Introduction to Microsoft Azure Storage
Microsoft Azure Storage is a Microsoft-managed cloud service that provides storage that is highly available, secure, durable, scalable, and redundant. Microsoft takes care of maintenance and handles critical problems for you.
Azure Storage consists of three data services: Blob storage, File storage, and Queue storage. Blob storage supports both standard and premium storage, with premium storage using only SSDs for the fastest performance possible. Another feature is cool storage, allowing you to store large amounts of rarely accessed data for a lower cost.
In this article, you learn about the following:
- the Azure Storage services
- the types of storage accounts
- accessing your blobs, queues, and files
- transferring data into or out of storage
- the many storage client libraries available.
To get up and running with Azure Storage, see Create a storage account.
Introducing the Azure Storage services
To use any of the services provided by Azure Storage -- Blob storage, File storage, and Queue storage -- you first create a storage account, and then you can transfer data to/from a specific service in that storage account.
Blobs are basically files like those that you store on your computer (or tablet, mobile device, and so on). They can be pictures, Microsoft Excel files, HTML files, virtual hard disks (VHDs), big data such as logs, database backups -- pretty much anything. Blobs are stored in containers, which are similar to folders.
After storing files in Blob storage, you can access them from anywhere in the world using URLs, the REST interface, or one of the Azure SDK storage client libraries. Storage client libraries are available for multiple languages, including Node.js, Java, PHP, Ruby, Python, and .NET.
There are three types of blobs -- block blobs, page blobs (used for VHD files), and append blobs.
- Block blobs are used to hold ordinary files up to about 4.7 TB.
- Page blobs are used to hold random access files up to 8 TB in size. These are used for the VHD files that back VMs.
- Append blobs are made up of blocks like the block blobs, but are optimized for append operations. These are used for things like logging information to the same blob from multiple VMs.
For very large datasets where network constraints make uploading or downloading data to Blob storage over the wire unrealistic, you can ship a set of hard drives to Microsoft to import or export data directly from the data center. See Use the Microsoft Azure Import/Export Service to Transfer Data to Blob Storage.
Azure Files enables you to set up highly available network file shares that can be accessed by using the standard Server Message Block (SMB) protocol. That means that multiple VMs can share the same files with both read and write access. You can also read the files using the REST interface or the storage client libraries.
One thing that distinguishes Azure Files from files on a corporate file share is that you can access the files from anywhere in the world using a URL that points to the file and includes a shared access signature (SAS) token. You can generate SAS tokens; they allow specific access to a private asset for a specific amount of time.
File shares can be used for many common scenarios:
Many on-premises applications use file shares. This feature makes it easier to migrate those applications that share data to Azure. If you mount the file share to the same drive letter that the on-premises application uses, the part of your application that accesses the file share should work with minimal, if any, changes.
Configuration files can be stored on a file share and accessed from multiple VMs. Tools and utilities used by multiple developers in a group can be stored on a file share, ensuring that everybody can find them, and that they use the same version.
Diagnostic logs, metrics, and crash dumps are just three examples of data that can be written to a file share and processed or analyzed later.
At this time, Active Directory-based authentication and access control lists (ACLs) are not supported, but they will be at some time in the future. The storage account credentials are used to provide authentication for access to the file share. This means anybody with the share mounted will have full read/write access to the share.
The Azure Queue service is used to store and retrieve messages. Queue messages can be up to 64 KB in size, and a queue can contain millions of messages. Queues are generally used to store lists of messages to be processed asynchronously.
For example, say you want your customers to be able to upload pictures, and you want to create thumbnails for each picture. You could have your customer wait for you to create the thumbnails while uploading the pictures. An alternative would be to use a queue. When the customer finishes his upload, write a message to the queue. Then have an Azure Function retrieve the message from the queue and create the thumbnails. Each of the parts of this processing can be scaled separately, giving you more control when tuning it for your usage.
Azure Table storage is now part of Azure Cosmos DB. To see Azure Table storage documentation, see the Azure Table Storage Overview. In addition to the existing Azure Table storage service, there is a new Azure Cosmos DB Table API offering that provides throughput-optimized tables, global distribution, and automatic secondary indexes. To learn more and try out the new premium experience, please check out Azure Cosmos DB Table API.
Azure Storage also includes managed and unmanaged disk capabilities used by virtual machines. For more information about these features, please see the Compute Service documentation.
