be posted to the file. To simplify this, an auto delete of Kernel EAs feature was added to NTFS.

Because not all Kernel EAs may want to be deleted in this scenario, an extended EA prefix name is used. If a Kernel EA begins with: "$Kernel.Purge." then if any of the following USN reasons are written to the USN journal, NTFS deletes all kernel EAs that exist on that file that conforms to the given naming syntax:

USN_REASON_DATA_OVERWRITE
USN_REASON_DATA_EXTEND
USN_REASON_DATA_TRUNCATION
USN_REASON_REPARSE_POINT_CHANGE

This delete of Kernel EAs is successful even in low memory situations.

Remarks

User-mode components can't tamper with kernel EAs. Kernel EAs can exist in the same file as a normal EA.