Types of storage accounts
This table shows the various kinds of storage accounts and which objects can be used with each.
|Type of storage account||General-purpose Standard||General-purpose Premium||Blob storage, hot and cool access tiers|
|Services supported||Blob, File, Queue Services||Blob Service||Blob Service|
|Types of blobs supported||Block blobs, page blobs, and append blobs||Page blobs||Block blobs and append blobs|
General-purpose storage accounts
There are two kinds of general-purpose storage accounts.
The most widely used storage accounts are standard storage accounts, which can be used for all types of data. Standard storage accounts use magnetic media to store data.
Premium storage provides high-performance storage for page blobs, which are primarily used for VHD files. Premium storage accounts use SSD to store data. Microsoft recommends using Premium Storage for all of your VMs.
Blob Storage accounts
The Blob Storage account is a specialized storage account used to store block blobs and append blobs. You can't store page blobs in these accounts, therefore you can't store VHD files. These accounts allow you to set an access tier to Hot or Cool; the tier can be changed at any time.
The hot access tier is used for files that are accessed frequently -- you pay a higher cost for storage, but the cost of accessing the blobs is much lower. For blobs stored in the cool access tier, you pay a higher cost for accessing the blobs, but the cost of storage is much lower.
Accessing your blobs, files, and queues
Each storage account has two authentication keys, either of which can be used for any operation. There are two keys so you can roll over the keys occasionally to enhance security. It is critical that these keys be kept secure because their possession, along with the account name, allows unlimited access to all data in the storage account.
This section looks at two ways to secure the storage account and its data. For detailed information about securing your storage account and your data, see the Azure Storage security guide.
Securing access to storage accounts using Azure AD
One way to secure access to your storage data is by controlling access to the storage account keys. With Resource Manager Role-Based Access Control (RBAC), you can assign roles to users, groups, or applications. These roles are tied to a specific set of actions that are allowed or disallowed. Using RBAC to grant access to a storage account only handles the management operations for that storage account, such as changing the access tier. You can't use RBAC to grant access to data objects like a specific container or file share. You can, however, use RBAC to grant access to the storage account keys, which can then be used to read the data objects.
Securing access using shared access signatures
You can use shared access signatures and stored access policies to secure your data objects. A shared access signature (SAS) is a string containing a security token that can be attached to the URI for an asset that allows you to delegate access to specific storage objects and to specify constraints such as permissions and the date/time range of access. This feature has extensive capabilities. For detailed information, refer to Using Shared Access Signatures (SAS).
Public access to blobs
The Blob Service allows you to provide public access to a container and its blobs, or a specific blob. When you indicate that a container or blob is public, anyone can read it anonymously; no authentication is required. An example of when you would want to do this is when you have a website that is using images, video, or documents from Blob storage. For more information, see Manage anonymous read access to containers and blobs
There are two basic kinds of encryption available for the Storage services. For more information about security and encryption, see the Azure Storage security guide.
Encryption at rest
Azure Storage Service Encryption (SSE) at rest helps you protect and safeguard your data to meet your organizational security and compliance commitments. With this feature, Azure Storage automatically encrypts your data prior to persisting to storage and decrypts prior to retrieval. The encryption, decryption, and key management are totally transparent to users.
SSE automatically encrypts data in all performance tiers (Standard and Premium), all deployment models (Azure Resource Manager and Classic), and all of the Azure Storage services (Blob, Queue, Table, and File). SSE does not affect Azure Storage performance.
For more information about SSE encryption at rest, see Azure Storage Service Encryption for Data at Rest.
The storage client libraries have methods you can call to programmatically encrypt data before sending it across the wire from the client to Azure. It is stored encrypted, which means it also is encrypted at rest. When reading the data back, you decrypt the information after receiving it.
For more information about client-side encryption, see Client-Side Encryption with .NET for Microsoft Azure Storage.
In order to ensure that your data is durable, Azure Storage will keep (and manage) multiple copies of your data. This is called replication, or sometimes redundancy. When you set up your storage account, you select a replication type. In most cases, this setting can be modified after the storage account is set up.
Locally-redundant storage (LRS)
Locally-redundant storage (LRS) is designed to provide at least 99.999999999% (11 9's) durability of objects over a given year. This means multiple copies of your data are managed by Azure Storage in the data center specified when the storage account was set up. When changes are committed, all copies are updated before returning success. This means the replicas are always in sync. Also, the copies reside in separate fault domains and upgrade domains, which means your data is available even if a storage node holding your data fails or is taken offline to be updated.
Zone-redundant storage (ZRS) (Preview)
Zone-redundant storage (ZRS) is designed to simplify the development of highly available applications. ZRS provides durability for storage objects of at least 99.9999999999% (12 9's) over a given year. ZRS replicates your data synchronously across multiple availability zones. Consider ZRS for scenarios like transactional applications where downtime is not acceptable. ZRS enables customers to read and write data even if a single zone is unavailable or unrecoverable. Inserts and updates to data are made synchronously and are strongly consistent.
The previous ZRS capability is now referred to as ZRS Classic. ZRS Classic accounts are available only for block blobs in general-purpose V1 storage accounts. ZRS Classic replicates data asynchronously across datacenters within one to two regions. A replica may not be available unless Microsoft initiates failover to the secondary. A ZRS Classic account cannot be converted to or from LRS or GRS, and does not have metrics or logging capability.
Geo-redundant storage (GRS)
Geo-redundant storage (GRS) is designed to provide 99.99999999999999% (16 9's) durability of objects over a given year by maintaining the local copies of your data in a primary region plus another set of copies of your data in a secondary region hundreds of miles away from the primary region. In the event of a failure at the primary region, Azure Storage will fail over to the secondary region.
Read-access geo-redundant storage (RA-GRS)
Read-access geo-redundant storage is exactly like GRS except that you get read access to the data in the secondary location. If the primary data center becomes unavailable temporarily, you can continue to read the data from the secondary location. This can be very helpful. For example, you could have a web application that changes into read-only mode and points to the secondary copy, allowing some access even though updates are not available.
You can change how your data is replicated after your storage account has been created. However, you may incur an additional one-time data transfer cost if you switch from LRS or ZRS to GRS or RA-GRS.
For more information about replication options, see Azure Storage replication.
For disaster recovery information, see What to do if an Azure Storage outage occurs.
For an example of how to leverage RA-GRS storage to ensure high availability, see Designing Highly Available Applications using RA-GRS.
Transferring data to and from Azure Storage
You can use the AzCopy command-line utility to copy blob, and file data within your storage account or across storage accounts. See one of the following articles for help:
AzCopy is built on top of the Azure Data Movement Library, which is currently available in preview.
The Azure Import/Export service can be used to import or export large amounts of blob data to or from your storage account. You prepare and mail multiple hard drives to an Azure data center, where they will transfer the data to/from the hard drives and send the hard drives back to you. For more information about the Import/Export service, see Use the Microsoft Azure Import/Export Service to Transfer Data to Blob Storage.
For detailed information about pricing for Azure Storage, see the Pricing page.
Storage APIs, libraries, and tools
Azure Storage resources can be accessed by any language that can make HTTP/HTTPS requests. Additionally, Azure Storage offers programming libraries for several popular languages. These libraries simplify many aspects of working with Azure Storage by handling details such as synchronous and asynchronous invocation, batching of operations, exception management, automatic retries, operational behavior, and so forth. Libraries are currently available for the following languages and platforms, with others in the pipeline:
Azure Storage data services
- Storage Services REST API
- Storage Client Library for .NET
- Storage Client Library for C++
- Storage Client Library for Java/Android
- Storage Client Library for Node.js
- Storage Client Library for PHP
- Storage Client Library for Python
- Storage Client Library for Ruby
- Storage Cmdlets for PowerShell
- Storage Commands for CLI 2.0
To get up and running with Azure Storage, see Create a storage account.
For .NET developers
- Get started with Azure Blob storage using .NET
- Develop for Azure Files with .NET
- Get started with Azure Table storage using .NET
- Get started with Azure Queue storage using .NET
For Java/Android developers
- How to use Blob storage from Java
- Develop for Azure Files with Java
- How to use Table storage from Java
- How to use Queue storage from Java
For Node.js developers
- How to use Blob storage from Node.js
- How to use Table storage from Node.js
- How to use Queue storage from Node.js
For PHP developers
- How to use Blob storage from PHP
- How to use Table storage from PHP
- How to use Queue storage from PHP
For Ruby developers
- How to use Blob storage from Ruby
- How to use Table storage from Ruby
- How to use Queue storage from Ruby
